Multi-Plex Control System (Diagnostic Codes): Diagnosis Honda Civic IX

Communication Devices 12 illustrations ~1704 words

DTC U128D: Immobilizer-Keyless Control Unit Lost Communication With Gauge Control Module

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A.

Scheme 150

Scheme 150: DTC U128D: Immobilizer-Keyless Control Unit Lost Communication With Gauge Control Module
Scheme 150: DTC U128D: Immobilizer-Keyless Control Unit Lost Communication With Gauge Control Module

Scheme 151

Scheme 151
Scheme 151

Scheme 152

Scheme 152
Scheme 152
  1. Problem verification: 1. Clear the DTCs with the HDS. 2. Turn the ignition switch to LOCK (0) and then back to ON (II). 3. Wait for at least 6 seconds. 4. Check for DTCs with the HDS. Is DTC U128D indicated? YES: Go to step 2. NO: Intermittent failure, the system is OK at this time. Check for loose or poor connections.
  2. Determine possible failure area (gauge control module (tach) power and ground, B_CAN line): 1. Select B-CAN CONTROL UNITS INFORMATION from the BODY ELECTRICAL SYSTEM SELECT menu, and then select CHECK CONNECTED CONTROL UNITS. 2. Check the DETECT/NOT AVAILABLE information of the GAUGE CONTROL MODULE. Is DETECT indicated? YES: Go to step 7 . NO: Go to step 3.
  3. Fuse check: 1. Check the following fuse. Fuse No. A29 (10 A) Location Under-hood fuse/relay box Is the fuse OK? YES: Go to step 4. NO: Replace the fuse. If the fuse blows again, repair a short to ground in the No. A29 (10 A) fuse circuit.
  4. Open wire check (+B_BACK_UP line): 1. Turn the ignition switch to LOCK (0). 2. Disconnect the following connector. Gauge control module (tach) 32P connector 3. Measure the voltage between test points 1 and 2. Test condition IG LOCK (0) Gauge control module (tach) 32P connector: disconnected Test circuit +B_BACK_UP Test point 1 Gauge control module (tach) 32P connector No. 1 (WHT) Test point 2 Body ground Is there battery voltage? YES: Go to step 5. NO: Repair an open or high resistance in the wire.
  5. Open wire check (GND lines): 1. Check for continuity between test points 1 and 2 individually. Test condition IG LOCK (0) Gauge control module (tach) 32P connector: disconnected Test circuit GND Test point 1 Gauge control module (tach) 32P connector No. 4 (BLK) Test point 2 Body ground Test circuit GND Test point 1 Gauge control module (tach) 32P connector No. 32 (BRN) Test point 2 Body ground Is there continuity? YES: Go to step 6. NO: Repair an open or high resistance in the ground wire or poor ground (G502/G503).
  6. Open wire check (B_CAN lines): 1. Disconnect the following connector. Immobilizer-keyless control unit 7P connector 2. Check for continuity between test points 1 and 2. Test condition IG LOCK (0) Gauge control module (tach) 32P connector: disconnected Immobilizer-keyless control unit 7P connector: disconnected Test circuit B_CAN-H Test point 1 Immobilizer-keyless control unit 7P connector No. 4 (PNK) Test point 2 Gauge control module (tach) 32P connector No. 30 (PNK) Is there continuity? YES: An open or poor connection in the B_CAN-L wire between the immobilizer-keyless control unit and the gauge control module (tach). NO: An open or poor connection in the B_CAN-H wire between the immobilizer-keyless control unit and the gauge control module (tach).
  7. Open wire check (B_CAN lines): 1. Turn the ignition switch to LOCK (0). 2. Disconnect the following connectors. Gauge control module (tach) 32P connector Immobilizer-keyless control unit 7P connector 3. Check for continuity between test points 1 and 2. Test condition IG LOCK (0) Gauge control module (tach) 32P connector: disconnected Immobilizer-keyless control unit 7P connector: disconnected Test circuit B_CAN-H Test point 1 Immobilizer-keyless control unit 7P connector No. 4 (PNK) Test point 2 Gauge control module (tach) 32P connector No. 30 (PNK) Is there continuity? YES: An open or poor connection in the B_CAN-L wire between the immobilizer-keyless control unit and the gauge control module (tach). NO: An open or poor connection in the B_CAN-H wire between the immobilizer-keyless control unit and the gauge control module (tach).

DTC U128D: Information Display Unit Lost Communication With Gauge Control Module

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A.

Scheme 153

Scheme 153: DTC U128D: Information Display Unit Lost Communication With Gauge Control Module
Scheme 153: DTC U128D: Information Display Unit Lost Communication With Gauge Control Module

Scheme 154

Scheme 154
Scheme 154

Scheme 155

Scheme 155
Scheme 155

Scheme 156

Scheme 156
Scheme 156

Scheme 157

Scheme 157
Scheme 157
  1. Problem verification: 1. Clear the DTCs with the HDS. 2. Turn the ignition switch to LOCK (0) and then back to ON (II). 3. Wait for at least 6 seconds. 4. Check for DTCs with the HDS. Is DTC U128D indicated? YES: Go to step 2. NO: Intermittent failure, the system is OK at this time. Check for loose or poor connections.
  2. Determine possible failure area (gauge control module (tach) power and ground, B_CAN line): 1. Select B-CAN CONTROL UNITS INFORMATION from the BODY ELECTRICAL SYSTEM SELECT menu, and then select CHECK CONNECTED CONTROL UNITS. 2. Check the DETECT/NOT AVAILABLE information of the GAUGE CONTROL MODULE. Is DETECT indicated? YES: Go to step 7 . NO: Go to step 3.
  3. Fuse check: 1. Check the following fuse. Fuse No. A29 (10 A) Location Under-hood fuse/relay box Is the fuse OK? YES: Go to step 4. NO: Replace the fuse. If the fuse blows again, repair a short to ground in the No. A29 (10 A) fuse circuit.
  4. Open wire check (+B_BACK_UP line): 1. Turn the ignition switch to LOCK (0). 2. Disconnect the following connector. Gauge control module (tach) 32P connector 3. Measure the voltage between test points 1 and 2. Test condition IG LOCK (0) Gauge control module (tach) 32P connector: disconnected Test circuit +B_BACK_UP Test point 1 Gauge control module (tach) 32P connector No. 1 (WHT) Test point 2 Body ground Is there battery voltage? YES: Go to step 5. NO: Repair an open or high resistance in the wire.
  5. Open wire check (GND lines): 1. Check for continuity between test points 1 and 2 individually. Test condition IG LOCK (0) Gauge control module (tach) 32P connector: disconnected Test circuit GND Test point 1 Gauge control module (tach) 32P connector No. 4 (BLK) Test point 2 Body ground Test circuit GND Test point 1 Gauge control module (tach) 32P connector No. 32 (BRN) Test point 2 Body ground Is there continuity? YES: Go to step 6. NO: Repair an open or high resistance in the ground wire or poor ground (G502/G503).
  6. Open wire check (B_CAN lines): 1. Disconnect the following connector. Information display unit 12P connector 2. Check for continuity between test points 1 and 2. Test condition IG LOCK (0) Gauge control module (tach) 32P connector: disconnected Information display unit 12P connector: disconnected Test circuit B_CAN-H Test point 1 Gauge control module (tach) 32P connector No. 30 (PNK) Test point 2 Information display unit 12P connector No. 9 (PNK) Is there continuity? YES: An open or poor connection in the B_CAN-L wire between the information display unit and the gauge control module (tach). NO: An open or poor connection in the B_CAN-H wire between the information display unit and the gauge control module (tach).
  7. Open wire check (B_CAN lines): 1. Turn the ignition switch to LOCK (0). 2. Disconnect the following connectors. Gauge control module (tach) 32P connector Information display unit 12P connector 3. Check for continuity between test points 1 and 2. Test condition IG LOCK (0) Gauge control module (tach) 32P connector: disconnected Information display unit 12P connector: disconnected Test circuit B_CAN-H Test point 1 Gauge control module (tach) 32P connector No. 30 (PNK) Test point 2 Information display unit 12P connector No. 9 (PNK) Is there continuity? YES: An open or poor connection in the B_CAN-L wire between the information display unit and the gauge control module (tach). NO: An open or poor connection in the B_CAN-H wire between the information display unit and the gauge control module (tach).

DTC U128D: MICU Lost Communication With Gauge Control Module

Note. Refer to the Electrical Wiring Diagrams for the location of the under-dash fuse/relay box connectors. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A.

Scheme 158

Scheme 158: DTC U128D: MICU Lost Communication With Gauge Control Module
Scheme 158: DTC U128D: MICU Lost Communication With Gauge Control Module

Scheme 159

Scheme 159
Scheme 159

Scheme 160

Scheme 160
Scheme 160

Scheme 161

Scheme 161
Scheme 161
  1. Problem verification: 1. Clear the DTCs with the HDS. 2. Turn the ignition switch to LOCK (0) and then back to ON (II). 3. Wait for at least 6 seconds. 4. Check for DTCs with the HDS. Is DTC U128D indicated? YES: Go to step 2. NO: Intermittent failure, the system is OK at this time. Check for loose or poor connections.
  2. Fuse check: 1. Check the following fuse. Fuse No. A29 (10 A) Location Under-hood fuse/relay box Is the fuse OK? YES: Go to step 3. NO: Replace the fuse. If the fuse blows again, repair a short to ground in the No. A29 (10 A) fuse circuit.
  3. Open wire check (+B_BACK_UP line): 1. Turn the ignition switch to LOCK (0). 2. Disconnect the following connector. Gauge control module (tach) 32P connector 3. Measure the voltage between test points 1 and 2. Test condition IG LOCK (0) Gauge control module (tach) 32P connector: disconnected Test circuit +B_BACK_UP Test point 1 Gauge control module (tach) 32P connector No. 1 (WHT) Test point 2 Body ground Is there battery voltage? YES: Go to step 4. NO: Repair an open or high resistance in the wire.
  4. Open wire check (GND lines): 1. Check for continuity between test points 1 and 2 individually. Test condition IG LOCK (0) Gauge control module (tach) 32P connector: disconnected Test circuit GND Test point 1 Gauge control module (tach) 32P connector No. 4 (BLK) Test point 2 Body ground Test circuit GND Test point 1 Gauge control module (tach) 32P connector No. 32 (BRN) Test point 2 Body ground Is there continuity? YES: Go to step 5. NO: Repair an open or high resistance in the ground wire or poor ground (G502/G503).
  5. Open wire check (B_CAN lines): 1. Disconnect the following connector. Under-dash fuse/relay box connector K (12P) 2. Check for continuity between test points 1 and 2. Test condition IG LOCK (0) Gauge control module (tach) 32P connector: disconnected Under-dash fuse/relay box connector K (12P): disconnected Test circuit B_CAN-H Test point 1 Under-dash fuse/relay box connector K (12P) No. 2 (PNK) Test point 2 Gauge control module (tach) 32P connector No. 30 (PNK) Is there continuity? YES: An open or poor connection in the B_CAN-L wire between the MICU and the gauge control module (tach). NO: An open or poor connection in the B_CAN-H wire between the MICU and the gauge control module (tach).
