DTC U0127: Gauge Control Module Lost Communication With TPMS Control Unit (TPMS Message) Honda Civic IX

Communication Devices 5 illustrations ~550 words

Note. If you have any loss of communication DTCs for the ECM/PCM, troubleshoot those DTCs first. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A.

Scheme 104

Scheme 104: DTC U0127: Gauge Control Module Lost Communication With TPMS Control Unit (TPMS Message)
Scheme 104: DTC U0127: Gauge Control Module Lost Communication With TPMS Control Unit (TPMS Message)

Scheme 105

Scheme 105
Scheme 105

Scheme 106

Scheme 106
Scheme 106

Scheme 107

Scheme 107
Scheme 107

Scheme 108

Scheme 108
Scheme 108
  1. Problem verification: 1. Clear the DTCs with the HDS. 2. Turn the ignition switch to LOCK (0) and then back to ON (II). 3. Wait for at least 6 seconds. 4. Check for DTCs with the HDS. Is DTC U0121 indicated? YES: Go to step 2. NO: Intermittent failure, the system is OK at this time. Check for loose or poor connections.
  2. Fuse check: 1. Check the following fuse. Fuse No. B40 (7.5 A) Location Under-dash fuse/relay box Is the fuse OK? YES: Go to step 3. NO: Replace the fuse. If the fuse blows again, repair a short to ground in the No. B40 (7.5 A) fuse circuit.
  3. Open wire check (+B_TPMS line): 1. Turn the ignition switch to LOCK (0). 2. Disconnect the following connector. TPMS control unit 20P connector 3. Measure the voltage between test points 1 and 2. Test condition IG LOCK (0) TPMS control unit 20P connector: disconnected Test circuit +B_TPMS Test point 1 TPMS control unit 20P connector No. 1 (BLU) Test point 2 Body ground Is there battery voltage? YES: Go to step 4. NO: Repair an open or high resistance in the wire.
  4. Open wire check (IG1_METER): 1. Measure the voltage between test points 1 and 2. Test condition IG ON (II) TPMS control unit 20P connector: disconnected Test circuit IG1_METER Test point 1 TPMS control unit 20P connector No. 3 (BRN) Test point 2 Body ground Is there battery voltage? YES: Go to step 5. NO: Repair an open or high resistance in the wire.
  5. Open wire check (GND): 1. Check for continuity between test points 1 and 2. Test condition IG LOCK (0) TPMS control unit 20P connector: disconnected Test circuit GND Test point 1 TPMS control unit 20P connector No. 8 (BLK) Test point 2 Body ground Is there battery voltage? YES: Go to step 6. NO: Repair an open or high resistance in the ground wire or poor ground (G501).
  6. Open wire check (F_CAN lines): 1. Turn the ignition switch to LOCK (0). 2. Disconnect the following connector. Gauge control module (tach) 32P connector 3. Check for continuity between test points 1 and 2 respectively. Test condition IG LOCK (0) TPMS control unit 20P connector: disconnected Gauge control module (tach) 32P connector: disconnected Test circuit F_CAN-H Test point 1 TPMS control unit 20P connector No. 9 (WHT) Test point 2 Gauge control module (tach) 32P connector No. 19 (WHT) Test circuit F_CAN-L Test point 1 TPMS control unit 20P connector No. 20 (RED) Test point 2 Gauge control module (tach) 32P connector No. 20 (RED) Is there continuity? YES: Replace the gauge control module (tach) See «GAUGE CONTROL MODULE (TACH) REMOVAL AND INSTALLATION»(ref-614110-S24253527182014050700000) , «REWRITING THE ODO DATA AND TRANSFERRING THE MAINTENANCE MINDER™ DATA TO A NEW GAUGE CONTROL MODULE»(ref-614119-S22749513832014050700000) or «GAUGE CONTROL MODULE (SPEEDO) REMOVAL AND INSTALLATION»(ref-614110-S22536531082014050700000) . NO: An open or poor connection in the F_CAN wires between the TPMS control unit and the gauge control module (tach).
