Torque Specifications
Note. Refer to the appropriate Service Information for the precautions and complete procedures. Refer to the appropriate Service Information for the bolts/nuts not indicated here. *1: Parts to be tightened in a particular order. *2: Follow the Service Information closely for torque, sequence, and special steps.
Design Specifications
| Item | Measurement | Qualification | Specification | |
|---|---|---|---|---|
| DIMENSIONS (4-door) | Overall length | 4,930 mm (194.1 in) | ||
| Overall width | 1,847 mm (72.7 in) | |||
| Overall height | 1,475 mm (58.1 in) | |||
| Wheelbase | 2,800 mm (110.2 in) | |||
| Track | 16 inch wheels | Front | 1,580 mm (62.2 in) | |
| Rear | 1,580 mm (62.2 in) | |||
| 17 inch wheels | Front | 1,590 mm (62.6 in) | ||
| Rear | 1,590 mm (62.6 in) | |||
| Seating capacity | Five (5) | |||
| DIMENSIONS (2-door) | Overall length | 4,849 mm (190.9 in) | ||
| Overall width | 1,848 mm (72.7 in) | |||
| Overall height | 1,432 mm (56.3 in) | |||
| Wheelbase | 2,740 mm (107.9 in) | |||
| Track | Front | 1,580 mm (62.2 in) | ||
| Rear | 1,580 mm (62.2 in) | |||
| Seating capacity | Five (5) | |||
| WEIGHT (4-door) | Gross Vehicle Weight Rating (GVWR) USA models | LX, LX-P, SE, LX PZEV, LX-P PZEV, SE PZEV | 1,950 kg (4,299 lbs) | |
| EX, EX-L, EX PZEV, EX-L PZEV | 2,010 kg (4,431 lbs) | |||
| Gross Vehicle Weight Rating (GVWR) Canada models | LX, LX-P, SE | 1,970 kg (4,343 lbs) | ||
| EX, EX-L | 2,030 kg (4,475 lbs) | |||
| WEIGHT (2-door) | Gross Vehicle Weight Rating (GVWR) USA models | LX, LX-S, LX PZEV | 1,950 kg (4,299 lbs) | |
| EX, EX-L, EX PZEV, EX-L PZEV | 2,000 kg (4,409 lbs) | |||
| Gross Vehicle Weight Rating (GVWR) Canada models | LX | 1,970 kg (4,343 lbs) | ||
| EX, EX-L | 2,020 kg (4,453 lbs) | |||
| ENGINE | Type | Water-cooled, 4-stroke DOHC i-VTEC gasoline engine | ||
| Cylinder arrangement | Inline 4-cylinder, transverse | |||
| Bore and stroke | 87.0 x 99.0 mm (3.425 x 3.898 in) | |||
| Displacement | 2,354 cm 3 (143.7 cu in) | |||
| Compression ratio | 10.5 | |||
| Valve train | Chain drive, DOHC i-VTEC 4 valves per cylinder | |||
| Lubrication system | Forced, wet sump, with trochoid pump | |||
| Fuel required | Regular UNLEADED gasoline with 87 Pump Octane Number or higher | |||
| STARTER | Type | Gear reduction | ||
| Nominal output | 1.6 kW | |||
| Nominal voltage | 12V | |||
| Hour rating | 30 seconds | |||
| Direction of rotation | Clockwise as viewed from drive end | |||
| CLUTCH | Type | Single plate dry, diaphragm spring | ||
| MANUAL TRANSMISSION | Type | Synchronized, five-speed forward, one reverse | ||
| Primary reduction | Direct 1:1 | |||
| Gear ratio | 1st | 3.267 | ||
| 2nd | 1.778 | |||
| 3rd | 1.154 | |||
| 4th | 0.870 | |||
| 5th | 0.647 | |||
| Reverse | 3.583 | |||
| Final reduction | Type | Single helical gear | ||
| Gear ratio | 4.389 | |||
| AUTOMATIC TRANSMISSION | Type | Electronically-controlled automatic, five-speed forward, one reverse, three-element torque converter with lock-up clutch | ||
| Primary reduction | Direct 1:1 | |||
| Gear ratio ('08-09 models) | 1st | 2.651 | ||
| 2nd | K24Z2 | 1.516 | ||
| K24Z3 | 1.613 | |||
| 3rd | K24Z2 | 1.037 | ||
| K24Z3 | 1.081 | |||
| 4th | K24Z2 | 0.738 | ||
| K24Z3 | 0.772 | |||
| 5th | 0.566 | |||
| Reverse | 2.000 | |||
| Gear ratio ('10-12 models) | 1st | 2.651 | ||
| 2nd | 1.516 | |||
| 3rd | 1.037 | |||
| 4th | 0.738 | |||
| 5th ('10 model) | 0.566 | |||
| 5th ('11-12 models) | 0.537 | |||
| Reverse | 2.000 | |||
| Final reduction | Type | Single helical gear | ||
| Gear ratio | 4.437 | |||
| STEERING | Type | Hydraulic power-assisted rack and pinion | ||
| Overall ratio | 13.1 | |||
| Turns, lock-to-lock | 2.56 | |||
| Steering wheel diameter | 370 mm (14.57 in) | |||
| SUSPENSION | Type | Front | Independent double wishbone with stabilizer, coil spring | |
| Rear | Independent multilink with stabilizer, coil spring | |||
| Shock absorber | Front | Telescopic, hydraulic, nitrogen gas-filled | ||
| Rear | Telescopic, hydraulic, nitrogen gas-filled | |||
| TIRES | Size (4-door) | Front and rear (LX, LX-P, SE, LX PZEV, LX-P PZEV, SE PZEV) | P215/60R16 94H | |
| Front and rear (EX, EX-L, EX PZEV, EX-L PZEV) | P225/50R17 93V | |||
| Spare | T135/80D16 101M | |||
| Size (2-door) | Front and rear | P225/50R17 93V | ||
| Spare | T135/80D16101M | |||
| WHEEL ALIGNMENT | Camber | Front | 0°00' | |
| Rear | 1°00' | |||
| Caster | Front (4-door) | 3°48' | ||
| Front (2-door) | 3°47' | |||
| Total toe-in | Front | 0 mm (0 in) | ||
| Rear | 2 mm (0.08 in) | |||
| Front wheel turning angle | Inward | 39°00' | ||
| Outward (reference) | 31°50' | |||
| BRAKES | Type of service brake | Front | Power-assisted self-adjusting ventilated disc | |
| Rear | Power-assisted self-adjusting solid disc | |||
| Type of parking brake | Mechanical actuating, rear wheels | |||
| Pad friction surface area (swept area) | Front (NISSIN without pad return spring) | 50.6 cm 2 (7.84 sq in) x 2 | ||
| Front (NISSIN with pad return spring: 4-door) | 46.2 cm 2 (7.16 sq in) x 2 | |||
| Front (NISSIN with pad return spring: 2-door) | 45.3 cm 2 (7.02 sq in) x 2 | |||
| Front: (AKEBONO) | 45.7 cm 2 (7.08 sq in) x 2 | |||
| Rear | 27.3 cm 2 (4.23 sq in) x 2 | |||
| AIR CONDITIONING | Compressor | Type | Swash plate/DENSO | |
| Capacity | 154.4 mL (9.42 cu in)/rev | |||
| Maximum speed | 8,400 RPM | |||
| Lubricant capacity | 70 mL (2 3/8 fl.oz) | |||
| Lubricant type | DENSO ND-OIL 8 | |||
| Condenser | Type | Corrugated fin | ||
| Evaporator | Type | Corrugated fin | ||
| Blower | Type | Stabilized swirling flow | ||
| Motor type | 216W/12V | |||
| Speed control | Infinitely variable | |||
| Maximum capacity | 505 m 3 (17,834 cu ft)/h | |||
| Temperature control | Air-mix type | |||
| Compressor clutch | Type | Dry, single plate, poly V-belt drive | ||
| Electrical power Consumption at 68°F(20°C) | 35 W maximum at 12 V | |||
| Refrigerant | Type | HFC-134a (R-134a) | ||
| Capacity | 400-450g (14.1-15.9 oz) | |||
| ELECTRICAL RATINGS | Battery | '08-11 USA 4-door models except PZEV | 12 V-45 Ah/20 HR (12 V-36 Ah/5 HR), 12 V-47 Ah/20 HR (12 V-36 Ah/5 HR), 12 V-47 Ah/20 HR (12 V-38 Ah/5 HR) | |
| '12 USA 4-door models except PZEV, USA 2-door models except PZEV, '08 Canada models | 12 V-47 Ah/20 HR (12 V-38 Ah/5 HR) | |||
| USA models PZEV, '09-12 Canada models | 12 V-65 Ah/20 HR (12 V-52 Ah/5 HR) | |||
| Fuse | Under-hood fuse/relay box | 100 A, 60 A, 50 A, 40 A, 30 A, 20 A, 15 A, 10 A, 7.5 A | ||
| Driver's under-dash fuse/relay box | 20 A, 15 A, 10 A, 7.5 A | |||
| Passenger's under-dash fuse/relay box | 20 A, 15 A, 10 A, 7.5 A | |||
| Light bulbs | Headlight high beam | 12V-60 W | ||
| Headlight low beam (4-door) | 12V-51 W | |||
| Headlight low beam (2-door) | 12V-55 W | |||
| Front turn signal/parking lights (4-door) | 12V-21/5 W | |||
| Front turn signal/parking lights (2-door) | 12V-24/2.2 CP | |||
| Front side marker lights (4-door) | 12V-3 CP | |||
| Front side marker lights (2-door) | 12V-5 W | |||
| Rear turn signal lights | 12V-21 W | |||
| Brake lights/taillights | 12V-21/5 W | |||
| High mount brake light | 12V-21 W | |||
| Back-up lights (4-door) | 12V-21 W | |||
| Back-up lights (2-door) | 12V-16 W | |||
| License plate lights | 12V-5 W | |||
| Ceiling light | 12V-8 W | |||
| Trunk light | 12V-5 W | |||
| Individual map light | 12V-8 W | |||
| Ambient light | LED | |||
| Vanity mirror lights | 12 V-1.1 W | |||
| Glove box light ('08-09 models) | 12V-2 CP | |||
| Door courtesy light | 12V-2 CP | |||
| Gauge lights | LED | |||
| Indicator lights | LED | |||
DESIGN SPECIFICATIONS
