Torque Specifications
| Description | Nm |
|---|---|
| Accelerator pedal and sensor assembly nuts | 9 |
TORQUE SPECIFICATIONS
The acceleration controls consist of the accelerator pedal and sensor assembly.
The engine management system electronically operates the throttle of the engine in response to accelerator pedal movements initiated by the driver. In the event of a system failure, the engine management system provides a "limp home" mode which allows the car to be driven with limited performance.
Refer to the INTRODUCTION article.
Scheme 1
| Item | Part Number | Description |
|---|---|---|
| 1 | 14A464 | Accelerator pedal sensor electrical connector |
| 2 | 9F836 | Accelerator pedal and sensor assembly |
| 3 | W702651 | Accelerator pedal and sensor nut (2 required) |
PARTS DESCRIPTION CHART
Removal and Installation
- Disconnect the accelerator pedal sensor electrical connector.
- Remove the 2 nuts and the accelerator pedal and sensor assembly. To install, tighten to 9 Nm (80 lb-in).
- To install, reverse the removal procedure.
