Seating: Other Ford Thunderbird XI

Driver Seat

The driver seat has the following features

1. manual lumbar
2. horizontal, vertical and front and rear tilt power adjustments
3. side air bag

Passenger Seat

The passenger seat has the following features

1. horizontal power adjustment
2. side air bag

Seats - Power Adjustment

Adjustment of the seat is accomplished with the seat regulator control switch located on the side of the seat.

Driver Seat - Manual Lumbar Support

The manual driver seat backrest lumbar is adjusted by a knob (57620) mounted on the front of the seat cushion.

Side Air Bag

Driver and passenger side air bags (611A08) are attached to the seat backrest frame. For diagnostic information or if the side air bag has been deployed, refer to AIR BAG RESTRAINT SYSTEMS .

The seat backrest trim covers cannot be repaired. If the seat backrest covers need to be repaired, an entirely new cover must be installed. Cleaning the seat backrest cover is permissible.

If a side air bag deployment took place, a new seat back pad, trim cover and side air bag module must be installed.

Install a new seat backrest frame if necessary.

Seats

Refer to POWER SEATS for schematic and connector information.

Scheme 69

Possible Causes

An inoperative power seat can be caused by

1. a fuse.
2. wiring, terminals, or connectors.
3. a faulty power seat switch.
4. a faulty power seat motor.

Scheme 70

A noisy power seat can be caused by

1. a misaligned seat track.
2. a faulty seat track component.
3. an object obstructing seat movement.
4. a faulty seat track motor and transmission assembly.

Scheme 71

A loose power seat can be caused by

1. loose fastening hardware.
2. a faulty seat track component.

Scheme 72

A power seat that does not make full travel can be caused by

1. an obstruction.
2. a faulty seat track component.

Scheme 73

An inoperative power seat can be caused by

1. a fuse.
2. wiring, terminals, or connectors.
3. a faulty power seat switch.
4. a faulty power seat motor.

Scheme 74

A power seat that does not move horizontally and/or vertically can be caused by

1. wiring, terminals, or connectors.
2. a faulty seat control switch.
3. a faulty seat track motor.
4. a faulty seat track motor and transmission assembly.

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

Scheme 80

A power seat that does not move horizontally can be caused by

1. wiring, terminals, or connectors.
2. a faulty seat control switch.
3. a faulty seat track motor.
4. a faulty seat track motor and transmission assembly.

Scheme 81

Scheme 82

An inoperative heated seat can be caused by

1. wiring, terminals, or connectors.
2. a faulty heated seat switch.
3. a faulty heated seat module.
4. a faulty heated seat element.
5. a faulty heated seat temperature sensor.

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

An inoperative heated seat can be caused by

1. wiring, terminals, or connectors.
2. a faulty heated seat switch.
3. a faulty heated seat module.
4. a faulty heated seat element.
5. a faulty heated seat temperature sensor.

Scheme 91

Scheme 92

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

The driver heated seat inoperative and does not operate in high can be caused by

1. wiring, terminals, or connectors.
2. a faulty heated seat switch.
3. a faulty heated seat module.

Scheme 99

Scheme 100

A driver heated seat inoperative and does not operate in low can be caused by

1. wiring, terminals, or connectors.
2. a faulty heated seat switch.
3. a faulty heated seat module.

Scheme 101

Scheme 102

A passenger heated seat inoperative and does not operate in high can be caused by

1. wiring, terminals, or connectors.
2. a faulty heated seat switch.
3. a faulty heated seat module.

Scheme 103

Scheme 104

A passenger heated seat inoperative and does not operate in low can be caused by

1. wiring, terminals, or connectors.
2. a faulty heated seat switch.
3. a faulty heated seat module.

Scheme 105

Scheme 106

Material

MATERIAL SPECIFICATION
