Multifunction Electronic Module: Diagnosis — Ford Thunderbird XI (2000-2005)

Diagnostic Trouble Code (DTC) Index

DTC	Description	Source	Action
B1201	Fuel Sender Circuit Failure	IC Module	REFER to INSTRUMENT CLUSTER .
B1201	Fuel Sender Circuit Failure	HEC Module	REFER to INSTRUMENT CLUSTER .
B1201	Fuel Sender Circuit Failure	REM	REFER to INSTRUMENT CLUSTER .
B1205	EIC Switch-1 Assembly Circuit Failure	IC Module	REFER to INSTRUMENT CLUSTER .
B1205	EIC Switch-1 Assembly Circuit Failure	HEC Module	REFER to INSTRUMENT CLUSTER .
B1209	EIC Switch-2 Assembly Circuit Failure	IC Module	REFER to INSTRUMENT CLUSTER .
B1209	EIC Switch-2 Assembly Circuit Failure	EIC Module	REFER to INSTRUMENT CLUSTER .
B1213	Anti -Theft Number of Programmed Keys is Below Minimum	IC Module	REFER to ANTI-THEFT - PATS .
B1213	Anti -Theft Number of Programmed Keys is Below Minimum	HEC Module	REFER to ANTI-THEFT - PATS .
B1231	Longitudinal Acceleration Threshold Exceeded	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1246	Dim Panel Potentiometer Switch Circuit Failure	IC Module	REFER to INSTRUMENT CLUSTER AND PANEL ILLUMINATION .
B1246	Dim Panel Potentiometer Switch Circuit Failure	HEC Module	REFER to INSTRUMENT CLUSTER AND PANEL ILLUMINATION .
B1318	Battery Voltage Low	RCM	REFER to GENERATORS & REGULATORS .
B1319	Drivers Door Ajar Circuit Failure	FEM	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1327	Passenger Door Ajar Circuit Failure	FEM	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1331	Decklid Ajar Rear Door Circuit Failure	REM	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1342	ECU is Defective	ABS Module	CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved, INSTALL a new ABS module. REFER to ANTI-LOCK CONTROL . CLEAR the DTCs. REPEAT the self-test.
B1342	ECU is Defective	ACM Module	CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved, INSTALL a new ACM module. CLEAR the DTCs. REPEAT the self-test.
B1342	ECU is Defective	FEM	CLEAR DTCs. REPEAT the self-test. If DTC B1342 is retrieved, INSTALL a new FEM. REFER to MODULE - FRONT ELECTRONIC (FEM) . CLEAR the DTCs. REPEAT the self-test.
B1342	ECU is Defective	IC Module	CLEAR DTCs. REPEAT the self-test. If DTC B1342 is retrieved, INSTALL a new instrument cluster. REFER to INSTRUMENT CLUSTER . CLEAR the DTCs. REPEAT the self-test.
B1342	ECU is Defective	HEC Module	CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved, INSTALL a new HEC module. REFER to INSTRUMENT CLUSTER . CLEAR the DTCs. REPEAT the self-test.
B1342	ECU is Defective	RCM Module	CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved, INSTALL a new RCM. REFER to AIR BAG RESTRAINT SYSTEMS . CLEAR the DTCs. REPEAT the self-test.
B1342	ECU is Defective	REM	CLEAR DTCs. REPEAT the self-test. If DTC B1342 is retrieved, INSTALL a new REM. REFER to MODULE - REAR ELECTRONIC (REM) . CLEAR the DTCs. REPEAT the self-test.
B1342	ECU is Defective	RKE	CLEAR DTCs. REPEAT the self-test. If DTC B1342 is retrieved, INSTALL a new RKE module. REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . CLEAR the DTCs. REPEAT the self-test.
B1352	Ignition Key-In Circuit Failure	IC Module	REFER to WARNING DEVICES .
B1352	Ignition Key-In Circuit Failure	HEC Module	REFER to WARNING DEVICES .
B1398	Driver Power Window One Touch Window Relay Circuit Failure	FEM	REFER to GLASS, FRAMES AND MECHANISMS .
B1402	Driver Power Window Down Switch Circuit Failure	FEM	REFER to GLASS, FRAMES AND MECHANISMS .
B1403	Driver Power Window Up Switch Circuit Failure	FEM	REFER to GLASS, FRAMES AND MECHANISMS .
B1410	Driver Power Window Circuit Failure	FEM	REFER to GLASS, FRAMES AND MECHANISMS .
B1418	Passenger Power Window Motor Circuit Failure	REM	REFER to GLASS, FRAMES AND MECHANISMS .
B1438	Wiper Mode Select Switch Circuit Failure	FEM	REFER to WIPERS AND WASHERS .
B1446	Wiper Park Sense Circuit Failure	FEM	REFER to WIPERS AND WASHERS .
B1470	Lamp Headlamp Input Circuit Failure	IC	REFER to EXTERIOR LIGHTING - THUNDERBIRD .
B1470	Lamp Headlamp Input Circuit Failure	HEC	REFER to EXTERIOR LIGHTING - THUNDERBIRD .
B1479	Wiper Washer Fluid Level Sensor Circuit Failure	FEM	REFER to WIPERS AND WASHERS .
B1483	Brake Pedal Input Circuit Failure	REM	REFER to BRAKE SYSTEM-GENERAL INFORMATION .
B1485	Stoplamp Switch Input Circuit Short to Battery	ABS Module	REFER to ANTI-LOCK CONTROL .
B1485	IVD Stoplamp Switch Input Circuit Short to Battery	ABS Module	REFER to ANTI-LOCK CONTROL .
B1492	Key Already Stored	IC Module	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1492	Key Already Stored	HEC Module	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1499	Lamp Turn Signal Left Circuit Failure	FEM	REFER to EXTERIOR LIGHTING - THUNDERBIRD .
B1501	Lamp Turn Signal Left Circuit Short to Battery	FEM	REFER to EXTERIOR LIGHTING - THUNDERBIRD .
B1503	Lamp Turn Signal Right Circuit Failure	FEM	REFER to EXTERIOR LIGHTING - THUNDERBIRD .
B1505	Lamp Turn Signal Right Circuit Short to Battery	FEM	REFER to EXTERIOR LIGHTING - THUNDERBIRD .
B1519	Hood Ajar Switch Circuit Failure	FEM	REFER to ANTI-THEFT - PERIMETER .
B1551	Decklid Release Circuit Failure	FEM	REFER to BODY CLOSURES .
B1567	Lamp Headlamp High-beam Circuit Failure	FEM	REFER to EXTERIOR LIGHTING - THUNDERBIRD .
B1567	Lamp Headlamp High-beam Circuit Failure	IC Module	REFER to EXTERIOR LIGHTING - THUNDERBIRD .
B1567	Lamp Headlamp High-beam Circuit Failure	HEC Module	REFER to EXTERIOR LIGHTING - THUNDERBIRD .
B1600	PATS Ignition Key Transponder Signal is Not Received	IC Module	REFER to ANTI-THEFT - PATS .
B1600	PATS Ignition Key Transponder Signal is Not Received	HEC Module	REFER to ANTI-THEFT - PATS .
B1601	PATS Received Incorrect Key- Code From Ignition Key Transponder	IC Module	REFER to ANTI-THEFT - PATS .
B1601	PATS Received Incorrect Key-Code From Ignition Key Transponder	HEC Module	REFER to ANTI-THEFT - PATS .
B1602	PATS Received Invalid Format Of Key-Code From Ignition Key Transponder	IC Module	REFER to ANTI-THEFT - PATS .
B1602	PATS Received Invalid Format Of Key-Code From Ignition Key Transponder	HEC Module	REFER to ANTI-THEFT - PATS .
B1676	Battery Voltage Out of Range	ABS Module	REFER to ANTI-LOCK CONTROL .
B1676	Battery Voltage Out of Range	FEM	REFER to BATTERY, MOUNTING & CABLES .
B1676	Battery Voltage Out of Range	IC Module	REFER to INSTRUMENT CLUSTER .
B1676	Battery Voltage Out of Range	HEC Module	REFER to INSTRUMENT CLUSTER .
B1676	Battery Voltage Out of Range	REM	REFER to BATTERY, MOUNTING & CABLES .
B1681	PATS Transceiver Module Signal is Not Received	IC Module	REFER to INSTRUMENT CLUSTER .
B1681	PATS Transceiver Module Signal is Not Received	HEC Module	REFER to INSTRUMENT CLUSTER .
B1689	Autolamp Delay Circuit Failure	IC Module	REFER to INSTRUMENT CLUSTER .
B1689	Autolamp Delay Circuit Failure	HEC Module	REFER to INSTRUMENT CLUSTER .
B1794	Lamp Headlamp Low-beam Circuit Failure	FEM	REFER to EXTERIOR LIGHTING - THUNDERBIRD .
B1830	Door Lock Disarm Switch Circuit Failure	FEM	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1869	Lamp Air Bag Warning Indicator Circuit Open	RCM	REFER to INSTRUMENT CLUSTER AND PANEL ILLUMINATION .
B1870	Lamp Air Bag Warning Indicator Circuit Short to Battery	RCM	REFER to INSTRUMENT CLUSTER AND PANEL ILLUMINATION .
B1871	Passenger Air Bag Deactivate Module Fault	RCM	REFER to AIR BAG RESTRAINT SYSTEMS AIR BAG RESTRAINT SYSTEMS .
B1875	Turn Signal/Hazard Switch Signal Circuit Failure	IC Module	REFER to EXTERIOR LIGHTING - THUNDERBIRD .
B1875	Turn Signal/Hazard Switch Signal Circuit Failure	HEC Module	REFER to EXTERIOR LIGHTING - THUNDERBIRD .
B1877	Safety belt Driver Pretensioner Circuit Open	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1878	Safety belt Driver Pretensioner Circuit Short to Battery	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1879	Safety belt Driver Pretensioner Circuit Short to Ground	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1881	Safety belt Passenger Pretensioner Circuit Open	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1882	Safety belt Driver Pretensioner Circuit Short to Battery	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1883	Safety belt Driver Pretensioner Circuit Short to Ground	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1884	PAD Warning Lamp Inoperative	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1885	Safety belt Driver Pretensioner Circuit Low on Squib	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1886	Safety belt Passenger Pretensioner Circuit Low on Squib	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1887	Driver Air Bag Circuit Short to Ground	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1888	Passenger Air Bag Circuit Short to Ground	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1889	Passenger Air Bag Deactivate Module Sensor Obstructed	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1890	PAD Warning Lamp Circuit Short to Battery	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1891	Air Bag Tone Warning Indicator Circuit Short to Battery	RCM	REFER to INSTRUMENT CLUSTER AND PANEL ILLUMINATION .
B1892	Air Bag Tone Warning Indicator Circuit Failure	RCM	REFER to INSTRUMENT CLUSTER AND PANEL ILLUMINATION .
B1901	Air Bag Crash Sensor No. 1 Feed/Return Circuit Open	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1916	Driver Air Bag Circuit Short to Battery	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1921	Air Bag Diagnostic Monitor Ground Circuit Open	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1925	Air Bag Passenger Circuit Short to Battery	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1932	Air Bag Driver Circuit Open	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1933	Air Bag Passenger Circuit Open	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1934	Air Bag Driver Inflator Circuit Resistance Low on Squib	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1935	Air Bag Passenger Inflator Circuit Resistance Low on Squib	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1941	Air Bag Crash Sensor No. 1 Feed/Return Circuit Open	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1992	Driver Side, Side Mount Air Bag Circuit Short to Battery	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1993	Driver Side, Side Mount Air Bag Circuit Short to Ground	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1994	Driver Side, Side Mount Air Bag Circuit Open	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1995	Driver Side, Side Mount Air Bag Circuit Resistance Low on Squib	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1996	Passenger Side, Side Mount Air Bag Circuit Short to Battery	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1997	Passenger Side, Side Mount Air Bag Circuit Short to Ground	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1998	Passenger Side, Side Mount Air Bag Circuit Open	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B1999	Passenger Side, Side Mount Air Bag Circuit Resistance Low on Squib	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B2103	Antenna Not Connected	IC Module	REFER to ANTI-THEFT - PATS .
B2103	Antenna Not Connected	HEC Module	REFER to ANTI-THEFT - PATS .
B2139	SCP Not Configured, PCM ID Does Not Match	IC Module	REFER to INSTRUMENT CLUSTER .
B2139	SCP Not Configured, PCM ID Does Not Match	HEC Module	REFER to INSTRUMENT CLUSTER .
B2141	NVM Configuration Failure	IC Module	REFER to INSTRUMENT CLUSTER .
B2141	NVM Configuration Failure	HEC Module	REFER to INSTRUMENT CLUSTER .
B2143	NVM Memory Failure	IC Module	REFER to INSTRUMENT CLUSTER .
B2143	NVM Memory Failure	HEC Module	REFER to INSTRUMENT CLUSTER .
B2162	Data Mismatch	IC Module	REFER to INSTRUMENT CLUSTER .
B2162	Data Mismatch	HEC Module	REFER to INSTRUMENT CLUSTER .
B2172	Inertia Switch Input Circuit Open	REM	REFER to VEHICLE SPEED CONTROL .
B2328	Column Reach Feedback Potentiometer Circuit Failure	IC Module	REFER to STEERING COLUMN .
B2328	Column Reach Feedback Potentiometer Circuit Failure	HEC Module	REFER to STEERING COLUMN .
B2332	Column Tilt Feedback Potentiometer Circuit Failure	IC Module	REFER to STEERING COLUMN .
B2332	Column Tilt Feedback Potentiometer Circuit Failure	HEC Module	REFER to STEERING COLUMN .
B2351	Steering Column Switch Circuit Failure	IC Module	REFER to STEERING COLUMN .
B2351	Steering Column Switch Circuit Failure	HEC Module	REFER to STEERING COLUMN .
B2401	Audio Tape Deck Mechanism Fault	ACM Module	Repair as necessary
B2402	Audio CD/DJ Thermal Shutdown Fault	ACM Module	Repair as necessary .
B2403	Audio CD/DJ Internal Fault	ACM Module	Repair as necessary .
B2404	Audio Steering Wheel Switch Circuit Fault	ACM Module	Repair as necessary .
B2405	Audio Single Disc CD Player Thermal Shutdown Fault	ACM Module	Repair as necessary .
B2406	Audio Single Disc CD Player Internal Fault	ACM Module	Repair as necessary .
B2425	Remote Keyless Entry Out of Synchronization	RKE	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2431	Transponder Programming Failure	IC Module	REFER to ANTI-THEFT - PATS .
B2432	Driver Safety Belt Buckle Switch Circuit Open	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B2434	Driver Safety Belt Buckle Switch Circuit Short to Ground	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B2435	Driver Safety Belt Buckle Switch Resistance Out of Range	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B2436	Passenger Safety Belt Buckle Switch Circuit Open	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B2438	Passenger Safety Belt Buckle Switch Circuit Short to Ground	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B2439	Passenger Safety Belt Buckle Switch Circuit Resistance Out of Range	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B2440	Passenger Side, Side Crash Sensor Mount Fault	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B2441	Driver Side, Side Crash Sensor Mount Fault	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B2444	Driver Side Crash Sensor Internal Fault	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B2445	Passenger Side Crash Sensor Internal Fault	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
B2472	Fog Lamp Switch Failure	HEC Module	REFER to EXTERIOR LIGHTING - THUNDERBIRD .
B2474	Passenger Door Lock Switch Circuit Short to Ground	REM	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2475	Passenger Door Unlock Switch Circuit Short to Ground	REM	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2477	Module Configuration Failure (Unconfigured, Incorrect or Rejected)	ABS Module	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure (Unconfigured, Incorrect or Rejected)	ACM Module	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure (Unconfigured, Incorrect or Rejected)	FEM	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure (Unconfigured, Incorrect or Rejected)	IC Module	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure (Unconfigured, Incorrect or Rejected)	HEC Module	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure (Unconfigured, Incorrect or Rejected)	RCM	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure (Unconfigured, Incorrect or Rejected)	REM	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure (Unconfigured, Incorrect or Rejected)	RKE	REFER to MODULE CONFIGURATION .
B2481	Convertible Top Up/Down Switch Failure	FEM	REFER to CONVERTIBLE TOP .
B2499	Courtesy Lamp Output Failure	FEM	REFER to INTERIOR LIGHTING .
B2500	Courtesy Lamp Output Circuit Short to Battery	FEM	REFER to INTERIOR LIGHTING .
B2519	High Mount Stop Lamp Circuit Failure	REM	REFER to EXTERIOR LIGHTING - THUNDERBIRD .
B2523	License Lamp Circuit Failure	REM	REFER to EXTERIOR LIGHTING - THUNDERBIRD .
B2524	License Lamp Circuit Short to Battery	REM	REFER to INTERIOR LIGHTING .
B2529	Left Rear Turn Lamp Circuit Failure	REM	REFER to EXTERIOR LIGHTING - THUNDERBIRD .
B2530	Left Rear Turn Lamp Circuit Short to Battery	REM	REFER to EXTERIOR LIGHTING - THUNDERBIRD .
B2535	Right Rear Turn Lamp Circuit Failure	REM	REFER to EXTERIOR LIGHTING - THUNDERBIRD .
B2536	Right Rear Turn Lamp Circuit Short to Battery	REM	REFER to EXTERIOR LIGHTING - THUNDERBIRD .
B2565	Right Tail Lamp Circuit Failure	REM	REFER to EXTERIOR LIGHTING - THUNDERBIRD .
B2572	Brake Shift Interlock Output Circuit Failure	FEM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION EXTERNAL CONTROLS .
B2573	Brake Shift Interlock Circuit Short to Ground	FEM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION EXTERNAL CONTROLS .
B2574	Drivers Door Lock Switch Circuit Short to Ground	REM	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2575	Drivers Door Unlock Switch Short to Ground	REM	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2576	Hardtop Sense Input Circuit Short to Ground	REM	REFER to CONVERTIBLE TOP .
B2577	Left Tail Lamp Circuit Failure	REM	REFER to EXTERIOR LIGHTING - THUNDERBIRD .
B2578	Passenger Power Window Down Switch Circuit Failure	REM	REFER to GLASS, FRAMES AND MECHANISMS .
B2579	Passenger Power Window Up Switch Circuit Failure	REM	REFER to GLASS, FRAMES AND MECHANISMS .
C1095	ABS Hydraulic Pump Motor Circuit Failure	ABS Module	REFER to ANTI-LOCK CONTROL .
C1125	Brake Fluid Level Sensor Input Circuit Failure	FEM	REFER to DISC .
C1145	Wheel Speed Sensor RF Input Circuit Failure	ABS Module	REFER to ANTI-LOCK CONTROL .
C1155	Wheel Speed Sensor LF Input Circuit Failure	ABS Module	REFER to ANTI-LOCK CONTROL .
C1165	Wheel Speed Sensor RR Input Circuit Failure	ABS Module	REFER to ANTI-LOCK CONTROL .
C1175	Wheel Speed Sensor LR Input Circuit Failure	ABS Module	REFER to ANTI-LOCK CONTROL .
C1233	Wheel Speed LF Input Signal Missing	ABS Module	REFER to ANTI-LOCK CONTROL .
C1234	Wheel Speed RF Input Signal Missing	ABS Module	REFER to ANTI-LOCK CONTROL .
C1235	Wheel Speed Sensor RR Input Signal Missing	ABS Module	REFER to ANTI-LOCK CONTROL .
C1236	Wheel Speed Sensor LR Input Signal Missing	ABS Module	REFER to ANTI-LOCK CONTROL .
C1277	Steering Wheel Angle 1 and 2 Circuit Failure	ABS Module	REFER to ANTI-LOCK CONTROL .
C1278	Steering Wheel Angle 1 and 2 Circuit Fault	ABS Module	REFER to ANTI-LOCK CONTROL .
C1279	Yaw Rate Sensor Circuit Failure	ABS Module	REFER to ANTI-LOCK CONTROL .
C1280	Yaw Rate Sensor Signal Fault	ABS Module	REFER to ANTI-LOCK CONTROL .
C1281	Lateral Accelerometer Circuit Failure	ABS Module	REFER to ANTI-LOCK CONTROL .
C1282	Lateral Accelerometer Signal Fault	ABS Module	REFER to ANTI-LOCK CONTROL .
C1283	Switch Test Signal Failure, STS	ABS Module	REFER to ANTI-LOCK CONTROL .
C1284	Oil Pressure Switch Circuit Failure	FEM	REFER to SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV
C1285	Booster Solenoid Output Circuit Failure	ABS Module	REFER to ANTI-LOCK CONTROL .
C1286	Booster Mechanical Failure	ABS Module	REFER to ANTI-LOCK CONTROL .
C1287	Booster Pedal Force Switch Circuit Failure	ABS Module	REFER to ANTI-LOCK CONTROL .
C1288	Pressure Transducer Main/Primary Input Circuit Failure	ABS Module	REFER to ANTI-LOCK CONTROL .
C1289	Pressure Transducer Redundant/Secondary Input Circuit Failure	ABS Module	REFER to ANTI-LOCK CONTROL .
C1414	Incorrect Module Design Level	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
C1446	Brake Switch Circuit Failure	FEM	REFER to EXTERIOR LIGHTING - THUNDERBIRD .
C1730	Reference Voltage Out of Range	ABS Module	REFER to ANTI-LOCK CONTROL .
C1805	Mismatched PCM and/or ABS/TC and/or IVD Module	ABS Module	CHECK for correct ABS module component and configuration for the PCM and ABS module, INSTALL a new as necessary. REFER to ANTI-LOCK CONTROL or SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV as necessary. CLEAR the DTC. REPEAT the self-test.
C1924	VAPS Solenoid Actuator Output Short to Ground	FEM	REFER to POWER STEERING .
C1925	VAPS Solenoid Actuator Return Circuit Failure	FEM	REFER to POWER STEERING .
C1960	Driver Brake Apply Circuit Fault	ABS Module	REFER to ANTI-LOCK CONTROL .
C1963	Stability Control Inhibit Warning	ABS Module	REFER to ANTI-LOCK CONTROL .
C1969	TC/YC Switch Lamp Circuit Failure	ABS Module	REFER to ANTI-LOCK CONTROL .
P1641	Fuel Pump Primary Circuit Failure	REM	REFER to VEHICLE SPEED CONTROL .
U1009	Actual Axle Torque Data Invalid	ABS Module	REFER to SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV .
U1027	Engine RPM With Throttle Position Data Invalid	ABS Module	REFER to SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV .
U1059	Transmission PRNDL Range Selected is Invalid	ABS Module	REFER to SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV .
U1073	Engine Coolant Fluid Temperature Status is Invalid	ABS Module	REFER to SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV .
U1243	Outside Air Temperature Status Invalid	ABS Module	REFER to SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV .
U1262	Actual Torque w/min. and max. Available Torque Status (5 seconds aging)	ABS Module	REFER to SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV .
U1263	Brake Lamp Pedal Switch Status-Active (5 seconds aging)	ABS Module	REFER to SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV .
U1264	Brake Lamp Pedal Switch Status-Inactive (5 seconds aging)	ABS Module	REFER to SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV .
U1265	Clutch Pedal Position Status (5 seconds aging)	ABS Module	REFER to SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV .
U1266	Engine Coolant Temperature Status (5 seconds aging)	ABS Module	REFER to SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV .
U1267	Engine RPM w/high res. rate of change w/Throttle Position Status (5 seconds aging)	ABS Module	REFER to SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV .
U1268	Engine Vacuum Status (5 seconds aging)	ABS Module	REFER to SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV .
U1269	Outside Air Temperature Status (25 seconds aging)	ABS Module	REFER to SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV .
U1270	Transmission Configuration Status (5 seconds aging)	ABS Module	SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV REFER to .
U1271	Transmission PRNDL Range Selected Status (5 seconds aging)	ABS Module	REFER to SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV .
U1272	Engine Configuration Status (1.8 seconds aging on power up only)	ABS Module	REFER to SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV .
U1273	Transmission Configuration Status (1.8 seconds aging on power up only)	ABS Module	REFER to SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV .
U2003	Audio CD/DJ is Not Responding	ACM	Repair as necessary .
U2005	Audio Rear Integrated Control Panel Unit is Not Responding	ACM	Repair as necessary .
U2008	Audio Phone is Not Responding	ACM	Repair as necessary .
U2017	Driver Side Crash Sensor Communications Fault	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .
U2018	Passenger Side Crash Sensor Communications Fault	RCM	REFER to AIR BAG RESTRAINT SYSTEMS .

DIAGNOSTIC TROUBLE CODE

Inspection and Verification

Verify the customer concern by operating the system.
Visually inspect for obvious signs of electrical damage. VISUAL INSPECTION Electrical Central junction box (CJB) fuse(s): 220 (10A) 230 (5A) 233 (10A) Wiring harness Connector(s) Circuitry
If the concern remains after the inspection, connect the diagnostic tool to the data link connector (DLC) located beneath the instrument panel and select the vehicle to be tested from the diagnostic tool menu. If the diagnostic tool does not communicate with the vehicle: check that the program card is correctly installed. check the connections to the vehicle. check the ignition switch position.
If the diagnostic tool still does not communicate with the vehicle, refer to the diagnostic tool manual.
Carry out the DATA LINK DIAGNOSTICS test. If the diagnostic tool responds with: CKT914, CKT915 or CKT70 = ALL ECUS NO RESP/NOT EQUIP, refer to «MODULE COMMUNICATIONS NETWORK»(ref-204591) . NO RESPONSE/NOT EQUIP for FEM, Go To «PINPOINT TEST A: NO COMMUNICATION WITH THE FRONT ELECTRONIC MODULE (FEM)»(ref-204602-S35349732202005111300000) . SYSTEM PASSED, retrieve and record the continuous diagnostic trouble codes (DTCs), erase the continuous DTCs and carry out self-test diagnostics for the FEM.
If the DTCs retrieved are related to the concern, go to the «Diagnostic Trouble Code (DTC) Index»(ref-204602-S30971026502005111300000) to continue diagnostics.
If no DTCs related to the concern are retrieved, return to the article that directed you here and continue diagnostics.

Symptom Chart

Condition	Possible Sources	Action
No communication with the front electronic module (FEM)	Central junction box (CJB) fuse(s): 220 (10A). 230 (5A). 233 (10A). Circuitry. FEM.	Go To PINPOINT TEST A: NO COMMUNICATION WITH THE FRONT ELECTRONIC MODULE (FEM) .

SYMPTOM

Scheme 55

Scheme 55: PINPOINT TEST A: NO COMMUNICATION WITH THE FRONT ELECTRONIC MODULE (FEM)

Scheme 56

Verify the customer concern by operating the system.
Visually inspect for obvious signs of electrical damage. VISUAL INSPECTION Electrical Battery junction box (BJB) fuse(s): 414 (30A) 423 (5A) 441 (15A) Wiring harness Connector(s) Circuitry
If the concern remains after the inspection, connect the diagnostic tool to the data link connector (DLC) located beneath the instrument panel and select the vehicle to be tested from the diagnostic tool menu. If the diagnostic tool does not communicate with the vehicle: check that the program card is correctly installed. check the connections to the vehicle. check the ignition switch position.
If the diagnostic tool still does not communicate with the vehicle, refer to the diagnostic tool manual.
Carry out the DATA LINK DIAGNOSTICS test. If the diagnostic tool responds with: CKT914, CKT915 or CKT70 = ALL ECUS NO RESP/NOT EQUIP, refer to «MODULE COMMUNICATIONS NETWORK»(ref-204591) . NO RESPONSE/NOT EQUIP for REM, Go To «PINPOINT TEST B: NO COMMUNICATION WITH THE REAR ELECTRONIC MODULE (REM)»(ref-204602-S07100348152005111300000) . SYSTEM PASSED, retrieve and record the continuous diagnostic trouble codes (DTCs), erase the continuous DTCs and carry out self-test diagnostics for the REM.
If the DTCs retrieved are related to the concern, go to the «Diagnostic Trouble Code (DTC) Index»(ref-204602-S30971026502005111300000) to continue diagnostics.
If no DTCs related to the concern are retrieved, return to the article that lead you here to continue diagnostics.

Condition	Possible Sources	Action
No communication with the rear electronic module (REM)	Battery junction box (BJB) fuse(s): 414 (30A). 423 (5A). 441 (15A). Circuitry. REM.	Go To PINPOINT TEST B: NO COMMUNICATION WITH THE REAR ELECTRONIC MODULE (REM) .

SYMPTOM

Scheme 57

Scheme 57: PINPOINT TEST B: NO COMMUNICATION WITH THE REAR ELECTRONIC MODULE (REM)

Scheme 58

Scheme 59

Scheme 59: Special Tool(s)

Verify the customer concern by operating the system.
Visually inspect for obvious signs of electrical damage. VISUAL INSPECTION Electrical Central junction box (CBJ) fuse 207 (5A) Wiring harness Connector(s) Circuitry
If the concern remains after the inspection, connect the diagnostic tool to the data link connector (DLC) located beneath the instrument panel and select the vehicle to be tested from the diagnostic tool menu. If the diagnostic tool does not communicate with the vehicle: check that the program card is correctly installed. check the connections to the vehicle. check the ignition switch position.
If the diagnostic tool still does not communicate with the vehicle, refer to the diagnostic tool manual.
Carry out the DATA LINK DIAGNOSTICS test. If the diagnostic tool responds with: CKT914, CKT915 or CKT70 = ALL ECUS NO RESP/NOT EQUIP, refer to «MODULE COMMUNICATIONS NETWORK»(ref-204591) . NO RESPONSE/NOT EQUIP for RKE, Go To «PINPOINT TEST C: NO COMMUNICATION WITH THE REMOTE KEYLESS ENTRY (RKE) MODULE»(ref-204602-S22296346052005111300000) . SYSTEM PASSED, retrieve and record the continuous diagnostic trouble codes (DTCs), erase the continuous DTCs and carry out self-test diagnostics for the RKE.
If the DTCs retrieved are related to the concern, go to the «Diagnostic Trouble Code (DTC) Index»(ref-204602-S30971026502005111300000) to continue diagnostics.
If no DTCs related to the concern are retrieved, return to the article that referenced you here to continue diagnostics

Condition	Possible Sources	Action
No communication with the remote keyless entry (RKE) module	Central junction box (CBJ) fuse 07 (5A). Circuitry. RKE.	Go To PINPOINT TEST C: NO COMMUNICATION WITH THE REMOTE KEYLESS ENTRY (RKE) MODULE .

SYMPTOM

Scheme 60

Scheme 60: PINPOINT TEST C: NO COMMUNICATION WITH THE REMOTE KEYLESS ENTRY (RKE) MODULE

Scheme 61

Scheme 61: Removal and Installation

Scheme 62

Scheme 63

Scheme 64

Remove the hardtop if installed and lower the convertible top.
Detach the 7 convertible top well cover pin-type retainers. To install, use new pin-type retainers.
Gently pull the two corners of the protective cover away from the top brace until the 3 pin-type retainers on each side are disengaged and position the cover aside.
Raise the convertible top.
Remove the water shield.
Disconnect the connector.
Remove the screws and the module.
To install, reverse the removal procedure.

Scheme 65

Scheme 65: Removal and Installation

Scheme 66

Scheme 67

Scheme 68

Remove the hardtop if installed and lower the convertible top.
Detach the 7 convertible top well cover pin-type retainers. To install, use new pin-type retainers.
Gently pull the two corners of the protective cover away from the top brace until the 3 pin-type retainers on each side are disengaged and position the cover aside.
Raise the convertible top.
Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING & CABLES»(ref-204581) .
Position the water shield aside.
Disconnect the electrical connectors.
Remove the bolts and the REM.
To install, reverse the removal procedure.

Scheme 69

Scheme 69: Removal and Installation

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING & CABLES»(ref-204581) .
Remove the LH scuff plate.
Release the retaining clips and remove the LH A -pillar lower trim panel.
Remove the lower instrument panel finish panel. Remove the courtesy lamp from the instrument panel finish panel.
Position the driver side carpet aside.
Position interior auxiliary junction box (AJB) aside. Remove the nuts.
Remove the nuts, bolt and position the FEM aside.
Remove the FEM. Disconnect the six electrical connectors.
To install, reverse the removal procedure.

Multifunction Electronic Module: Diagnosis Ford Thunderbird XI

Diagnostic Trouble Code (DTC) Index

Inspection and Verification

Symptom Chart

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

More articles — Multifunction Electronic Module

Login / Signup

Enter the code

You have successfully logged in!
