Inspection and Verification
- Verify the customer concern by operating the system.
- Visually inspect for obvious signs of electrical damage. VISUAL INSPECTION CHART Electrical Central junction box (CJB) fuse 206 (10A) Rear power distribution box (RPDB) fuse 26 (40A) Wiring harness Loose or corroded connections
- If the concern remains after the inspection, connect diagnostic tool to the data link connector (DLC) located beneath the instrument panel and select the vehicle to be tested from diagnostic tool menu. If diagnostic tool does not communicate with the vehicle: check that the program card is correctly installed. check the connections to the vehicle. check the ignition switch position. If the diagnostic tool still does not communicate with the vehicle, go to «PINPOINT TEST L: NO MODULE / NETWORK COMMUNICATION -NO POWER TO THE DIAGNOSTIC TOOL»(ref-204591-S07579669052005111300000) .
- Go to «PINPOINT TEST PC: DATA LINK DIAGNOSTICS NETWORK TEST»(ref-204591-S15648842842005111300000) .
Scheme 2
Symptom Chart
| Condition | Possible Sources | Action |
|---|---|---|
| The anti-lock brake system (ABS) control module does not respond to the diagnostic tool | Circuit or connection in the standard corporate protocol (SCP) network. ABS control module. | GO to PINPOINT TEST A: THE ANTI-LOCK BRAKE SYSTEM (ABS) CONTROL MODULE DOES NOT RESPOND TO THE DIAGNOSTIC TOOL |
| The front electronic module (FEM) does not respond to the diagnostic tool | Circuit or connection in the SCP network. FEM. | GO to PINPOINT TEST B: THE FRONT ELECTRONIC MODULE (FEM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL |
| The restraint control module (RCM) does not respond to the diagnostic tool | Circuit or connection in the International Standards Organization (ISO) 9141 network. RCM. | GO to PINPOINT TEST C: THE RESTRAINT CONTROL MODULE (RCM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL |
| The instrument cluster module does not respond to the diagnostic tool | Circuit or connection in the SCP network. Instrument cluster. | GO to PINPOINT TEST D: THE INSTRUMENT CLUSTER MODULE DOES NOT RESPOND TO THE DIAGNOSTIC TOOL |
| The powertrain control module (PCM) does not respond to the diagnostic tool | Circuit or connection in the SCP network. PCM. | GO to PINPOINT TEST E: THE POWERTRAIN CONTROL MODULE (PCM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL |
| The dual automatic temperature control (DATC) module does not respond to the diagnostic tool | Circuit or connection in the SCP network. DATC module. | GO to PINPOINT TEST F: THE DUAL AUTOMATIC TEMPERATURE CONTROL (DATC) MODULE DOES NOT RESPOND TO THE DIAGNOSTIC TOOL |
| The audio control module (ACM) does not respond to the diagnostic tool | Circuit or connection in the SCP network. ACM. | GO to PINPOINT TEST G: THE AUDIO CONTROL MODULE (ACM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL |
| The remote keyless entry module (RKE) does not respond to the diagnostic tool. | Circuit or connection in the SCP network. RKE. | GO to PINPOINT TEST H: THE REMOTE KEYLESS ENTRY MODULE (RKE) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL |
| The rear electronic module (REM) does not respond to the diagnostic tool | Circuit or connection in the SCP network. REM. | GO to PINPOINT TEST I: THE REAR ELECTRONIC MODULE (REM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL |
| No ISO 9141 network communication | Circuit or connection in the ISO 9141 network. ISO 9141 networked modules. | GO to PINPOINT TEST J: NO ISO 9141 NETWORK COMMUNICATION |
| No SCP network communication | Circuit or connection in the SCP network. SCP networked modules. | GO to PINPOINT TEST K: NO SCP NETWORK COMMUNICATION |
| No module/network communication - no power to the diagnostic tool | Central junction box (CJB) fuse 206 (10A). Rear power distribution box (RPDB) fuse 26 (40A). DLC pins. Diagnostic tool. Circuitry. | GO to PINPOINT TEST L: NO MODULE / NETWORK COMMUNICATION -NO POWER TO THE DIAGNOSTIC TOOL |
SYMPTOM CHART
