General Specifications
| Item | Specification |
|---|---|
| Heat shrink tube overlap mm (inch) | 12.7 (0.5) |
| Wire insulation removal length (twist side) mm (inch) | 37.2 (1.5) |
| Wire insulation removal length (receiving side) mm (inch) | 19.5 (0.75) |
| Raychem SCT(R) heat shrink tubing, Motorcraft part number WT-5627 | ESB-M99056-AZ |
GENERAL SPECIFICATIONS
Torque Specifications
| Description | N.m |
|---|---|
| Battery ground cable | 10 |
TORQUE SPECIFICATIONS
The communications network consists of the following components
- standard corporate protocol (SCP) communication network
- international standards organization (ISO 9141) communication network
- data link connector (DLC)
- powertrain control module (PCM)
- dual automatic temperature control (DATC) module
- audio control module (ACM)
- instrument cluster
- remote keyless entry module (RKE)
- front electronic module (FEM)
- anti-lock brake system (ABS) control module
- restraint control module (RCM)
- rear electronic module (REM)
- auxiliary junction box
Refer to appropriate wiring diagram in SYSTEM WIRING DIAGRAMS for schematic and connector information.
