Anti-Lock Control: Other Ford Thunderbird XI

Material

MATERIAL SPECIFICATION CHART

Scheme 28

Scheme 29

Scheme 30

Scheme 31

1. Raise and support the vehicle. For additional information, refer to «JACKING & HOISTING»(ref-232595-S06496072622006051700000) .
2. Position the inner splash shield aside. Remove the pin-type retainers. Position the inner splash shield aside.
3. Disconnect the wheel speed sensor electrical connector.
4. Remove the wheel speed sensor harness from the brake hose clips.
5. Remove the wheel speed sensor. Remove the wheel speed sensor clip. Remove the wheel speed sensor.
6. To install, reverse the removal procedure. Apply a 2.5 mm (0.1 in) bead of silicone sealant to the outside diameter of the wheel speed sensor.

Scheme 32

Scheme 33

Scheme 34

Scheme 35

1. Raise and support the vehicle. For additional information, refer to «JACKING & HOISTING»(ref-232595-S06496072622006051700000) .
2. Disconnect the rear wheel speed sensor electrical connector.
3. Remove the rear wheel speed sensor harness from the control arm clips.
4. Remove the rear wheel speed sensor. Remove the wheel speed sensor bolt. Remove the wheel speed sensor.
5. To install, reverse the removal procedure.
