Anti-Lock Control-Traction Control: Specifications Ford Thunderbird XI

Anti-Lock/traction Control 1 illustration ~106 words

Torque Specifications

DescriptionN.m
Anti-lock brake system (ABS) module-to-hydraulic control unit (HCU) bolts2
Hydraulic control unit (HCU) bracket-to-HCU bolts11
Brake line nut-to-hydraulic control unit (HCU) (M12, M10)18
Brake line nut-to-tube nut adapter (M12, M10)25
Tube nut adapter-to-hydraulic control unit (HCU) (M12)45
Tube nut adapter-to-hydraulic control unit (HCU) (M10)33
Hydraulic control unit (HCU) bracket-to-body bolts18
Front wheel speed sensor-to-cap bolt3
Rear wheel speed sensor-to-knuckle bolt11
Sensor cluster bracket-to-body bolt9

TORQUE SPECIFICATIONS

The four wheel anti-lock brake system (4WABS) with traction control consists of the following components

  1. anti-lock brake control module
  2. front anti-lock brake sensors
  3. front anti-lock brake sensor indicators
  4. hydraulic control unit (HCU)
  5. rear anti-lock brake sensors
  6. rear anti-lock brake sensor indicators
  7. traction control event indicator
  8. traction control switch
  9. yellow anti-lock brake warning indicator

For removal and installation of the front anti-lock brake sensor indicators, refer to FRONT in Suspension .

For removal and installation of the rear anti-lock brake sensor indicators, refer to REAR DRIVE HALFSHAFTS .

Scheme 36

Scheme 36: Special Tool(s)

Refer to ANTI-LOCK BRAKES for schematic and connector information.
