TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | |
|---|---|---|
| Front seat | ||
| Backrest bolts | 38 (51) | |
| Pivot bolt | 38 (51) | |
| Track mounting bolts | 35 (47) | |
| Instrument panel | ||
| Brace mounting bolts | 15 (20) | |
| Cowl side mounting nuts & bolts | 15 (20) | |
| Upper reinforcement mounting bolts | 15 (20) | |
| Seat belt | ||
| Guide anchor bolt | 30 (40) | |
| Lower anchor bolt | 30 (40) | |
| Pretensioner mounting bolt | 30 (40) | |
| Steering column | ||
| Intermediate shaft pinch bolt | 26 (35) | |
| Mounting nuts | 40 (30) | |
| Steering wheel mounting bolt | 28 (38) | |
| INCH Lbs. (N.m) | ||
| Driver-side air bag module screws | 97 (11) | |
| Floor console mounting bolts | 53 (6) | |
| Horn switch mounting bolts | 53 (6) | |
| Instrument panel | ||
| Cowl top retaining screws | 27 (3) | |
| Upper bulkhead electrical connector mounting bolt | 27 (3) | |
| Passenger-side air bag module mounting nuts & bolts | 80 (9) | |
| Plenum chamber mounting bolts | 53 (6) | |
| Restraints control module mounting bolts | 106 (12) | |
| Side air bag module nuts | 71 (8) | |
| Side air bag crash sensor bolts | 106 (12) | |
| Steering column | ||
| Brace nut & bolt | 106 (12) | |
| Opening reinforcement retaining screws | 80 (9) | |
