Engine Ignition - 3.0L (4V): Specifications Ford Taurus IV facelift

Ignition System 4 illustrations ~262 words

GENERAL SPECIFICATIONS

ItemSpecification
Base ignition timingNot adjustable
Firing order1-4-2-5-3-6
Spark plug gap1.37 mm (0.054 in)
Spark plug typeAGSF-32FM
Silicone Brake Caliper Grease and Dielectric Compound D7AZ-19A331-AESE-M1C171-A

GENERAL SPECIFICATIONS

Torque Specifications

DescriptionNm
Spark plugs15
Coil-on-plug bolts6

Torque Specifications

The electronic ignition (EI) system for the 3.0L Duratec engine consists of the following components

  1. Ignition-coil-on plug
  2. Spark plug
  3. Crankshaft position (CKP) sensor
  4. Camshaft position (CMP) sensor

The crankshaft position (CKP) sensor

  1. Is a variable reluctance sensor.
  2. Is mounted in the front cover.
  3. Is triggered by a 36-minus-1 tooth trigger wheel located behind the front cover.
  4. Provides base timing and crankshaft speed (RPM) to the powertrain control module (PCM).

The camshaft position (CMP) sensor

  1. Is a variable reluctance sensor.
  2. Is mounted in the front cover.
  3. Is triggered by the high point mark on the LH exhaust camshaft.
  4. Provides camshaft rotational location information to the powertrain control module (PCM).

Refer to the INTRODUCTION - CNG, FLEX-FUEL & GASOLINE for diagnosis and testing of the electronic ignition (EI) system.

Scheme 8

Scheme 8: Material

Scheme 9

Scheme 9: Removal and Installation
  1. Disconnect the electrical connector from the ignition coils.
  2. Remove the bolts and the ignition coils.
  3. To install, reverse the removal procedure. Apply a light film of Silicone Brake Caliper Grease and Dielectric compound D7AZ-19A331-A or equivalent meeting Ford specifications ESE-M1C171-A to the inside of the coil boots before installation.

Scheme 10

Scheme 10: Material

Scheme 11

Scheme 11: Removal and Installation
  1. Remove the upper intake manifold. For additional information, refer to «ENGINE - 3.0L (4V)»(ref-212099) .
  2. Disconnect the electrical connectors from the ignition coils.
  3. Remove the bolts and the ignition coils.
  4. To install, reverse the removal procedure. Apply a light film of Silicone Brake Caliper Grease and Dielectric compound D7AZ-19A331-A or equivalent meeting Ford specifications ESE-M1C171-A to the inside of the coil boots before installation.
