Electronic Automatic Temperature Control (EATC) Module

The EATC module is located in the instrument panel below the audio unit. The EATC module is on the medium speed CAN. The EATC module controls automatic climate functions that maintain the vehicle interior temperature at a constant setting. For additional information, refer to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION .

Smart Junction Box (SJB)

The SJB is on the medium speed CAN. The SJB is equipped on all vehicles. The SJB is a combination of a multifunction control module and an interior power junction box. SJB functions control multiple systems which include

  1. Speed dependent interval windshield wipers
  2. Illuminated entry and interior lamps
  3. Power door locks
  4. Windshield wipers
  5. Warning chimes
  6. Battery saver
  7. Accessory delay
  8. Power windows

For additional information, refer to MULTIFUNCTION ELECTRONIC CONTROL MODULES .

Restraints Control Module (RCM)

The RCM is the only module on the ISO 9141 network. The RCM controls the deployment of the air bags based on sensor input. For additional information, refer to AIR BAG RESTRAINT SYSTEMS article.

Powertrain Control Module (PCM)

The PCM is on the high speed CAN. The PCM controls the engine for better fuel economy, emissions control, failure mode detection and storage. Refer to the INTRODUCTION - CNG, FLEX-FUEL & GASOLINE article for diagnosis and testing of the PCM.

Passive Anti-Theft System (PATS)

The PATS is integrated into the PCM. The PCM controls the PATS system functions as well as illumination of the anti-theft indicator. The PCM stores the ignition key codes and controls engine disable. For additional information, refer to ANTI-THEFT - PATS .

Instrument Cluster

The instrument cluster is on the high speed CAN. It is an analog face cluster with a digital odometer. The instrument cluster displays a variety of information. For additional information, refer to INSTRUMENT CLUSTER .

Scheme 2

Scheme 2: Inspection and Verification
  1. Verify the customer concern.
  2. Visually inspect for obvious signs of mechanical or electrical damage.
  3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
  4. If the cause is not visually evident, connect the diagnostic tool to the data link connector and select the vehicle to be tested from the diagnostic tool menu. If the diagnostic tool does not communicate with the vehicle: Check that the program card is correctly installed. Check the connections to the vehicle. Check the ignition switch position. If the diagnostic tool still does not communicate with the vehicle, refer to the diagnostic tool operating manual. GO to «PINPOINT TEST PC»(ref-212136-S27075147162005122300000) .

Scheme 3

Scheme 3: PINPOINT TEST PC: DATA LINK DIAGNOSTICS TEST

Scheme 4

Scheme 4: Symptom Chart

Scheme 5

Scheme 5

Scheme 6

Scheme 6: PINPOINT TEST A: THE ANTI-LOCK BRAKE SYSTEM (ABS) MODULE DOES NOT RESPOND TO THE DIAGNOSTIC TOOL

Scheme 7

Scheme 7

Scheme 8

Scheme 8: PINPOINT TEST B: THE ELECTRONIC AUTOMATIC TEMPERATURE CONTROL (EATC) MODULE DOES NOT RESPOND TO THE

Scheme 9

Scheme 9: PINPOINT TEST C: THE SMART JUNCTION BOX (SJB) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL

Scheme 10

Scheme 10

Scheme 11

Scheme 11: PINPOINT TEST D: THE POWERTRAIN CONTROL MODULE (PCM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL

Scheme 12

Scheme 12

Scheme 13

Scheme 13: PINPOINT TEST E: THE INSTRUMENT CLUSTER DOES NOT RESPOND TO THE DIAGNOSTIC TOOL

Scheme 14

Scheme 14

Scheme 15

Scheme 15: PINPOINT TEST F: NO MEDIUM SPEED CONTROLLER AREA NETWORK (CAN) COMMUNICATION

Scheme 16

Scheme 16

Scheme 17

Scheme 17

Scheme 18

Scheme 18

Scheme 19

Scheme 19

Scheme 20

Scheme 20: PINPOINT TEST G: NO HIGH SPEED CONTROLLER AREA NETWORK (CAN) COMMUNICATION

Scheme 21

Scheme 21

Scheme 22

Scheme 22

Scheme 23

Scheme 23

Scheme 24

Scheme 24

Scheme 25

Scheme 25: PINPOINT TEST H: NO INTERNATIONAL STANDARDS ORGANIZATION (ISO) 9141 NETWORK COMMUNICATION

Scheme 26

Scheme 26

Scheme 27

Scheme 27: PINPOINT TEST I: NO MODULE/NETWORK COMMUNICATION - NO POWER TO THE DIAGNOSTIC TOOL
