Diagnostic Trouble Code (DTC) Index
| DTC | Description | Source | Action |
|---|---|---|---|
| B1202 | Fuel Sender Circuit Open | Instrument Cluster | REFER to PINPOINT TEST B in INSTRUMENT CLUSTER article. |
| B1204 | Fuel Sender Circuit Short to Ground | Instrument Cluster | REFER to PINPOINT TEST B in INSTRUMENT CLUSTER article. |
| B1205 | EIC Switch-1 Assembly Circuit Failure | Instrument Cluster | Information not available. REFER to INSTRUMENT CLUSTER article. |
| B1208 | EIC Switch-1 Assembly Circuit Short to Ground | Instrument Cluster | Information not available. REFER to INSTRUMENT CLUSTER article. |
| B1217 | Horn Relay Coil Circuit Failure | SJB | REFER to PINPOINT TEST A: THE HORN IS INOPERATIVE if horn is inoperative. If horn sounds continuously, refer to PINPOINT TEST B: THE HORN IS ALWAYS ON in HORN article. |
| B1218 | Horn Relay Coil Circuit Short to battery | SJB | REFER to PINPOINT TEST A: THE HORN IS INOPERATIVE in HORN article. |
| B1231 | Longitudinal Acceleration Threshold Exceeded | RCM | Crash data memory is full. Replace Restraints Control Module (RCM) and impact sensors. REFER to RESTRAINTS CONTROL MODULE (RCM) in AIR BAG RESTRAINT SYSTEMS article. |
| B1249 | Blend Door Failure | EATC | REFER to PINPOINT TEST A in CLIMATE CONTROL SYSTEM-GENERAL INFORMATION article. |
| B1251 | Air Temperature Internal Sensor Circuit Open | EATC | REFER to PINPOINT TEST B in CLIMATE CONTROL SYSTEM-GENERAL INFORMATION article. |
| B1253 | Air Temperature Internal Sensor Circuit Short to Ground | EATC | REFER to PINPOINT TEST B in CLIMATE CONTROL SYSTEM-GENERAL INFORMATION article. |
| B1255 | Air Temperature External Sensor Circuit Open | Instrument Cluster | Information not available. REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION article. |
| B1257 | Air Temperature External Sensor Circuit Short to Ground | Instrument Cluster | Information not availalbe. REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION article. |
| B1259 | Solar Radiation Sensors Circuit Open | EATC | REFER to PINPOINT TEST C in CLIMATE CONTROL SYSTEM-GENERAL INFORMATION article. |
| B1261 | Solar Radiation Sensor Circuit Short to Ground | EATC | REFER to PINPOINT TEST C in CLIMATE CONTROL SYSTEM-GENERAL INFORMATION article. |
| B1302 | Accessory Delay Relay Coil Circuit. Failure | SJB | If the delayed accessory feature is inoperative, GO to PINPOINT TEST H . If the delayed accessory feature does not turn off, GO to PINPOINT TEST G in GLASS, FRAMES AND MECHANISMS article. |
| B1304 | Accessory Delay Relay Coil Circuit Short to Battery | SJB | REFER to PINPOINT TEST H in GLASS, FRAMES AND MECHANISMS article. |
| B1309 | Power Door Lock Circuit Short to Ground | SJB | REFER to PINPOINT TEST A in HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article. |
| B1314 | Battery Saver Relay Coil Circuit Open | SJB | REFER to PINPOINT TEST H in INTERIOR LIGHTING article. |
| B1315 | Battery Saver Relay Coil Circuit Short to Battery | SJB | REFER to PINPOINT TEST H in INTERIOR LIGHTING article. |
| BI317 | Battery Voltage High | Instrument Cluster | Battery voltage high. Light continuous. Ensure battery voltage is less than 16 volts. REFER to GENERATORS & REGULATORS article. |
| B1317 | Battery Voltage High | SJB | Battery voltage high. Light continuous. Ensure battery voltage is less than 16 volts. REFER to GENERATORS & REGULATORS article. |
| B1317 | Battery Voltage High | RCM | Battery voltage high. Light continuous. Ensure battery voltage is less than 16 volts. REFER to GENERATORS & REGULATORS article. |
| B1318 | Battery Voltage Low | SJB | Battery voltage low. Light continuous. Ensure battery voltage is more than 9 volts. REFER to GENERATORS & REGULATORS article. |
| B1318 | Battery Voltage Low | Instrument Cluster | Battery voltage low. Light continuous. Ensure battery voltage is more than 9 volts. REFER to GENERATORS & REGULATORS article. |
| B1318 | Battery Voltage Low | RCM | Battery voltage low. Light continuous. Ensure battery voltage is more than 9 volts. REFER to GENERATORS & REGULATORS article. |
| B1322 | Driver Door Ajar Circuit Short to Ground | SJB | REFER to PINPOINT TEST C IN INTERIOR LIGHTING article. |
| B1330 | Passenger Door Ajar Circuit Short to Ground | SJB | REFER to PINPOINT TEST C IN INTERIOR LIGHTING article. |
| B1334 | Decldid Ajar Rear Door Circuit Short to Ground | SJB | REFER to PINPOINT TEST F IN INTERIOR LIGHTING article. |
| B1338 | Door Ajar RR Circuit Short to Ground | SJB | REFER to PINPOINT TEST C IN INTERIOR LIGHTING article. |
| B1341 | Power Door Unlock Circuit Short to Ground | SJB | REFER to PINPOINT TEST A in HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article. |
| B1342 | ECU Is Defective | Instrument Cluster | CLEAR the DTCs. REPEAT the self-test. If DTC B 1342 is retrieved again, INSTALL a new instrument cluster. REFER to INSTRUMENT CLUSTER in INSTRUMENT CLUSTER article. CLEAR the DTCs. REPEAT the self-test. |
| B1342 | ECU Is Defective | RCM | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new RCM. REFER to RESTRAINTS CONTROL MODULE (RCM) in AIR BAG RESTRAINT SYSTEMS article. Again, CLEAR the DTCs. REPEAT the self-test. |
| B1342 | ECU Is Defective | ABS Module | CLEAR the DTCs. REPEAT the self-test. If DTC B 1342 is retrieved again, INSTALL a new ABS Module. REFER to ANTI-LOCK BRAKE SYSTEM (ABS) MODULE in ANTI-LOCK CONTROL article. CLEAR the DTCs. REPEAT the self-test. |
| B1342 | ECU Is Defective | EATC | CLEAR the DTCs. REPEAT the self-test. If DTC B 1342 is retrieved again, INSTALL a new EATC Module. REFER to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION article. CLEAR the DTCs. REPEAT the self-test. |
| B1342 | ECU Is Defective | SJB | CLEAR the DTCs. REPEAT the self-test. If DTC B 1342 is retrieved again, INSTALL a new SJB. REFER to Smart Junction Box (SJB) . CLEAR the DTCs. REPEAT the self-test. |
| B1345 | Heated Backlite Input Circuit Short to Ground | SJB | REFER to PINPOINT TEST F in GLASS, FRAMES AND MECHANISMS article. |
| B1347 | Heated Backlite Relay Circuit Failure | SJB | REFER to PINPOINT TEST E PINPOINT TEST F in GLASS, FRAMES AND MECHANISMS article. |
| B1349 | Heated Backlite Relay Short to Battery | SJB | REFER to PINPOINT TEST E in GLASS, FRAMES AND MECHANISMS article. |
| B1352 | Ignition Key-In Circuit Failure | Instrument Cluster | Information not available. REFER to STEERING COLUMN SWITCHES article. |
| B1352 | Ignition Key-In Circuit Failure | SJB | Information not available. REFER to STEERING COLUMN SWITCHES article. |
| B 1359 | Ignition Run/Acc Circuit Failure | SJB | REFER to PINPOINT TEST B in STEERING COLUMN SWITCHES article. |
| B1371 | Illuminated Entry Relay Circuit Failure | SJB | If the interior lamps are inoperative, Go To PINPOINT TEST A . If the interior lamps remain on continuously, Go To PINPOINT TEST C in INTERIOR LIGHTING article. |
| B1373 | Illuminated Entry Relay Short to Battery | SJB | REFER to PINPOINT TEST A in INTERIOR LIGHTING article. |
| B1398 | Driver Power Window One Touch Window Relay Circuit Failure | SJB | If only the one-touch down feature is inoperative, GO to PINPOINT TEST D . If the driver front window is inoperative, GO to PINPOINT TEST A in GLASS, FRAMES AND MECHANISMS article. |
| B1400 | Driver Power Window One Touch Window Relay Circuit Short to Battery | SJB | REFER to PINPOINT TEST D in GLASS, FRAMES AND MECHANISMS article. |
| B1405 | Driver Power Window Down Circuit Short to Battery | SJB | REFER to PINPOINT TEST A in GLASS, FRAMES AND MECHANISMS article. |
| B1408 | Driver Power Window Up Circuit Short to Battery | SJB | Information not available. REFER to GLASS, FRAMES AND MECHANISMS article. |
| B1432 | Wiper Brake/Run Relay Circuit Short to Battery | SJB | Refer to PINPOINT TEST A in WIPERS AND WASHERS article. |
| B1434 | Wiper Hi/Low Speed Relay Coil Circuit Failure | SJB | Refer to PINPOINT TEST C in WIPERS AND WASHERS article. |
| B1436 | Wiper Hi/Low Speed Relay Coil Circuit Short to Battery | SJB | Refer to PINPOINT TEST C in WIPERS AND WASHERS article. |
| B1438 | Wiper Mode Select Switch Circuit Failure | SJB | If the windshield wipers are inoperative, GO to PINPOINT TEST A . If the windshield wipers do not operate correctly, GO to PINPOINT TEST C in WIPERS AND WASHERS article. |
| B1441 | Wiper Mode Select Switch Circuit Short to Ground | SJB | Refer to PINPOINT TEST B in WIPERS AND WASHERS article. |
| B1446 | Wiper Park Sense Circuit Failure | SJB | If the windshield wipers are inoperative, GO to PINPOINT TEST A . If the windshield wipers do not operate correctly, GO to PINPOINT TEST C in WIPERS AND WASHERS article. |
| B1448 | Wiper Park Sense Circuit Short to Battery | SJB | If the windshield wipers stay on continuously, GO to PINPOINT TEST B . If the windshield wipers do not operate correctly, GO to PINPOINT TEST C in WIPERS AND WASHERS article. |
| B1450 | Wiper Wash/Delay Switch Circuit Failure | SJB | If windshield washer is inoperative, GO to PINPOINT TEST D . If the windshield wipers do not operate correctly, GO to PINPOINT TEST C in WIPERS AND WASHERS article. |
| B1453 | Wiper Wash/Delay Switch Circuit Short To Ground | SJB | Refer to PINPOINT TEST D in WIPERS AND WASHERS article. |
| B1458 | Wiper Washer Pump Motor Relay Circuit Failure | SJB | If windshield washer is inoperative, GO to PINPOINT TEST D . If windshield washer stays on continuously, GO to PINPOINT TEST E in WIPERS AND WASHERS article. |
| B1460 | Wiper Washer Pump Motor Relay Coil Circuit Short to Battery | SJB | If windshield washer is inoperative, GO to PINPOINT TEST D . If windshield washer stays on continuously, GO to PINPOINT TEST E in WIPERS AND WASHERS article. |
| B1465 | Wiper Brake/Run Relay Circuit. Open | SJB | If the windshield wipers are inoperative, GO to PINPOINT TEST A . If the windshield wipers stay on continuously, GO to PINPOINT TEST B in WIPERS AND WASHERS article. |
| B1466 | Wiper Hi/Low Speed Not Switching | SJB | If the windshield wipers are inoperative, GO to PINPOINT TEST A . If the windshield wipers stay on continuously, GO to PINPOINT TEST B . If the windshield wipers do not operate correctly, GO to PINPOINT TEST C in WIPERS AND WASHERS article. |
| B1472 | Lamp Headlamp Input Circuit Short to Ground | SJB | CLEAR the DTCs. REPEAT the self-test. If DTC B1472 is retrieved again, INSTALL a new SJB. REFER to Smart Junction Box (SJB) . CLEAR the DTCs. REPEAT the self-test. |
| B1484 | Brake Pedal Input Open Circuit | ABS Module | REFER to Pinpoint Test C: DTC B1484 - Brake Pedal Input Open Circuit in ANTI-LOCK CONTROL article. |
| B1522 | Hood Switch Circuit Short to Ground | SJB | REFER to PINPOINT TEST C in ANTI-THEFT - PERIMETER article. |
| B1526 | Keyless Entry Circuit Short to Ground | SJB | REFER to PINPOINT TEST E in HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article. |
| B1551 | Decklid Release Circuit Failure. | SJB | REFER to PINPOINT TEST B in HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article. |
| B1553 | Decklid Release Circuit Short to Battery | SJB | REFER to PINPOINT TEST B in HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article. |
| B1554 | Decklid Release Circuit Short to Ground | SJB | REFER to PINPOINT TEST B in HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article. |
| B1555 | Ignition Run/St:art Circuit Failure | SJB | REFER to PINPOINT TEST C in STEERING COLUMN SWITCHES article. |
| B1574 | Door Ajar LR Circuit Short to Ground | SJB | REFER to PINPOINT TEST C in INTERIOR LIGHTING article. |
| B1577 | Lamp Park Input Circuit Short to Battery | SJB | REFER to PINPOINT TEST P: THE PARKING, REAR OR LICENSE LAMPS ARE ON CONTINUOUSLY in EXTERIOR LIGHTING article. |
| B1623 | Lamp Keypad Output Circuit Failure | SJB | REFER to PINPOINT TEST L in HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article. |
| B1676 | Battery Voltage Out of Range | EATC | Information not available. REFER to GENERATORS & REGULATORS article. |
| B1676 | Battery Voltage Out of Range | ABS Module | Information not available. REFER to Pinpoint Test B: DTC B1676, Battery Pack Voltage Out Of Range in Anti-Lock Control - Taurus & Sable article. |
| B1688 | Lamp Dome Input Circuit Short to Ground | SJB | Information not available. REFER to INTERIOR LIGHTING article. |
| B1696 | Autolamp On Circuit Short to Ground | SJB | CLEAR the DTCs. REPEAT the self-test. If DTC B1696 is retrieved again, INSTALL a new SJB. REFER to Smart Junction Box (SJB) . CLEAR the DTCs. REPEAT the self-test. |
| B1790 | Autolamp Sensor Input Circuit Failure | SJB | REFER to PINPOINT TEST F: THE AUTOLAMPS ARE INOPERATIVE in EXTERIOR LIGHTING article. |
| B1833 | Door Unlock Disarm Switch Circuit Short to Ground | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article. |
| B1868 | Lamp Air Bag Warning indicator Circuit Open | RCM | REFER to PINPOINT TEST N in INSTRUMENT CLUSTER article. |
| B1869 | Lamp Air Bag Warning indicator Circuit Open | RCM | REFER to TEST B: AIR BAG WARNING LIGHT CIRCUIT OPEN OR SHORT TO GROUND (DTC B1869) in AIR BAG RESTRAINT SYSTEMS article. |
| B1870 | Lamp Air Bag Warning Indicator Circuit Short To Battery | RCM | REFER to PINPOINT TEST N in INSTRUMENT CLUSTER article. |
| B1884 | PAD Warning Lamp Circuit Failure | RCM | REFER to TEST D: PASSENGER-SIDE AIR BAG DEACTIVATION (PAD) WARNING LIGHT FAILURE (DTC B1884) in AIR BAG RESTRAINT SYSTEMS article. |
| B1890 | PAD Warning Lamp Circuit Short To Battery | RCM | REFER to TEST E: PASSENGER-SIDE AIR BAG DEACTIVATION (PAD) WARNING LIGHT SHORT TO BATTERY (DTC B1890) in AIR BAG RESTRAINT SYSTEMS article. |
| B1891 | Air Bag Tone Warning Indicator Circuit Short to Battery | RCM | REFER to TEST F: AIR BAG TONE WARNING INDICATOR CIRCUIT SHORT TO BATTERY (DTC B1891) in AIR BAG RESTRAINT SYSTEMS article. |
| B1892 | Air Bag Tone Warning Indicator Circuit Failure | RCM | REFER to TEST G: AIR BAG TONE WARNING INDICATOR CIRCUIT SHORT TO GROUND OR OPEN (DTC B1892) in AIR BAG RESTRAINT SYSTEMS article. |
| B1921 | Air Bag Diagnostic Monitor Ground Circuit Open | RCM | REFER to TEST H: AIR BAG DIAGNOSTIC MONITOR GROUND CIRCUIT OPEN (DTC B1921) in AIR BAG RESTRAINT SYSTEMS article. |
| B1982 | Driver Door Unlock Relay Circuit Failure | SJB | REFER to PINPOINT TEST D in HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article. |
| B1983 | Driver Door Unlock Relay Circuit Short to Battery | SJB | REFER to PINPOINT TEST D in HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article. |
| B2097 | Compass Module Failure | Instrument Cluster | Install a new compass module. Refer to INSTRUMENT CLUSTER AND PANEL ILLUMINATION . |
| B2143 | Odometer NVM Checksum Failure | Instrument Cluster | Information not available. REFER to INSTRUMENT CLUSTER article. |
| B2183 | Wiper Mode Select Switch Circuit H Short to Ground | SJB | Information not available. Refer to WIPERS AND WASHERS article. |
| B2249 | Headlamp Relay Coil Short to Battery | SJB | CLEAR the DTCs. REPEAT the self-test. If DTC B2249 is retrieved again, INSTALL a new SJB. REFER to Smart Junction Box (SJB) . CLEAR the DTCs. REPEAT the self-test. |
| B2250 | All Doors Unlock Relay Circuit Failure | SJB | REFER to PINPOINT TEST C in HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article. |
| B2251 | Parklamp Output Relay Driver Circuit Failure | SJB | CLEAR the DTCs. REPEAT the self-test. If DTC B2251 is retrieved again, INSTALL a new SJB. REFER to Smart Junction Box (SJB) . CLEAR the DTCs. REPEAT the self-test. |
| B2252 | Parklamp Output Relay Driver Short to Battery | SJB | CLEAR the DTCs. REPEAT the self-test. If DTC B2252 is retrieved again, INSTALL a new SJB. REFER to Smart Junction Box (SJB) . CLEAR the DTCs. REPEAT the self-test. |
| B2290 | Occupant Classification System Fault Front Passenger Side | RCM | REFER to TEST I: OCCUPANT CLASSIFICATION SENSOR (OCS) CIRCUIT FAULT (DTC B2290) in AIR BAG RESTRAINT SYSTEMS article. |
| B2291 | Occupant Position Systems Status, Front Passenger Side | RCM | Information not available. REFER to AIR BAG RESTRAINT SYSTEMS article. |
| B2292 | Restraint System Seatbelt Pretensioner Status | RCM | REFER to TEST J: RESTRAINT SYSTEM-SEAT BELT PRETENSIONER STATUS (DTC B2292) in AIR BAG RESTRAINT SYSTEMS article. |
| B2293 | Restraint System Airbag Status | RCM | REFER to TEST K: RESTRAINT SYSTEM-AIR BAG STATUS (DTC B2293) in AIR BAG RESTRAINT SYSTEMS article. |
| B2294 | Restraint System Curtain Status | RCM | Information not available. REFER to AIR BAG RESTRAINT SYSTEMS article. |
| B2295 | Restraint System Side Airbag Status | RCM | REFER to TEST L: RESTRAINT SYSTEM-SIDE AIR BAG STATUS (DTC B2295) in AIR BAG RESTRAINT SYSTEMS article. |
| B2296 | Restraint System Impact Sensor Status | RCM | REFER to TEST M: RESTRAINT SYSTEM-IMPACT SENSOR STATUS (DTC B2296) in AIR BAG RESTRAINT SYSTEMS article. |
| B2425 | Remote Keyless Entry Out of Synchronization | SJB | REFER to PINPOINT TEST J in HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article. |
| B2434 | Drivers Seat Belt Buckle Switch Circuit Short To Ground | RCM | REFER to TEST N: LEFT SEAT BELT BUCKLE CIRCUIT SHORT TO GROUND (DTC B2434) in AIR BAG RESTRAINT SYSTEMS article. |
| B2435 | Drivers Seat Belt Buckle Switch Resistance Out Of Range | RCM | REFER to TEST O: LEFT SEAT BELT BUCKLE CIRCUIT RESISTANCE OUT OF RANGE (DTC B2435) in AIR BAG RESTRAINT SYSTEMS article. |
| B2438 | Passengers Seat Belt Buckle Switch Circuit Short to Ground | RCM | REFER to TEST P: RIGHT SEAT BELT BUCKLE CIRCUIT SHORT TO GROUND (DTC B2438) in AIR BAG RESTRAINT SYSTEMS article. |
| B2439 | Passengers Seat Belt Buckle Switch Resistance Out Of Range | RCM | REFER to TEST Q: RIGHT SEAT BELT BUCKLE CIRCUIT RESISTANCE OUT OF RANGE (DTC B2439) in AIR BAG RESTRAINT SYSTEMS article. |
| B2477 | Module Configuration Failure | Instrument Cluster | Configure the instrument cluster. REFER to MODULE CONFIGURATION to continue diagnosis. |
| B2477 | Module Configuration Failure | RCM | Module configuration failure. Replace RCM. REFER to RESTRAINTS CONTROL MODULE (RCM) in AIR BAG RESTRAINT SYSTEMS article. |
| B2598 | Headlamp Relay Circuit Failure | SJB | CLEAR the DTCs. REPEAT the self-test. If DTC B2598 is retrieved again, INSTALL a new SJB. REFER to Smart Junction Box (SJB) . CLEAR the DTCs. REPEAT the self-test. |
| B2691 | Front Drivers Seat Belt Buckle Switch Circuit Fault | RCM | REFER to TEST R: LEFT SEAT BELT BUCKLE SWITCH CIRCUIT FAULT (DTC B2691) in AIR BAG RESTRAINT SYSTEMS article. |
| B2692 | Front Passengers Seat Belt Buckle Switch Circuit Fault | RCM | REFER to TEST S: RIGHT SEAT BELT BUCKLE SWITCH CIRCUIT FAULT (DTC B2692) in AIR BAG RESTRAINT SYSTEMS article. |
| B2909 | Belt Tension Sensor Fault | RCM | REFER to TEST T: SEAT BELT TENSION SENSOR FAULT (DTC B2909) in AIR BAG RESTRAINT SYSTEMS article. |
| C1093 | Traction Control Disable Switch Circuit Failure | Instrument Cluster | REFER to PINPOINT TEST R in INSTRUMENT CLUSTER article. |
| C1145 | Speed Wheel Sensor RF Input Circuit Failure | ABS Module | REFER to Pinpoint Test E: DTC C1145 (RF), DTC C1155 (LF), DTC C1165 (RR). DTC C1175 (LR) - Wheel Speed Sensor Input Circuit Failure in ANTI-LOCK CONTROL article. |
| C1155 | Speed Wheel Sensor LF Input Circuit Failure | ABS Module | REFER to Pinpoint Test E: DTC C1145 (RF), DTC C1155 (LF), DTC C1165 (RR). DTC C1175 (LR) - Wheel Speed Sensor Input Circuit Failure in ANTI-LOCK CONTROL article. |
| C1165 | Speed Wheel Sensor RR Input Circuit Failure | ABS Module | REFER to Pinpoint Test E: DTC C1145 (RF), DTC C1155 (LF), DTC C1165 (RR). DTC C1175 (LR) - Wheel Speed Sensor Input Circuit Failure in ANTI-LOCK CONTROL article. |
| Cl167 | Park Brake Actuator Assembly Switch Released Circuit Short to Ground | SJB | No information available. |
| C1175 | Speed Wheel Sensor LR Input Circuit Failure | ABS Module | REFER to Pinpoint Test E: DTC C1145 (RF), DTC C1155 (LF), DTC C1165 (RR). DTC C1175 (LR) - Wheel Speed Sensor Input Circuit Failure in ANTI-LOCK CONTROL article. |
| C1189 | Brake Fluid Level Sensor Input Short Circuit to Ground | SJB | No information available. |
| C1222 | Speed Wheel Mismatch | ABS Module | REFER to Pinpoint Test F: DTC C1222 - Wheel Speed Mismatch, DTC C1296 (LF), DTC C1297 (RF), DTC C1298 (RR), DTC C1299 - Wheel Speed Sensor Signal Fault in ANTI-LOCK CONTROL article. |
| C1284 | Oil Pressure Switch Failure | Instrument Cluster | Go To PINPOINT TEST E in INSTRUMENT CLUSTER article. |
| C1266 | ABS Valve Power Relay Circuit Failure | ABS Module | REFER to Pinpoint Test G: DTC C1266 Anti-Lock Brake System (ABS) Power Valve Relay Circuit Failure in ANTI-LOCK CONTROL article. |
| C1284 | Oil Pressure Pressure Switch Failure | Instrument Cluster | No information available. REFER to Information And Message Center - Sable & Taurus article. |
| C1296 | Wheel Speed LF Signal Fault | ABS Module | REFER to Pinpoint Test F: DTC C1222 - Wheel Speed Mismatch, DTC C1296 (LF), DTC C1297 (RF), DTC C1298 (RR), DTC C1299 - Wheel Speed Sensor Signal Fault in ANTI-LOCK CONTROL article. |
| C1297 | Wheel Speed RF Signal Fault | ABS Module | REFER to Pinpoint Test F: DTC C1222 - Wheel Speed Mismatch, DTC C1296 (LF), DTC C1297 (RF), DTC C1298 (RR), DTC C1299 - Wheel Speed Sensor Signal Fault in ANTI-LOCK CONTROL article. |
| C1298 | Wheel Speed RR Signal Fault | ABS Module | REFER to Pinpoint Test F: DTC C1222 - Wheel Speed Mismatch, DTC C1296 (LF), DTC C1297 (RF), DTC C1298 (RR), DTC C1299 - Wheel Speed Sensor Signal Fault in ANTI-LOCK CONTROL article. |
| C1299 | Wheel Speed LR Signal Fault | ABS Module | REFER to Pinpoint Test F: DTC C1222 - Wheel Speed Mismatch, DTC C1296 (LF), DTC C1297 (RF), DTC C1298 (RR), DTC C1299 - Wheel Speed Sensor Signal Fault in ANTI-LOCK CONTROL article. |
| C1300 | ABS Module Pump Motor Circuit Failure | ABS Module | REFER to Pinpoint Test D: DTC C1300 - ABS Hydraulic Pump Motor Circuit Failure in ANTI-LOCK CONTROL article. |
| C1414/15 | TEST U: INCORRECT MODULE DESIGN LEVEL (DTC C1414) in AIR BAG RESTRAINT SYSTEMS article. | ||
| C1805 | Mismatched PCM and/or ABS/TC Module | ABS Module | CARRY OUT the PCM Self-Test CHECK for correct PCM and ABS Module part numbers. REFER to ANTI-LOCK CONTROL article. |
| C1947 | Driver Seat Track Position Switch Circuit Short to Ground | RCM | REFER to TEST V: SEAT TRACK POSITION SENSOR CIRCUIT SHORT TO GROUND (DTC C1947) in AIR BAG RESTRAINT SYSTEMS article. |
| C1948 | Driver Seat Track Position Switch Circuit Resistance Out Of Range | RCM | REFER to TEST W: SEAT TRACK POSITION SENSOR CIRCUIT RESISTANCE OUT OF RANGE (DTC C1948) in AIR BAG RESTRAINT SYSTEMS article. |
| C1981 | Front Drivers Seat Track Position Switch Circuit Fault | RCM | REFER to TEST X: SEAT TRACK POSITION SENSOR CIRCUIT FAULT (DTC C1981) AIR BAG RESTRAINT SYSTEMS article. |
| PXXXX | Any P Codes Not Covered Here | PCM | Refer to POWERTRAIN DTC CHARTS & DESCRIPTIONS - CNG, FLEX-FUEL & GASOLINE article |
| P0705 | Digital TR sensor. | PCM | Refer to PINPOINT TEST D in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P0708 | Digital TR sensor. | PCM | Refer to PINPOINT TEST D in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P0712 | 171 °C (340°F) indicated TFT sensor circuit grounded. | PCM | Refer to PINPOINT TEST B in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P0713 | 43°C (-45°F) indicated TFT sensor circuit open. | PCM | Refer to PINPOINT TEST B in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P0715 | Insufficient input from Turbine Shaft Speed (TSS) Sensor. | PCM | Refer to PINPOINT TEST F in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P0717 | Insufficient input from Turbine Shaft Speed (TSS) sensor. | PCM | Refer to PINPOINT TEST F in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P0718 | TSS signal intermittent. | PCM | Refer to PINPOINT TEST F in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P0720 | Insufficient input from OSS sensor. | PCM | Refer to PINPOINT TEST G in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P0721 | Output shaft speed sensor signal noisy. | PCM | Refer to PINPOINT TEST G in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P0722 | Output shaft speed sensory signal intermittent. | PCM | Refer to PINPOINT TEST G in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P0731 | SSA, SSB, or internal parts | PCM | Refer to PINPOINT TEST A in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P0732 | 2nd gear failure. | PCM | Refer to PINPOINT TEST A in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P0733 | SSA, SSC, or internal parts | PCM | Refer to PINPOINT TEST A in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P0734 | SSA, SSC, or internal parts | PCM | Refer to PINPOINT TEST A in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P0741 | Converter Clutch Error. | PCM | Refer to PINPOINT TEST C in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P0743 | TCC solenoid circuit failure during on-board diagnostic. | PCM | Refer to PINPOINT TEST C in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P0750 | SSA solenoid circuit failure. | PCM | Refer to PINPOINT TEST A in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P0753 | SSA solenoid circuit failure. | PCM | Refer to PINPOINT TEST A in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P0755 | SSB solenoid circuit failure. | PCM | Information not available. Refer to PINPOINT TEST A in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P0756 | Shift Solenoid B functional failure. | PCM | Information not available. Refer to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P0758 | SSB solenoid circuit failure. | PCM | Refer to PINPOINT TEST A in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P0760 | SSC solenoid circuit failure. | PCM | Refer to PINPOINT TEST A in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P0761 | Shift solenoid C functional failure. | PCM | Information not available. Refer to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P0763 | SSC solenoid circuit failure. | PCM | Refer to PINPOINT TEST A in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P1112 | IAT sensor or circuit signal intermittent. | PCM | Refer to A: Intake Air Temperature (IAT) Sensor STEP DA7 SELF-TEST DTCS P0112, P0113, P0114 OR P1112: INTERMITTENT CHECK in Pinpoint Tests - CNG, Flex-Fuel & Gasoline article. |
| P1117 | ECT sensor or circuit signal intermittent. | PCM | Refer to L: Cylinder Head Temperature (CHT) Sensor STEP DL15 DTCS P0117, P0118, P0119, P1117, P1289 OR P1290: INTERMITTENT CHECK in Pinpoint Tests - CNG, Flex-Fuel & Gasoline article. |
| P1700 | LOW OWC | PCM | Refer to DIAGNOSIS BY SYMPTOM in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P1702 | Digital TR sensor. | PCM | Refer to PINPOINT TEST D in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P1704 | Digital TR sensor. | PCM | Information not available. Refer to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P1705 | Digital TR sensor. | PCM | Refer to PINPOINT TEST D in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P1711 | TFT out of on-board diagnostic range. | PCM | Refer to PINPOINT TEST B in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P1713 | No change in TFT - low range. | PCM | Information not available. Refer to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P1714 | SSA failure. | PCM | Refer to PINPOINT TEST H in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P1715 | SSB failure. | PCM | Refer to PINPOINT TEST H in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P1716 | SSB failure. | PCM | Refer to PINPOINT TEST H in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P1718 | No change in TFT - high range. | PCM | Information not available. Refer to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P1740 | TCC failure. | PCM | Refer to PINPOINT TEST C in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P1741 | Continuous slip ERROR. | PCM | Information not available. Refer to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P1742 | TCC Solenoid Failed ON. | PCM | Refer to PINPOINT TEST C in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P1743 | TCC Solenoid Failed ON. | PCM | Refer to PINPOINT TEST C in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P1744 | Excessive slip detected. | PCM | Refer to PINPOINT TEST C in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P1746 | EPC | PCM | Information not available. Refer to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P1747 | EPC solenoid circuit failure, shorted circuit or output driver. | PCM | Refer to PINPOINT TEST E in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P1751 | Shift solenoid A functional failure. | PCM | Information not available. Refer to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P1756 | Shift solenoid B functional failure. | PCM | Information not available. Refer to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P1760 | EPC solenoid circuit failure, shorted circuit or output driver. | PCM | Information not available. Refer to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P1761 | Shift solenoid C functional failure. | PCM | Information not available. Refer to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P1779 | Check Transaxle Lamp | PCM | Information not available. Refer to AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P1783 | Transaxle overtemp condition indicated (300°F). | PCM | Refer to PINPOINT TEST B in AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N article. |
| P1882 | Engine Coolant Level Switch Circuit Short to Ground | SJB | Information not available. REFER to ENGINE COOLING article. |
| U0002 | High Speed CAN Communication Bus Performance | Instrument Cluster | Bus timeout occured. INSPECT high speed CAN wiring and instrument cluster connections, REFER to PINPOINT TEST A in INSTRUMENT CLUSTER article. |
| U0020 | Low Speed CAN Communication Bus Performance | Instrument Cluster | Bus timeout occured. INSPECT CAN wiring and instrument cluster connections. REFER to PINPOINT TEST A in INSTRUMENT CLUSTER article. |
| U0073 | Control Module Communication Bus Off | EATC | Information not available. REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0073 | Control Module Communication Bus Off | ABS Module | Information not available. REFER to MODULE COMMUNICATIONS NETWORK article. |
| U1900 | CAN Communication Bus Fault - Receive Error | Instrument Cluster | Information not available. REFER to MODULE COMMUNICATIONS NETWORK article. |
| U1900 | CAN Communication Bus Fault - Receive Error | ABS Module | Information not available. REFER to MODULE COMMUNICATIONS NETWORK article. |
| U1900 | CAN Communication Bus Fault - Recieve Error | SJB | Information not available. REFER to MODULE COMMUNICATIONS NETWORK article. |
| U1901 | CAN Network #2 Communication Bus Fault - Receive Error | Instrument Cluster | Information not available. REFER to MODULE COMMUNICATIONS NETWORK article. |
| U2006 | Audio Remote Climate Control Unit is Not Responding | EATC | REFER to PINPOINT TEST D CLIMATE CONTROL SYSTEM-GENERAL INFORMATION in article. |
| U2013 | Compass Module Not Responding | Instrument Cluster | REFER to PINPOINT TEST B in Information And Message Center - Sable & Taurus article. |
| U2023 | Fault Received From External Node | Instrument Cluster | Information not available. REFER to MODULE COMMUNICATIONS NETWORK article. |
| U2023 | Fault Received From External Node | ABS Module | Information not available. REFER to MODULE COMMUNICATIONS NETWORK article. |
DIAGNOSTIC TROUBLE CODE (DTC) INDEX
Scheme 32
Scheme 33
Scheme 34
Scheme 35
Scheme 36
Scheme 37
- Disconnect the battery. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-212128) .
- Disconnect the bulkhead connectors from the smart junction box (SJB).
- Disconnect the connectors from the bottom of the SJB.
- Remove the SJB. Remove the retaining nuts. Unclip and remove the SJB.
- To install, reverse the removal procedure.
