Automatic Transmission External Controls: Specifications Ford Taurus IV facelift

Torque Specifications Chart (1 Of 2)

Torque Specifications Chart (1 Of 2)

Torque Specifications Chart (2 Of 2)

Torque Specifications Chart (2 Of 2)

Scheme 799

Scheme 800

Scheme 801

The transaxle shift control linkage consists of

1. A steering column or floor-mounted transaxle range selector lever.
2. A shift cable connecting the steering column to the transaxle range selector lever.
3. An ignition/shifter interlock cable on floor shift vehicles which connects the transaxle range selector lever to the steering column lock assembly.
4. An ignition/shift interlock actuator that is integral to the ignition/shift interlock cable. The ignition/shifter interlock cable
5. Locks the transaxle range selector lever in the PARK position when the ignition switch is in the LOCK position.
6. Requires the transaxle range selector lever to be in the PARK position to turn the ignition switch to the LOCK position.

Refer to SYSTEM WIRING DIAGRAMS (Taurus) or SYSTEM WIRING DIAGRAMS (Sable) for schematic and connector information.

Scheme 802

Scheme 803

1. Verify the customer concern by operating the system.
2. Visually inspect for obvious signs of mechanical or electrical damage.
3. If an obvious cause for an observed or reported concern is found, correct the cause before proceeding to the next step.
4. If the concern is not visually evident, verify the symptom. GO to «SYMPTOM CHART»(ref-212112-S03532876412005122300000).

Scheme 804

Scheme 805

Scheme 806

Scheme 807

Scheme 808

Scheme 809

Scheme 810

Scheme 811
