Automatic Transmission External Controls: Adjustments Ford Taurus IV facelift

Automatic Trans 12 illustrations ~261 words

Selector Lever Cable Adjustment - Floor Shift

Note. The shift control cable adjustment procedure must be performed in the order shown.

Scheme 812

Scheme 812: Selector Lever Cable Adjustment - Floor Shift

Scheme 813

Scheme 813
  1. Position the transaxle range selector lever in OVERDRIVE.
  2. Loosen the manual control lever-to-shift control cable nut.
  3. Position the manual control lever in OVERDRIVE. Tighten the nut.
  4. Check the operation of the transaxle in each transaxle range selector lever position.

Selector Lever Cable Adjustment - Column Shift

Note. The shift control adjustment procedure must be performed in the order shown.

Scheme 814

Scheme 814: Selector Lever Cable Adjustment - Column Shift

Scheme 815

Scheme 815
  1. Position the transaxle range selector lever in OVERDRIVE. Hang a 1.4 kg (3 lb) weight on the lever.
  2. Loosen the manual control lever-to-shift control cable nut.
  3. Position the manual control lever in OVERDRIVE. Tighten the manual control lever-to-shift control cable nut.
  4. Remove the 1.4 kg (3 lb) weight. Check the operation of the transaxle in each transaxle range selector lever position.

Scheme 816

Scheme 816: Removal

Scheme 817

Scheme 817

Scheme 818

Scheme 818

Scheme 819

Scheme 819

Scheme 820

Scheme 820

Scheme 821

Scheme 821

Scheme 822

Scheme 822

Scheme 823

Scheme 823
  1. Remove the center console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-212149) .
  2. Remove the ignition/shifter interlock cable from the floor shift. Disconnect the cable from the bracket. Disconnect the cable from the shift cam.
  3. Remove the LH lower instrument panel trim.
  4. Disconnect four electrical connectors.
  5. Remove the steering column support bracket. Remove the diagnostic electrical connector bolts. Remove the steering column support bracket bolts.
  6. Remove the nuts and lower the steering column.
  7. Disconnect the shift interlock electrical connector.
  8. Remove the bolts.
  9. Remove the ignition/shifter interlock cable and actuator assembly.
