Automatic Transmission Cooling: Diagnosis Ford Taurus IV facelift

Automatic Trans 18 illustrations ~495 words

Inspection and Verification

  1. Verify the customer's concern by operating the vehicle to duplicate the condition.
  2. If the inspection reveals obvious concern(s) that can be readily identified, repair as necessary.
  3. Install new components if a fluid leak is found in any of the transaxle cooling components.
  4. If the concern(s) remains after the inspection, determine the symptom(s). GO to «SYMPTOM CHART»(ref-212111-S04795208712005122300000) .

Scheme 781

Scheme 781: Symptom Chart

Scheme 782

Scheme 782

Scheme 783

Scheme 783: Removal and Installation

Scheme 784

Scheme 784

Scheme 785

Scheme 785
  1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-207576) .
  2. Remove the splash shield. Remove the five screws and air deflector, if equipped. Remove the remaining seven screws and the splash shield.
  3. Disengage the clamps and remove the transmission fluid cooler hoses and the power steering fluid cooler hoses.
  4. Remove the bolts and the combination fluid cooler.
  5. To install, reverse the removal procedure. Fill the transaxle to the specified level. For additional information, refer to «AUTOMATIC TRANSAXLE/TRANSMISSION - 4F50N»(ref-212110) . Fill and purge the power steering system of air. For additional information, refer to «STEERING SYSTEM-GENERAL INFORMATION»(ref-212093) .

Scheme 786

Scheme 786: Special Tool(s)

Scheme 787

Scheme 787: Removal and Installation

Scheme 788

Scheme 788

Scheme 789

Scheme 789

Scheme 790

Scheme 790

Scheme 791

Scheme 791

Scheme 792

Scheme 792

Scheme 793

Scheme 793

Scheme 794

Scheme 794

Scheme 795

Scheme 795

Scheme 796

Scheme 796

Scheme 797

Scheme 797

Scheme 798
