Audio Unit System: Component Locations Ford Taurus IV рестайлинг

Special Tool(s)

SPECIAL TOOL SPECIFICATIONS Radio Removing Tool 415-001 (T87P-19061-A)

Scheme 1

Scheme 2

1. Using the special tool, pull the integrated control panel (ICP) out of the instrument panel.
2. Remove the ICP. Disconnect the electrical connectors.
3. To install, reverse the removal procedure.

Scheme 3

1. Remove the LH luggage compartment trim panel.
2. Disconnect the wiring connectors and the antenna lead in cable from the audio unit.
3. Remove the retaining nuts and remove the audio unit.
4. To install, reverse the removal procedure.

Scheme 4

1. Remove the LH spare tire trim panel.
2. Remove the spare tire.
3. Disconnect the wiring connectors and the antenna lead-in cable.
4. Remove the audio unit. Remove the 2 retaining screws. Remove the retaining nut. Remove the audio unit.
5. To install, reverse the removal procedure.
