Antenna System: Removal & Installation Ford Taurus IV рестайлинг

Removal and Installation

Wagon only

Scheme 73

Scheme 74

1. Remove the LH spare tire trim panel and the spare tire.
2. Disconnect the antenna lead-in cable from the audio unit. Sedan only
3. Remove the LH luggage compartment trim panel.
4. Disconnect the antenna lead-in cable from the audio unit. All vehicles
5. Remove the antenna mast.
6. Remove and discard the antenna base nut.
7. Remove the nut and bolt from the antenna base bracket.
8. Remove the antenna base and the antenna lead-in cable.
9. To install, reverse the removal procedure. Transfer the parts as necessary. Install a new antenna base nut.

Scheme 75

Scheme 76

Scheme 77

1. Remove the audio unit. For additional information, refer to «AUDIO UNIT»(ref-233752) .
2. Remove the antenna mast nut and stanchion.
3. Remove the nut and the bolt from inside the vehicle.
4. Lower the power antenna out from behind the quarter panel.
5. Disconnect the pin-type retainer for the lead-in cable.
6. Disconnect the electrical connector and lead-in cable and remove the antenna assembly.
7. To install, reverse the removal procedure.
