TORQUE SPECIFICATIONS TABLE
| Description | Nm |
|---|---|
| Smart junction box (SJB) bracket nuts | 5 |
TORQUE SPECIFICATIONS TABLE
Module Controlled Functions
Note. The smart junction box (SJB) is also known as the generic electronic module (GEM).
The vehicle is equipped with a SJB and a driver seat module (DSM).
Smart Junction Box (SJB)
Note. The time out for the battery saver relay and the accessory delay relay (both are controlled by the SJB) is 1 minute if the vehicle has less than 80 km (50 miles). Once the vehicle passes the approximate mileage threshold of 80 km (50 miles), the time out for both relays will be the normal 10 minute time out, as described by the Owner's Literature. For the battery saver relay, Refer to INTERIOR LIGHTING article. For the accessory delay relay, refer to GLASS, FRAMES AND MECHANISMS article.
The SJB is a combination of a multifunction control module and a central junction box (CJB). The following systems are controlled by the SJB
- Accessory delay relay
- Battery saver relay
- Exterior lighting
- Interior lighting
- Heated rear window
- Horn
- Perimeter anti-theft
- Power door locks (including smart locks, autolocking and liftgate/luggage compartment lid release)
- Remote keyless entry (RKE)/keyless entry keypad
- Tire pressure monitoring system (TPMS)
Driver Seat Module (DSM)
The DSM controls the user selected comfort functions. These functions are the memory seat, memory mirrors and memory pedals. Up to 2 personal settings can be programmed into the DSM memory and when selected, the DSM returns the user adjustable features to the programmed positions. For additional information on programming the memory feature, refer to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article.
Diagnostic Trouble Code (DTC) Table
Note. Most powertrain (P-code) DTCs are diagnosed in the Powertrain Control/Emissions Diagnosis (PC/ED). If the P-code retrieved is not listed below, refer to the Introduction - Gasoline Engines article to continue diagnostics.
Note. The smart junction box (SJB) is also known as the generic electronic module (GEM).
| DTC | Description | Source | Action |
|---|---|---|---|
| B1003 | Mode Door Circuit Failure | Heating Ventilation Air Conditioning (HVAC) Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS article. |
| B1010 | Parking Aid Module Switch Not Connected | Parking Aid Module (PAM) | REFER to PARKING AID article. |
| B1031 | SDARS Satellite Antenna Open | Satellite Digital Audio Receiver System (SDARS) Module | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B1032 | SDARS Satellite Antenna Short | SDARS Module | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B1038 | Microphone Input Circuit Failure | Accessory Protocol Interface Module (APIM) | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B1046 | Driver Side Airbag Curtain Cross Link to Another Firing Loop | Restraints Control Module (RCM) | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B1047 | Driver Side, Side Mount Airbag Cross Link to Another Firing Loop | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B1048 | Passenger Side Airbag Cross Link to Another Firing Loop | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B1049 | Passenger Seatbelt Pretensioner Cross Link to Another Firing Loop | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B1054 | Driver Seatbelt Pretensioner Cross Link to Another Firing Loop | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B1055 | Passenger Side, Side Mount Airbag Cross Link to Another Firing Loop | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B1056 | Passenger Side Airbag Curtain Cross Link to Another Firing Loop | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B1057 | Driver Airbag Cross Link to Another Firing Loop | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B1058 | Driver Airbag Cross Link to Another Firing Loop - Loop #2 | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B1059 | Passenger Airbag cross link to another firing loop - Loop #2 | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B105D | Deployable Steering Column Cross Link to Another Firing Loop | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B1065 | Radio Volume Cutback Circuit Short to Battery | PAM | REFER to PARKING AID article. |
| B1066 | Radio Volume Cutback Circuit Failure | PAM | REFER to PARKING AID article. |
| B106A | TPMS Sensor Pressure Range Bit Incorrect State | SJB | REFER to WHEELS AND TIRES article. |
| B106B | Tire Pressure Sensor Low Battery | SJB | REFER to WHEELS AND TIRES article. |
| B106D | Tire Pressure Monitor System (TPMS) Initiators Not Configured | SJB | DTC B106D is only present when a new SJB is installed, the SJB is reprogrammed, or the SJB is reconfigured. REFER to MODULE COMMUNICATIONS NETWORK article to CARRY OUT the programmable module installation (PMI) procedure in order to CLEAR this DTC. |
| B106E | Solid State Driver Disabled Due to Short Circuit | Driver Seat Module (DSM) | REFER to Driver Seat Module (DSM) . |
| B106E | Solid State Driver Disabled Due to Short Circuit | LTM | REFER to BODY CLOSURES article. |
| B106E | Solid State Driver Disabled Due to Short Circuit | SJB | REFER to Smart Junction Box (SJB) . |
| B106F | Module Disabled Due to External Fault | DSM | REFER to Driver Seat Module (DSM) . |
| B106F | Module Disabled Due to External Fault | LTM | REFER to BODY CLOSURES article. |
| B106F | Module Disabled Due to External Fault | SJB | REFER to Smart Junction Box (SJB) . |
| B107D | Obstacle Detected While Closing | LTM | REFER to BODY CLOSURES article. |
| B1085 | Restraint System - Seatbelt Load Limiter Status | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B1105 | Rear Open/Close Switch Active During Self Test | LTM | REFER to BODY CLOSURES article. |
| B1117 | Audio Steering Wheel Button Stuck | Audio Control Module (ACM) | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B1117 | Audio Steering Wheel Button Stuck | APIM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B1119 | Audio Disc DVD Player Thermal Shutdown | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B1119 | Audio Disc DVD Player Thermal Shutdown | Rear Entertainment Module (RETM) | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B111F | LCD Thermal Shutdown | RETM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B1136 | Audio Steering Wheel Switch #2 Circuit Failure | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B1136 | Audio Steering Wheel Switch #2 Circuit Failure | APIM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B1137 | Data Not Programmed | Instrument Cluster (IC) | REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) article. |
| B1138 | Memory Full | IC | The SJB has 4 IKTs stored in memory and cannot program any more IKTs into the SJB memory. REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) article. |
| B1138 | Memory Full | SJB | The SJB has 4 IKTs stored in memory and cannot program any more IKTs into the SJB memory. REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) article. |
| B1139 | Invalid Transmitter Identification Code | IC | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article. |
| B1139 | Invalid Transmitter Identification Code | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article. |
| B1140 | Map Disk Invalid | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B1154 | Subwoofer #1 Short to Ground | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B1155 | Subwoofer #1 Short to Battery | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B1158 | Subwoofer #2 Open | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B1179 | Latch Motor Circuit Short to Battery | LTM | REFER to BODY CLOSURES article. |
| B117A | Latch Motor Circuit Short to Ground | LTM | REFER to BODY CLOSURES article. |
| B117B | Latch Motor Circuit Open | LTM | REFER to BODY CLOSURES article. |
| B117C | Latch Centering Switch Invalid | LTM | REFER to BODY CLOSURES article. |
| B1200 | Climate Control Pushbutton Circuit Failure | HVAC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS article. |
| B1202 | Fuel Sender Circuit Open | IC | REFER to INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES article. |
| B1204 | Fuel Sender Circuit Short to Ground | IC | REFER to INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES article. |
| B1205 | EIC Switch-1 Assembly Circuit Failure | IC | REFER to INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES article. |
| B1213 | Anti-Theft Number of Programmed Keys is Below Minimum | IC | REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) article. |
| B1231 | Event Threshold Exceeded | Occupant Classification System Module (OCSM) | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B1231 | Event Threshold Exceeded | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B1242 | Air Flow Recirculation Door Driver Circuit Failure | HVAC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS article. |
| B1251 | Air Temperature Internal Sensor Circuit Open | HVAC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS article. |
| B1253 | Air Temperature Internal Sensor Circuit Short to Ground | HVAC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS article. |
| B1255 | Air Temperature External Sensor Circuit Open | HVAC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS article. |
| B1257 | Air Temperature External Sensor Circuit Short to Ground | HVAC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS article. |
| B1299 | Power Supply Sensor Circuit Short to Ground | PAM | REFER to PARKING AID article. |
| B1302 | Accessory Delay Relay Coil Circuit Failure | SJB | REFER to GLASS, FRAMES AND MECHANISMS article. |
| B1304 | Accessory Delay Relay Coil Circuit Short to Battery | SJB | REFER to GLASS, FRAMES AND MECHANISMS article. |
| B1317 | Battery Voltage High | 4X4 Control Module | REFER to CHARGING SYSTEM - GENERAL INFORMATION article. |
| B1317 | Battery Voltage High | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B1317 | Battery Voltage High | APIM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B1317 | Battery Voltage High | DSM | REFER to CHARGING SYSTEM - GENERAL INFORMATION article. |
| B1317 | Battery Voltage High | HVAC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS article. |
| B1317 | Battery Voltage High | IC | REFER to CHARGING SYSTEM - GENERAL INFORMATION article. |
| B1317 | Battery Voltage High | LTM | REFER to CHARGING SYSTEM - GENERAL INFORMATION article. |
| B1317 | Battery Voltage High | OCSM | REFER to CHARGING SYSTEM - GENERAL INFORMATION article. |
| B1317 | Battery Voltage High | Power Steering Control Module (PSCM) | REFER to STEERING SYSTEM - GENERAL INFORMATION article. |
| B1317 | Battery Voltage High | RCM | REFER to CHARGING SYSTEM - GENERAL INFORMATION article. |
| B1317 | Battery Voltage High | RETM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B1317 | Battery Voltage High | SJB | REFER to CHARGING SYSTEM - GENERAL INFORMATION article. |
| B1318 | Battery Voltage Low | 4X4 Control Module | REFER to CHARGING SYSTEM - GENERAL INFORMATION article. |
| B1318 | Battery Voltage Low | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B1318 | Battery Voltage Low | APIM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B1318 | Battery Voltage Low | DSM | REFER to CHARGING SYSTEM - GENERAL INFORMATION article. |
| B1318 | Battery Voltage Low | HVAC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS article. |
| B1318 | Battery Voltage Low | IC | REFER to CHARGING SYSTEM - GENERAL INFORMATION article. |
| B1318 | Battery Voltage Low | LTM | REFER to CHARGING SYSTEM - GENERAL INFORMATION article. |
| B1318 | Battery Voltage Low | OCSM | REFER to CHARGING SYSTEM - GENERAL INFORMATION article. |
| B1318 | Battery Voltage Low | PSCM | REFER to STEERING SYSTEM - GENERAL INFORMATION article. |
| B1318 | Battery Voltage Low | RCM | REFER to CHARGING SYSTEM - GENERAL INFORMATION article. |
| B1318 | Battery Voltage Low | RETM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B1318 | Battery Voltage Low | SDARS Module | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B1318 | Battery Voltage Low | SJB | REFER to CHARGING SYSTEM - GENERAL INFORMATION article. |
| B1320 | Driver Door Ajar Circuit Open | SJB | REFER to INTERIOR LIGHTING article. |
| B1328 | Passenger Door Ajar Circuit Open | SJB | REFER to INTERIOR LIGHTING article. |
| B1331 | Decklid Ajar Rear Door Circuit Failure | SJB | REFER to INTERIOR LIGHTING article. |
| B1336 | Door Ajar RR Circuit Open | SJB | REFER to INTERIOR LIGHTING article. |
| B1342 | ECU is Faulted | 4X4 Control Module | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new 4X4 control module. REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS article. TEST the system for normal operation. |
| B1342 | ECU is Faulted | ABS Module | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new ABS module. REFER to VEHICLE DYNAMIC SYSTEMS article. TEST the system for normal operation. |
| B1342 | ECU is Faulted | ACM | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new ACM. REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. TEST the system for normal operation. |
| B1342 | ECU is Faulted | APIM | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new APIM. REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. TEST the system for normal operation. |
| B1342 | ECU is Faulted | DSM | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new DSM. REFER to Driver Seat Module (DSM) . TEST the system for normal operation. |
| B1342 | ECU is Faulted | HVAC Module | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new automatic HVAC Module. REFER to CLIMATE CONTROL article. TEST the system for normal operation. |
| B1342 | ECU is Faulted | IC | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new IC. REFER to INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES article. TEST the system for normal operation. |
| B1342 | ECU is Faulted | LTM | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new LTM. REFER to BODY CLOSURES article. TEST the system for normal operation. |
| B1342 | ECU is Faulted | OCSM | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new OCSM. REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. TEST the system for normal operation. |
| B1342 | ECU is Faulted | PAM | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new PAM. REFER to PARKING AID article. TEST the system for normal operation. |
| B1342 | ECU is Faulted | PCM | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new PCM. REFER to ELECTRONIC ENGINE CONTROLS article. TEST the system for normal operation. |
| B1342 | ECU is Faulted | PSCM | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new PSCM. REFER to POWER STEERING article. TEST the system for normal operation. |
| B1342 | ECU is Faulted | RCM | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new RCM. REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. TEST the system for normal operation. |
| B1342 | ECU is Faulted | RETM | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new RETM. REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. TEST the system for normal operation. |
| B1342 | ECU is Faulted | SDARS Module | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new SDARS module. REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. TEST the system for normal operation. |
| B1342 | ECU is Faulted | SJB | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new SJB. REFER to Smart Junction Box (SJB) . TEST the system for normal operation. |
| B1352 | Ignition Key-In Circuit Failure | SJB | REFER to INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES article. |
| B1472 | Lamp Headlamp Input Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING article. |
| B1482 | Wiper Washer Fluid Level Sensor Circuit Short to Ground | IC | REFER to INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES article. |
| B1485 | Brake Pedal Input Short to Battery | SJB | REFER to EXTERIOR LIGHTING article. |
| B1510 | Flash to Pass Switch Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING article. |
| B1520 | Hood Switch Circuit Open | SJB | REFER to ANTI-THEFT - PERIMETER article. |
| B1530 | Memory Set Switch Circuit Short to Ground | DSM | REFER to SEATING article. |
| B1534 | Memory 1 Switch Circuit Short to Ground | DSM | REFER to SEATING article. |
| B1538 | Memory 2 Switch Circuit Short to Ground | DSM | REFER to SEATING article. |
| B1572 | Door Ajar LR Circuit Open | SJB | REFER to INTERIOR LIGHTING article. |
| B1578 | Lamp Park Input Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING article. |
| B1596 | Service Continuous Codes | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS article. |
| B1600 | PATS Ignition Key Transponder Signal is Not Received | IC | REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) article. |
| B1601 | PATS Received Incorrect Key-Code From Ignition Key Transponder | IC | REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) article. |
| B1602 | PATS Ignition Invalid Format of Key-Code From Ignition Key Transponder | IC | REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) article. |
| B1624 | Lamp Keypad Output Open Circuit | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article. |
| B1626 | Lamp Keypad Output Short Circuit to Ground | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article. |
| B1663 | Seat Driver Front Up/Down Motor Stalled | DSM | REFER to SEATING article. |
| B1664 | Seat Driver Rear Up/Down Motor Stalled | DSM | REFER to SEATING article. |
| B1665 | Seat Driver Forward/Backward Motor Stalled | DSM | REFER to SEATING article. |
| B1666 | Seat Driver Recline Motor Stalled | DSM | REFER to SEATING article. |
| B1667 | Mirror Driver Up/Down Motor Stalled | DSM | REFER to REAR VIEW MIRRORS article. |
| B1668 | Mirror Driver Right/Left Motor Stalled | DSM | REFER to REAR VIEW MIRRORS article. |
| B1669 | Mirror Passenger Up/Down Motor Stalled | DSM | REFER to REAR VIEW MIRRORS article. |
| B1670 | Mirror Passenger Right/Left Motor Stalled | DSM | REFER to REAR VIEW MIRRORS article. |
| B1676 | Battery Pack Voltage Out of Range | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS article. |
| B1681 | PATS Transceiver Module Signal is Not Received | IC | REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) article. |
| B1685 | Lamp Dome Input Circuit Failure | SJB | REFER to INTERIOR LIGHTING article. |
| B1688 | Lamp Dome Input Circuit Short to Ground | SJB | REFER to INTERIOR LIGHTING article. |
| B1696 | Autolamp On Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING article. |
| B1703 | Seat Driver Recline Forward Switch Circuit Short To Battery | DSM | REFER to SEATING article. |
| B1707 | Seat Driver Recline Rearward Switch Circuit Short To Battery | DSM | REFER to SEATING article. |
| B1711 | Seat Driver Front Up Switch Circuit Short to Battery | DSM | REFER to SEATING article. |
| B1715 | Seat Driver Front Down Switch Circuit Short to Battery | DSM | REFER to SEATING article. |
| B1719 | Seat Driver Forward Switch Circuit Short to Battery | DSM | REFER to SEATING article. |
| B1723 | Seat Driver Rearward Switch Circuit Short to Battery | DSM | REFER to SEATING article. |
| B1727 | Seat Driver Rear Up Switch Circuit Short to Battery | DSM | REFER to SEATING article. |
| B1731 | Seat Driver Rear Down Switch Circuit Short to Battery | DSM | REFER to SEATING article. |
| B1733 | Mirror Driver Vertical Switch Circuit Failure | DSM | REFER to REAR VIEW MIRRORS article. |
| B1737 | Mirror Driver Horizontal Switch Circuit Failure | DSM | REFER to REAR VIEW MIRRORS article. |
| B1741 | Mirror Passenger Vertical Switch Circuit Failure | DSM | REFER to REAR VIEW MIRRORS article. |
| B1745 | Mirror Passenger Horizontal Switch Circuit Failure | DSM | REFER to REAR VIEW MIRRORS article. |
| B1791 | Autolamp Sensor Input Circuit Open | SJB | REFER to EXTERIOR LIGHTING article. |
| B1793 | Autolamp Sensor Input Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING article. |
| B1868 | Lamp Air Bag Warning Indicator Circuit Failure | IC | CLEAR the DTCs. REPEAT the self-test. If DTC B1868 is retrieved again, INSTALL a new IC. REFER to INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES article. TEST the system for normal operation. |
| B1884 | PAD Warning Lamp Circuit Failure | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B1890 | PAD Warning Lamp Circuit Short to Battery | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B1952 | Seat Rear Up/Down Position Feedback Circuit Short to Battery | DSM | REFER to SEATING article. |
| B1953 | Seat Rear Up/Down Position Feedback Circuit Short to Ground | DSM | REFER to SEATING article. |
| B1956 | Seat Front Up/Down Position Feedback Circuit Short to Battery | DSM | REFER to SEATING article. |
| B1957 | Seat Front Up/Down Position Feedback Circuit Short to Ground | DSM | REFER to SEATING article. |
| B1960 | Seat Recline Forward/Backward Feedback Circuit Short to Battery | DSM | REFER to SEATING article. |
| B1961 | Seat Recline Forward/Backward Position Feedback Circuit Short to Ground | DSM | REFER to SEATING article. |
| B1964 | Seat Horizontal Forward/Rearward Position Feedback Circuit Short to Battery | DSM | REFER to SEATING article. |
| B1965 | Seat Horizontal Forward/Rearward Position Feedback Circuit Short to Ground | DSM | REFER to SEATING article. |
| B1987 | Pedal Forward/Rearward Motor Stalled | DSM | REFER to BRAKE SYSTEM - GENERAL INFORMATION article. |
| B1988 | Pedal Position Forward Switch Circuit Short to Battery | DSM | REFER to BRAKE SYSTEM - GENERAL INFORMATION article. |
| B1989 | Pedal Position Rearward Switch Circuit Short to Battery | DSM | REFER to BRAKE SYSTEM - GENERAL INFORMATION article. |
| B1991 | Pedal Forward / Rearward Potentiometer Feedback Circuit Short to Battery | DSM | REFER to BRAKE SYSTEM - GENERAL INFORMATION article. |
| B2008 | Wipers On Signal Circuit Short to Ground | SJB | REFER to WIPERS AND WASHERS article. |
| B2019 | Liftgate Exceeded Time Allowed to Cinch Door | LTM | REFER to BODY CLOSURES article. |
| B201A | Power System Disabled Due to High Manual Closing Speed | LTM | REFER to BODY CLOSURES article. |
| B2031 | Left Corner Lamp Output Circuit Failure | SJB | REFER to EXTERIOR LIGHTING article. |
| B2032 | Right Corner Lamp Output Circuit Failure | SJB | REFER to EXTERIOR LIGHTING article. |
| B2044 | Left Rear Stop Lamp Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING article. |
| B2045 | Left Rear Stop Lamp Circuit Open | SJB | REFER to EXTERIOR LIGHTING article. |
| B2046 | Right Rear Stop Lamp Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING article. |
| B2047 | Right Rear Stop Lamp Circuit Open | SJB | REFER to EXTERIOR LIGHTING article. |
| B2048 | Left Rear Turn Lamp Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING article. |
| B2049 | Left Rear Turn Lamp Circuit Open | SJB | REFER to EXTERIOR LIGHTING article. |
| B2050 | Right Rear Turn Lamp Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING article. |
| B2051 | Right Rear Turn Lamp Circuit Open | SJB | REFER to EXTERIOR LIGHTING article. |
| B2071 | Hazard Switch Signal Short to Ground | SJB | REFER to EXTERIOR LIGHTING article. |
| B2077 | Liftgate Ajar Sw Circuit Failure | SJB | REFER to INTERIOR LIGHTING article. |
| B2084 | Memory Set Indicator Short to Ground | DSM | REFER to SEATING article. |
| B2097 | Compass Module Failure | IC | REFER to INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES article. |
| B2100 | Door Driver Key Cylinder Switch Failure | SJB | REFER to ANTI-THEFT - PERIMETER article. |
| B2103 | Antenna Not Connected | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B2103 | Antenna Not Connected | IC | REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) article. |
| B2108 | Trunk Key Cylinder Switch Failure | SJB | The DTC is not applicable. The vehicle is not equipped with a trunk key cylinder switch. CLEAR the DTCs. REPEAT the self-test. |
| B2141 | NVM Configuration Failure | IC | REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) article. |
| B2143 | NVM Memory Failure | IC | CLEAR the DTCs. REPEAT the self-test. If DTC B2143 is retrieved again, INSTALL a new IC. REFER to INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES article. TEST the system for normal operation. |
| B2204 | GPS Antenna Connection Open or Short | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B2212 | Panel Dim Switch Out of Range | SJB | REFER to INTERIOR LIGHTING article. |
| B2223 | Mirror Driver Drive Circuit Failure | DSM | REFER to REAR VIEW MIRRORS article. |
| B2224 | Mirror Passenger Drive Circuit Failure | DSM | REFER to REAR VIEW MIRRORS article. |
| B2254 | Front Fog Lamp Switch Failure | SJB | REFER to EXTERIOR LIGHTING article. |
| B2266 | Left Side Blend Door Circuit Failure | HVAC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS article. |
| B2267 | Right Side Blend Door Circuit Failure | HVAC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS article. |
| B2274 | Phone Transceiver Active Circuit Failure | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B2275 | Pedal Forward/Rearward Pot. Feedback Ckt. Short to GND | DSM | REFER to BRAKE SYSTEM - GENERAL INFORMATION article. |
| B2276 | Less Than 2 Transmitters Programmed | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article. |
| B2281 | Right Turn Switch Short to Ground | SJB | REFER to EXTERIOR LIGHTING article. |
| B2282 | Left Turn Switch Short to Ground | SJB | REFER to EXTERIOR LIGHTING article. |
| B2290 | Occupant Classification System Fault | OCSM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B2290 | Occupant Classification System Fault | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B2292 | Restraint System - Seatbelt Pretensioner Fault | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B2293 | Restraint System - Airbag Fault | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B2294 | Restraint System - Curtain Fault | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B2295 | Restraint System - Side Airbag Fault | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B2296 | Restraint System - Impact Sensor Fault | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B2312 | Mirror Passenger Horizontal Feedback Potentiometer Circuit Failure | DSM | REFER to REAR VIEW MIRRORS article. |
| B2314 | Mirror Passenger Horizontal Feedback Potentiometer Circuit Short to Battery | DSM | REFER to REAR VIEW MIRRORS article. |
| B2316 | Mirror Passenger Vertical Feedback Potentiometer Circuit Failure | DSM | REFER to REAR VIEW MIRRORS article. |
| B2318 | Mirror Passenger Vertical Feedback Potentiometer Circuit Short to Battery | DSM | REFER to REAR VIEW MIRRORS article. |
| B2320 | Mirror Driver Horizontal Feedback Potentiometer Circuit Failure | DSM | REFER to REAR VIEW MIRRORS article. |
| B2322 | Mirror Driver Horizontal Feedback Potentiometer Circuit Short to Battery | DSM | REFER to REAR VIEW MIRRORS article. |
| B2324 | Mirror Driver Vertical Feedback Potentiometer Circuit Failure | DSM | REFER to REAR VIEW MIRRORS article. |
| B2326 | Mirror Driver Vertical Feedback Potentiometer Circuit Short to Battery | DSM | REFER to REAR VIEW MIRRORS article. |
| B236A | Chime Output Circuit Open | LTM | REFER to BODY CLOSURES article. |
| B2373 | LED #1 Circuit Short to Battery | PAM | REFER to PARKING AID article. |
| B2384 | Audio Reverse Aid Mute Input Ckt. Failure | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B2404 | Audio Steering Wheel Switch Circuit Fault | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B2405 | Audio Disc CD Player Thermal Shutdown Fault | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B2406 | Audio Disc CD Player Internal Fault | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B2418 | Sensor Power Short to Ground | LTM | REFER to BODY CLOSURES article. |
| B2419 | Sensor 1 Invalid | LTM | REFER to BODY CLOSURES article. |
| B2420 | Sensor 2 Invalid | LTM | REFER to BODY CLOSURES article. |
| B2425 | Remote Keyless Entry Out of Synchronization | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article. |
| B2426 | Passenger Solar Radiation Sensor Circuit Open | HVAC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS article. |
| B2427 | Passenger Solar Radiation Sensor Circuit Short to Ground | HVAC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS article. |
| B2431 | Transponder Programming Failed | IC | VERIFY if the correct PATS key is being used. If the PATS key is defective, use a new key for programming. REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) article. TEST the system for normal operation. |
| B2434 | Drivers Seat Belt Buckle Switch Circuit Short to Ground | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B2435 | Drivers Seat Belt Buckle Switch Resistance Out of Range | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B2438 | Passengers Seat Belt Buckle Switch Circuit Short to Ground | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B2439 | Passengers Seat Belt Buckle Switch Resistance Out of Range | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B2477 | Module Configuration Failure | ABS Module | REFER to MODULE CONFIGURATION article. |
| B2477 | Module Configuration Failure | ACM | REFER to MODULE CONFIGURATION article. |
| B2477 | Module Configuration Failure | APIM | REFER to MODULE CONFIGURATION article. |
| B2477 | Module Configuration Failure | DSM | REFER to MODULE CONFIGURATION article. |
| B2477 | Module Configuration Failure | IC | REFER to MODULE CONFIGURATION article. |
| B2477 | Module Configuration Failure | PAM | REFER to MODULE CONFIGURATION article. |
| B2477 | Module Configuration Failure | PSCM | REFER to MODULE CONFIGURATION article. |
| B2477 | Module Configuration Failure | RCM | REFER to MODULE CONFIGURATION article. |
| B2477 | Module Configuration Failure | RETM | REFER to MODULE CONFIGURATION article. |
| B2477 | Module Configuration Failure | SDARS Module | REFER to MODULE CONFIGURATION article. |
| B2477 | Module Configuration Failure | SJB | REFER to MODULE CONFIGURATION article. |
| B2479 | Park Brake Switch Circuit Short to Ground | SJB | REFER to INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES article. |
| B2498 | Headlamp Switch Multiple Signals Input Active | SJB | REFER to EXTERIOR LIGHTING article. |
| B2552 | Vbatt 2 Circuit Open | LTM | REFER to BODY CLOSURES article. |
| B2572 | Brake Shift Interlock Output Circuit Failure | SJB | REFER to STEERING COLUMN SWITCHES article. |
| B2627 | Fuel Sender Circuit Open #2 | IC | REFER to INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES article. |
| B2628 | Fuel Sender Circuit Short to Ground #2 | IC | REFER to INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES article. |
| B2633 | Driver-Front Microphone Circuit Failure | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B2656 | DVD (Digital Versatile Disk) Error | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B2656 | DVD (Digital Versatile Disk) Error | RETM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B2666 | Liftgate Release Switch Circuit Failure | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article. |
| B2667 | Liftglass Release Switch Circuit Failure | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article. |
| B2691 | Seat Belt Buckle Switch Circuit Fault, Front Driver's Side | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B2692 | Front Passenger's Seat Belt Buckle Switch Circuit Fault | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B2699 | Left Pinch Strip Open or Short to Battery | LTM | REFER to BODY CLOSURES article. |
| B2700 | Right Pinch Strip Open or Short to Battery | LTM | REFER to BODY CLOSURES article. |
| B2701 | Left Pinch Strip Stuck Active | LTM | REFER to BODY CLOSURES article. |
| B2702 | Right Pinch Strip Stuck Active | LTM | REFER to BODY CLOSURES article. |
| B2703 | Open/Close Switch Stuck Active | LTM | REFER to BODY CLOSURES article. |
| B2718 | Liftgate/Decklid Ajar Output Short to Battery | LTM | REFER to BODY CLOSURES article. |
| B2721 | Liftgate/Decklid Ajar Output Short to Ground or Open | LTM | REFER to BODY CLOSURES article. |
| B2723 | Glass Position Switch Active During Selftest | LTM | REFER to BODY CLOSURES article. |
| B273A | Liftgate Release Output Circuit Shorted to Ground | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article. |
| B273B | Liftgate Release Output Circuit Open or Shorted to Battery Voltage | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article. |
| B2794 | 3rd Row Power Fold Circuit Failure | SJB | REFER to SEATING article. |
| B2795 | Driver Solar Radiation Sensor Circuit Short to Ground | HVAC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS article. |
| B2796 | Driver Solar Radiation Sensor Circuit Open | HVAC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS article. |
| B2819 | Gate Motor Circuit Short to Battery | LTM | REFER to BODY CLOSURES article. |
| B2826 | Front Evaporator Temp Sensor Circuit Failure | HVAC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS article. |
| B2827 | Front Evaporator Temp Sensor Short to Ground | HVAC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS article. |
| B2844 | Ignition Fault | SJB | REFER to STEERING COLUMN SWITCHES article. |
| B2868 | Left Front Tire Pressure Sensor Fault | SJB | DTC B2868 is only present when a new SJB is installed, the SJB is flashed, or the SJB is reconfigured. REFER to WHEELS AND TIRES article to CARRY OUT TPMS sensor training in order to CLEAR the DTC. |
| B2869 | Right Front Tire Pressure Sensor Fault | SJB | DTC B2869 is only present when a new SJB is installed, the SJB is flashed, or the SJB is reconfigured. REFER to WHEELS AND TIRES article to CARRY OUT TPMS sensor training in order to CLEAR the DTC. |
| B2870 | Right Rear Tire Pressure Sensor Fault | SJB | DTC B2870 is only present when a new SJB is installed, the SJB is flashed, or the SJB is reconfigured. REFER to WHEELS AND TIRES article to CARRY OUT TPMS sensor training in order to CLEAR the DTC. |
| B2871 | Left Rear Tire Pressure Sensor Fault | SJB | DTC B2871 is only present when a new SJB is installed, the SJB is flashed, or the SJB is reconfigured. REFER to WHEELS AND TIRES article to CARRY OUT TPMS sensor training in order to CLEAR the DTC. |
| B2872 | Tire Pressure Sensor Fault | SJB | REFER to WHEELS AND TIRES article. |
| B2879 | Fuel Tank Jet Pump Fault | IC | REFER to INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES article. |
| B287A | Tire Pressure System Fault | SJB | REFER to WHEELS AND TIRES article. |
| B2900 | VIN Mismatch | 4X4 Control Module | CONFIGURE the 4X4 control module. REFER to MODULE CONFIGURATION article to carry out PMI. CLEAR the DTCs. REPEAT the self-test. If DTC B2900 is retrieved again, INSTALL a new 4X4 control module. REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS article. REPEAT the self-test. |
| B2900 | VIN Mismatch | ABS Module | VERIFY the ABS module and the PCM have the correct As-Built Data. REFER to Programmable Module Installation in MODULE CONFIGURATION article. |
| B2900 | VIN Mismatch | RCM | CONFIGURE the RCM. REFER to MODULE CONFIGURATION article to carry out PMI. CLEAR the DTCs. REPEAT the self-test. If DTC B2900 is retrieved again, INSTALL a new RCM. REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. REPEAT the self-test. |
| B2903 | Chime Output Circuit Short to Battery | LTM | REFER to BODY CLOSURES article. |
| B2908 | Latch Switch Invalid | LTM | REFER to BODY CLOSURES article. |
| B2909 | Belt Tension Sensor Fault | OCSM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B2913 | Audio Subwoofer Not Connected | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B2916 | Rear Blend Door Circuit Failure | HVAC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS article. |
| B2917 | Rear Mode Door Circuit Failure | HVAC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS article. |
| B2918 | Aux Temp Blend Input Circuit Failure | HVAC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS article. |
| B2919 | Aux Blower Motor Speed Input Circuit Failure | HVAC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS article. |
| B2924 | Audio Button Stuck | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B2924 | Audio Button Stuck | RETM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B2935 | Drive Unit Failure | LTM | REFER to BODY CLOSURES article. |
| B2936 | Gate Motor Open | LTM | REFER to BODY CLOSURES article. |
| B2937 | Gate Motor Short to Ground | LTM | REFER to BODY CLOSURES article. |
| B2939 | Gate Clutch Short to Ground or Open | LTM | REFER to BODY CLOSURES article. |
| B2940 | Chime Output Circuit Short to Ground | LTM | REFER to BODY CLOSURES article. |
| B2965 | Audio System Speaker Circuit Fault | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| B2984 | Deployable Steering Column Circuit Open | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B2985 | Deployable Steering Column Circuit Short to Battery | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B2986 | Deployable Steering Column Circuit Short to Ground | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B2987 | Deployable Steering Column Circuit Resistance Low on Squib | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B29B7 | White Lighting Output Circuit Open | SJB | REFER to INTERIOR LIGHTING article. |
| B29B8 | White Lighting Output Circuit Short to Ground | SJB | REFER to INTERIOR LIGHTING article. |
| B2A20 | Ignition Stuck in START | IC | REFER to INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES article. |
| B2A20 | Ignition Stuck in START | SJB | REFER to STEERING COLUMN SWITCHES article. |
| B2A21 | One or More Configuration Files Missing or Corrupt | SJB | REFER to MODULE CONFIGURATION article. |
| B2A22 | Headlamp OFF Circuit Open | SJB | REFER to EXTERIOR LIGHTING article. |
| B2A23 | High Beam Input Circuit Short To Ground | SJB | REFER to EXTERIOR LIGHTING article. |
| B2A24 | Turn Signal Input Circuit Failure | SJB | REFER to EXTERIOR LIGHTING article. |
| B2A25 | Trim Panel Lock Switch Circuit Failure | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article. |
| B2A26 | Keypad Switch Circuit Failure | SJB | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article. |
| B2A27 | Right Front Turn Lamp Circuit Open | SJB | REFER to EXTERIOR LIGHTING article. |
| B2A28 | Right Front Turn Lamp Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING article. |
| B2A29 | Left Front Turn Lamp Circuit Open | SJB | REFER to EXTERIOR LIGHTING article. |
| B2A2A | Left Front Turn Lamp Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING article. |
| B2A2B | Left Corner Lamp Output Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING article. |
| B2A2C | Right Corner Lamp Output Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING article. |
| B2A2D | 3rd Row Power Fold Circuit Short to Ground | SJB | REFER to SEATING article. |
| B2A2E | Right Front Lamp Low Beam Circuit Open | SJB | REFER to EXTERIOR LIGHTING article. |
| B2A2F | Right Front Lamp Low Beam Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING article. |
| B2A30 | Left Front Lamp Low Beam Circuit Open | SJB | REFER to EXTERIOR LIGHTING article. |
| B2A31 | Left Front Lamp Low Beam Circuit Short to Ground | SJB | REFER to EXTERIOR LIGHTING article. |
| B2A32 | LED Backlighting Output Circuit Open | SJB | REFER to INSTRUMENT CLUSTER AND PANEL ILLUMINATION article. |
| B2A33 | LED Backlighting Output Circuit Short to Ground | SJB | REFER to INSTRUMENT CLUSTER AND PANEL ILLUMINATION article. |
| B2A35 | Interior Lighting Output Circuit Open | SJB | REFER to INTERIOR LIGHTING article. |
| B2A36 | Interior Lighting Output Circuit Short to Ground | SJB | REFER to INTERIOR LIGHTING article. |
| B2A37 | Floor Lamp Output Circuit Open | SJB | REFER to INTERIOR LIGHTING article. |
| B2A38 | Floor Lamp Output Circuit Short to Ground | SJB | REFER to INTERIOR LIGHTING article. |
| B2A39 | Puddle Lamp Output Circuit Open | SJB | REFER to INTERIOR LIGHTING article. |
| B2A3A | Puddle Lamp Output Circuit Short to Ground | SJB | REFER to INTERIOR LIGHTING article. |
| B2A3F | Seatbelt Load Limiter Driver Cross Link to Another Firing Loop | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| B2A40 | Seatbelt Load Limiter Front Passenger Cross Link to Another Firing Loop | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| C1093 | Traction Control Disable Switch Circuit Failure | IC | REFER to VEHICLE DYNAMIC SYSTEMS article. |
| C1125 | Brake Fluid Level Sensor Input Circuit Failure | SJB | REFER to INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES article. |
| C1145 | Speed Wheel Sensor RF Input Circuit Failure | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS article. |
| C1155 | Speed Wheel Sensor LF Input Circuit Failure | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS article. |
| C1165 | Speed Wheel Sensor RR Input Circuit Failure | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS article. |
| C1175 | Speed Wheel Sensor LR Input Circuit Failure | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS article. |
| C1222 | Speed Wheel Mismatch | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS article. |
| C1266 | ABS Valve Power Relay Circuit Failure | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS article. |
| C1278 | STEERING Wheel Angle 1 and 2 Signal Faulted | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS article. |
| C1279 | Yaw Rate Sensor Circuit Failure | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS article. |
| C1280 | Yaw Rate Sensor Signal Fault | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS article. |
| C1282 | Lateral Accelerometer Signal Fault | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS article. |
| C1288 | Pressure Transducer Main / Primary Input Circuit Failure | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS article. |
| C1296 | Wheel Speed LF Signal Fault | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS article. |
| C1297 | Wheel Speed RF Signal Fault | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS article. |
| C1298 | Wheel Speed RR Signal Fault | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS article. |
| C1299 | Wheel Speed LR Signal Fault | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS article. |
| C1300 | ABS Pump Motor Circuit Failure | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS article. |
| C1414 | Incorrect Module Design Level | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| C1440 | Pressure Transducer Main / Primary Signal Faulted | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS article. |
| C1446 | Brake Switch Circuit Failure | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS article. |
| C1484 | Brake Pads Worn Input Short to Ground | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS article. |
| C1699 | Left Rear Sensor Circuit Short to Vbat | PAM | REFER to PARKING AID article. |
| C1700 | Left Rear Sensor Circuit Failure or Blockage | PAM | REFER to PARKING AID article. |
| C1701 | Left Rear Sensor Circuit Fault | PAM | REFER to PARKING AID article. |
| C1702 | Right Rear Sensor Circuit Short to Vbat | PAM | REFER to PARKING AID article. |
| C1703 | Right Rear Sensor Circuit Failure or Blockage | PAM | REFER to PARKING AID article. |
| C1704 | Right Rear Sensor Circuit Fault | PAM | REFER to PARKING AID article. |
| C1705 | Left Rear Center Sensor Circuit Short to Vbatt | PAM | REFER to PARKING AID article. |
| C1706 | Left Rear Center Sensor Circuit Failure | PAM | REFER to PARKING AID article. |
| C1707 | Left Rear Center Sensor Circuit Fault | PAM | REFER to PARKING AID article. |
| C1708 | Right Rear Center Sensor Circuit Short to Vbat | PAM | REFER to PARKING AID article. |
| C1709 | Right Rear Center Sensor Circuit Failure | PAM | REFER to PARKING AID article. |
| C1710 | Right Rear Center Sensor Circuit Fault | PAM | REFER to PARKING AID article. |
| C1742 | Rear Sounder Circuit Failure | PAM | REFER to PARKING AID article. |
| C1743 | Rear Sounder Circuit Short to Vbatt | PAM | REFER to PARKING AID article. |
| C1748 | Switch Input Circuit Short to Gnd | PAM | REFER to PARKING AID article. |
| C1805 | Mismatched PCM and/or ABS-TC Module | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS article. |
| C1920 | LED #1 Circuit Failure | PAM | REFER to PARKING AID article. |
| C192A | Solenoid Actuator Circuit Failure | PSCM | REFER to STEERING SYSTEM - GENERAL INFORMATION article. |
| C192B | Solenoid Actuator Circuit Open | PSCM | REFER to STEERING SYSTEM - GENERAL INFORMATION article. |
| C192C | Solenoid Actuator Circuit Short to Battery | PSCM | REFER to STEERING SYSTEM - GENERAL INFORMATION article. |
| C192D | Solenoid Actuator Circuit Short to Ground | PSCM | REFER to STEERING SYSTEM - GENERAL INFORMATION article. |
| C1933 | Solenoid Current Out Of Range | PSCM | REFER to STEERING SYSTEM - GENERAL INFORMATION article. |
| C1941 | Zero Seat Weight Test Failure | OCSM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| C1947 | Front Driver's Seat Track Position Switch Circuit Short to Ground | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| C1948 | Front Driver's Seat Track Position Switch Circuit Resistance Out of Range | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| C1955 | Steering Angle Sensor Circuit Open | PSCM | REFER to STEERING SYSTEM - GENERAL INFORMATION article. |
| C1956 | Steering Angle Sensor Circuit Failure | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS article. |
| C1956 | Steering Angle Sensor Circuit Failure | PSCM | REFER to STEERING SYSTEM - GENERAL INFORMATION article. |
| C195A | Steering Angle Sensor Circuit Short To Battery | PSCM | REFER to STEERING SYSTEM - GENERAL INFORMATION article. |
| C195B | Steering Angle Sensor Circuit Short To Ground | PSCM | REFER to STEERING SYSTEM - GENERAL INFORMATION article. |
| C1963 | Stability Control Inhibit Warning | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS article. |
| C1975 | IVD Plausibility Failure | ABS Module | REFER to VEHICLE DYNAMIC SYSTEMS article. |
| C1981 | Front Driver's Seat Track Position Switch Circuit Fault | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| C1992 | Vehicle Speed Circuit Failure | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| C2200 | Front Passenger's Seat Track Position Switch Circuit Fault | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| C2202 | Front Passenger's Seat Track Position Switch Circuit Short to Ground | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| C2204 | Front Passenger's Seat Track Position Switch Circuit Resistance Out of Range | RCM | REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. |
| C2780 | ECU in Manufacturer Sub-State | SJB | DTC C2780 is only present when a new SJB is installed, the SJB is reprogrammed, or the SJB is reconfigured. REFER to WHEELS AND TIRES article to CARRY OUT the TPMS sensor training in order to CLEAR this DTC. |
| P0512 | Starter Request Circuit | PCM | REFER to STARTING SYSTEM article. |
| P0563 | System Voltage High | PCM | REFER to CHARGING SYSTEM - GENERAL INFORMATION article. |
| P0579 | Cruise Control Multifunction Input A Circuit Range/Performance | PCM | REFER to SPEED CONTROL article. |
| P0581 | Cruise Control Multifunction Input A Circuit High | PCM | REFER to SPEED CONTROL article. |
| P0620 | Generator Control Circuit | PCM | REFER to CHARGING SYSTEM - GENERAL INFORMATION article. |
| P0625 | Generator Field Terminal Circuit Low | PCM | REFER to CHARGING SYSTEM - GENERAL INFORMATION article. |
| P0626 | Generator Field Terminal Circuit High | PCM | REFER to CHARGING SYSTEM - GENERAL INFORMATION article. |
| P062F | Internal Control Module EEPROM Error | SJB | INSTALL a new SJB. REFER to Smart Junction Box (SJB) . REPEAT the self-test. |
| P065B | Generator Control Circuit Range/Performance | PCM | REFER to CHARGING SYSTEM - GENERAL INFORMATION article. |
| P0720 | Output Speed Circuit Fault | PCM | REFER to the Introduction - Gasoline Engines article. |
| P0812 | Reverse Input Circuit | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| P1260 | Theft Detected, Vehicle Immobilized | PCM | REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) article. |
| P1572 | Brake Pedal Switch Circuit | PCM | REFER to SPEED CONTROL article. |
| P1635 | Tire/Axle Out of Acceptable Range | 4X4 Control Module | REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS article. |
| P1703 | Brake Switch Out of Self-Test Range | PCM | REFER to SPEED CONTROL article. |
| P1824 | 4-Wheel Drive Clutch Relay Circuit Failure | 4X4 Control Module | REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS article. |
| P1825 | 4-Wheel Drive Clutch Relay Open Circuit | 4X4 Control Module | REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS article. |
| PXXXX | All other DTCs | PCM | REFER to the Introduction - Gasoline Engines article. |
| U0073 | Control Module Communication Bus A Off | ABS Module | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0073 | Control Module Communication Bus A Off | HVAC Module | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0073 | Control Module Communication Bus A Off | IC | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0073 | Control Module Communication Bus A Off | PSCM | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0074 | Control Module Communication Bus B Off | ABS Module | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0074 | Control Module Communication Bus B Off | IC | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0100 | Lost Communication With ECM/PCM | 4X4 Control Module | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0100 | Lost Communication With ECM/PCM | ABS Module | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0100 | Lost Communication With ECM/PCM | IC | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0100 | Lost Communication With ECM/PCM | PSCM | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0100 | Lost Communication With ECM/PCM | RCM | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0102 | Lost Communication with Transfer Case Control Module (4x4CM) | ABS Module | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0114 | Lost Communication With Four-Wheel Drive Clutch Control Module | IC | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0121 | Lost Communication With Anti-Lock Brake System (ABS) Control Module | 4X4 Control Module | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0121 | Lost Communication With Anti-Lock Brake System (ABS) Control Module | IC | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0121 | Lost Communication With Anti-Lock Brake System (ABS) Control Module | PSCM | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0126 | Lost Communication With Steering Angle Sensor Module | PSCM | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0131 | Lost Communication With Power Steering Control Module (VAPS) | PSCM | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0140 | Lost Communication With Body Control Module (GEM) | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| U0140 | Lost Communication With Body Control Module (GEM) | DSM | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0140 | Lost Communication With Body Control Module (GEM) | HVAC Module | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0140 | Lost Communication With Body Control Module (GEM) | IC | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0140 | Lost Communication With Body Control Module (GEM) | LTM | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0140 | Lost Communication With Body Control Module (GEM) | RETM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| U0151 | Lost Communication With Restraints Control Module | IC | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0151 | Lost Communication With Restraints Control Module | OCSM | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0154 | Lost Communication With Restraints Occupant Classification System Module (OCS) | RCM | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0155 | Lost Communication With Instrument Panel Cluster (IC) Control Module | 4X4 Control Module | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0155 | Lost Communication With Instrument Panel Cluster (IC) Control Module | ABS Module | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0155 | Lost Communication With Instrument Panel Cluster (IC) Control Module | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| U0155 | Lost Communication With Instrument Panel Cluster (IC) Control Module | DSM | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0155 | Lost Communication With Instrument Panel Cluster (IC) Control Module | LTM | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0155 | Lost Communication With Instrument Panel Cluster (IC) Control Module | PSCM | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0155 | Lost Communication With Instrument Panel Cluster (IC) Control Module | SJB | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0159 | Lost Communication With Parking Assist Control Module (PAM) | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| U0164 | Lost Communication With HVAC Control Module (EATC) | IC | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0184 | Lost Communication With Radio (ACM) | APIM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| U0184 | Lost Communication With Radio (ACM) | RETM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| U0184 | Lost Communication With Radio (ACM) | SDARS Module | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| U0193 | Lost Communication With Digital Audio Control Module (SDARS) | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| U0193 | Lost Communication With Digital Audio Control Module (SDARS) | RETM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| U0196 | Lost Communication With Entertainment Control Module - Rear (AUX) | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| U0196 | Lost Communication With Entertainment Control Module - Rear (AUX) | APIM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| U0196 | Lost Communication With Entertainment Control Module - Rear (AUX) | SDARS Module | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| U0197 | Lost Communication With Telephone Control Module | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| U0197 | Lost Communication With Telephone Control Module | SDARS Module | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| U0208 | Lost Communication With Seat Control Module (DSM) | IC | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0212 | Lost Communication With Steering Column Control Module (SWC) | PSCM | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0230 | Lost Communication With Rear Gate Module (LTM) | IC | REFER to MODULE COMMUNICATIONS NETWORK article. |
| U0238 | Lost Communication With Digital Audio Control Module "D" (DSP) | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| U0249 | Lost Communication With Entertainment Control Module - Rear "B" (RCU) | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| U0249 | Lost Communication With Entertainment Control Module - Rear (AUX) | APIM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| U0249 | Lost Communication With Entertainment Control Module - Rear "B" (RCU) | SDARS Module | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| U0255 | Lost Communication With Front Controls Interface Module | APIM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| U0255 | Lost Communication With Front Controls Interface Module | SDARS Module | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| U0256 | Lost Communication With Front Display Interface Module | APIM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| U0256 | Lost Communication With Front Display Interface Module | SDARS Module | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| U0300 | Internal Control Module Software Incompatibility | HVAC Module | REFER to MODULE CONFIGURATION article. |
| U0401 | Invalid Data Received From ECM/PCM | 4X4 Control Module | RETRIEVE and FOLLOW non-network DTCs from the PCM. |
| U0415 | Invalid Data Received From Anti-Lock Brake System Control Module | 4X4 Control Module | RETRIEVE and FOLLOW non-network DTCs from the ABS module. |
| U2013 | Compass Module is Not Responding | IC | REFER to INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES article. |
| U2023 | Fault Received From External Node | ABS Module | RETRIEVE and FOLLOW non-network DTCs from other modules. |
| U2023 | Fault Received From External Node | IC | REFER to INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES article. |
| U2023 | Fault Received From External Node | PSCM | RETRIEVE and FOLLOW non-network DTCs from other modules. |
| U2023 | Fault Received From External Node | RCM | RETRIEVE and FOLLOW non-network DTCs from other modules. |
| U2050 | No Application Present | 4X4 Control Module | REFER to MODULE CONFIGURATION article. |
| U2050 | No Application Present | ABS Module | REFER to MODULE CONFIGURATION article. |
| U2050 | No Application Present | ACM | REFER to MODULE CONFIGURATION article. |
| U2050 | No Application Present | APIM | REFER to MODULE CONFIGURATION article. |
| U2050 | No Application Present | DSM | REFER to MODULE CONFIGURATION article. |
| U2050 | No Application Present | HVAC Module | REFER to MODULE CONFIGURATION article. |
| U2050 | No Application Present | IC | REFER to MODULE CONFIGURATION article. |
| U2050 | No Application Present | LTM | REFER to MODULE CONFIGURATION article. |
| U2050 | No Application Present | OCSM | REFER to MODULE CONFIGURATION article. |
| U2050 | No Application Present | PSCM | REFER to MODULE CONFIGURATION article. |
| U2050 | No Application Present | RCM | REFER to MODULE CONFIGURATION article. |
| U2050 | No Application Present | RETM | REFER to MODULE CONFIGURATION article. |
| U2050 | No Application Present | SDARS Module | REFER to MODULE CONFIGURATION article. |
| U2050 | No Application Present | SJB | REFER to MODULE CONFIGURATION article. |
| U2051 | One or More Calibration Files Missing/Corrupt | 4X4 Control Module | REFER to MODULE CONFIGURATION article. |
| U2051 | One or More Calibration Files Missing/Corrupt | ACM | REFER to MODULE CONFIGURATION article. |
| U2051 | One or More Calibration Files Missing/Corrupt | HVAC Module | REFER to MODULE CONFIGURATION article. |
| U2051 | One or More Calibration Files Missing/Corrupt | LTM | REFER to MODULE CONFIGURATION article. |
| U2051 | One or More Calibration Files Missing/Corrupt | OCSM | REFER to MODULE CONFIGURATION article. |
| U2196 | Invalid 'Engine RPM' Data | IC | REFER to INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES article. |
| U2199 | Invalid 'Engine Coolant Temperature' Data | IC | REFER to INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES article. |
| U2471 | Unexpected PRNDL State | LTM | REFER to BODY CLOSURES article. |
| U2472 | Unexpected Ignition State | IC | REFER to INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES article. |
| U2472 | Unexpected Ignition State | LTM | REFER to BODY CLOSURES article. |
| U2472 | Unexpected Ignition State | SJB | REFER to STEERING COLUMN SWITCHES article. |
| U2473 | Unexpected Vehicle Speed (VSS) | ACM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| U2473 | Unexpected Vehicle Speed (VSS) | LTM | REFER to BODY CLOSURES article. |
| U2473 | Unexpected Vehicle Speed (VSS) | SJB | REFER to Smart Junction Box (SJB) . |
| U2510 | CAN - Invalid Data for Vehicle Security | IC | REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) article. |
| U2511 | CAN - Data Mis-Match (Receive Data Does Not Match Expected) | IC | REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) article. |
| U251C | USB #1 Device Error | APIM | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS article. |
| U261A | CAN Data / Configuration Setup Mismatch | IC | REFER to MODULE CONFIGURATION article. |
DIAGNOSTIC TROUBLE CODE (DTC) TABLE
Special Tools Illustration Tool Name Tool Number Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool
Scheme 76
Principles of Operation
Note. The time out for the battery saver relay and the accessory delay relay (both are controlled by the SJB) is 1 minute if the vehicle has less than 80 km (50 miles). Once the vehicle passes the approximate mileage threshold of 80 km (50 miles), the time out for both relays will be the normal 10 minute time out, as described by the Owner's Literature. For the battery saver relay, refer to INTERIOR LIGHTING article. For the accessory delay relay, refer to GLASS, FRAMES AND MECHANISMS article.
Note. The smart junction box (SJB) is also known as the generic electronic module (GEM).
The SJB is a multifunction module that controls many of the vehicle systems. Most of the SJB functions utilize hardwired inputs and/or outputs. The SJB controls the following hardwired functions, using the corresponding inputs and outputs
| Function | Input(s) | Output(s) |
|---|---|---|
| Accessory delay | Master power window switch Power sliding roof switch Audio control module (ACM) | Accessory delay relay |
| Autolamps (if equipped) | Headlamp switch Ambient light sensor | Exterior lamps |
| Battery saver | Internal to SJB | Battery saver relay |
| Daytime running lamps (if equipped) | Ignition switch status Parking brake status | Low beam headlamps |
| Luggage compartment lid release | Luggage compartment lid release switch | Luggage compartment lid release relay |
| Fog lamps (if equipped) | Headlamp switch | Fog lamp relay |
| Headlamps (low beam) | Headlamp switch | Low beam headlamps |
| Headlamps (high beam and flash-to-pass) | Headlamp switch Multifunction switch | High beam relay |
| Heated rear window | Heated rear window switch | Heated rear window relay |
| Horn | Horn switch | Horn relay |
| Parking lamps | Headlamp switch | Parking lamps relay |
| Power door locks | Driver door lock control switch Passenger door lock control switch | Door lock/unlock relays |
| Remote keyless entry (RKE) system | Keyless entry keypad RKE transmitter (part of the integrated keyhead transmitter [IKT] key) | Power door locks Parking lamps Horn |
| Stoplamps | Stoplamp switch | Stoplamps |
| Turn signal/hazard lamps | Multifunction switch Hazard lamps switch | Turn signal/hazard lamps |
In addition, the SJB is involved in other vehicle systems through communication over the medium speed controller area network (MS-CAN). For a detailed list of SJB network inputs and outputs, refer to MODULE COMMUNICATIONS NETWORK article, Principles of Operation .
Some SJB parameters are programmable. Two types of programmable parameters are available: vehicle configuration and customer preference. Refer to MODULE CONFIGURATION article.
Inspection and Verification
- Verify the customer concern.
- Visually inspect for obvious signs of electrical damage. VISUAL INSPECTION CHART Electrical Battery junction box (BJB) fuse(s): 1 (80A) 2 (80A) 33 (20A) Smart junction box (SJB) fuse 5 (10A) Wiring, terminals or connectors SJB
- If an obvious cause of an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
- If the cause is not visually evident, connect the scan tool to the data link connector (DLC).
- If the scan tool does not communicate with the VCM: Check the VCM connection to the vehicle. Check the scan tool connection to the VCM. Refer to «MODULE COMMUNICATIONS NETWORK»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-communications-network-system) article, No Power To The Scan Tool, to diagnose no communication with the scan tool.
- If the scan tool does not communicate with the vehicle: Verify the ignition key is in the ON position. Verify the scan tool operation with a known good vehicle. Refer to «MODULE COMMUNICATIONS NETWORK»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-communications-network-system) article to diagnose no response from the PCM.
- Carry out the network test. If the scan tool responds with no communication for one or more modules, refer to «MODULE COMMUNICATIONS NETWORK»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-communications-network-system) article. If the network test passes, retrieve and record the continuous memory DTCs.
- Clear the continuous DTCs and carry out the self-test diagnostics for the SJB.
- If the DTCs retrieved are related to the concern, go to DTC Tables. For all other DTCs, refer to «Diagnostic Trouble Code (DTC) Chart»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#multifunction-electronic-modules-system__diagnostic-trouble-code-dtc-table) .
- If no DTCs related to the concern are retrieved, go to «Symptom Chart»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#multifunction-electronic-modules-system) .
DTC Tables
| DTC | Description | Action |
|---|---|---|
| B106E | Solid State Driver Disabled Due to Short Circuit | Go to Pinpoint Test A . |
| B106F | Module Disabled Due to External Fault | Go to Pinpoint Test A . |
| P062F | No Application Present | CONFIGURE the SJB. REFER to MODULE CONFIGURATION article to carry out PMI. CLEAR the DTCs. REPEAT the self-test. If DTC P062F is retrieved again, INSTALL a new SJB. REFER to Smart Junction Box (SJB) . TEST the system for normal operation. |
| U2472 | Unexpected Ignition State | REFER to STEERING COLUMN SWITCHES article. |
| U2473 | Unexpected Vehicle Speed (VSS) | Set during self-test if vehicle speed exceeds 5 km/h (3 mph), or vehicle speed can not be determined. |
| All other DTCs | REFER to Diagnostic Trouble Code (DTC) Chart . |
SMART JUNCTION BOX (SJB) DTC TABLE
Symptom Chart
| Condition | Possible Sources | Action |
|---|---|---|
| No communication with the smart junction box (SJB) | Fuse Wiring, terminals or connectors SJB | REFER to MODULE COMMUNICATIONS NETWORK article. |
Symptom Chart
Normal Operation
When a repetitive fault causing a circuit overload is detected on certain output circuits, the SJB disables the circuit by removing voltage, or ground, to the affected circuit. The circuit remains disabled until the fault is corrected and the DTCs are cleared, and then the self-test is repeated. When the on-demand self-test has been run after all faults have been corrected, any DTCs related to the fault are cleared.
- DTC B106E sets when the SJB has disabled a circuit due to a repetitive fault causing a circuit overload. For a complete list of corresponding DTCs, refer to «Principles of Operation»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#multifunction-electronic-modules-system__principles-of-operation) .
- DTC B106F (Module Disabled Due to External Fault) - sets when one or more output functions are permanently disabled due to a repetitive circuit overload fault. DTC B106F will be set with DTC B106E. When DTC B106F is present, the SJB must be replaced after the fault condition has been corrected.
This pinpoint test is intended to diagnose the following
- Output circuit short to ground or voltage
- SJB
PINPOINT TEST A: DTC B106E - SOLID STATE DRIVER DISABLED DUE TO SHORT CIRCUIT
| CAUTION | If DTC B106F is present and the SJB is to be replaced, the fault condition must be corrected first. Failure to correct the fault condition first may cause damage to the new SJB, resulting in a repeat repair. |
- A1 REVIEW THE DTCs Review the DTCs from the SJB self-test. Is only DTC B106F present? YES : INSTALL a new SJB. REFER to «Smart Junction Box (SJB)»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#multifunction-electronic-modules-system) . TEST the system for normal operation. NO : CORRECT any DTCs present other than DTC B106E (DTC B106F may also be present). REFER to «Diagnostic Trouble Code (DTC) Chart»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#multifunction-electronic-modules-system__diagnostic-trouble-code-dtc-table) . After the repair, go to A2 .
- A2 CARRY OUT THE SJB SELF-TEST Carry out the SJB self-test. Is only DTC B106F present? YES : INSTALL a new SJB. REFER to «Smart Junction Box (SJB)»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#multifunction-electronic-modules-system) . TEST the system for normal operation. NO : The system is operating correctly at this time. The concern was caused by a fault in one of the output circuits, which is no longer present.
Special Tools Illustration Tool Name Tool Number Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool
Note. The smart junction box (SJB) is also known as the generic electronic module (GEM).
The driver seat module (DSM) allows the driver to program a personalized seat position that can be recalled using the memory switch or a remote keyless entry (RKE) transmitter (part of the integrated keyhead transmitter [IKT] key). In addition to the position of the driver seat, the DSM also controls the position of the exterior mirrors and the adjustable pedals. Refer to SEATING article.
The DSM is part of the medium speed controller area network (MS-CAN), over which it receives the selected transmission gear message. All other functions of the DSM are hardwired.
- Verify the customer concern.
- Visually inspect for obvious signs of electrical damage. VISUAL INSPECTION CHART Electrical Battery junction box (BJB) fuse 32 (30A) Smart junction box (SJB) fuse 12 (7.5A) Wiring, terminals or connectors Driver seat module (DSM)
- If an obvious cause of an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
- If the cause is not visually evident, connect the scan tool to the data link connector (DLC).
- If the scan tool does not communicate with the VCM: Check the VCM connection to the vehicle. Check the scan tool connection to the VCM. Refer to «MODULE COMMUNICATIONS NETWORK»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-communications-network-system) article, No Power To The Scan Tool, to diagnose no communication with the scan tool.
- If the scan tool does not communicate with the vehicle: Verify the ignition key is in the ON position. Verify the scan tool operation with a known good vehicle. Refer to «MODULE COMMUNICATIONS NETWORK»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-communications-network-system) article to diagnose no response from the PCM.
- Carry out the network test. If the scan tool responds with no communication for one or more modules, refer to «MODULE COMMUNICATIONS NETWORK»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-communications-network-system) article. If the network test passes, retrieve and record the continuous memory DTCs.
- Clear the continuous DTCs and carry out the self-test diagnostics for the DSM.
- If the DTCs retrieved are related to the concern, go to DTC Tables. For all other DTCs, refer to «Diagnostic Trouble Code (DTC) Chart»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#multifunction-electronic-modules-system__diagnostic-trouble-code-dtc-table) .
- If no DTCs related to the concern are retrieved, go to «Symptom Chart»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#multifunction-electronic-modules-system) .
| DTC | Description | Action |
|---|---|---|
| B106E | Solid State Driver Disabled Due to Short Circuit | Go to Pinpoint Test B . |
| B106F | Module Disabled Due to External Fault | Go to Pinpoint Test B . |
| All other DTCs | REFER to Diagnostic Trouble Code (DTC) Chart . |
DRIVER SEAT MODULE (DSM) DTC TABLE
| Condition | Possible Sources | Action |
|---|---|---|
| No communication with the driver seat module (DSM) | Fuse Wiring, terminals or connectors DSM | REFER to MODULE COMMUNICATIONS NETWORK article. |
Symptom Chart
When a repetitive fault causing a circuit overload is detected on certain output circuits, the driver seat module (DSM) disables the circuit by removing voltage, or ground, to the affected circuit. The circuit remains disabled until the fault is corrected and an on-demand self-test is run. When the on-demand self-test has been run after all faults have been corrected, any DTCs related to the fault are cleared.
- DTC B106E sets when the DSM has disabled a circuit due to a repetitive fault causing a circuit overload. For a complete list of corresponding DTCs, refer to «Principles of Operation»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#multifunction-electronic-modules-system__principles-of-operation) .
- DTC B106F (Module Disabled Due to External Fault) - sets when one or more output functions are permanently disabled due to a repetitive circuit overload fault. DTC B106F will be set with DTC B106E. When DTC B106F is present, the DSM must be replaced after the fault condition has been corrected.
This pinpoint test is intended to diagnose the following
- Output circuit short to ground or voltage
- DSM
PINPOINT TEST B: DTC B106E - SOLID STATE DRIVER DISABLED DUE TO SHORT CIRCUIT
| CAUTION | If DTC B106F is present and the DSM is to be replaced, the fault condition must be corrected first. Failure to correct the fault condition first may cause damage to the new DSM, resulting in a repeat repair. |
- B1 REVIEW THE DTCs Review the DTCs from the DSM self-test. Is only DTC B106F present? YES : INSTALL a new DSM. REFER to «Driver Seat Module (DSM)»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#multifunction-electronic-modules-system) . TEST the system for normal operation. NO : CORRECT any DTCs present other than DTC B106E (DTC B106F may also be present). REFER to «Diagnostic Trouble Code (DTC) Chart»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#multifunction-electronic-modules-system__diagnostic-trouble-code-dtc-table) . After the repair, go to B2 .
- B2 CARRY OUT THE DSM SELF-TEST Carry out the DSM self-test. Is only DTC B106F present? YES : INSTALL a new DSM. REFER to «Driver Seat Module (DSM)»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#multifunction-electronic-modules-system) . TEST the system for normal operation. NO : The system is operating correctly at this time. The concern was caused by a fault in one of the output circuits, which is no longer present.
Scheme 77
| Item | Part Number | Description |
|---|---|---|
| 1 | Smart junction box (SJB) electrical connectors (part of 14401) | |
| 2 | SJB electrical connectors (part of 14290) | |
| 3 | SJB electrical connectors (part of 14A005) | |
| 4 | Harness pushpins (2 required) | |
| 5 | SJB release tab | |
| 6 | 15604 | SJB |
REMOVAL
| CAUTION | If the smart junction box (SJB) is dropped, damage to the internal components may occur. A new SJB must be installed. |
| CAUTION | Electronic modules are sensitive to static electrical charges. If exposed to these charges, damage may result. |
Note. Prior to the replacement of the module, it is necessary to upload the module configuration information to the scan tool. This information must be downloaded into the new module after installation. For additional information, refer to MODULE CONFIGURATION article. In the event that As-Built data is required (SJB will not communicate), all remote keyless entry (RKE) devices must be programmed to the new SJB. A minimum of 2 devices are necessary to complete the configuration and turn off the flashing interior lights.
Note. The tire pressure monitoring system (TPMS) functionality is integral to the SJB.
Note. The steps included in the SJB removal and installation procedure are critical to restoring the vehicle security and tire pressure monitoring systems to normal operation. A new SJB is delivered in a manufacturing mode with 7 pre-set DTCs related to the TPMS. To clear the DTCs, successful configuration of the SJB must occur, followed by successful TPMS sensor training, and a successful self-test, including clearing of the DTCs. The DTCs are as follows: B106D (Tire Pressure Monitor System [TPMS] Initiators Not Configured) B2477 (Module Configuration Failure) B2868 (Left Front Tire Pressure Sensor Fault) B2869 (Right Front Tire Pressure Sensor Fault) B2870 (Right Rear Tire Pressure Sensor Fault) B2871 (Left Rear Tire Pressure Sensor Fault) C2780 (ECU in Manufacturer Sub-State)
- Upload the module configuration information from the SJB. For additional information, refer to «MODULE CONFIGURATION»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-configuration-system) article.
- Remove the steering column cover. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(/ford/taurus-x/i-2007-2009/remont/gauges-instrument-panels/#instrument-panel-and-console) article.
- Disconnect the 6 SJB electrical connectors.
- Remove the 2 harness pushpins from the SJB.
- Using a suitable tool, lift the SJB release tab (away from the SJB bracket), slide the SJB (wiggling it to the left) and remove.
- Disconnect the SJB B+ connector.
- If necessary, remove the 3 nuts and the SJB bracket.
INSTALLATION
- If necessary, install the 3 nuts and the SJB bracket. Tighten to 5 Nm (44 lb-in).
- Install the SJB. Connect the SJB B+ connector. Locate the SJB into the 3 tabs and slide the SJB (to the right) to engage the SJB release tab into the SJB bracket. Connect the 6 electrical connectors. Install the 2 harness pushpins into the SJB.
- Install the steering column cover.
- Download the SJB configuration information from the scan tool. For additional information, refer to «MODULE CONFIGURATION»(/ford/taurus-x/i-2007-2009/remont/communication-devices/#module-configuration-system) article.
- Train the tire pressure sensors. For additional information, refer to «WHEELS AND TIRES»(/ford/taurus-x/i-2007-2009/remont/wheel-tire-system/#wheels-tires) article.
- Carry out the SJB self-test (must include an on-demand self-test) and then repeat the self-test to confirm all DTCs have been cleared.
- Rotate the instrument panel dimmer switch from the full dim position to the dome ON position. This will make sure that all displays are visible under all lighting conditions.
Special Tools Illustration Tool Name Tool Number Heavy-Duty Riveter 501-D011 (D80L-23200-A)
Scheme 78
| Item | Part Number | Description |
|---|---|---|
| 1 | 14C724 | Climate controlled seat module (if equipped) |
| 2 | Driver seat module (DSM) electrical connectors (part of 14A699) | |
| 3 | DSM rivets (2 required) | |
| 4 | 14C708 | DSM |
REMOVAL AND INSTALLATION
- Remove the driver seat. For additional information, refer to «SEATING»(/ford/taurus-x/i-2007-2009/remont/seats/#seat-system) article.
- If equipped, position the dual climate control seat module (DCSM) aside.
- Disconnect the driver seat module (DSM) electrical connectors.
- Using a drill, remove the 2 rivets and the DSM.
- To install, reverse the removal procedure. Use the special tool to install the 2 rivets.
See also:
• INTERIOR LIGHTING
• GLASS, FRAMES AND MECHANISMS
• HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS
• Introduction - Gasoline Engines
• CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS
• PARKING AID
• INFORMATION AND ENTERTAINMENT SYSTEMS
• SUPPLEMENTAL RESTRAINT SYSTEM
• WHEELS AND TIRES
• MODULE COMMUNICATIONS NETWORK
• BODY CLOSURES
• ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS)
• INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES
• CHARGING SYSTEM - GENERAL INFORMATION
• STEERING SYSTEM - GENERAL INFORMATION
• FOUR WHEEL DRIVE (4WD) SYSTEMS
• VEHICLE DYNAMIC SYSTEMS
• CLIMATE CONTROL
• ELECTRONIC ENGINE CONTROLS
• POWER STEERING
• EXTERIOR LIGHTING
• ANTI-THEFT - PERIMETER
• SEATING
• REAR VIEW MIRRORS
• BRAKE SYSTEM - GENERAL INFORMATION
• WIPERS AND WASHERS
• MODULE CONFIGURATION
• STEERING COLUMN SWITCHES
• INSTRUMENT CLUSTER AND PANEL ILLUMINATION
• STARTING SYSTEM
• SPEED CONTROL
• INSTRUMENT PANEL AND CONSOLE
• Driver Seat Module (DSM)
• Principles of Operation
• Diagnostic Trouble Code (DTC) Chart
• Pinpoint Test A
• Pinpoint Test B
