DIAGNOSTIC TROUBLE CODE CHART
| DTC | Description | Source | Action |
|---|---|---|---|
| B1213 | Anti -Theft Number of Programmed Keys is Below Minimum | PCM | REFER to ANTI-THEFT . |
| B1231 | Longitudinal Acceleration Threshold Exceeded | RCM | REFER to AIR BAG RESTRAINT SYSTEMS . |
| B1309 | Power Door Lock Circuit Short to Ground | Central security module | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B1313 | Battery Saver Relay Coil Circuit Open, Short to Ground | GEM | REFER to INTERIOR LIGHTING . |
| B1315 | Battery Saver Relay Circuit Short to Battery | GEM | REFER to INTERIOR LIGHTING . |
| B1317 | Battery Voltage High | 4WD control module | REFER to GENERATORS & REGULATORS . |
| B1317 | Battery Voltage High | GEM | REFER to GENERATORS & REGULATORS . |
| B1318 | Battery Voltage Low | 4WD control module | REFER to GENERATORS & REGULATORS . |
| B1318 | Battery Voltage Low | RCM | REFER to GENERATORS & REGULATORS . |
| B1318 | Battery Voltage Low | GEM | REFER to GENERATORS & REGULATORS . |
| B1322 | Driver Door Ajar Circuit Short to Ground | GEM | REFER to INTERIOR LIGHTING . |
| B1323 | Door Ajar Lamp Circuit Failure | GEM | REFER to INSTRUMENT CLUSTER . |
| B1325 | Door Ajar Lamp Circuit Short to Battery | GEM | REFER to INSTRUMENT CLUSTER . |
| B1330 | RF Door Ajar Circuit Short to Ground | GEM | REFER to INTERIOR LIGHTING . |
| B1334 | Decklid Ajar Rear Door Circuit Short to Ground | GEM | REFER to INTERIOR LIGHTING . |
| B1340 | Chime Input Request Circuit Short to Ground | GEM | REFER to WARNING DEVICES . |
| B1341 | Power Door Unlock Circuit Short to Ground | Central security module | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B1342 | ECU is Defective | ABS module | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved, INSTALL a new ABS module. Refer to ANTI-LOCK CONTROL . CLEAR the DTCs. REPEAT the self-test. |
| B1342 | ECU is Defective | Central security module | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved, INSTALL a new central security module. REFER to CENTRAL SECURITY MODULE . CLEAR the DTCs. REPEAT the self-test. |
| B1342 | ECU is Defective | 4WD control module | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved, INSTALL a new 4WD Control Module. REFER to FOUR- WHEEL DRIVE SYSTEMS . CLEAR the DTCs. REPEAT the self-test. |
| B1342 | ECU is Defective | GEM | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved, INSTALL a new GEM. REFER to GENERIC ELECTRONIC MODULE (GEM) . CLEAR the DTCs. REPEAT the self-test. |
| B1342 | ECU is Defective | RCM | CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved, INSTALL a new RCM. refer to AIR BAG RESTRAINT SYSTEMS . CLEAR the DTCs. REPEAT the self-test. |
| B1345 | Heated Backlite Input Circuit Short to Ground | GEM | REFER to GLASS, FRAMES AND MECHANISMS . |
| B1347 | Heated Backlite Relay Circuit Failure | GEM | REFER to GLASS, FRAMES AND MECHANISMS . |
| B1349 | Heated Backlite Relay Short to Battery | GEM | REFER to GLASS, FRAMES AND MECHANISMS . |
| B1352 | Ignition Key-In Circuit Failure | GEM | REFER to WARNING DEVICES . |
| B1355 | Ignition Run Circuit Failure | 4WD control module | REFER to STEERING COLUMN SWITCHES . |
| B1355 | Ignition Run Circuit Failure | GEM | REFER to STEERING COLUMN SWITCHES . |
| B1359 | Ignition Run/ACC Circuit Failure | GEM | REFER to STEERING COLUMN SWITCHES . |
| B1365 | Ignition Start Circuit Failure | GEM | REFER to STEERING COLUMN SWITCHES . |
| B1371 | Illuminated Entry Relay Circuit Failure | GEM | REFER to INTERIOR LIGHTING . |
| B1373 | Illuminated Entry Relay Short to Battery | GEM | REFER to INTERIOR LIGHTING . |
| B1398 | LF Power Window One Touch Window Relay Circuit Failure | GEM | REFER to GLASS, FRAMES AND MECHANISMS . |
| B1400 | LF Power Window One Touch Window Relay Circuit Short to Battery | GEM | REFER to GLASS, FRAMES AND MECHANISMS . |
| B1405 | LF Power Window Down Circuit Short to Battery | GEM | REFER to GLASS, FRAMES AND MECHANISMS . |
| B1408 | LF Power Window Up Circuit Short to Battery | GEM | REFER to GLASS, FRAMES AND MECHANISMS . |
| B1410 | LF Power Window Motor Circuit Failure | GEM | REFER to GLASS, FRAMES AND MECHANISMS . |
| B1426 | Safety Belt Lamp Circuit Short to Battery | GEM | REFER to INSTRUMENT CLUSTER . |
| B1428 | Safety Belt Lamp Circuit Failure | GEM | REFER to INSTRUMENT CLUSTER . |
| B1431 | Wiper Brake/Run Relay Circuit Failure | GEM | REFER to WIPERS AND WASHERS . |
| B1432 | Wiper Brake/Run Relay Circuit Short to Battery | GEM | REFER to WIPERS AND WASHERS . |
| B1434 | Wiper Hi/Low Speed Relay Circuit Failure | GEM | REFER to WIPERS AND WASHERS . |
| B1436 | Wiper Hi/Low Speed Relay Circuit Short to Battery | GEM | REFER to WIPERS AND WASHERS . |
| B1438 | Wiper Mode Select Switch Circuit Failure | GEM | REFER to WIPERS AND WASHERS . |
| B1441 | Wiper Mode Select Switch Circuit Short to Ground | GEM | REFER to WIPERS AND WASHERS . |
| B1446 | Wiper Park Sense Circuit Failure | GEM | REFER to WIPERS AND WASHERS . |
| B1450 | Wiper Wash/Delay Switch Circuit Failure | GEM | REFER to WIPERS AND WASHERS . |
| B1453 | Wiper Wash/Delay Switch Circuit Short to Ground | GEM | REFER to WIPERS AND WASHERS . |
| B1458 | Wiper Washer Pump Motor Relay Circuit Failure | GEM | REFER to WIPERS AND WASHERS . |
| B1460 | Wiper Washer Pump Motor Relay Circuit Short to Battery | GEM | REFER to WIPERS AND WASHERS . |
| B1462 | Safety Belt Switch Circuit Failure | GEM | REFER to WARNING DEVICES . |
| B1466 | Wiper Hi/Low Speed Not Switching | GEM | REFER to WIPERS AND WASHERS . |
| B1473 | Wiper Low Speed Circuit Motor Failure | GEM | REFER to WIPERS AND WASHERS . |
| B1476 | Wiper High Speed Circuit Motor Failure | GEM | REFER to WIPERS AND WASHERS . |
| B1483 | Brake Pedal Input Circuit Failure | GEM | REFER to FOUR- WHEEL DRIVE SYSTEMS . |
| B1485 | Brake Pedal Input Circuit Short to Battery | 4WD control module | REFER to FOUR- WHEEL DRIVE SYSTEMS . |
| B1485 | Brake Pedal Input Circuit Short to Battery | ABS module | REFER to FOUR- WHEEL DRIVE SYSTEMS . |
| B1485 | Brake Pedal Input Circuit Short to Battery | Central security module | REFER to FOUR- WHEEL DRIVE SYSTEMS . |
| B1526 | Keyless Entry Circuit Short to Ground | Central security module | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B1555 | Ignition Run/Start Circuit Failure | 4WD control module | REFER to STEERING COLUMN SWITCHES . |
| B1562 | Door Lock Cylinder Circuit Short to Ground | Central security module | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B1577 | Park Lamp Input Circuit Short to Battery | GEM | REFER to WARNING DEVICES . |
| B1600 | PATS Ignition Key Transponder Signal is Not Received | PCM | Refer to ANTI-THEFT . |
| B1601 | PATS Received Incorrect Key-Code From Ignition Key Transponder | PCM | Refer to ANTI-THEFT . |
| B1602 | PATS Received Invalid Format of Key-Code From Ignition Key Transponder | PCM | REFER to ANTI-THEFT . |
| B1610 | Illuminated Entry Input Circuit Short to Ground | GEM | REFER to INTERIOR LIGHTING . |
| B1629 | PRNDL Reverse Input Short to Battery | Central security module | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B1676 | Battery Pack Voltage Out of Range | ABS module | REFER to ANTI-LOCK CONTROL . |
| B1681 | PATS Transceiver Module Signal is Not Received | PCM | REFER to ANTI-THEFT . |
| B1840 | Wiper Front Power Circuit Failure | GEM | REFER to WIPERS AND WASHERS . |
| B1869 | Lamp Air Bag Warning Indicator Circuit Open | RCM | REFER to AIR BAG RESTRAINT SYSTEMS . |
| B1870 | Lamp Air Bag Warning Indicator Circuit Short to Battery | RCM | REFER to AIR BAG RESTRAINT SYSTEMS . |
| B1871 | Passenger Air Bag Deactivate Module Fault | RCM | REFER to AIR BAG RESTRAINT SYSTEMS . |
| B1877 | Driver Safety Belt Pretensioner Circuit Open | RCM | REFER to AIR BAG RESTRAINT SYSTEMS . |
| B1878 | Driver Safety Belt Pretensioner Circuit Short to Battery | RCM | REFER to AIR BAG RESTRAINT SYSTEMS . |
| B1879 | Driver Safety Belt Pretensioner Circuit Short to Ground | RCM | REFER to AIR BAG RESTRAINT SYSTEMS . |
| B1881 | Passenger Safety Belt Pretensioner Circuit Open | RCM | REFER to AIR BAG RESTRAINT SYSTEMS . |
| B1882 | Passenger Safety Belt Pretensioner Circuit Short to Battery | RCM | REFER to AIR BAG RESTRAINT SYSTEMS . |
| B1883 | Passenger Safety Belt Pretensioner Circuit Short to Ground | RCM | REFER to AIR BAG RESTRAINT SYSTEMS . |
| B1884 | PAD Warning Lamp Inoperative | RCM | REFER to AIR BAG RESTRAINT SYSTEMS . |
| B1885 | Driver Safety Belt Pretensioner Circuit Resistance Low on Squib | RCM | REFER to AIR BAG RESTRAINT SYSTEMS . |
| B1886 | Passenger Safety Belt Pretensioner Circuit Resistance Low on Squib | RCM | REFER to AIR BAG RESTRAINT SYSTEMS . |
| B1887 | Driver Air Bag Circuit Short to Ground | RCM | REFER to AIR BAG RESTRAINT SYSTEMS . |
| B1888 | Passenger Air Bag Circuit Short to Ground | RCM | REFER to AIR BAG RESTRAINT SYSTEMS . |
| B1889 | Passenger Air Bag Deactivate Module Sensor Obstructed | RCM | REFER to AIR BAG RESTRAINT SYSTEMS . |
| B1890 | PAD Warning Lamp Circuit Short to Battery | RCM | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B1891 | Air Bag tone Warning Indicator Circuit Short to Battery | RCM | REFER to AIR BAG RESTRAINT SYSTEMS . |
| B1892 | Air Bag Tone Warning Indicator Circuit Failure | RCM | REFER to AIR BAG RESTRAINT SYSTEMS . |
| B1901 | Air Bag Crash Sensor No. 1 Feed/Return Circuit Short to Ground | RCM | REFER to AIR BAG RESTRAINT SYSTEMS . |
| B1916 | Driver Air Bag Circuit Short to Battery | RCM | REFER to AIR BAG RESTRAINT SYSTEMS . |
| B1921 | Air Bag Diagnostic Monitor Ground Circuit Open | RCM | REFER to AIR BAG RESTRAINT SYSTEMS . |
| B1925 | Passenger Air Bag Circuit Short to Battery | RCM | REFER to AIR BAG RESTRAINT SYSTEMS . |
| B1932 | Driver Air Bag Circuit Open | RCM | REFER to AIR BAG RESTRAINT SYSTEMS . |
| B1933 | Passenger Air Bag Circuit Open | RCM | REFER to AIR BAG RESTRAINT SYSTEMS . |
| B1934 | Driver Air Bag Inflator Circuit Resistance Low on Squib | RCM | REFER to AIR BAG RESTRAINT SYSTEMS . |
| B1935 | Passenger Air Bag Inflator Circuit Resistance Low on Squib | RCM | REFER to AIR BAG RESTRAINT SYSTEMS . |
| B1941 | Air Bag Crash Sensor No. 1 Feed/Return Circuit Open | RCM | REFER to AIR BAG RESTRAINT SYSTEMS . |
| B2103 | Antenna Not Connected | PCM | Refer to ANTI-THEFT . |
| B2106 | Throttle Position Input Out of Range High | 4WD control module | REFER to TROUBLE SHOOTING - NO CODES - EEC-V - GASOLINE & NVG . |
| B2276 | Less Than Two Transmitters Programmed | Central security module | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B2425 | Remote Keyless Entry Out of Synchronization | Central security module | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B2431 | Transponder Programming Failure | PCM | REFER to ANTI-THEFT . |
| B2477 | Module Configuration Failure | Central security module | REFER to MODULE CONFIGURATION . |
| B2477 | Module Configuration Failure | GEM | REFER to MODULE CONFIGURATION . |
| B2477 | Module Configuration Failure | RCM | REFER to MODULE CONFIGURATION . |
| B9610 | Illuminated Entry Input Short Circuit to Ground | GEM | No Action |
| C1095 | ABS Hydraulic Pump Motor Circuit Failure | ABS module | REFER to ANTI-LOCK CONTROL . |
| C1145 | RF Wheel Speed Sensor Input Circuit Failure | ABS module | REFER to ANTI-LOCK CONTROL . |
| C1155 | LF Wheel Speed Sensor Input Circuit Failure | ABS module | REFER to ANTI-LOCK CONTROL . |
| C1230 | Wheel Speed Sensor Rear Center Input Circuit Failure | ABS module | REFER to ANTI-LOCK CONTROL . |
| C1233 | LF Wheel Speed Input Signal Missing | ABS module | REFER to ANTI-LOCK CONTROL . |
| C1234 | RF Wheel Speed Input Signal Missing | ABS module | REFER to ANTI-LOCK CONTROL . |
| C1237 | Rear Wheel Speed Input Signal Missing | ABS module | REFER to ANTI-LOCK CONTROL . |
| C1728 | Transfer Case Unable to Transition Between 2H and 4H | 4WD control module | REFER to FOUR- WHEEL DRIVE SYSTEMS . |
| C1729 | Transfer Case Unable to Transition Between 4H and 4L | 4WD control module | REFER to FOUR- WHEEL DRIVE SYSTEMS . |
| C1939 | Brake Pressure Switch Input Circuit Failure | ABS module | REFER to ANTI-LOCK CONTROL . |
| P0500 | Vehicle Speed Sensor (VSS) Malfunction | 4WD control module | Refer to ANTI-LOCK CONTROL . |
| P0500 | Vehicle Speed Sensor (VSS) Malfunction | GEM | REFER to FOUR- WHEEL DRIVE SYSTEMS . |
| P1804 | Transmission 4 -Wheel Drive High Indicator Circuit Failure | 4WD control module | REFER to FOUR- WHEEL DRIVE SYSTEMS . |
| P1806 | Transmission 4 -Wheel Drive High Indicator Circuit Short to Battery | 4WD control module | REFER to FOUR- WHEEL DRIVE SYSTEMS . |
| P1808 | Transmission 4 -Wheel Drive Low Indicator Circuit Failure | 4WD control module | REFER to FOUR- WHEEL DRIVE SYSTEMS . |
| P1810 | Transmission 4 -Wheel Drive Low Indicator Circuit Short to Battery | 4WD control module | REFER to FOUR- WHEEL DRIVE SYSTEMS . |
| P1812 | Transmission 4 -Wheel Drive Mode Select Circuit Failure | 4WD control module | REFER to FOUR- WHEEL DRIVE SYSTEMS . |
| P1815 | Transmission 4 -Wheel Drive Mode Select Circuit Short to Ground | 4WD control module | REFER to FOUR- WHEEL DRIVE SYSTEMS . |
| P1816 | Transmission Neutral Safety Switch Circuit Failure | 4WD control module | REFER to FOUR- WHEEL DRIVE SYSTEMS . |
| P1819 | Transmission Neutral Safety Switch Circuit Short to Ground | 4WD control module | REFER to FOUR- WHEEL DRIVE SYSTEMS . |
| P1849 | Transmission Transfer Case Contact Plate A Circuit Short to Ground | 4WD control module | REFER to FOUR- WHEEL DRIVE SYSTEMS . |
| P1853 | Transmission Transfer Case Contact Plate B Circuit Short to Ground | 4WD control module | REFER to FOUR- WHEEL DRIVE SYSTEMS . |
| P1857 | Transmission Transfer Case Contact Plate C Circuit Short to Ground | 4WD control module | REFER to FOUR- WHEEL DRIVE SYSTEMS . |
| P1861 | Transmission Transfer Case Contact Plate D Circuit Short to Ground | 4WD control module | REFER to FOUR- WHEEL DRIVE SYSTEMS . |
| P1867 | Transmission Transfer Case Contact Plate General Circuit Failure | 4WD control module | REFER to FOUR- WHEEL DRIVE SYSTEMS . |
| P1891 | Transmission Transfer Case Contact Plate Ground Return Circuit Open | 4WD control module | REFER to FOUR- WHEEL DRIVE SYSTEMS . |
DIAGNOSTIC TROUBLE CODE (DTC) CHART
Scheme 33
Inspection And Verification
- Verify the customer concern by operating the system.
- Visually inspect for obvious signs of electrical damage. VISUAL INSPECTION CHART Electrical Central junction box (CJB) fuse: 26 (10A) 10 (7.5A) Wiring harness Connector(s) Circuitry
- If the concern remains after the inspection, connect the diagnostic tool to the data link connector (DLC) located beneath the instrument panel and select the vehicle to be tested from the diagnostic tool menu. If the diagnostic tool does not communicate with the vehicle: check that the program card is correctly installed. check the connections to the vehicle. check the ignition switch position.
- If diagnostic tool still does not communicate with the vehicle, refer to the diagnostic tool manual.
- Carry out the DATA LINK DIAGNOSTICS test. If the diagnostic tool responds with: CKT914, CKT915 or CKT70 = ALL ECUS NO RESP/NOT EQUIP, refer to «PINPOINT TEST PC: DATA LINK DIAGNOSTICS TEST»(ref-205003-S02664299712005111600000) . NO RESPONSE/NOT EQUIP for GEM, go to «PINPOINT TEST A»(ref-205006-S07302407152005111600000) . SYSTEM PASSED, retrieve and record the continuous diagnostic trouble codes (DTCs), erase the continuous DTCs and carry out self-test diagnostics for the GEM.
- If the DTCs retrieved are related to the concern, go to the «GEM DIAGNOSTIC TROUBLE CODE (DTC) INDEX»(ref-205006-S26083135082005111600000) to continue diagnostics.
- If no DTCs related to the concern are retrieved, diagnose by symptom. See related article.
Symptom Chart
| Condition | Possible Sources | Action |
|---|---|---|
| No communication with the generic electronic module (GEM) | Central junction box (CJB) Fuse: 26 (10A). 10 (7.5A). Circuitry. GEM. | GO to PINPOINT TEST A . |
SYMPTOM CHART
Scheme 34
Scheme 35
- Verify the customer concern by operating the system.
- Visually inspect for obvious signs of electrical damage. VISUAL INSPECTION CHART Electrical Battery junction box (BJB) fuse: 9 (20A) 11 (50A) 33 (15A) Central junction box (CJB) fuse 11 (7.5A) Wiring harness Connector(s) Circuitry
- If the concern remains after the inspection, connect the diagnostic tool to the data link connector (DLC) located beneath the instrument panel and select the vehicle to be tested from the diagnostic tool menu. If the diagnostic tool does not communicate with the vehicle: check that the program card is correctly installed. check the connections to the vehicle. check the ignition switch position.
- If diagnostic tool still does not communicate with the vehicle, refer to the diagnostic tool manual.
- Carry out the DATA LINK DIAGNOSTICS test. If the diagnostic tool responds with: CKT914, CKT915 or CKT70 = ALL ECUS NO RESP/NOT EQUIP, refer to «PINPOINT TEST PC: DATA LINK DIAGNOSTICS TEST»(ref-205003-S02664299712005111600000) . NO RESPONSE/NOT EQUIP for central security module, go to «PINPOINT TEST B»(ref-205006-S20032047072005111600000) . SYSTEM PASSED, retrieve and record the continuous diagnostic trouble codes (DTCs), erase the continuous DTCs and carry out self-test diagnostics for the central security module.
- If the DTCs retrieved are related to the concern, go to the «DIAGNOSTIC TROUBLE CODE CHART»(ref-205006-S26083135082005111600000) to continue diagnostics.
- If no DTCs related to the concern are retrieved, diagnose by symptom. See related article.
| Condition | Possible Sources | Action |
|---|---|---|
| No communication with the central security module | Battery junction box (BJB) fuse: 9 (20A). 11 (50A). 33 (15A). Central junction box (CJB) fuse 11 (7.5A). Circuitry. Central security module. | GO to PINPOINT TEST B . |
SYMPTOM CHART
Scheme 36
Scheme 37
Scheme 38
Scheme 39
- Depower the supplemental restraint system (SRS). For additional information, refer to «AIR BAG RESTRAINT SYSTEMS»(ref-150629) .
- Remove the radio chassis.
- Remove the center instrument panel finish panel. Remove the screws. Remove the center instrument panel finish panel. Disconnect electrical connectors.
- Remove the generic electronic module (GEM). Remove the screw. Disconnect the two connectors from the GEM. Remove the GEM.
- To install, reverse the removal procedure. Check for correct operation.
Scheme 40
Scheme 41
Scheme 42
- Disconnect the battery ground cable. For additional information, refer to «BATTERY»(ref-204997-S30789322942005111600000) .
- Remove the passenger air bag module. Refer to «PASSENGER-SIDE AIR BAG MODULE»(ref-150629-S41799647502002112000000) .
- Reposition the central security module. Remove the three screws. Pull the central security module straight out from the bracket.
- Disconnect the two electrical connectors.
- Remove the bracket from the central security module.
- To install, reverse the removal procedure.
