GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Heat Shrink Tube Overlap - mm (inch) | 12.7 (0.5) |
| Wire Insulation Removal Length (Twist Side) - mm (inch) | 37.2 (1.5) |
| Wire Insulation Removal Length (Receiving Side) - mm (inch) | 19.5 (0.75) |
| Raychem SCT(R) Heat Shrink Tubing, Motorcraft Part Number WT-5627 | ESB-M99D56-A2 |
GENERAL SPECIFICATIONS
The module communications network consists of the following items
- Restraints Control Module (RCM)
- Generic Electronic Module (GEM)
- 4-wheel Drive (4WD) control module
- 4-wheel Anti-Lock Brake (4WABS) control module
- Powertrain Control Module (PCM)
- Central Security Module
- Standard Corporate Protocol (SCP) communications network
- International Standard Organization (ISO) communications network
Refer to COMPUTER DATA LINES for schematic and connector information.
Scheme 1
See also:
• SELF-DIAGNOSTICS - EEC-V - GASOLINE & NGV
