Inspection & Verification
- Verify the customer concern.
- Visually inspect for obvious signs of electrical damage. Refer to the following chart: VISUAL INSPECTION Electrical Central Junction Box (CJB) Fuse 17 (20 A) Damaged Wiring Harness Loose Or Corroded Connectors
- If the concern remains after the inspection, connect the diagnostic tool to the Data Link Connector (DLC) located beneath the instrument panel and select the vehicle to be tested from the diagnostic tool menu. If the diagnostic tool does not communicate with the vehicle: check that the program card is correctly installed. check the connections to the vehicle. check the ignition switch is in RUN. If the diagnostic tool still does not communicate with the vehicle, go to «PINPOINT TEST I: NO MODULE / NETWORK COMMUNICATION - NO POWER TO THE DIAGNOSTIC TOOL»(ref-205003-S20789426022005111600000) .
- Go to «PINPOINT TEST PC: DATA LINK DIAGNOSTICS TEST»(ref-205003-S02664299712005111600000) .
Scheme 2
Symptom Chart
| Condition | Possible Sources | Action |
|---|---|---|
| The 4-wheel Anti-Lock Brake (4WABS) Control Module Does Not Respond To The Diagnostic Tool | Circuit Or Connection In International Standards Organization (ISO) 9141 Network. 4WABS Control Module (If Equipped). | GO to PINPOINT TEST A: THE 4-WHEEL ANTI-LOCK BRAKE (4WABS) CONTROL MODULE DOES NOT RESPOND TO THE DIAGNOSTIC TOOL . |
| The Generic Electronic Module (GEM) Does Not Respond To The Diagnostic Tool | Circuit Or Connection In ISO 9141 Network GEM | GO To PINPOINT TEST B: THE GENERIC ELECTRONIC MODULE (GEM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL . |
| The Restraints Control Module (RCM) Does Not Respond To The Diagnostic Tool | Circuit Or Connection In ISO 9141 Network RCM | GO To PINPOINT TEST C: THE RESTRAINT CONTROL MODULE (RCM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL . |
| The Central Security Module Does Not Respond To The Diagnostic Tool | Circuit Or Connection In ISO 9141 Network Central Security Module (If Equipped) | GO To PINPOINT TEST D: THE CENTRAL SECURITY MODULE DOES NOT RESPOND TO THE DIAGNOSTIC TOOL . |
| The Powertrain Control Module (PCM) Does Not Respond To The Diagnostic Tool | Circuit Or Connection In Standard Corporate Protocol (SCP) Network PCM | GO To PINPOINT TEST E: THE POWERTRAIN CONTROL MODULE (PCM) DOES NOT RESPOND TO THE DIAGNOSTIC TOOL . |
| The Four Wheel Drive (4WD) Control Module Does Not Respond To The Diagnostic Tool | Circuit Or Connection In SCP Network 4WD Control Module (If Equipped) | GO To PINPOINT TEST F: THE FOUR WHEEL DRIVE (4WD) CONTROL MODULE DOES NOT RESPOND TO THE DIAGNOSTIC TOOL . |
| No ISO 9141 Network Module/Network Communication | Circuit Or Connection In ISO 9141 Network ISO 9141 networked modules | GO To PINPOINT TEST G: NO MODULE / NETWORK COMMUNICATION - ISO 9141 NETWORK . |
| No SCP Module/Network Communication | Circuit Or Connection In SCP Network SCP Networked Modules | GO To PINPOINT TEST H: NO MODULE / NETWORK COMMUNICATION - SCP LINK . |
| No Module/Network Communication - No Power To The Diagnostic Tool | DLC Central Junction Box (CJB) Fuse 17 (20 A) Circuitry Diagnostic Tool | GO To PINPOINT TEST I: NO MODULE / NETWORK COMMUNICATION - NO POWER TO THE DIAGNOSTIC TOOL . |
SYMPTOM CHART
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
Scheme 12
Scheme 13
Scheme 14
Scheme 15
Scheme 16
Scheme 17
Scheme 18
Scheme 19
Scheme 20
Scheme 21
Scheme 22
Scheme 23
Scheme 24
Scheme 25
Scheme 26
Scheme 27
Scheme 28
Scheme 29
Scheme 30
Scheme 31
- Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING & CABLES»(ref-204997) .
- Strip the wires.
- Solder the wires. Install the heat shrink tube. Twist the wires together. Solder the wires together.
- Bend the wires back in a straight line.
- Position the (A) heat shrink tube over the (B) wire repair. Overlap the heat shrink tube on both wires.
- Use the heat gun to heat the repaired area until adhesive flows out both ends of the heat shrink tube.
- Reconnect the battery ground cable.
