Automatic Transmission Cooling: Maintenance Ford Ranger I

TRANSMISSION FLUID COOLER - BACKFLUSHING & CLEANING

For additional information, refer to OVERHAUL - 5R44E & 5R55E - RANGER .

COOLER, FLUID

For additional information, refer to ENGINE COOLING .

Scheme 729

Scheme 730

Scheme 731

1. Raise the vehicle on a hoist.
2. Disconnect the fluid cooler inlet tube (7A030) and the fluid cooler tube (7A031) from the radiator (8005).
3. Disconnect the fluid cooler inlet tube and the fluid cooler tube from the transmission
4. Remove the transmission fluid cooler line clip, the fluid cooler inlet tube and the fluid cooler tube.

Scheme 732

Scheme 733

Scheme 734

1. Position the fluid cooler inlet tube and the fluid cooler tube. Install the transmission fluid cooler line clip on the engine.
2. Connect the fluid cooler inlet tube and the fluid cooler tube to the transmission.
3. Connect the fluid cooler inlet tube and the fluid cooler tube to the radiator.

Scheme 735

Scheme 736

Scheme 737

1. Raise the vehicle on a hoist.
2. Disconnect the fluid cooler inlet tube (7A030) from the radiator (8005).
3. Disconnect the fluid cooler inlet tube and the fluid cooler tube (7A031) from the transmission.
4. Remove the transmission fluid cooler line clip, the fluid cooler inlet tube and the fluid cooler tube from the engine.

Scheme 738

Scheme 739

Scheme 740

1. Position the fluid cooler inlet tube and fluid cooler tube. Install the transmission fluid cooler line clip on the engine.
2. Connect the fluid cooler inlet tube and fluid cooler tube to the transmission.
3. Connect the fluid cooler inlet tube and fluid cooler tube to the radiator.

Scheme 741

Scheme 742

Scheme 743

1. Raise the vehicle on a hoist.
2. Disconnect the fluid cooler inlet tube (7A030) and the fluid cooler tube (7A031) from the radiator (8005).
3. Disconnect the fluid cooler inlet tube and the fluid cooler tube from the transmission.
4. Remove the transmission fluid cooler line clip, the fluid cooler inlet tube and the fluid cooler tube and C-clips.

Scheme 744

Scheme 745

Scheme 746

1. Position the fluid cooler inlet tube and fluid cooler tube. Install the transmission fluid cooler line clip and C-clips.
2. Connect the fluid cooler inlet tube and fluid cooler tube to the transmission
3. Connect the fluid cooler inlet tube and fluid cooler tube to the radiator.
