Engine Mechanical - 3.7L: Component Locations Ford Mustang V рестайлинг

Mechanical 180 illustrations ~2693 words

Special Tool(s)

SPECIAL TOOLS REFERENCE Handle 205-153 (T80T-4000-W) Installer, Differential Bearing Cone 205-142 (T80T-4000-J) Installer, Spark Plug Tube Seal 303-1247/2 Remover, Spark Plug Tube Seal 303-1247/1

Scheme 296

Scheme 296: Special Tool(s)
Scheme 296: Special Tool(s)

Scheme 297

Scheme 297
Scheme 297

Scheme 298

Scheme 298
Scheme 298

Scheme 299

Scheme 299
Scheme 299

SPECIAL TOOLS REFERENCE Handle 205-153 (T80T-4000-W) Installer, Differential Bearing Cone 205-142 (T80T-4000-J) Installer, Spark Plug Tube Seal 303-1247/2 Remover, Spark Plug Tube Seal 303-1247/1

Scheme 300

Scheme 300: Special Tool(s)
Scheme 300: Special Tool(s)

Scheme 301

Scheme 301
Scheme 301

SPECIAL TOOLS REFERENCE 3 Jaw Puller 303-D121 or equivalent Installer, Front Cover Oil Seal 303-335 Replacer, Crankshaft Vibration Damper 303-102 (T74P-6316-B) Strap Wrench 303-D055 (D85L-6000-A) or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

Scheme 302

Scheme 302: Special Tool(s)
Scheme 302: Special Tool(s)

Scheme 303

Scheme 303
Scheme 303

Scheme 304

Scheme 304
Scheme 304

Scheme 305

Scheme 305
Scheme 305

SPECIAL TOOLS REFERENCE Installer, Crankshaft Vibration Damper 303-102 (T74P-6316-B) Installer, Front Crankshaft Seal 303-1251 Remover, Oil Seal 303-409 (T92C-6700CH)

Scheme 306

Scheme 306: Special Tool(s)
Scheme 306: Special Tool(s)

Scheme 307

Scheme 307
Scheme 307

Scheme 308

Scheme 308
Scheme 308

SPECIAL TOOLS REFERENCE Handle 205-153 (T80T-4000-W) Installer, Spindle Bearing 205-149 (T80T-4000-R) Installer, Spindle Bearing 205-150 (T80T-4000-S)

Scheme 309

Scheme 309: Special Tool(s)
Scheme 309: Special Tool(s)

Scheme 310

Scheme 310
Scheme 310

Scheme 311

Scheme 311
Scheme 311

SPECIAL TOOLS REFERENCE Remover/Installer, Water Tube Seal 303-1528

Scheme 312

Scheme 312: Special Tool(s)
Scheme 312: Special Tool(s)

Scheme 313

Scheme 313
Scheme 313
ItemPart NumberDescription
16B055Front cover radial seal

FRONT COVER RADIAL SEAL REFERENCE CHART

SPECIAL TOOLS REFERENCE Hold Down, Secondary Chain 303-1530 Tool, Camshaft Holding 303-1248

Scheme 314

Scheme 314: Special Tool(s)
Scheme 314: Special Tool(s)

Scheme 315

Scheme 315
Scheme 315

Scheme 316

Scheme 316
Scheme 316
ItemPart NumberDescription
16256LH intake Variable Camshaft Timing (VCT) assembly
26C525LH exhaust VCT assembly
36K297LH secondary timing chain tensioner shoe
46B274LH primary timing chain guide
56268Primary timing chain
66306Crankshaft timing chain sprocket
76L266Primary timing chain tensioner
86K255RH primary timing chain tensioner arm
96K297RH secondary timing chain tensioner shoe
106C525RH exhaust VCT assembly
116256RH intake VCT assembly
126K297RH primary timing chain guide
138501Channel cover plate
146K297LH primary timing chain guide
156268RH secondary timing chain
166K254RH secondary timing chain tensioner
176K254LH secondary timing chain tensioner
186268LH secondary timing chain

TIMING DRIVE COMPONENTS REFERENCE CHART

SPECIAL TOOLS REFERENCE Hold Down, Secondary Chain 303-1530 Tool, Camshaft Holding 303-1248

Scheme 317

Scheme 317: Special Tool(s)
Scheme 317: Special Tool(s)

Scheme 318

Scheme 318
Scheme 318

SPECIAL TOOLS REFERENCE Hold Down, Secondary Chain 303-1530 Tool, Camshaft Holding 303-1248

Scheme 319

Scheme 319: Special Tool(s)
Scheme 319: Special Tool(s)

Scheme 320

Scheme 320
Scheme 320

SPECIAL TOOLS REFERENCE Compressor, Valve Spring 303-300 (T87C-6565-A) Compressor, Valve Spring 303-350 (T89P-6565-A) Compressor, Valve Spring 303-1249 Installer, Valve Stem Oil Seal 303-470 (T94P-6510-CH)

Scheme 321

Scheme 321: Special Tool(s)
Scheme 321: Special Tool(s)

Scheme 322

Scheme 322
Scheme 322

Scheme 323

Scheme 323
Scheme 323

Scheme 324

Scheme 324
Scheme 324

SPECIAL TOOLS REFERENCE Eye, Engine Lift 303-1245 Lift Eye, RH Front 303-1529 Support Bar, Engine 303-F072

Scheme 325

Scheme 325: Special Tool(s)
Scheme 325: Special Tool(s)

Scheme 326

Scheme 326
Scheme 326

Scheme 327

Scheme 327
Scheme 327

SPECIAL TOOLS REFERENCE Eye, Engine Lift 303-1245 Lift Eye, RH Front 303-1529 Support Bar, Engine 303-F072 Tool, Camshaft Holding 303-1248

Scheme 328

Scheme 328: Special Tool(s)
Scheme 328: Special Tool(s)

Scheme 329

Scheme 329
Scheme 329

Scheme 330

Scheme 330
Scheme 330

Scheme 331

Scheme 331
Scheme 331

SPECIAL TOOLS REFERENCE Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

SPECIAL TOOLS REFERENCE Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

SPECIAL TOOLS REFERENCE Handle 205-153 (T80T-4000-W) Installer, Rear Main Seal 303-1250 Remover, Crankshaft Rear Oil Seal 303-519 (T95P-6701-EH) Slide Hammer 307-005 (T59L-100-B)

Scheme 332

Scheme 332: Special Tool(s)
Scheme 332: Special Tool(s)

Scheme 333

Scheme 333
Scheme 333

Scheme 334

Scheme 334
Scheme 334

Scheme 335

Scheme 335
Scheme 335

SPECIAL TOOLS REFERENCE Eye, Engine Lift 303-1245 Handle 205-153 (T80T-4000-W) Installer, Rear Main Seal 303-1250 Lift Eye, RH Front 303-1529 Remover, Crankshaft Rear Oil Seal 303-519 (T95P-6701-EH) Slide Hammer 307-005 (T59L-100-B) Support Bar, Engine 303-F072 Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

Scheme 336

Scheme 336: Special Tool(s)
Scheme 336: Special Tool(s)

Scheme 337

Scheme 337
Scheme 337

Scheme 338

Scheme 338
Scheme 338

Scheme 339

Scheme 339
Scheme 339

Scheme 340

Scheme 340
Scheme 340

Scheme 341

Scheme 341
Scheme 341

SPECIAL TOOLS REFERENCE Eye, Engine Lift 303-1245 Lift Eye, RH Front 303-1529 Support Bar, Engine 303-F072

Scheme 342

Scheme 342: Special Tool(s)
Scheme 342: Special Tool(s)

Scheme 343

Scheme 343
Scheme 343

Scheme 344

Scheme 344: Engine Support Insulator - LH
Scheme 344: Engine Support Insulator - LH
ItemPart NumberDescription
1W712530LH engine mount bracket-to-engine mount nut
2W500723LH engine mount bracket bolt (3 required)
36B033LH engine mount bracket
4W707641LH engine mount bolt (2 required)
56038LH engine mount

ENGINE SUPPORT INSULATOR REFERENCE CHART

Scheme 345

Scheme 345: Engine Support Insulator - RH (View 1 of 2)
Scheme 345: Engine Support Insulator - RH (View 1 of 2)
ItemPart NumberDescription
1W520103Wiring harness retainer bracket nut
2Wiring harness retainer bracket (part of 14B060)
3Wiring harness retainer (part of 14B060) (manual transmission only)
4W520103Transmission cooling tube retainer nut (automatic transmission only)
5Transmission cooling tubes retainer (part of 7H420) (automatic transmission only)

ENGINE SUPPORT INSULATOR REFERENCE CHART

Scheme 346

Scheme 346: Engine Support Insulator - RH (View 2 of 2)
Scheme 346: Engine Support Insulator - RH (View 2 of 2)
ItemPart NumberDescription
1W712530RH engine mount bracket-to-engine mount nut
2W500723RH engine mount bracket bolt
3W714924RH engine mount bracket stud bolt (2 required)
46037RH engine mount bracket
5W707641RH engine mount bolt (2 required)
66038RH engine mount

ENGINE SUPPORT INSULATOR REFERENCE CHART

SPECIAL TOOLS REFERENCE Eye, Engine Lift 303-1245 Lift Eye, RH Front 303-1529 2,200# Floor Crane, Fold Away 300-OTC1819E Retainer, Torque Converter 307-346 (T97T-7902-A) or equivalent Spreader Bar 303-D089 (D93P-6001-A3) or equivalent

Scheme 347

Scheme 347: Special Tool(s)
Scheme 347: Special Tool(s)

Scheme 348

Scheme 348
Scheme 348

Scheme 349

Scheme 349
Scheme 349

Scheme 350

Scheme 350
Scheme 350
WARNINGDo not smoke, carry lighted tobacco or have an open flame of any type when working on or near any fuel-related component. Highly flammable mixtures are always present and may be ignited. Failure to follow these instructions may result in serious personal injury.
WARNINGBefore working on or disconnecting any of the fuel tubes or fuel system components, relieve the fuel system pressure to prevent accidental spraying of fuel. Fuel in the fuel system remains under high pressure, even when the engine is not running. Failure to follow this instruction may result in serious personal injury.

Scheme 351

Scheme 351
Scheme 351

Scheme 352

Scheme 352
Scheme 352

Scheme 353

Scheme 353
Scheme 353

Scheme 354

Scheme 354
Scheme 354

Scheme 355

Scheme 355
Scheme 355

Scheme 356

Scheme 356
Scheme 356

Scheme 357

Scheme 357
Scheme 357

Scheme 358

Scheme 358
Scheme 358

Scheme 359

Scheme 359
Scheme 359

Scheme 360

Scheme 360
Scheme 360

Scheme 361

Scheme 361
Scheme 361

Scheme 362

Scheme 362
Scheme 362

Scheme 363

Scheme 363
Scheme 363

Scheme 364

Scheme 364
Scheme 364

Scheme 365

Scheme 365
Scheme 365

Scheme 366

Scheme 366
Scheme 366

Scheme 367

Scheme 367
Scheme 367

Scheme 368

Scheme 368
Scheme 368

Scheme 369

Scheme 369
Scheme 369

Scheme 370

Scheme 370
Scheme 370

Scheme 371

Scheme 371
Scheme 371

Scheme 372

Scheme 372
Scheme 372

Scheme 373

Scheme 373
Scheme 373

Scheme 374

Scheme 374
Scheme 374

Scheme 375

Scheme 375
Scheme 375

Scheme 376

Scheme 376
Scheme 376

Scheme 377

Scheme 377
Scheme 377

Scheme 378

Scheme 378
Scheme 378

Scheme 379

Scheme 379
Scheme 379

Scheme 380

Scheme 380
Scheme 380

Scheme 381

Scheme 381
Scheme 381

Scheme 382

Scheme 382
Scheme 382

Scheme 383

Scheme 383
Scheme 383

Scheme 384

Scheme 384
Scheme 384

Scheme 385

Scheme 385
Scheme 385

Scheme 386

Scheme 386
Scheme 386

Scheme 387

Scheme 387
Scheme 387

Scheme 388

Scheme 388
Scheme 388

Scheme 389

Scheme 389
Scheme 389

Scheme 390

Scheme 390
Scheme 390

Scheme 391

Scheme 391
Scheme 391

Scheme 392

Scheme 392
Scheme 392

Scheme 393

Scheme 393
Scheme 393

Scheme 394

Scheme 394
Scheme 394
  1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-439777) article.
  2. Release the fuel system pressure. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-439829) article.
  3. Remove the battery tray. For additional information, refer to «BATTERY, MOUNTING & CABLES»(ref-439815) article.
  4. Drain the engine cooling system. For additional Information, refer to «ENGINE COOLING SYSTEM»(ref-439830) article.
  5. Detach the 2 windshield washer hose retainers and the 8 hood insulation pin-type retainers (2 shown in illustration).
  6. Detach the 2 windshield washer hose retainers and disconnect the 2 windshield washer hose C-Lock Couplers. For additional information, refer to «WIPER SYSTEM & WASHER SYSTEM»(ref-439820) article.
  7. Remove the 4 bolts (2 shown in illustration) and the hood.
  8. If equipped, remove the 4 nuts (2 shown in illustration) and the strut tower cross brace.
  9. If equipped, detach the 2 retainers and remove the engine appearance cover.
  10. Remove the 2 LH cowl vent screen plastic rivets.
  11. Lift the cowl screen and remove the bolt and ground strap. Detach the wiring harness retainer from the cowl.
  12. Remove the engine Air Cleaner (ACL) and ACL outlet pipe. For additional information, refer to «INTAKE AIR DISTRIBUTION SYSTEM & INTAKE AIR FILTERING SYSTEM»(ref-439816) article.
  13. Remove the degas bottle. For additional information, refer to «ENGINE COOLING SYSTEM»(ref-439830) article.
  14. Remove the accessory drive belt and A/C compressor belt. For additional information, refer to «ENGINE ACCESSORY DRIVE BELTS»(ref-439789) article.
  15. Disconnect the upper and lower radiator hoses from the thermostat housing.
  16. Disconnect the fuel supply tube quick connect coupling from the fuel rail. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-439829) article.
  17. Disconnect Evaporative Emission (EVAP) tube from intake manifold. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-439829) article. Detach the EVAP tube retainer from the intake manifold.
  18. Detach the fuel supply tube and EVAP tube retainer from the LH valve cover and position aside.
  19. Disconnect the brake booster vacuum hose from the engine.
  20. Disconnect the engine wiring harness electrical connector. Detach the wiring harness pin-type retainer from the bracket.
  21. Disconnect the middle PCM electrical connector. Detach the PCM wiring harness pin-type retainer.
  22. Disconnect the 2 heater hose couplings (1 shown in illustration) at the RH rear of the engine. For additional information, refer to «HVAC - CLIMATE CONTROL SYSTEM - GENERAL INFORMATION & DIAGNOSTICS»(ref-439786) article.
  23. Detach and disconnect the RH and LH Heated Oxygen Sensor (HO2S) electrical connectors.
  24. Remove the nut and disconnect the generator B+ cable.
  25. Disconnect the generator electrical connector. Detach the 2 generator wiring harness retainer from the valve cover and valve cover stud bolt.
  26. Remove the nut and the LH valve cover stud bolt wiring harness bracket.
  27. If equipped, disconnect the block heater electrical connector.
  28. Install the LH engine lift eye.
  29. Detach the wiring harness retainer from the A/C compressor stud bolt.
  30. Remove the A/C compressor nut and the stud.
  31. Loosen the A/C compressor bolt and stud bolt and position the A/C compressor aside.
  32. Install the RH front lift eye.
  33. Remove the RH and LH engine mount-to-engine bracket mount nuts.
  34. Remove the 3 bolts and lower the underbody shield.
  35. Remove the drain plug and drain the engine oil. Install the drain plug and tighten to 27 Nm (20 lb-ft).
  36. Remove and discard the engine oil filter.
  37. Remove the 4 nuts (2 shown in illustration) and the front crossmember brace.
  38. Remove the starter motor. For additional information, refer to «STARTING SYSTEM»(ref-439822) article.
  39. Remove the 2 pin-type retainers and the access cover.
  40. Remove the 4 torque converter nuts.
  41. Remove and discard the 2 LH and RH catalytic converter-to-exhaust manifold nuts.
  42. Remove the bolt and the ground wire from the rear of the RH cylinder head.
  43. Detach the 2 wiring harness retainers (1 shown in illustration) from the 2 upper transmission stud bolts.
  44. Remove the 4 upper bellhousing-to-engine bolts and stud bolts (2 shown in illustration).
  45. Loosen the engine-to-bellhousing bolt.
  46. Loosen the bellhousing-to-engine bolt.
  47. Remove the oil pan-to-bellhousing bolt.
  48. Remove the 2 LH bellhousing-to-oil pan bolts.
  49. Remove the LH bellhousing-to-engine bolt.
  50. Remove the nut from the rear side of the RH engine mount bracket and position the wiring harness retainer aside.
  51. Remove the nut from the front side of the RH engine mount bracket and position the transmission cooler tube clamp aside.
  52. Remove the stud bolt from the front side of the RH engine mount bracket.
  53. Remove the bolt from the front side of the LH engine mount bracket.
  54. Raise the underbody shield and install the 3 bolts for clearance for the floor crane. Do not torque at this time.
  55. Support the bellhousing of the transmission with a suitable floor jack and a block of wood.
  56. Remove the engine-to-bellhousing bolt.
  57. Remove the bellhousing-to-engine bolt.
  58. Using the Floor Crane and Spreader Bar, support the engine.
  59. Remove the 2 LH engine mount bracket bolts and remove the bracket.
  60. Remove the RH engine mount bracket bolt, stud bolt and remove the bracket.
  61. Using the Floor Crane and Spreader Bar, remove the engine.
  62. Install the Torque Converter Retainer.

Scheme 395

Scheme 395
Scheme 395

SPECIAL TOOLS REFERENCE Eye, Engine Lift 303-1245 Lift Eye, RH Front 303-1529 2,200# Floor Crane, Fold Away 300-OTC1819E Spreader Bar 303-D089 (D93P-6001-A3) or equivalent

Scheme 396

Scheme 396: Special Tool(s)
Scheme 396: Special Tool(s)

Scheme 397

Scheme 397
Scheme 397

Scheme 398

Scheme 398
Scheme 398

Scheme 399

Scheme 399
Scheme 399
WARNINGDo not smoke, carry lighted tobacco or have an open flame of any type when working on or near any fuel-related component. Highly flammable mixtures are always present and may be ignited. Failure to follow these instructions may result in serious personal injury.
WARNINGBefore working on or disconnecting any of the fuel tubes or fuel system components, relieve the fuel system pressure to prevent accidental spraying of fuel. Fuel in the fuel system remains under high pressure, even when the engine is not running. Failure to follow this instruction may result in serious personal injury.

Scheme 400

Scheme 400
Scheme 400

Scheme 401

Scheme 401
Scheme 401

Scheme 402

Scheme 402
Scheme 402

Scheme 403

Scheme 403
Scheme 403

Scheme 404

Scheme 404
Scheme 404

Scheme 405

Scheme 405
Scheme 405

Scheme 406

Scheme 406
Scheme 406

Scheme 407

Scheme 407
Scheme 407

Scheme 408

Scheme 408
Scheme 408

Scheme 409

Scheme 409
Scheme 409

Scheme 410

Scheme 410
Scheme 410

Scheme 411

Scheme 411
Scheme 411

Scheme 412

Scheme 412
Scheme 412

Scheme 413

Scheme 413
Scheme 413

Scheme 414

Scheme 414
Scheme 414

Scheme 415

Scheme 415
Scheme 415

Scheme 416

Scheme 416
Scheme 416

Scheme 417

Scheme 417
Scheme 417

Scheme 418

Scheme 418
Scheme 418

Scheme 419

Scheme 419
Scheme 419

Scheme 420

Scheme 420
Scheme 420

Scheme 421

Scheme 421
Scheme 421

Scheme 422

Scheme 422
Scheme 422

Scheme 423

Scheme 423
Scheme 423

Scheme 424

Scheme 424
Scheme 424

Scheme 425

Scheme 425
Scheme 425

Scheme 426

Scheme 426
Scheme 426

Scheme 427

Scheme 427
Scheme 427

Scheme 428

Scheme 428
Scheme 428

Scheme 429

Scheme 429
Scheme 429

Scheme 430

Scheme 430
Scheme 430

Scheme 431

Scheme 431
Scheme 431

Scheme 432

Scheme 432
Scheme 432

Scheme 433

Scheme 433
Scheme 433

Scheme 434

Scheme 434
Scheme 434

Scheme 435

Scheme 435
Scheme 435

Scheme 436

Scheme 436
Scheme 436

Scheme 437

Scheme 437
Scheme 437

Scheme 438

Scheme 438
Scheme 438

Scheme 439

Scheme 439
Scheme 439

Scheme 440

Scheme 440
Scheme 440

Scheme 441

Scheme 441
Scheme 441
  1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-439777) article.
  2. Release the fuel system pressure. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-439829) article.
  3. Remove the battery tray. For additional information, refer to «BATTERY, MOUNTING & CABLES»(ref-439815) article.
  4. Drain the engine cooling system. For additional Information, refer to «ENGINE COOLING SYSTEM»(ref-439830) article.
  5. Detach the 2 windshield washer hose retainers and the 8 hood insulation pin-type retainers (2 shown in illustration).
  6. Detach the 2 windshield washer hose retainers and disconnect the 2 windshield washer hose C-Lock Couplers. For additional information, refer to «WIPER SYSTEM & WASHER SYSTEM»(ref-439820) article.
  7. Remove the 4 bolts (2 shown in illustration) and the hood.
  8. If equipped, remove the 4 nuts (2 shown in illustration) and the strut tower cross brace.
  9. If equipped, detach the 2 retainers and remove the engine appearance cover.
  10. Remove the 2 LH cowl vent screen plastic rivets.
  11. Lift the cowl screen and remove the bolt and ground strap. Detach the wiring harness retainer from the cowl.
  12. Remove the engine Air Cleaner (ACL) and ACL outlet pipe. For additional information, refer to «INTAKE AIR DISTRIBUTION SYSTEM & INTAKE AIR FILTERING SYSTEM»(ref-439816) article.
  13. Remove the degas bottle. For additional information, refer to «ENGINE COOLING SYSTEM»(ref-439830) article.
  14. Remove the accessory drive belt and A/C compressor belt. For additional information, refer to «ENGINE ACCESSORY DRIVE BELTS»(ref-439789) article.
  15. Disconnect the upper and lower radiator hoses from the thermostat housing.
  16. Disconnect the fuel supply tube quick connect coupling from the fuel rail. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-439829) article.
  17. Disconnect Evaporative Emission (EVAP) tube from intake manifold. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-439829) article. Detach the EVAP tube retainer from the intake manifold.
  18. Detach the fuel supply tube and EVAP tube retainer from the LH valve cover and position aside.
  19. Disconnect the brake booster vacuum hose from the engine.
  20. Disconnect the engine wiring harness electrical connector. Detach the wiring harness pin-type retainer from the bracket.
  21. Disconnect the middle PCM electrical connector. Detach the PCM wiring harness pin-type retainer.
  22. Disconnect the 2 heater hose couplings (1 shown in illustration) at the RH rear of the engine. For additional information, refer to «HVAC - CLIMATE CONTROL SYSTEM - GENERAL INFORMATION & DIAGNOSTICS»(ref-439786) article.
  23. Detach and disconnect the RH and LH Heated Oxygen Sensor (HO2S) electrical connectors.
  24. Remove the nut and disconnect the generator B+ cable.
  25. Disconnect the generator electrical connector. Detach the generator wiring harness retainer from the valve cover stud bolt.
  26. Remove the nut and the LH valve cover stud bolt wiring harness bracket.
  27. If equipped, disconnect the block heater electrical connector.
  28. Install the LH engine lift eye.
  29. Detach the wiring harness retainer from the A/C compressor stud bolt.
  30. Remove the A/C compressor nut and the stud.
  31. Loosen the A/C compressor bolt and stud bolt and position the A/C compressor aside.
  32. Install the RH front lift eye.
  33. Remove the RH and LH engine mount-to-engine bracket mount nuts.
  34. Remove the 3 bolts and lower the underbody shield.
  35. Remove the drain plug and drain the engine oil. Install the drain plug and tighten to 27 Nm (20 lb-ft).
  36. Remove and discard the engine oil filter.
  37. Remove the 4 nuts (2 shown in illustration) and the front crossmember brace.
  38. Remove the starter motor. For additional information, refer to «STARTING SYSTEM»(ref-439822) article.
  39. Remove the 2 pin-type retainers and the access cover.
  40. Remove and discard the 2 LH and RH catalytic converter-to-exhaust manifold nuts.
  41. Remove the bolt and the ground wire from the rear of the RH cylinder head.
  42. Detach the 2 wiring harness retainers (1 shown in illustration) from the 2 upper transmission stud bolts.
  43. Remove the 4 upper bellhousing-to-engine bolt and stud bolts (2 shown in illustration).
  44. Loosen the engine-to-bellhousing bolt.
  45. Loosen the LH bellhousing-to-oil pan bolt.
  46. Remove the oil pan-to-bellhousing bolt.
  47. Remove the LH bellhousing-to-engine bolt and LH bellhousing-to-oil pan stud bolt.
  48. Remove the nut from the rear side of the RH engine mount bracket stud bolt and position the wiring harness retainer aside.
  49. Detach the wiring harness retainer from the front side of the RH engine mount bracket stud bolt and position aside.
  50. Remove the stud bolt from the front side of the RH engine mount bracket.
  51. Remove the bolt from the front side of the LH engine mount bracket.
  52. Raise the underbody shield and install the 3 bolts for clearance for the floor crane. Do not torque at this time.
  53. Support the front of the transmission with a suitable floor jack and a block of wood.
  54. Remove the engine-to-bellhousing bolt.
  55. Remove the LH bellhousing-to-oil pan bolt.
  56. Using the Floor Crane and Spreader Bar, support the engine.
  57. Remove the 2 LH engine mount bracket bolts and remove the bracket.
  58. Remove the RH engine mount bracket bolt, stud bolt and remove the bracket.
  59. Using the Floor Crane and Spreader Bar, remove the engine.

Scheme 442

Scheme 442
Scheme 442

SPECIAL TOOLS REFERENCE 3 Jaw Puller 303-D121 Handle 205-153 (T80T-4000-W) 2,200# Floor Crane, Fold Away 300-OTC1819E Hold Down, Secondary Chain 303-1530 Installer, Differential Bearing Cone 205-142 (T80T-4000-J) Installer, Spindle Bearing 205-150 (T80T-4000-S) Remover, Crankshaft Rear Oil Seal 303-519 (T95P-6701-EH) Remover, Oil Seal 303-409 (T92C-6700CH) Remover, VCT Spark Plug Tube Seal 303-1247/1 Slide Hammer 307-005 (T59L-100-B) Spreader Bar 303-D089 (D93P-6001-A3) or equivalent Strap Wrench 303-D055 (D85L-6000-A) Tool, Camshaft Holding 303-1248

Scheme 443

Scheme 443: Special Tool(s)
Scheme 443: Special Tool(s)

Scheme 444

Scheme 444
Scheme 444

Scheme 445

Scheme 445
Scheme 445

Scheme 446

Scheme 446
Scheme 446

Scheme 447

Scheme 447
Scheme 447

Scheme 448

Scheme 448
Scheme 448

Scheme 449

Scheme 449
Scheme 449

Scheme 450

Scheme 450
Scheme 450

Scheme 451

Scheme 451
Scheme 451

Scheme 452

Scheme 452
Scheme 452

Scheme 453

Scheme 453
Scheme 453

SPECIAL TOOLS REFERENCE Compressor, Valve Spring 303-300 (T87C-6565-A) Compressor, Valve Spring 303-350 (T89P-6565-A) Compressor, Valve Spring 303-1249 Installer, Valve Stem Oil Seal 303-470 (T94P-6510-CH)

Scheme 454

Scheme 454: Special Tool(s)
Scheme 454: Special Tool(s)

Scheme 455

Scheme 455
Scheme 455

SPECIAL TOOLS REFERENCE Compressor, Piston Ring 303-D032 (D81L-6002-C) Dial Indicator Gauge with Holding Fixture 100-002 (TOOL-4201-C) Eye, Engine Lift 303-1245 Lift Eye, RH Front 303-1529 Handle 205-153 (T80T-4000-W) Hold Down, Secondary Chain 303-1530 Installer, Differential Bearing Cone 205-142 (T80T-4000-J) Installer, Spindle Bearing 205-149 (T80T-4000-R) 2,200# Floor Crane, Fold Away 300-OTC1819E Installer, Crankshaft Vibration Damper 303-102 (T74P-6316-B) Installer, Front Cover Oil Seal 303-335 Installer, Front Crankshaft Seal 303-1251 Installer, Rear Main Seal 303-1250 Installer, VCT Spark Plug Tube Seal 303-1247/2 Spreader Bar 303-D089 (D93P-6001-A3) or equivalent Strap Wrench 303-D055 (D85L-6000-A) Tool, Camshaft Holding 303-1248

Scheme 456

Scheme 456: Special Tool(s)
Scheme 456: Special Tool(s)

Scheme 457

Scheme 457
Scheme 457

Scheme 458

Scheme 458
Scheme 458

Scheme 459

Scheme 459
Scheme 459

Scheme 460

Scheme 460
Scheme 460

Scheme 461

Scheme 461
Scheme 461

Scheme 462

Scheme 462
Scheme 462

Scheme 463

Scheme 463
Scheme 463

Scheme 464

Scheme 464
Scheme 464

Scheme 465

Scheme 465
Scheme 465

Scheme 466

Scheme 466
Scheme 466

Scheme 467

Scheme 467
Scheme 467

Scheme 468

Scheme 468
Scheme 468

Scheme 469

Scheme 469
Scheme 469

Scheme 470

Scheme 470
Scheme 470

Scheme 471

Scheme 471
Scheme 471

SPECIAL TOOLS REFERENCE 2,200# Floor Crane, Fold Away 300-OTC1819E Spreader Bar 303-D089 (D93P-6001-A3) or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

Scheme 472

Scheme 472: Special Tool(s)
Scheme 472: Special Tool(s)

Scheme 473

Scheme 473
Scheme 473

SPECIAL TOOLS REFERENCE 2,200# Floor Crane, Fold Away 300-OTC1819E Spreader Bar 303-D089 (D93P-6001-A3) or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

Scheme 474

Scheme 474: Special Tool(s)
Scheme 474: Special Tool(s)

Scheme 475

Scheme 475
Scheme 475

More articles — Engine Mechanical - 3.7L
