SPECIFICATIONS
| Item | Specification | Fill Capacity |
|---|---|---|
| Silicone Brake Caliper Grease and Dielectric Compound XG-3-A | ESE-M1C171-A |
MATERIAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Base ignition timing | 10 degrees Before Top Dead Center (BTDC) non-adjustable |
| Firing order | 1-3-7-2-6-5-4-8 |
| Spark plug gap | 0.85-0.95 mm (0.033-0.037 in) |
| Spark plug type | 12405 |
GENERAL SPECIFICATIONS
| Description | Nm |
|---|---|
| Ignition coil cover bolts | 10 |
| Spark plugs | 18 |
TORQUE SPECIFICATIONS
The Electronic Ignition (EI) system is a coil-on-plug ignition system. The coil-on-plug ignition system consists of the
- Crankshaft Position (CKP) sensor.
- Camshaft Position (CMP) sensor.
- ignition coils.
- spark plugs.
The CKP sensor
- is a variable reluctance sensor.
- is mounted to the lower RH side of the front cover.
- is triggered by a 36-minus-1 tooth trigger wheel mounted on the crankshaft.
- provides base timing and crankshaft speed (rpm) to the PCM.
The CMP sensor
- is mounted on the LH side of the front cover.
- sends the PCM a signal indicating camshaft position used for fuel and spark synchronization.
The 8 separate ignition coils
- convert low voltage signals from the PCM to high voltage pulses.
- produce the high voltage pulses for the spark plugs.
- are connected directly to each spark plug.
The spark plugs
- convert a high voltage pulse into a spark which ignites the fuel and air mixture.
- originally installed on the vehicle have a platinum-enhanced active electrode for long life.
Refer to the ENGINE CONTROLS - INTRODUCTION (EXCEPT DIESEL & HYBRID) (SECTION 0) .
Scheme 9
| Item | Part Number | Description |
|---|---|---|
| 1 | W701621 | Ignition coil-on-plug cover bolt (2 required) |
| 2 | 6P067 | Ignition coil-on-plug cover |
| 3 | 14A464 | Ignition coil-on-plug electrical connector (part of 12B637) (4 required) |
| 4 | 12A366 | Ignition coil-on-plug (4 required) |
| 5 | 12405 | Spark plug (4 required) |
Scheme 10
| Item | Part Number | Description |
|---|---|---|
| 1 | W706827 | Wire harness retainer (part of 12B637) (2 required) |
| 2 | W712595 | Ignition coil-on-plug cover stud bolt (2 required) |
| 3 | 6P068 | Ignition coil-on-plug cover |
| 4 | 12A366 | Ignition coil-on-plug (4 required) |
| 5 | 14A464 | Ignition coil-on-plug electrical connector (part of 12B637) (4 required) |
| 6 | 12405 | Spark plug (4 required) |
- For additional information, refer to the appropriate procedures.
