Evaporative Emissions System - 2.0L: Overview Ford Kuga II

Removal & Installation 1 illustration

Overview

The EVAP system prevents hydrocarbon emissions from entering the atmosphere by storing fuel vapors and routing the vapors to the engine to be consumed during normal engine operation.

The EVAP system consists of

  1. EVAP canister
  2. EVAP canister purge valve
  3. EVAP canister vent solenoid
  4. Fuel Tank Pressure (FTP) sensor and tube
  5. Easy Fuel (capless) fuel tank filler pipe

System Operation

Refer to the ENGINE CONTROLS - DESCRIPTION & OPERATION (EXCEPT DIESEL & HYBRID) (SECTION 1).

Scheme 217

Scheme 217: System Diagram
ItemDescription
1Valve cover
2Turbocharger inlet pipe
3Air Cleaner (ACL) outlet pipe
4Vapor ejector
5Turbocharger to CAC (Charge Air Cooler) tube
6Dual check valve
7EVAP (Evaporative Emission) canister purge valve
8Intake manifold
9PCV (Positive Crankcase Ventilation) valve
10EVAP canister
11Fuel vapor vent valve
12Fuel tank filler pipe
13Fuel tank
14Fuel Tank Pressure (FTP) sensor and tube
15Fuel level sensor
16EVAP canister inlet filter
17EVAP canister vent solenoid
