Powertrain Control Module (PCM)
| Item | Description |
|---|---|
| 1 | PCM |
Camshaft Position (CMP) Sensor
| Name | Specification |
|---|---|
| Motorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil (U.S.) XO-5W20-QSP (U.S.) | WSS-M2C945-A |
MATERIAL SPECIFICATION
Scheme 127
- NOTE: The O-ring seal is to be reused unless damaged.
Catalyst Monitor Sensor
SPECIAL TOOL DESCRIPTION 303-476 (T94P-9472-A) Socket, Exhaust Gas Oxygen Sensor TKIT-1994-F TKIT-1994-FLM/FM TKIT-1994-LM/M
Scheme 128
| Name | Specification |
|---|---|
| High Temperature Nickel Anti-Seize Lubricant XL-2 | |
| Penetrating and Lock Lubricant XL-1 |
MATERIAL SPECIFICATION
Scheme 129
- Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-658843-S31152527922014092900000) .
- Use Special Service Tool: 303-476 (T94P-9472-A) Socket, Exhaust Gas Oxygen Sensor . Material: Penetrating and Lock Lubricant/XL-1
Crankshaft Position (CKP) Sensor
SPECIAL TOOL DESCRIPTION 303-1417 Tool, Crank Sensor Alignment TKIT-2008ET-FLM TKIT-2008ET-ROW 303-507 Timing Peg, Crankshaft TDC TKIT-2001N-FLM TKIT-2001N-ROW Ford Diagnostic Equipment
Scheme 130
Scheme 131
Heated Oxygen Sensor (HO2S)
SPECIAL TOOL DESCRIPTION 303-476 (T94P-9472-A) Socket, Exhaust Gas Oxygen Sensor TKIT-1994-F TKIT-1994-FLM/FM TKIT-1994-LM/M
| Name | Specification |
|---|---|
| High Temperature Nickel Anti-Seize Lubricant XL-2 | |
| Penetrating and Lock Lubricant XL-1 |
MATERIAL SPECIFICATION
Scheme 132
Scheme 133
- Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-658843-S31152527922014092900000) .
- Use Special Service Tool: 303-476 (T94P-9472-A) Socket, Exhaust Gas Oxygen Sensor . Material: Penetrating and Lock Lubricant/XL-1
Scheme 134
- Calculate the correct torque wrench setting for the following torque. Refer to Torque Wrench Adapter Formula in the Apex. Use Special Service Tool: 303-476 (T94P-9472-A) Socket, Exhaust Gas Oxygen Sensor . Material: High Temperature Nickel Anti-Seize Lubricant/XL-2 Torque: 35 lb.ft (48 Nm)
Special Tool(s)/General Equipment
Ford Diagnostic Equipment
Scheme 135
- Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-658843-S31152527922014092900000) .
- NOTE: Powertrain Control Module (PCM) installation DOES NOT require new keys or programming of keys, only a Parameter Reset of the PATS . NOTE: This step is only necessary when installing a new component. Download the module information to the diagnostic tool using the Programmable Modules Installation routine. Refer to: «MODULE CONFIGURATION - SYSTEM OPERATION AND COMPONENT DESCRIPTION»(ref-658827-S36740861182014092900000) . Use the General Equipment: Ford Diagnostic Equipment
- Remove the LH fender splash shield. Refer to: «FENDER SPLASH SHIELD»(ref-658872-S14314641892014092900000) .
