2013 Model Year Electronic Engine Controls - LH
| Item | Description |
|---|---|
| 1 | Exhaust VCT oil control solenoid |
| 2 | Intake VCT oil control solenoid |
| 3 | FRP sensor |
| 4 | Front KS |
| 5 | MAP sensor |
| 6 | Turbocharger boost pressure and charge air temperature sensor |
| 7 | Rear KS |
| 8 | IAT sensor |
| 9 | Intake CMP sensor |
| 10 | Exhaust CMP sensor |
Scheme 113
| Item | Description |
|---|---|
| 1 | Exhaust VCT oil control solenoid |
| 2 | Intake VCT oil control solenoid |
| 3 | FRP sensor |
| 4 | Front KS |
| 5 | MAP sensor |
| 6 | Turbocharger boost pressure and charge air temperature sensor |
| 7 | Rear KS |
| 8 | IAT sensor |
| 9 | Intake CMP sensor |
| 10 | Exhaust CMP sensor |
Electronic Engine Controls - RH
| Item | Description |
|---|---|
| 1 | Turbocharger bypass valve solenoid |
| 2 | ECT sensor |
| 3 | HO2S |
| 4 | Catalyst monitor sensor |
| 5 | Turbocharger wastegate regulating valve solenoid |
| 6 | CKP sensor |
| 7 | Wastegate actuator |
| 8 | CHT sensor |
Powertrain Control Module (PCM)
| Item | Description |
|---|---|
| 1 | PCM |
Catalyst Monitor Sensor
SPECIAL TOOL DESCRIPTION 303-476 (T94P-9472-A) Socket, Exhaust Gas Oxygen Sensor TKIT-1994-F TKIT-1994-FLM/FM TKIT-1994-LM/M
Scheme 114
| Name | Specification |
|---|---|
| High Temperature Nickel Anti-Seize Lubricant XL-2 | |
| Penetrating and Lock Lubricant XL-1 |
MATERIAL SPECIFICATION
Crankshaft Position (CKP) Sensor
SPECIAL TOOL DESCRIPTION 303-1521 Alignment Tool, Crankshaft Position Sensor TKIT-2010C-FLM TKIT-2010C-FLM 303-507 Timing Peg, Crankshaft TDC TKIT-2001N-FLM TKIT-2001N-ROW Ford Diagnostic Equipment
Scheme 115
Scheme 116
Engine Coolant Temperature (ECT) Sensor
| Name | Specification |
|---|---|
| Motorcraft® Orange Antifreeze/Coolant Prediluted (U.S.) VC-3DIL-B (U.S.) | WSS-M97B44-D2 |
MATERIAL SPECIFICATION
Heated Oxygen Sensor (HO2S)
SPECIAL TOOL DESCRIPTION 303-476 (T94P-9472-A) Socket, Exhaust Gas Oxygen Sensor TKIT-1994-F TKIT-1994-FLM/FM TKIT-1994-LM/M
| Name | Specification |
|---|---|
| High Temperature Nickel Anti-Seize Lubricant XL-2 | |
| Penetrating and Lock Lubricant XL-1 |
MATERIAL SPECIFICATION
Special Tool(s)/General Equipment
Ford Diagnostic Equipment
Scheme 117
Scheme 118
Scheme 119
- Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-658843-S31152527922014092900000) .
- NOTE: Powertrain Control Module (PCM) installation DOES NOT require new keys or programming of keys, only a Parameter Reset of the PATS . NOTE: This step is only necessary when installing a new component. Download the module information to the diagnostic tool using the Programmable Modules Installation routine. Refer to: «MODULE CONFIGURATION - SYSTEM OPERATION AND COMPONENT DESCRIPTION»(ref-658827-S36740861182014092900000) . Use the General Equipment: Ford Diagnostic Equipment
- Remove the LH fender splash shield. Refer to: «FENDER SPLASH SHIELD»(ref-658872-S14314641892014092900000) .
