2013 Model Year Electronic Engine Controls - LH
| Item | Description |
|---|---|
| 1 | Intake VCT oil control solenoid |
| 2 | MAP sensor |
| 3 | Front KS |
| 4 | Rear KS |
| 5 | ECT sensor |
| 6 | Intake CMP sensor |
| 7 | IAT sensor |
| 8 | Turbocharger boost pressure and charge air temperature sensor |
Scheme 85
| Item | Description |
|---|---|
| 1 | Intake VCT oil control solenoid |
| 2 | MAP sensor |
| 3 | Front KS |
| 4 | Rear KS |
| 5 | ECT sensor |
| 6 | Intake CMP sensor |
| 7 | IAT sensor |
| 8 | Turbocharger boost pressure and charge air temperature sensor |
Electronic Engine Controls - RH
| Item | Description |
|---|---|
| 1 | Exhaust CMP sensor |
| 2 | HO2S |
| 3 | Catalyst monitor sensor |
| 4 | Turbocharger bypass valve solenoid |
| 5 | Electrically controlled turbocharger bypass valve |
| 6 | CKP sensor |
| 7 | Wastegate actuator |
| 8 | Exhaust VCT oil control solenoid |
Powertrain Control Module (PCM)
| Item | Description |
|---|---|
| 1 | PCM |
Catalyst Monitor Sensor
SPECIAL TOOLS/GENERAL EQUIPMENT 303-476 (T94P-9472-A) Socket, Exhaust Gas Oxygen Sensor TKIT-1994-F TKIT-1994-FLM/FM TKIT-1994-LM/M
Scheme 86
| Name | Specification |
|---|---|
| High Temperature Nickel Anti-Seize Lubricant XL-2 | |
| Penetrating and Lock Lubricant XL-1 |
MATERIALS SPECIFICATIONS
Engine Coolant Temperature (ECT) Sensor
| Name | Specification |
|---|---|
| Motorcraft® Orange Antifreeze/Coolant Prediluted (U.S.) VC-3DIL-B (U.S.) | WSS-M97B44-D2 |
MATERIALS SPECIFICATIONS
Heated Oxygen Sensor (HO2S)
SPECIAL TOOLS/GENERAL EQUIPMENT 303-476 (T94P-9472-A) Socket, Exhaust Gas Oxygen Sensor TKIT-1994-F TKIT-1994-FLM/FM TKIT-1994-LM/M
| Name | Specification |
|---|---|
| High Temperature Nickel Anti-Seize Lubricant XL-2 | |
| Penetrating and Lock Lubricant XL-1 |
MATERIALS SPECIFICATIONS
Scheme 87
Scheme 88
- Refer to: «BATTERY TRAY»(ref-658873-S33576642202014100900000) .
- Use Special Service Tool: 303-476 (T94P-9472-A) Socket, Exhaust Gas Oxygen Sensor . Material: Penetrating and Lock Lubricant/XL-1
Special Tool(s)/General Equipment
Ford Diagnostic Equipment
Scheme 89
Scheme 90
Scheme 91
- Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-658843-S31152527922014092900000) .
- NOTE: Powertrain Control Module (PCM) installation DOES NOT require new keys or programming of keys, only a Parameter Reset of the PATS. NOTE: This step is only necessary when installing a new component. Download the module information to the diagnostic tool using the Programmable Modules Installation routine. Refer to: «MODULE CONFIGURATION - SYSTEM OPERATION AND COMPONENT DESCRIPTION»(ref-658827-S36740861182014092900000) . Use the General Equipment: Ford Diagnostic Equipment
- Remove the LH fender splash shield. Refer to: «FENDER SPLASH SHIELD»(ref-658872-S14314641892014092900000) .
Variable Camshaft Timing (VCT) Oil Control Solenoid
| Name | Specification |
|---|---|
| Motorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil (U.S.) XO-5W20-QSP (U.S.) | WSS-M2C945-A |
MATERIALS SPECIFICATIONS
Scheme 92
Scheme 93
Scheme 94
Scheme 95
- Remove the stud/nut. Remove the nut. Position aside the air induction tube.
- NOTE: The O-ring seals are to be reused unless damaged. NOTE: Note the position of the components before removal.
Scheme 96
Scheme 97
- NOTE: Make sure that the components are installed to the position noted before removal. Material: Motorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil (U.S.)/XO-5W20-QSP (U.S.) (WSS-M2C945-A) Torque: 71 lb.in (8 Nm)
- Position in place the air induction tube. Install the nut. Install the stud/nut. Torque: 44 lb.in (5 Nm)
