Engine Cooling System - 2.0L: Removal & Installation Ford Kuga II

Cooling System (Mechanical) 13 illustrations ~536 words

Removal

Note. Removal steps in this procedure may contain installation details.

  1. Refer to: «COOLING SYSTEM DRAINING AND VACUUM FILLING»(ref-658854-S21377632492014092900000) .
  2. NOTE: Make sure the block heater wiring is routed and secured away from rotating or hot components.
  3. Torque : 30 lb.ft (40 Nm)

Installation

  1. To install, reverse the removal procedure.

Pinpoint Test C

C4 A/C
  1. NOTE: Cover the A/C belt to prevent coolant contamination of the belt.
  2. Completely cover the A/C belt with waterproof plastic.

Pinpoint Test C

C3 A/C
  1. click to open the image

Note. Removal steps in this procedure may contain installation details.

Scheme 29

Scheme 29: Removal
Scheme 29: Removal

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35
  1. Refer to: «COOLING SYSTEM DRAINING AND VACUUM FILLING»(ref-658854-S21377632492014092900000) .
  2. Refer to: «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-658833-S06588196542014092900000) .
  3. Torque : 133 lb.in (15 Nm)
  4. NOTE: Cover the generator to prevent coolant contamination of the generator. Completely cover the generator with waterproof plastic. Use the General Equipment: Hose Clamp Remover/Installer
  5. Use the General Equipment: Hose Clamp Remover/Installer
  6. NOTE: Some vehicles are equipped with a grille shutter assembly framework only. These vehicles will not have a grille shutter actuator or a grille shutter linkage. Refer to: «ACTIVE GRILLE SHUTTER»(ref-658872-S14801360282014092900000) .
  7. Torque : 44 lb.in (5 Nm)
  8. If equipped.
  9. Both sides. Torque : 18 lb.ft (25 Nm)
  10. Both sides. Torque : 18 lb.ft (25 Nm)
  11. Torque : 18 lb.ft (25 Nm)
  1. To install, reverse the removal procedure.
  2. Fill and bleed the cooling system. Refer to: «COOLING SYSTEM DRAINING AND VACUUM FILLING»(ref-658854-S21377632492014092900000) .
  3. Evacuate, leak test and charge the A/C system. Refer to: «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-658833-S06588196542014092900000) .

Note. Removal steps in this procedure may contain installation details.

  1. Refer to: «COOLING MODULE»(ref-658854-S40645816862014092900000) .
  2. Use the General Equipment: Hose Clamp Remover/Installer
  1. To install, reverse the removal procedure.
WARNINGAlways allow the engine to cool before opening the cooling system. Do not unscrew the coolant pressure relief cap when the engine is operating or the cooling system is hot. The cooling system is under pressure; steam and hot liquid can come out forcefully when the cap is loosened slightly. Failure to follow these instructions may result in serious personal injury.

Note. Removal steps in this procedure may contain installation details.

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38
  1. Use the General Equipment: Fluid Suction Gun Use the General Equipment: Locking Pliers
  2. Use the General Equipment: Hose Clamp(s)
  1. To install, reverse the removal procedure.
  2. Fill the degas bottle with the recommended coolant mixture and fill level. Refer to: «COOLING SYSTEM DRAINING AND VACUUM FILLING»(ref-658854-S21377632492014092900000) .

Note. Removal steps in this procedure may contain installation details.

Scheme 39

Scheme 39: Removal
Scheme 39: Removal

Scheme 40

Scheme 40
Scheme 40
  1. Refer to: «COOLING MODULE»(ref-658854-S40645816862014092900000) .
  2. Use the General Equipment: Hose Clamp Remover/Installer
  3. Torque : 44 lb.in (5 Nm)
  4. Use the General Equipment: Knife
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 41

Scheme 41
Scheme 41
  1. Refer to: «COOLING SYSTEM DRAINING AND VACUUM FILLING»(ref-658854-S21377632492014092900000) .
  2. NOTE: Cover the generator to prevent coolant contamination of the generator. Completely cover the generator with waterproof plastic. Use the General Equipment: Hose Clamp Remover/Installer
  3. Use the General Equipment: Hose Clamp Remover/Installer
  4. Torque : 89 lb.in (10 Nm)
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

  1. Refer to: «COOLING FAN MOTOR AND SHROUD»(ref-658854-S07581495202014092900000) .
  1. To install, reverse the removal procedure.
  1. To install, reverse the removal procedure.
  2. Refer to: «COOLING SYSTEM DRAINING AND VACUUM FILLING»(ref-658854-S21377632492014092900000) .
