Automatic Transmission - Cvt: Specifications Ford Freestyle I

GENERAL SPECIFICATIONS

GENERAL SPECIFICATIONS

TORQUE SPECIFICATIONS

TORQUE SPECIFICATIONS

Torque Converter

The converter consists of the impeller, the turbine wheel, the reactive element (stator) and the fluid used to transmit the torque. The impeller is driven by the engine and imparts a circular flow to the fluid in the converter. The angle of the fluid flow is deflected when it strikes the turbine wheel. The fluid leaves the turbine wheel close to the hub, and passes through the stator, where it is again deflected and enters the impeller at an angle. The change in the direction of fluid flow at the stator generates a reaction torque that increases the torque at the turbine. The ratio between turbine torque and impeller torque is the torque conversion ratio. The greater the speed difference between the impeller and the turbine, the greater the increase in torque; this increase reaches a maximum when the turbine is stationary. As turbine speed rises, the increase in torque lessens. When the turbine is running at about 85 percent of the impeller speed, the increase in torque drops to one, that is to say turbine and impeller torques are identical. The stator, which bears against the gearbox housing via a one-way clutch and the stator shaft, can then revolve freely in the fluid flow, and the freewheel is overrun. From this moment, the converter operates purely as a fluid coupling. During the torque conversion phase, the stator is stationary and bears against the housing through the freewheel.

Torque Converter Clutch

The torque converter clutch is a device that eliminates slip in the torque converter and therefore helps to keep fuel consumption to a minimum.

Torque Converter Diagnosis

SPECIAL TOOL(S) Worldwide Diagnostic System (WDS) Vehicle Communication Module (VCM) with appropriate adapters, or equivalent diagnostic tool

Prior to torque converter installation, all diagnostic procedures must be followed. This is to prevent the unnecessary installation of new or remanufactured torque converters. Only after a complete diagnostic evaluation can the decision be made to install a new or remanufactured torque converter.

Begin with the normal diagnostic procedures as follows

1. Preliminary Inspection
2. Know and Understand the Customer's Concern
3. Verify the Concern - carry out the torque converter operation test.
4. Carry out Diagnostic Procedures: Run on-board diagnostics. Refer to «DIAGNOSTICS»(ref-255278-S30514288692007053000000) . Repair all non-transaxle-related DTCs first. Repair all transaxle DTCs. Rerun On-Board Diagnostic to verify repair. Carry out diagnostic routines. Refer to «DIAGNOSIS BY SYMPTOM»(ref-255278-S35055894832007053000000) . Use the index to locate the appropriate routine that best describes the symptom(s). The routine will list all possible components that may cause or contribute to the symptom. Check each component listed, diagnose and repair as required, before repairing the torque converter.

Torque Converter Operation Test

Note. The torque converter clutch will not engage if the transmission fluid temperature is below 0°C (32°F).

1. Using the special tool, make sure that the transmission fluid temperature is within specification 43-47°C (109-117°F).
2. Accelerate the vehicle to 35-60 km/h (22-37 mph) and maintain a consistent speed.
3. Release the accelerator pedal to close the throttle and press the accelerator to partially open the throttle while monitoring the special tool engine speed and TCC PID 194D. The TCC PID on the special will read 0 when the TCC clutch is released, and 1 when the TCC is applied. The engine speed will increase when the TCC is released and decrease when the TCC is applied.
4. If these actions do not occur, refer to «DIAGNOSIS BY SYMPTOM»(ref-255278-S35055894832007053000000) .

PINPOINT TEST D: TORQUE CONVERTER CLUTCH

1. D1 ELECTRONIC DIAGNOSTICS Check to make sure the transaxle harness connector is fully seated, pins are fully engaged in the connector and in good condition before proceeding. Connect the scan tool. Drive the vehicle with a steady speed up to and above 24 km/h (15 mph). Monitor PIDs: (TSS_SRC, RPMTCM, SSPCE). The torque converter clutch (TCC) commanded pressure should be greater than 400 kPa (44 psi) and the turbine shaft speed (TSS) should be equal to engine speed. Is the lockup commanded pressure greater than 400 kPa (44 psi) and the turbine speed equal to engine speed? Yes: CLEAR all DTCs. ROAD TEST to verify if concern is still present. Concern could be intermittent. No: INSTALL a new torque converter. REFER to «TRANSAXLE - ALL WHEEL DRIVE (AWD)»(ref-255278-S16604547282007053000000) or «TRANSAXLE - FRONT WHEEL DRIVE (FWD)»(ref-255278-S10276806392007053000000) .

Fluid Leakage in Torque Converter Area

In diagnosing and correcting fluid leaks in the torque converter area, use the following procedures to locate the exact cause of the leakage. Leakage at the front of the transaxle, as evidenced by fluid around the torque converter housing, may have several sources. By careful observation it is possible, in many instances, to pinpoint the source of the leak before removing the transaxle from the vehicle. The paths which the fluid takes to reach the bottom of the torque converter housing are shown in the illustration. The 5 steps following correspond with the numbers in the illustration.

Scheme 1

1. Fluid leaking by the converter hub seal lip will tend to move along the drive hub and onto the back of the torque converter. Except in the case of a total seal failure, fluid leakage by the lip of the seal will be deposited on the inside of the torque converter housing only, near the outside diameter of the housing.
2. Fluid leakage by the outside diameter of the converter hub seal and the case will follow the same path that leaks by the inside diameter of the converter hub seal follow.
3. Fluid leakage from the converter cover weld or the converter-to-flexplate stud weld will appear at the outside diameter of the torque converter on the back face of the flexplate and in the converter housing only near the flexplate. If a converter-to-flexplate stud or converter cover weld leak is suspected, install a new torque converter.
4. Fluid leaking from the pump cover, pump cover bolts or the torque converter hub seal inside the converter housing will flow down the back of the torque converter housing. Leakage may be from loose or missing pump cover bolts, defective pump cover seal or defective torque converter hub seal.
5. Engine oil leaks are sometimes incorrectly diagnosed as transaxle converter hub seal leaks. The following areas of possible leakage should also be checked to determine if engine oil leakage is causing the concern. Leakage at the valve cover gasket may allow oil to flow over the torque converter housing or seep down between the torque converter housing and cylinder block, causing oil to be present in or at the bottom of the torque converter housing. Oil galley plug leaks will allow oil to flow down the rear face of the cylinder block to the bottom of the torque converter housing. Leakage at the crankshaft rear oil seal will work back to the flexplate and then into the torque converter housing. Leakage at the oil pressure sensor. Cracks in the block. Leakage from the engine oil pan.

Torque Converter Operation Concerns: No Apply

TORQUE CONVERTER OPERATION CONCERNS: NO APPLY

Torque Converter Operation Concern: Always Applied

TORQUE CONVERTER OPERATION CONCERN: ALWAYS APPLIED

Torque Converter Operation Concern: Cycling/Shudder/Chatter

TORQUE CONVERTER OPERATION CONCERN: CYCLING/SHUDDER/CHATTER

1. A new torque converter must be installed if one or more of the following statements is true: A torque converter malfunction has been determined based on complete diagnostic procedures. Converter stud or studs, impeller hub or bushing are damaged. Discoloration or distortion of cover (due to overheating). Evidence of transaxle assembly or fluid contamination due to the following transaxle or converter failure modes: Major metallic failure. Multiple clutches or clutch plate failures. Sufficient component wear which results in metallic contamination. Internal torque converter contamination present. For additional information, refer to «TORQUE CONVERTER CONTAMINATION INSPECTION»(ref-255278-S10789759152007053000000)

Torque Converter Contamination Inspection

MATERIALS

1. If a new torque converter is not being installed, the following steps must be completed.
2. With the torque converter on a bench, pour a small amount of CVT transmission fluid from the torque converter onto an absorbent white tissue or through a paper filter and examine the CVT transmission fluid.
3. Observe the color and odor of the fluid. The CVT transmission fluid should be green or dark green, not brown or black. Odor may indicate an overheating condition such as clutch disc failure.
4. Examine the stain on the tissue for evidence of particles (spec of any kind). If particles are present in the fluid a new torque converter must be installed.
5. If there are no particles or contamination present, drain the remainder of the transmission fluid from the torque converter.

Torque Converter Housing, Reverse Clutch and Pump Assembly - Disassembly

SPECIAL TOOL(S) Slide Hammer 100-001 (T50T-100-A) Remover, Transfer Case Bearing Cup 308-125 (T87P-7120-D) Remover and Installer, Stator Needle Bearing 307-540 (includes 307-540/1 and 307-540/2) Piston Spring Compressor 307-525 Remover, Differential Bearing Race 307-532 Actuator Pin 303-D012 D80L-100-H Collet, 1-1/2 to 1-3/4 303-D023 D80L-100-U

Scheme 2

Scheme 3

Scheme 4

Scheme 5
