Automatic Transmission Cooling: Removal & Installation Ford Freestyle I

Removal and Installation

Note. Refer to the following when adding transmission fluid.

1. The CVT transaxle uses: Motorcraft Continuously Variable Chain Type Transmission Fluid (XT-7-QCFT)
2. The 6-speed transaxle uses: Motorcraft Premium Automatic Transmission Fluid (XT-8-QAW)

Do not mix the fluid together, damage to internal components will result.

Scheme 690

Scheme 691

Scheme 692

Scheme 693

Scheme 694

Scheme 695

Scheme 696

Scheme 697

Scheme 698

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-255244) .
2. Remove the radiator grille. Refer to «REMOVAL AND INSTALLATION»(ref-255290-S39122392182007053000000) for Five Hundred, Montego or «REMOVAL AND INSTALLATION»(ref-255290-S35093747792007053000000) for Freestyle .
3. Remove the LH air deflector pushpins. Position the air deflector aside.
4. Remove the RH air deflector pushpins. Position the air deflector aside.
5. Remove the bolt from the LH A/C condenser bracket. To install, tighten to 10 Nm (89 lb-in).
6. Remove the bolt from the RH A/C condenser bracket. To install, tighten to 10 N.m (89 lb-in).
7. Carefully lift the A/C condenser off the retaining clips and position the condenser aside.
8. Remove the screw for the cooler tube retainer. To install, tighten to 10 N.m (89 lb-in).
9. Disconnect the fluid cooler hoses from the fluid cooler.
10. Lift the fluid cooler off the retainers and remove the fluid cooler.
11. Remove the fluid fill plug. To install, tighten to 35 N.m (26 lb-ft).
12. Partially fill the transaxle with clean automatic transmission fluid to make up what was lost during the installation of a new transmission fluid cooler. Using the transmission fluid level setting (CVT) procedure, continue filling the transaxle. For additional information, refer to «TRANSAXLE COOLING»(ref-255304-S31031580742007053000000) .
13. Remove the fluid fill plug. To install, tighten to 39 N.m (29 lb-ft).
14. To install, reverse the removal procedure. Fill the transaxle with Motorcraft Premium Automatic Transmission Fluid XT-8-QAW meeting Ford specification WSS-M2C924-A to the specified level. Prior to adding any transmission fluid, make sure that the vehicle is on a level surface. Check the fluid level to determine how much fluid will need to be added. Using a diagnostic tool, monitor the fluid temperature. Make sure that the fluid temperature is within specification. The fluid level should be within the normal operating range on the fluid level indicator.
15. Check the transaxle for correct operation.

Note. Refer to the following when adding transmission fluid.

1. The CVT transaxle uses: Motorcraft Continuously Variable Chain Type Transmission Fluid (XT-7-QCFT)
2. The 6-speed transaxle uses

1. Motorcraft Premium Automatic Transmission Fluid (XT-8-QAW)

Do not mix the fluid together, damage to internal components will result.

Scheme 699

Scheme 700

Scheme 701

Scheme 702

Scheme 703

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-255244) .
2. Disconnect the cooler hoses from the fluid cooler.
3. Disconnect the transmission fluid cooler tubes from the transaxle. To install, tighten to 10 N.m (89 lb-in).
4. Disconnect the wiring harness from the cooler tube.
5. Remove the fluid cooler tube bracket from the transaxle. Remove the fluid cooler tubes. To install, tighten to 10 N.m (89 lb-in).
6. Remove the fluid fill plug. To install, tighten to 35 N.m (26 lb-ft).
7. Partially fill the transaxle with clean automatic transmission fluid to make up what was lost during the installation of a new transmission fluid cooler tube. Using the transmission fluid level setting CVT procedure, continue filling the transaxle. For additional information, refer to «TRANSAXLE COOLING»(ref-255304-S31031580742007053000000) .
8. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-255244) .
9. Disconnect the cooler hoses from the fluid cooler.
10. Disconnect the transmission fluid cooler tubes at the transaxle. To install, tighten to 10 N.m (89 lb-in).
11. Disconnect the transmission fluid cooler tube bracket. Remove the fluid cooler tubes. To install, tighten to 10 Nm (89 lb-in).
12. Remove the fluid fill plug. To install, tighten to 39 N.m (29 lb-ft).
13. To install, reverse the removal procedure. Fill the transaxle with Motorcraft Premium Automatic Transmission Fluid XT-8-QAW meeting Ford specification WSS-M2C924-A to the specified level. Prior to adding any transmission fluid, make sure that the vehicle is on a level surface. Check the fluid level to determine how much fluid will need to be added. Using a diagnostic tool, monitor the fluid temperature. Make sure that the fluid temperature is within specification. The fluid level should be within the normal operating range on the fluid level indicator.
14. Check the transaxle for correct operation.
