TORQUE SPECIFICATIONS
| Description | N.m |
|---|---|
| Front axle wheel hub nut | 350 |
| Wheel bearing and hub-to-wheel knuckle bolts | 110 |
| Lower arm ball joint nut | 115 |
| Wheel knuckle-to-strut and spring assembly nut | 175 |
| Strut and spring assembly mounting bracket nuts | 30 |
| Strut and spring assembly mount nut | 80 |
| Lower arm-to-subframe bolt | 150 |
| Lower arm bushing-to-subframe bolts | 99 |
| Front subframe bolts | 150 |
| Front subframe bracket bolts | 55 |
| Stabilizer bar bracket bolts | 50 |
| Stabilizer bar link-to-stabilizer bar nut | 55 |
| Front stabilizer bar link-to-strut nut | 55 |
| Tie-rod-to-wheel knuckle nut | 115 |
| ABS sensor retaining bolt | 14 |
TORQUE SPECIFICATIONS
The front suspension consists of the following components
- Lower arm
- Strut and spring assembly
- Stabilizer bar
- Stabilizer bar link
- Wheel bearing and wheel hub
- Wheel knuckle
- Wheel and tire assembly
Refer to SUSPENSION SYSTEM-GENERAL INFORMATION .
Scheme 1
Scheme 2
Scheme 3
- For additional information, refer to the appropriate procedure.
