MATERIAL
| Item | Specification | Fill Capacity |
|---|---|---|
| Motorcraft MERCON® LV Automatic Transmission Fluid XT-10-QLV | MERCON® LV | 6.7L (7 qt) |
MATERIAL
Transaxle Cooling
The transmission fluid cooling system consists of the following
- Oil-to-air (OTA) transmission fluid combo cooler
- Transmission fluid cooler tube assembly
- Transmission fluid cooler inlet tube
- Transmission fluid cooler outlet tube
These vehicles are equipped with an external transmission fluid cooler. The transmission fluid cooler is part of the A/C condenser and cannot be serviced separately. The transmission fluid cooler is mounted in front of the engine radiator. Transmission fluid travels from the transaxle to the transmission fluid cooler and back to the transaxle. The transmission fluid cooler transfers heat from the transmission fluid to the outside air.
Scheme 27
| Item | Part Number | Description |
|---|---|---|
| 1 | 19E908 | Transmission fluid cooler |
| 2 | 7J081 | Secondary latches |
| 3 | 7890A | Transmission fluid cooler outlet tube |
| 4 | 7890B | Transmission fluid cooler inlet tube |
SPECIAL TOOLS - TRANSAXLE COOLING Illustration Tool Name Tool Number Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool
Scheme 28
| Item | Specification |
|---|---|
| Motorcraft MERCON® LV Automatic Transmission Fluid XT-10-QLV | MERCON® LV |
MATERIAL - TRANSAXLE COOLING
