Automatic Transmission External Controls System: Removal & Installation Ford Focus I facelift

REMOVAL AND INSTALLATION

1. The brake shift interlock is not serviced. If a problem is detected with the brake shift interlock, install a new shifter assembly. For additional information, refer to «Transmission Selector Lever»(ref-278265-S41058983682008012400000) .

Scheme 88

REMOVAL

All vehicles

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-278237) article.
2. Remove the battery tray. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-278287) article.
3. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-278287) article.
4. Remove the air cleaner. For additional information, refer to «INTAKE AIR DISTRIBUTION AND FILTERING»(ref-278249) article.
5. Support the flexible exhaust pipe, using a suitable wrap.
6. Disconnect the front exhaust pipe and detach the support isolators. Discard the gasket.
7. Disconnect the center exhaust hanger and support the exhaust with wire.
8. Remove the exhaust heat shield. Unclip the selector lever cable.
9. Disconnect the selector lever cable from the selector lever bracket and manual control lever. Disconnect the shift cable end from the manual control lever. Depress the tabs on the shift cable and remove the cable from the bracket.
10. Remove the floor console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-278275) article.
11. Remove the selector lever cable from the selector lever. Shift the selector lever to PARK. Unclip the selector lever cable. Unclip the selector lever cable outer sleeve.
12. Remove the center armrest brace.
13. Remove the center console lower trim panels. Remove the screws. Release the clip.
14. Remove the footwell heater channel.
15. Remove the heater housing cover. Unclip the 4 clips. Remove the 2 screws.
16. Detach the floor covering and the insulator material and position it aside.
17. Attach a suitable length of draw cord to the transaxle end of the selector lever cable and secure it to the transaxle.
18. Remove the selector lever cable grommet nuts and the grommet.
19. Remove the selector lever cable. Pull the cable and draw cord through the floor panel.

INSTALLATION

All vehicles

1. Attach the draw cord to the transaxle end of the selector lever cable.
2. Pull the selector lever cable through the floor panel.
3. Install the selector lever cable grommet and nuts. Tighten to 9 Nm (80 lb-in).
4. Secure the insulator material and the floor covering with adhesive tape.
5. Install the heater housing cover. Locate the 4 clips. Install the 2 screws.
6. Install the footwell heater channel.
7. Install the center console lower trim panels. Install the clip. Install the screws.
8. Install the armrest brace. Tighten to 10 Nm (89 lb-in).
9. Install the selector cable to the selector lever. Shift the selector lever to PARK. Clip in the selector lever cable outer sleeve. Clip in the selector lever cable.
10. Install the floor console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-278275) article.
11. Remove the draw cord.
12. Unlock the shift cable end. Make sure that the cable end moves freely.
13. Connect the shift cable end to the manual control lever. Connect the shift cable to the cable bracket. Connect the shift cable end to the manual control lever.
14. Press the lock tab down to secure the cable end from moving.
15. Install the exhaust heat shield.
16. Connect the center exhaust hanger and remove the support wire.
17. Attach the exhaust pipe support insulators and connect the front exhaust pipe. Tighten to 47 Nm (35 lb-ft).
18. Remove the support wrap.
19. Adjust the selector lever cable. For additional information, refer to «Selector Lever Cable Adjustment»(ref-278265-S40326383182008012400000) .
20. Connect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-278287) article.
21. Install the air cleaner. For additional information, refer to «INTAKE AIR DISTRIBUTION AND FILTERING»(ref-278249) article.
22. Install the battery tray. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-278287) article.
23. Check that the vehicle starts in PARK and NEUTRAL and the reverse lamps illuminate in REVERSE.

1. Remove the floor console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-278275) article.
2. Remove the selector lever cable from the selector. Shift the selector lever to PARK. Unclip the selector lever cable. Unclip the selector lever cable outer sleeve.
3. Disconnect the selector lever assembly electrical connector.
4. Remove the selector lever assembly. Remove the 4 nuts.

1. Install the selector lever assembly. Install the 4 nuts. Tighten to 9 Nm (80 lb-in).
2. Connect the selector lever assembly electrical connector.
3. Install the selector cable to the selector lever. Shift the selector lever to PARK. Clip in the selector lever cable outer sleeve. Clip in the selector lever cable.
4. Install the floor console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-278275) article.
5. Adjust the selector lever cable. For additional information, refer to «Selector Lever Cable Adjustment»(ref-278265-S40326383182008012400000) .

Scheme 89

1. Remove the selector lever knob. For additional information, refer to «Selector Lever Knob»(ref-278265-S31166775232008012400000) .
2. Remove the selector lever bezel. Unclip the bezel. Unclip the lamp.

1. Install the selector lever bezel. Clip in the bezel. Clip in the lamp.
2. Install the selector lever knob. For additional information, refer to «Selector Lever Knob»(ref-278265-S31166775232008012400000) .

Scheme 90

1. Remove the floor console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-278275) article.
2. Disconnect the overdrive (O/D) switch electrical connector.
3. Remove the selector lever knob. Remove and discard the screw. Pull off the knob.

1. Position the selector lever knob onto the lever and route the wiring harness through the transmission range indicator.
2. Slide the selector lever knob down the shaft and install a new screw.
3. Connect the O/D switch electrical connector.
4. Install the floor console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-278275) article.
