Engine Ignition - 2.0l Ecoboost Ford Focus ST III

Ignition System 4 illustrations ~287 words

Specifications

ItemSpecification
Spark plug12405
Spark plug gap0.028-0.031 in (.7-.8 mm)

GENERAL SPECIFICATIONS

Scheme 3

Scheme 3: 2.0L Gasoline Turbocharged Direct Injection (GTDI)
Scheme 3: 2.0L Gasoline Turbocharged Direct Injection (GTDI)
ItemDescription
1Ignition coil-on-plug(s)
2Spark plug(s)

System Operation

ENGINE CONTROLS - DESCRIPTION & OPERATION (EXCEPT DIESEL & HYBRID) .

Component Description

ENGINE CONTROLS - DESCRIPTION & OPERATION (EXCEPT DIESEL & HYBRID) .

Ford diagnostic equipment

GENERAL EQUIPMENT

  1. For PCM Diagnostic Trouble Codes (DTCs), Refer to: Electronic Engine Controls ( «ELECTRONIC ENGINE CONTROLS»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electronic-engine-controls-20l-ecoboost) ). MIL Code List. For driveability symptoms without Diagnostic Trouble Codes (DTCs), ENGINE CONTROLS - SYMPTOM CHARTS (EXCEPT DIESEL & HYBRID) .

Ignition Coil-On-Plug

NameSpecification
Silicone Brake Caliper Grease and Dielectric Compound XG-3-AESE-M1C171-A

MATERIALS SPECIFICATIONS

Removal

WARNINGBefore beginning any service procedure in this service information, refer to Safety Warnings in SERVICE INFORMATION General Information. Failure to follow this instruction may result in serious personal injury.

Note. Removal steps in this procedure may contain installation details.

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6
  1. Refer to: Health and Safety Precautions ( «HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#service-information-introduction-except-electric) ).
  2. Torque : 5 Nm Torque : 5 Nm
  3. Depress the locking tab on the ignition coil-on-plug electrical connector, and disconnect the electrical connector from the ignition coil-on-plug.
  4. NOTE: Use compressed air to remove any foreign material from the ignition coil-on-plugs and surrounding area before removing the ignition coil-on-plugs. NOTE: When removing the ignition coil-on-plugs, a slight twisting motion will break the seal and ease removal. NOTE: When installing, apply a small amount of silicone brake caliper grease and dielectric compound to the inside of the ignition coil-on-plug boots before installation. Torque : 8 Nm Material : Silicone Brake Caliper Grease and Dielectric Compound / XG-3-A (ESE-M1C171-A)
  5. Inspect the ignition coil-on-plug rubber boot for cracks, rips, or tears. Replace any damaged coil-on-plug rubber boots.

Installation

  1. To install, reverse the removal procedure.
WARNINGBefore beginning any service procedure in this service information, refer to Safety Warnings in SERVICE INFORMATION General Information. Failure to follow this instruction may result in serious personal injury.

Note. Removal steps in this procedure may contain installation details.

  1. Refer to: Health and Safety Precautions ( «HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#service-information-introduction-except-electric) ).
  2. Refer to: «Ignition Coil-On-Plug»(/ford/focus-st/iii-2012-2015/remont/ignition-system/#engine-ignition-20l-ecoboost__ignition-coil-on-plug) .
  3. Torque : 12 Nm
  1. To install, reverse the removal procedure.
