Engine Ignition - 2.0l Duratec-He Ford Focus ST III

Ignition System 2 illustrations ~248 words

Specifications

ItemNm
Ignition coil-on-plug bolts10
Spark plugs15

TORQUE SPECIFICATIONS

ItemValue
Spark plug12405
Spark plug gap0.035 in (.9 mm)

SPARK PLUG

Scheme 1

Scheme 1: Ignition Coil-On-Plug 2.0L Gasoline Direct Injection (GDI)
Scheme 1: Ignition Coil-On-Plug 2.0L Gasoline Direct Injection (GDI)
ItemDescription
1Ignition coil-on-plug bolt (4 required)
2Ignition coil-on-plug (4 required)
3Ignition coil-on-plug electrical connector

Scheme 2

Scheme 2: Spark Plugs 2.0L Gasoline Direct Injection (GDI)
Scheme 2: Spark Plugs 2.0L Gasoline Direct Injection (GDI)
ItemDescription
1Spark plug (4 required)

System Operation

ENGINE CONTROLS - DESCRIPTION & OPERATION (EXCEPT DIESEL & HYBRID) .

Component Description

ENGINE CONTROLS - DESCRIPTION & OPERATION (EXCEPT DIESEL & HYBRID) .

Ford diagnostic equipment

GENERAL EQUIPMENT

  1. For PCM Diagnostic Trouble Codes (DTCs), Refer to: Electronic Engine Controls ( «ELECTRONIC ENGINE CONTROLS»(/ford/focus-st/iii-2012-2015/remont/removal-installation/#electronic-engine-controls-20l-duratec-he) ). MIL Code List. For driveability symptoms without Diagnostic Trouble Codes (DTCs), ENGINE CONTROLS - SYMPTOM CHARTS (EXCEPT DIESEL & HYBRID) .

Ignition Coil-On-Plug

NameSpecification
Silicone Brake Caliper Grease and Dielectric Compound XG-3-AESE-M1C171-A

MATERIALS SPECIFICATIONS

Removal

WARNINGBefore beginning any service procedure in this service information, refer to Safety Warnings in SERVICE INFORMATION General Information. Failure to follow this instruction may result in serious personal injury.

Note. Removal steps in this procedure may contain installation details.

  1. Refer to: Health and Safety Precautions ( «HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#service-information-introduction-except-electric) ). Refer to: «Engine Ignition - Component Location»(/ford/focus-st/iii-2012-2015/remont/ignition-system/#engine-ignition-20l-duratec-he) .
  2. If equipped, remove the engine cover.
  3. Disconnect the 4 ignition coil-on-plug electrical connectors.
  4. Remove the 4 ignition coil-on-plug bolts. Torque : 10 Nm
  5. Remove the 4 ignition coil-on-plugs. Material : Silicone Brake Caliper Grease and Dielectric Compound / XG-3-A (ESE-M1C171-A)

Installation

  1. To install, slide the new ignition coil-on-plug boot onto the ignition coil until it is fully seated at the top of the ignition coil-on-plug.
  2. To install, reverse the removal procedure.
WARNINGBefore beginning any service procedure in this service information, refer to Safety Warnings in SERVICE INFORMATION General Information. Failure to follow this instruction may result in serious personal injury.

Note. Removal steps in this procedure may contain installation details.

  1. Refer to: Health and Safety Precautions ( «HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#service-information-introduction-except-electric) . Refer to: «Engine Ignition - Component Location»(/ford/focus-st/iii-2012-2015/remont/ignition-system/#engine-ignition-20l-duratec-he) .
  2. Refer to: «Ignition Coil-On-Plug»(/ford/focus-st/iii-2012-2015/remont/ignition-system/#engine-ignition-20l-duratec-he__ignition-coil-on-plug) .
  3. Torque : 15 Nm
  1. To install, reverse the removal procedure.
