Overview
The interior lighting system consists of
- Courtesy lamps
- Demand lamps
- Ambient lighting (if equipped)
The courtesy lamps subsystem consists of
- Interior lamps (roof mounted and front footwells)
- Puddle lamps
- Door ajar switches (integrated into the door latches)
- Courtesy lamp switch (integrated into the front interior lamp)
- DDM
- PDM
- BCM
The courtesy lamps provide illumination to the interior of the vehicle (and below the exterior mirrors if equipped with puddle lamps) when entering or exiting the vehicle or when requested using the courtesy lamp switch located on the front/driver interior lamp.
The demand lamps subsystem consists of
- Interior lamps (map lamps)
- Vanity mirror lamps
- Luggage compartment lamp
- BCM
The demand lamps provide illumination to specific areas within the vehicle when needed.
The BCM energizes the interior light relay to supply voltage to the demand lamps when the battery saver feature is not active.
The ambient lighting subsystem consists of
- Ambient lighting Light Emitting Diodes (LEDs)
- Ambient lighting module (integrated into the overhead console)
- Ambient lighting switches (integrated into the overhead console)
The ambient lighting provides aesthetically colored illumination to the center console cup holders, the door map pockets, the overhead console, the door release handles, and the front footwells for illuminated entry or when the ignition is in RUN with the parking lamps on. The ambient lighting is controlled using the buttons and knob on the overhead console.
Scheme 1
Network Message Chart
| Broadcast Message | Originating Module | Message Purpose |
|---|---|---|
| RKE data | RFA module | Provides information regarding the RKE system for the BCM to activate or deactivate the illuminated entry/exit features. |
| Drivers door latch status | DDM | Provides door lock status to the BCM to activate or deactivate the illuminated entry/exit features |
| Passengers door latch status | PDM | Provides door lock status to the BCM to activate or deactivate the illuminated entry/exit features |
BCM NETWORK INPUT MESSAGES
| Broadcast Message | Originating Module | Message Purpose |
|---|---|---|
| Puddle lamp activation | BCM | Provides puddle lamp request from the BCM to activate the exterior mirror puddle lamps. |
DDM AND PDM NETWORK INPUT MESSAGES
Battery Saver
Note. Time-out is 30 seconds if the vehicle is in Factory or Transport mode.
The BCM provides automatic shut-off of the courtesy and demand lamps after a time-out period when the ignition is OFF. A timer in the BCM starts when
- the ignition transitions to OFF.
- any door or liftgate/luggage compartment lid becomes ajar.
- an UNLOCK button of the RKE transmitter is pressed.
- a door is unlocked using a key.
- the door lock switch is pressed.
When 10 minutes (30 minutes for demand lamps) have elapsed, the BCM automatically shuts off voltage to the lamps. The timer restarts (voltage is restored if the BCM is in battery saver mode) if
- the ignition transitions out of OFF.
- any door or liftgate/luggage compartment lid becomes ajar.
- the UNLOCK button of the RKE transmitter is pressed.
- a door is unlocked using a key.
- the door lock switch is pressed.
Courtesy Lamps
The BCM controls the courtesy lighting functions and timing by monitoring inputs from the following
- Door ajar switches
- Ignition state
- RKE system
For vehicles equipped with puddle lamps, the DDM and the PDM provide voltage to the left and right puddle lamps based on messaged input from the BCM over the communication network.
The BCM sends a voltage signal to each door or liftgate ajar switch. When the doors or liftgate are closed, the circuit is switched to ground and the voltage is pulled low, indicating closed doors.
For vehicles equipped with door modules, the DDM and the PDM provides ground for the door ajar switch.
The BCM monitors the ignition state and inputs from the RKE system to determine when to energize the interior light relay. When the interior light relay is energized, voltage is provided to the interior lamps. The BCM controls the ground side of the courtesy lamps for the illuminated entry and exit features.
For keyless entry, the BCM monitors input from the RKE transmitter (directly from the integrated keyhead transmitters (IKTs on vehicles without intelligent access (IA)) or from the RFA module (on vehicles with intelligent access (IA)) to determine when to activate/deactivate the illuminated entry and exit functions.
The interior courtesy lamps can also be activated from the courtesy lamp switch mounted on the front/ driver interior lamp. The front interior lamp (vehicles without a roof opening panel) or the driver interior lamp (vehicles with a roof opening panel) controls the courtesy lamp function of the remaining interior lamp(s). When the courtesy lamp button is pressed on the front/driver interior lamp, the courtesy lamp function for all the lamps is turned on/off. If any door is open, the BCM command overrides the function of the front/driver courtesy lamp switch and activates the courtesy lamps.
Illuminated Entry and Exit
The illuminated entry and exit features provide temporary illumination of the parking lamps, the dimmable backlighting, the ambient backlighting and the courtesy lamps. Refer to the chart for additional information.
Note. An arbitrator (software programming) within the BCM determines which actions take precedence over others (for example, an open door keeps the courtesy lamps on even when a command to lock the doors is received).
| Action | Parking Lamps | Courtesy Lamps | Dimmable Backlighting | Ambient Lighting |
|---|---|---|---|---|
| RKE transmitter or mechanical unlocking of the doors | On for 25 seconds | On for 25 seconds | On for 25 seconds | Off (activated when door becomes open) |
| RKE transmitter or mechanical locking of the doors | Off | Off | Off | Off after 3 seconds |
| Open a closed door after previously unlocking (no ignition state change since unlock) | Off (on for remaining time if unlocked from transmitter or mechanical unlocking of the doors) | On | On | On |
| Close all doors | Off | On for 25 seconds | On for 25 seconds | On for 25 seconds |
| Ignition changed to ON | Off | On for 25 seconds | Off | On/Off according to customer setting |
| Ignition changed out of ON | Off | On for 25 seconds | On for 25 seconds | On for 25 seconds |
| Open a door after the ignition is changed to OFF | Off | On | Off | On for 25 seconds (multi color turns RED) |
| Ignition is OFF and doors are unlocked from the door lock switch | Off | On for 25 seconds | Off | Off |
| Ignition is OFF and doors are locked from the door lock switch | Off | Off | Off | Off |
Theater Lighting
The theater lighting option ramps-up the courtesy lamps over 0.7 seconds when courtesy lamp is requested. The theater lighting feature ramps-down the courtesy lamps over 1.7 seconds when interior lighting deactivation is requested by any feature other than the panic alarm or battery saver.
Demand Lamps
When the BCM is in not in battery saver mode, the interior light relay is energized to provide voltage to the demand lamps.
Ambient Lighting
The ambient lighting subsystem consists of the ambient lighting switch, dimmer control and the ambient lighting module (all integrated into the overhead console), and the Light Emitting Diodes (LEDs) located within the floor console cup holders, front door panels and under the instrument panel footwell areas. The ambient lighting is operational when the ignition is in any state other than OFF (the exception is when it is used in conjunction with the illuminated entry/exit features), the headlamps are on and the outside ambient light level is low. The ambient lighting switch cycles the Light Emitting Diodes (LEDs) through 7 different color combinations. The brightness is changed using the dimmer control which allows the Light Emitting Diodes (LEDs) to be turned off as well.
The right search mode control switch activates all ambient light areas and all dome lamps. The search mode control switch needs to be pressed again to deactivate the dome lamps and return to the previously selected ambient light color.
The ambient lighting control module controls the color and light intensity. The ambient lighting module receives information from the BCM through a LIN circuit for illuminated entry/exit functions. The ambient lighting module provides voltage to all of the Light Emitting Diodes (LEDs). A secondary LIN circuit is routed from the ambient lighting module to all of the Light Emitting Diodes (LEDs). Each LED changes color and intensity based on the input from the ambient lighting module.
As an additional function, the ambient lighting illuminates red on any open door.
Door Ajar Switch
The door ajar switches (ground switches) each receive a voltage signal from the BCM on independent circuits. When the door is closed, the door ajar switch is closed, routing the signal to ground. When the door is opened, the door ajar switch opens.
Ground is provided to the door ajar switches from the door modules.
Interior Lamp
All of the interior lamps receive voltage from the interior lamp relay (integrated into the BCM) when the battery saver feature is not active. This is used by each interior lamp to power the LED within it.
The front interior lamp uses a private communication protocol to command the rear lamps on or off.
Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: DIAGNOSTIC METHODS .
DTC Chart: Body Control Module (BCM)
| DTC | Description | Action |
|---|---|---|
| B1088:86 | LIN Bus "B": Signal Invalid | GO to Pinpoint Test H |
| B1088:88 | LIN Bus "B": Bus off | GO to Pinpoint Test H |
| B1175:64 | Drivers Door Ajar Switch: Signal Plausibility Failure | If the courtesy lamps are inoperative from the driver door, GO to Pinpoint Test A If the courtesy lamps are always on, GO to Pinpoint Test C |
| B11E9:13 | Left Rear Door Ajar Switch: Circuit Open | GO to Pinpoint Test C |
| B11EA:13 | Right Rear Door Ajar Switch: Circuit Open | GO to Pinpoint Test C |
| B1318:13 | Right Front Door Ajar Switch: Circuit Open | GO to Pinpoint Test C |
| B131B:13 | Left Front Door Ajar Switch: Circuit Open | GO to Pinpoint Test C |
| B1390:87 | Ambient Light Control Module: Missing Message | GO to Pinpoint Test H |
| B1D13:11 | Interior Lights Circuit "A": Circuit Short to Ground | If the interior courtesy lamps are always on, GO to Pinpoint Test D If the interior courtesy lamps are inoperative, GO to Pinpoint Test B |
| B1D13:12 | Interior Lights Circuit "A": Circuit Short To Battery | GO to Pinpoint Test B |
BCM DTC CHART
DTC Chart: Driver Door Module (DDM)
| DTC | Description | Action |
|---|---|---|
| B12C2:11 | Puddle Lamp: Circuit Short To Ground | GO to Pinpoint Test I |
| B12C2:15 | Puddle Lamp: Circuit Short To Battery Or Open | GO to Pinpoint Test I |
DDM DTC CHART
DTC Chart: Passenger Door Module (PDM)
| DTC | Description | Action |
|---|---|---|
| B12C2:11 | Puddle Lamp: Circuit Short To Ground | GO to Pinpoint Test I |
| B12C2:15 | Puddle Lamp: Circuit Short To Battery Or Open | GO to Pinpoint Test I |
PDM DTC CHART
Symptom Chart(s)
Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: DIAGNOSTIC METHODS .
Symptom Chart: Interior Lighting
| Condition | Possible Sources | Actions |
|---|---|---|
| A module does not respond to the scan tool | Fuse Wiring, terminals or connectors Module | REFER to: COMMUNICATIONS NETWORK . |
| The courtesy lamps flash on and off | The BCM is not configured correctly | This symptom is present due to incomplete or improper Programmable Module Installation (PMI) procedures. REPEAT/PERFORM the Programmable Module Installation (PMI) procedure as directed by the scan tool. REFER to: MODULE CONFIGURATION - SYSTEM OPERATION AND COMPONENT DESCRIPTION . |
| The courtesy lamps do not illuminate with a door open | Refer to the Diagnostic Routine | GO to Pinpoint Test A |
| One or more interior courtesy lamps are inoperative | Refer to the Diagnostic Routine | GO to Pinpoint Test B |
| A puddle lamp is inoperative or always on | Refer to the Diagnostic Routine | GO to Pinpoint Test I |
| All the courtesy lamps stay on continuously | Refer to the Diagnostic Routine | GO to Pinpoint Test C |
| The interior courtesy lamps stay on continuously | Refer to the Diagnostic Routine | GO to Pinpoint Test D |
| The luggage compartment lamp is inoperative or on continuously | Refer to the Diagnostic Routine | GO to Pinpoint Test E |
| One or more demand lamps are inoperative | Refer to the Diagnostic Routine | GO to Pinpoint Test F |
| The battery saver does not deactivate after timeout | Refer to the Diagnostic Routine | GO to Pinpoint Test G |
| The ambient lighting is inoperative | Refer to the Diagnostic Routine | GO to Pinpoint Test H |
| The ambient lighting does not cycle through all color combinations | Overhead console | NOTE: Make sure that the ambient lighting has not been placed in "search mode" using the ambient lighting switch on the right. This places the ambient lighting in a "white light" setting and does not allow the color to change. The ambient lighting switch on the left is used to cycle through the different color variations. INSTALL a new overhead console. REFER to: OVERHEAD CONSOLE . |
| The ambient lighting brightness setting cannot be changed | Overhead console | INSTALL a new overhead console. REFER to: OVERHEAD CONSOLE . |
| An individual ambient light is inoperative or does not change color | Refer to the Diagnostic Routine | GO to Pinpoint Test J |
| NOTE |
|---|
| Make sure that the ambient lighting has not been placed in "search mode" using the ambient lighting switch on the right. This places the ambient lighting in a "white light" setting and does not allow the color to change. The ambient lighting switch on the left is used to cycle through the different color variations. |
SYMPTOM CHART
The Courtesy Lamps Do Not Illuminate With a Door Open
Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: DIAGNOSTIC METHODS .
Refer to REMOTE KEYLESS ENTRY AND ALARM for schematic and connector information.
Normal Operation and Fault Conditions
Possible Sources
- Wiring, terminals or connectors
- Door latch
- BCM
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| B1175:64 | Drivers Door Ajar Switch: Signal Plausibility Failure | Sets when the BCM detects a short to ground from the driver door ajar input circuit. |
DTC FAULT TRIGGER CONDITIONS
PINPOINT TEST A: THE COURTESY LAMPS DO NOT ILLUMINATE WITH A DOOR OPEN
- A1: CHECK THE OPERATION OF THE COURTESY LAMP FUNCTION FROM THE FRONT/DRIVER INTERIOR LAMP Ignition OFF. Use the courtesy lamp switch on the front interior lamp to activate the overhead courtesy lamps. Do the overhead courtesy lamps illuminate? Yes: GO to A2 No: GO to «Pinpoint Test B»(/ford/focus-st/iii-2012-2015/remont/interiorillumination-lights/#interior-lighting-system-except-electric)
- A2 CHECK THE DOOR AJAR SWITCH OPERATION Deactivate the overhead courtesy lamps from the front interior lamp. Disconnect: Suspect Door Latch. Do the courtesy lamps illuminate? Yes: For a front door, INSTALL a new front door latch. REFER to: «FRONT DOOR LATCH»(/ford/focus-st/iii-2012-2015/remont/door-locks-anti-theft-systems/#handles-locks-latches-and-entry-systems-vehicles-without-one-touch-up-door-window-except-electric__front-door-latch) (Vehicles Without: One-Touch Up Door Window) . or REFER to: «FRONT DOOR LATCH»(/ford/focus-st/iii-2012-2015/remont/door-locks-anti-theft-systems/#handles-locks-latches-and-entry-systems-vehicles-with-one-touch-up-door-window-except-electric__front-door-latch) (Vehicles With: One-Touch Up Door Window) . For a rear door, INSTALL a new rear door latch. REFER to: «REAR DOOR LATCH»(/ford/focus-st/iii-2012-2015/remont/door-locks-anti-theft-systems/#handles-locks-latches-and-entry-systems-vehicles-without-one-touch-up-door-window-except-electric) (Vehicles Without: One-Touch Up Door Window) . or REFER to: «REAR DOOR LATCH»(/ford/focus-st/iii-2012-2015/remont/door-locks-anti-theft-systems/#handles-locks-latches-and-entry-systems-vehicles-with-one-touch-up-door-window-except-electric) (Vehicles With: One-Touch Up Door Window) . No: GO to A3
- A3 CHECK THE DOOR AJAR SWITCH INPUT CIRCUIT FOR A SHORT TO GROUND Disconnect: BCM C2280B. Measure: LH FRONT DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C525-3 ohms - RH FRONT DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C609-6 ohms - LH REAR DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C705-3 ohms - RH REAR DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C805-6 ohms - Is the resistance greater than 10, 000 ohms? Yes: GO to A4 No: REPAIR the circuit.
- A4 CHECK FOR CORRECT BODY CONTROL MODULE (BCM) OPERATION Disconnect and inspect all BCM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the BCM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new BCM. REFER to: «BODY CONTROL MODULE (BCM)»(/ford/focus-st/iii-2012-2015/remont/cruise-control-systems/#multifunction-electronic-modules-except-electric) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues. CLEAR the Diagnostic Trouble Codes (DTCs).
One Or More Interior Courtesy Lamps Are Inoperative
Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: DIAGNOSTIC METHODS .
Refer to INTERIOR LAMPS for schematic and connector information.
- Fuse
- Wiring, terminals or connectors
- Interior lamp
- BCM
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| B1D13:11 | Interior Lights Circuit "A": Circuit Short To Ground | Sets when the BCM detects an open from the courtesy lighting ground control circuit. |
| B1D13:12 | Interior Lights Circuit "A": Circuit Short To Battery | Sets when the BCM detects a short to battery voltage from the courtesy lighting ground control circuit. |
DTC FAULT TRIGGER CONDITIONS
Visual Inspection and Diagnostic Pre-checks
- Verify BCM fuse 60 (10A) is OK.
Scheme 2
Scheme 3
Scheme 4
- B1: CHECK THE DOOR AJAR PARAMETER IDENTIFICATIONS (PIDS) Ignition ON. Using a scan tool, view the BCM Parameter Identifications (PIDs). Monitor the BCM DOOR_SW_LR, DOOR_SW_PSGR, DOOR_SW_LR and DOOR_SW_RR Parameter Identifications (PIDs) while opening and closing all the doors. Do all the door ajar switch Parameter Identification (PID) values agree with the door positions? Yes: GO to B2 No: GO to «Pinpoint Test A»(/ford/focus-st/iii-2012-2015/remont/interiorillumination-lights/#interior-lighting-system-except-electric__pinpoint-test-a-the-courtesy-lamps)
- B2 CHECK THE OPERATION OF ALL THE INTERIOR COURTESY LAMPS Open a door and observe the interior courtesy lamps. Are all the interior courtesy lamps inoperative? Yes: VERIFY the BCM fuse 60 (10A) is OK. If OK, GO to B3 If not OK, REFER to the OEM WIRING DIAGRAMS to identify the possible causes of the circuit short. No: If all of the overhead courtesy lamps are inoperative, GO to B3 If both footwell lamps are inoperative, GO to B8 If an individual footwell lamp is inoperative (without ambient lighting), GO to B9 If only the front interior lamp is inoperative (without a roof opening panel), INSTALL a new interior lamp. If only the LH front interior lamp is inoperative (with a roof opening panel), INSTALL a new interior lamp. If the rear lamp (without a roof opening panel) is inoperative, GO to B9 If the RH front or a rear lamp (with a roof opening panel) is inoperative, GO to B9 If the RH front, and rear lamp (with a roof opening panel) are both inoperative, GO to B15
- B3 CHECK FOR VOLTAGE TO THE FRONT/DRIVER COURTESY LAMP Close the door. Ignition OFF. Disconnect: Front Interior Lamp C931 (without a roof opening panel). Disconnect: LH Front Interior Lamp C908 (with a roof opening panel). Ignition ON. Open a door. Measure: FRONT INTERIOR LAMP (WITHOUT A ROOF OPENING PANEL) Positive Lead Measurement / Action Negative Lead C931-1 - LH FRONT INTERIOR LAMP (WITH A ROOF OPENING PANEL) Positive Lead Measurement / Action Negative Lead C908-1 - Is the voltage greater than 11 volts? Yes: GO to B5 No: GO to B4
- B4 BYPASS THE BODY CONTROL MODULE (BCM) (INTERIOR LIGHT RELAY) Ignition OFF. Connect: Front Interior Lamp C931 (without a roof opening panel). Connect: LH Front Interior Lamp C908 (with a roof opening panel). Disconnect: BCM C2280F. Connect: Positive Lead Measurement / Action Negative Lead C2280F-12 Battery Positive Ignition ON. Open any door. Do the courtesy lamps illuminate? Yes: REMOVE the jumper wire. GO to B20 No: REMOVE the jumper wire. REPAIR the courtesy lamp voltage supply circuit for an open.
- B5 CHECK THE FRONT/DRIVER COURTESY LAMP GROUND CIRCUIT FOR AN OPEN Measure: FRONT INTERIOR LAMP (WITHOUT A ROOF OPENING PANEL) Positive Lead Measurement / Action Negative Lead C931-1 C931-5 LH FRONT INTERIOR LAMP (WITH A ROOF OPENING PANEL) Positive Lead Measurement / Action Negative Lead C908-1 C908-5 Is the voltage greater than 11 volts? Yes: GO to B6 No: REPAIR the circuit.
- B6 BYPASS THE BCM (BODY CONTROL MODULE) GROUND CONTROL Ignition OFF. Connect: Front Interior Lamp C931 (without a roof opening panel). Connect: LH Front Interior Lamp C908 (with a roof opening panel). Disconnect: BCM C2280H. Connect: Positive Lead Measurement / Action Negative Lead C2280H-11 - Ignition ON. Open any door. Do the courtesy lamps illuminate? Yes: REMOVE the jumper wire. GO to B20 No: LEAVE the jumper wire connected. GO to B7
- B7 CHECK THE COURTESY LAMP GROUND CONTROLLED CIRCUIT FOR AN OPEN Disconnect: Front Interior Lamp C931 (without a roof opening panel). Disconnect: LH Front Interior Lamp C908 (with a roof opening panel). Measure: FRONT INTERIOR LAMP (WITHOUT A ROOF OPENING PANEL) Positive Lead Measurement / Action Negative Lead C931-1 C931-4 LH FRONT INTERIOR LAMP (WITH A ROOF OPENING PANEL) Positive Lead Measurement / Action Negative Lead C908-1 C908-4 Is the voltage greater than 11 volts? Yes: REMOVE the jumper wire. INSTALL a new interior lamp. No: REMOVE the jumper wire. REPAIR the circuit.
- B8 CHECK THE FOOTWELL LAMP GROUND CONTROLLED CIRCUIT FOR AN OPEN Ignition OFF. Disconnect: BCM C2280C. Connect: Positive Lead Measurement / Action Negative Lead C2280C-21 - Ignition ON. Do the footwell lamps illuminate? Yes: REMOVE the jumper wire. GO to B20 No: REMOVE the jumper wire. REPAIR the circuit.
- B9 CHECK FOR VOLTAGE TO THE INOPERATIVE INTERIOR COURTESY LAMP Ignition OFF. Disconnect: Inoperative Interior Lamp. Ignition ON. Measure: LH INCANDESCENT FOOTWELL LAMP Positive Lead Measurement / Action Negative Lead C209-1 - RH INCANDESCENT FOOTWELL LAMP Positive Lead Measurement / Action Negative Lead C266-1 - LH LED FOOTWELL LAMP Positive Lead Measurement / Action Negative Lead C2056-1 - RH LED FOOTWELL LAMP Positive Lead Measurement / Action Negative Lead C2057-1 - RH FRONT INTERIOR LAMP (WITH A ROOF OPENING PANEL) Positive Lead Measurement / Action Negative Lead C903-1 - REAR INTERIOR LAMP Positive Lead Measurement / Action Negative Lead C901-1 - Is the voltage greater than 11 volts? Yes: GO to B10 No: REPAIR the courtesy lamp voltage supply circuit for an open.
- B10 CHECK THE COURTESY LAMP GROUND CIRCUIT FOR AN OPEN Measure: LH INCANDESCENT FOOTWELL LAMP Positive Lead Measurement / Action Negative Lead C209-1 C209-2 RH INCANDESCENT FOOTWELL LAMP Positive Lead Measurement / Action Negative Lead C266-1 C266-2 LH LED FOOTWELL LAMP Positive Lead Measurement / Action Negative Lead C2056-1 C2056-2 RH LED FOOTWELL LAMP Positive Lead Measurement / Action Negative Lead C2057-1 C2057-2 RH FRONT INTERIOR LAMP (WITH A ROOF OPENING PANEL) Positive Lead Measurement / Action Negative Lead C903-1 C903-5 REAR INTERIOR LAMP Positive Lead Measurement / Action Negative Lead C901-1 C901-5 Is the voltage greater than 11 volts? Yes: For a footwell lamp, INSTALL a new footwell lamp. For any overhead interior lamp, GO to B11 No: REPAIR the circuit.
- B11 CHECK THE PASSENGER/REAR LAMP CONTROL CIRCUIT FOR REFERENCE VOLTAGE Open any door. Measure: RH FRONT INTERIOR LAMP (WITH A ROOF OPENING PANEL) Positive Lead Measurement / Action Negative Lead C903-4 - REAR INTERIOR LAMP Positive Lead Measurement / Action Negative Lead C901-4 - Is the voltage between 4 and 6 volts? Yes: INSTALL a new rear interior lamp. No: For vehicles equipped with a roof opening panel, REPAIR the passenger/rear lamp control circuit for an open. For vehicles not equipped with a roof opening panel, GO to B12
- B12 CHECK THE REAR LAMP CONTROL CIRCUIT FOR A SHORT TO VOLTAGE Ignition OFF. Disconnect: Front Interior Lamp C931. Ignition ON. Measure: Positive Lead Measurement / Action Negative Lead C931-2 - Is any voltage present? Yes: REPAIR the circuit. No: GO to B13
- B13 CHECK THE REAR LAMP CONTROL CIRCUIT FOR A SHORT TO GROUND Ignition OFF. Measure: Positive Lead Measurement / Action Negative Lead C931-2 ohms - Is the resistance greater than 10, 000 ohms? Yes: GO to B14 No: REPAIR the circuit.
- B14 CHECK THE REAR LAMP CONTROL CIRCUIT FOR AN OPEN Measure: Positive Lead Measurement / Action Negative Lead C931-2 ohms C901-4 Is the resistance less than 3 ohms? Yes: INSTALL a new front interior lamp. No: REPAIR the circuit.
- B15 ISOLATE THE PASSENGER INTERIOR LAMP Close the door. Ignition OFF. Disconnect: RH Front Interior Lamp C903. Open any door. Does the rear interior lamp illuminate? Yes: INSTALL a new RH front interior lamp. No: GO to B16
- B16 ISOLATE THE REAR INTERIOR LAMP Close the door. Ignition OFF. Connect: RH Front Interior Lamp C903. Disconnect: Rear Interior Lamp C901. Open any door. Does the RH front interior lamp illuminate? Yes: INSTALL a new RH front interior lamp. No: GO to B17
- B17 CHECK THE PASSENGER/REAR LAMP CONTROL CIRCUIT FOR A SHORT TO VOLTAGE Close the door. Disconnect: RH Front Interior Lamp C903. Disconnect: LH Front Interior Lamp C908. Ignition ON. Measure: Positive Lead Measurement / Action Negative Lead C908-2 - Is any voltage present? Yes: REPAIR the circuit. No: GO to B18
- B18 CHECK THE PASSENGER/REAR LAMP CONTROL CIRCUIT FOR A SHORT TO GROUND Ignition OFF. Measure: Positive Lead Measurement / Action Negative Lead C908-2 ohms - Is the resistance greater than 10, 000 ohms? Yes: GO to B19 No: REPAIR the circuit.
- B19 CHECK THE PASSENGER/REAR LAMP CONTROL CIRCUIT FOR AN OPEN Measure: Positive Lead Measurement / Action Negative Lead C908-2 ohms C901-4 Is the resistance less than 3 ohms? Yes: INSTALL a new LH front interior lamp. No: REPAIR the circuit.
- B20 CHECK FOR CORRECT BODY CONTROL MODULE (BCM) OPERATION Disconnect and inspect all BCM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the BCM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new BCM. REFER to: «BODY CONTROL MODULE (BCM)»(/ford/focus-st/iii-2012-2015/remont/cruise-control-systems/#multifunction-electronic-modules-except-electric) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues. CLEAR the Diagnostic Trouble Codes (DTCs).
All The Courtesy Lamps Stay On Continuously
Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: DIAGNOSTIC METHODS .
Refer to INTERIOR LAMPS for schematic and connector information.
- Wiring, terminals or connectors
- Ajar switch
- BCM
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| B1175:64 | Drivers Door Ajar Switch: Signal Plausibility Failure | May set when the BCM detects an open from the left front door ajar circuit. |
| B11E9:13 | Left Rear Door Ajar Switch: Circuit Open | Sets when the BCM detects an open from the left rear door ajar circuit. |
| B11EA:13 | Right Rear Door Ajar Switch: Circuit Open | Sets when the BCM detects an open from the right rear door ajar circuit. |
| B1318:13 | Right Front Door Ajar Switch: Circuit Open | Sets when the BCM detects an open from the right front door ajar circuit. |
| B131B:13 | Left Front Door Ajar Switch: Circuit Open | Sets when the BCM detects an open from the left front door ajar circuit. |
DTC FAULT TRIGGER CONDITIONS
Scheme 5
- C1: CHECK THE DOOR AJAR SWITCH PARAMETER IDENTIFICATIONS (PIDS) Ignition ON. Using a scan tool, view BCM Parameter Identifications (PIDs). Monitor the BCM DOOR_SW_DRVR, DOOR_SW_PSGR, DOOR_SW_LR and DOOR_SW_RR Parameter Identifications (PIDs) while opening and closing all the doors. Do all the door ajar switch Parameter Identification (PID) values agree with the door positions? Yes: GO to «Pinpoint Test D»(/ford/focus-st/iii-2012-2015/remont/interiorillumination-lights/#interior-lighting-system-except-electric__pinpoint-test-d-the-interior-courtesy) No: GO to C2
- C2 BYPASS THE SUSPECT DOOR LATCH Disconnect: Suspect Door Switch. Connect: LH FRONT DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C525-3 C525-5 RH FRONT DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C609-6 C609-4 LH REAR DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C705-3 C705-5 RH REAR DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C805-6 C805-4 Using a scan tool, view BCM Parameter Identifications (PIDs). Monitor the BCM DOOR_SW_DRVR, DOOR_SW_PSGR, DOOR_SW_LR and DOOR_SW_RR Parameter Identifications (PIDs). Does the Parameter Identification (PID) indicate the door in question is closed? Yes: REMOVE the jumper wire. For a front door, INSTALL a new front door latch. REFER to: «FRONT DOOR LATCH»(/ford/focus-st/iii-2012-2015/remont/door-locks-anti-theft-systems/#handles-locks-latches-and-entry-systems-vehicles-without-one-touch-up-door-window-except-electric__front-door-latch) (Vehicles Without: One-Touch Up Door Window) ). or REFER to: «FRONT DOOR LATCH»(/ford/focus-st/iii-2012-2015/remont/door-locks-anti-theft-systems/#handles-locks-latches-and-entry-systems-vehicles-with-one-touch-up-door-window-except-electric__front-door-latch) (Vehicles With: One-Touch Up Door Window) . REMOVE the jumper wire. For a rear door, INSTALL a new rear door latch. REFER to: «REAR DOOR LATCH»(/ford/focus-st/iii-2012-2015/remont/door-locks-anti-theft-systems/#handles-locks-latches-and-entry-systems-vehicles-without-one-touch-up-door-window-except-electric) (Vehicles Without: One-Touch Up Door Window) . or REFER to: «REAR DOOR LATCH»(/ford/focus-st/iii-2012-2015/remont/door-locks-anti-theft-systems/#handles-locks-latches-and-entry-systems-vehicles-with-one-touch-up-door-window-except-electric) (Vehicles With: One-Touch Up Door Window) . No: REMOVE the jumper wire. GO to C3
- C3 BYPASS THE DOOR LATCH GROUND CIRCUIT Connect: LH FRONT DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C525-3 - RH FRONT DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C609-6 - LH REAR DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C705-3 - RH REAR DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C805-6 - Monitor the BCM DOOR_SW_DRVR, DOOR_SW_PSGR, DOOR_SW_LR and DOOR_SW_RR Parameter Identifications (PIDs). Does the PID indicate the door in question is closed? Yes: REMOVE the jumper wire. For vehicles not equipped with a door module, REPAIR door latch ground circuit in question for an open. For vehicles equipped with a door module, GO to C5 No: REMOVE the jumper wire. GO to C4
- C4 CHECK THE SUSPECT DOOR AJAR SWITCH INPUT CIRCUIT FOR AN OPEN Disconnect: BCM C2280B. Measure: LH FRONT DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C525-3 ohms C2280B-45 RH FRONT DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C609-6 ohms C2280B-46 LH REAR DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C705-3 ohms C2280B-44 RH REAR DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C805-6 ohms C2280B-25 Is the resistance less than 3 ohms? Yes: GO to C7 No: REPAIR the door ajar input circuit in question.
- C5 CHECK THE DOOR LATCH RETURN CIRCUIT TO THE DOOR MODULE FOR AN OPEN Connect: Suspect Door Latch. Disconnect: Suspect Door Module. Connect: LH FRONT DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C501A-14 - RH FRONT DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C652A-14 - LH REAR DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C728-14 - RH REAR DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C832-14 - Close the door. Monitor the BCM DOOR_SW_DRVR, DOOR_SW_PSGR, DOOR_SW_LR and DOOR_SW_RR Parameter Identifications (PIDs). Does the Parameter Identification (PID) indicate the door is closed? Yes: REMOVE the jumper wire. GO to C6 No: REMOVE the jumper wire. REPAIR the door latch return circuit in question.
- C6 CHECK THE DOOR MODULE GROUND CIRCUIT FOR AN OPEN Connect: LH FRONT DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C501A-14 C501A-13 RH FRONT DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C652A-14 C652A-13 LH REAR DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C728-14 C728-13 RH REAR DOOR AJAR SWITCH Positive Lead Measurement / Action Negative Lead C832-14 C831-13 Monitor the BCM DOOR_SW_DRVR, DOOR_SW_PSGR, DOOR_SW_LR and DOOR_SW_RR Parameter Identifications (PIDs). Does the Parameter Identification (PID) indicate the door is closed? Yes: REMOVE the jumper wire. INSTALL a new door module in question. REFER to: «DOOR MODULE»(/ford/focus-st/iii-2012-2015/remont/cruise-control-systems/#multifunction-electronic-modules-except-electric) . No: REMOVE the jumper wire. REPAIR the circuit.
- C7 CHECK FOR CORRECT BODY CONTROL MODULE (BCM) OPERATION Disconnect and inspect all BCM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the BCM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new BCM. REFER to: «BODY CONTROL MODULE (BCM)»(/ford/focus-st/iii-2012-2015/remont/cruise-control-systems/#multifunction-electronic-modules-except-electric) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues. CLEAR the Diagnostic Trouble Codes (DTCs).
The Interior Courtesy Lamps Stay On Continuously
Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: DIAGNOSTIC METHODS .
Refer to INTERIOR LAMPS for schematic and connector information.
- Wiring, terminals or connectors
- BCM
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| B1D13:11 | Interior Lights Circuit "A": Circuit Short To Ground | Sets when the BCM detects a short to ground from the courtesy lighting ground control circuit. |
DTC FAULT TRIGGER CONDITIONS
PINPOINT TEST D: THE INTERIOR COURTESY LAMPS STAY ON CONTINUOUSLY
- D1: CHECK THE DOOR AJAR SWITCH PARAMETER IDENTIFICATIONS (PIDS) Ignition ON. Using a scan tool, monitor the BCM Parameter Identifications (PIDs). Monitor the BCM DOOR_SW_DRVR, DOOR_SW_PSGR, DOOR_SW_LR and DOOR_SW_RR Parameter Identifications (PIDs) while opening and closing all the doors. Do all the door ajar switch Parameter Identification (PID) values agree with the door positions? Yes: If equipped with footwell lamps, GO to D2 If not equipped with footwell lamps, GO to D3 No: GO to «Pinpoint Test C»(/ford/focus-st/iii-2012-2015/remont/interiorillumination-lights/#interior-lighting-system-except-electric)
- D2 CHECK THE FOOTWELL LAMP GROUND CONTROLLED CIRCUIT FOR A SHORT TO GROUND Ignition OFF. Disconnect: BCM C2280C. Ignition ON. Do the footwell lamps continue to illuminate? Yes: REPAIR the circuit. No: GO to D3
- D3 ISOLATE THE BODY CONTROL MODULE (BCM) Ignition OFF. Disconnect: BCM C2280H. Ignition ON. Do the interior courtesy lamps continue to illuminate? Yes: GO to D4 No: GO to D5
- D4 CHECK THE INTERIOR COURTESY LAMP GROUND CONTROLLED CIRCUIT FOR A SHORT TO GROUND Ignition OFF. Disconnect: Front Interior Lamp C931 (without a roof opening panel). Disconnect: LH Front Interior Lamp C908 (with a roof opening panel). Measure: FRONT INTERIOR LAMP (WITHOUT A ROOF OPENING PANEL) Positive Lead Measurement / Action Negative Lead C931-4 ohms - LH FRONT INTERIOR LAMP (WITH A ROOF OPENING PANEL) Positive Lead Measurement / Action Negative Lead C908-4 ohms - Is the resistance greater than 10, 000 ohms? Yes: INSTALL a new LH front/front interior lamp. No: REPAIR the circuit.
- D5 CHECK FOR CORRECT BODY CONTROL MODULE (BCM) OPERATION Disconnect and inspect all BCM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the BCM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new BCM. REFER to: «BODY CONTROL MODULE (BCM)»(/ford/focus-st/iii-2012-2015/remont/cruise-control-systems/#multifunction-electronic-modules-except-electric) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues. CLEAR the Diagnostic Trouble Codes (DTCs).
The Luggage Compartment Lamp Is Inoperative Or On Continuously
Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: DIAGNOSTIC METHODS .
Refer to INTERIOR LAMPS for schematic and connector information.
- Wiring, terminals or connectors
Scheme 6
Scheme 7
- E1: DETERMINE IF THE LAMP IS ON WITH THE LIFTGATE/LUGGAGE COMPARTMENT LID CLOSED Ignition ON. Make sure the liftgate is fully latched and observe the luggage compartment lamp(s). Is the luggage compartment lamp illuminated? Yes: GO to E2 No: GO to E3
- E2 CHECK THE LUGGAGE COMPARTMENT LAMP GROUND CIRCUIT FOR A SHORT TO GROUND Disconnect: Liftgate/Luggage Compartment Lid Latch C4223. Does the luggage compartment lamp continue to illuminate? Yes: REPAIR the circuit. No: For a 4-door vehicle, INSTALL a new luggage compartment lid latch. REFER to: «LUGGAGE COMPARTMENT LID LATCH»(/ford/focus-st/iii-2012-2015/remont/door-locks-anti-theft-systems/#handles-locks-latches-and-entry-systems-vehicles-without-one-touch-up-door-window-except-electric) (Vehicles Without: One-Touch Up Door Window) . or REFER to: «LUGGAGE COMPARTMENT LID LATCH»(/ford/focus-st/iii-2012-2015/remont/door-locks-anti-theft-systems/#handles-locks-latches-and-entry-systems-vehicles-with-one-touch-up-door-window-except-electric) (Vehicles With: One-Touch Up Door Window) . For a 5-door vehicle, INSTALL a new liftgate latch. REFER to: «LIFTGATE LATCH»(/ford/focus-st/iii-2012-2015/remont/door-locks-anti-theft-systems/#handles-locks-latches-and-entry-systems-vehicles-without-one-touch-up-door-window-except-electric) (Vehicles Without: One-Touch Up Door Window) . or REFER to: «LIFTGATE LATCH»(/ford/focus-st/iii-2012-2015/remont/door-locks-anti-theft-systems/#handles-locks-latches-and-entry-systems-vehicles-with-one-touch-up-door-window-except-electric) (Vehicles With: One-Touch Up Door Window) .
- E3 CHECK THE OPERATION OF THE COURTESY LAMPS Ignition OFF. Open any door. Do the interior courtesy lamps illuminate? Yes: GO to E4 No: GO to «Pinpoint Test B»(/ford/focus-st/iii-2012-2015/remont/interiorillumination-lights/#interior-lighting-system-except-electric)
- E4 CHECK FOR VOLTAGE TO THE LUGGAGE COMPARTMENT LAMP Disconnect: Inoperative Luggage Compartment Lamp. Ignition ON. Measure: LUGGAGE COMPARTMENT LAMP (4-DOOR) Positive Lead Measurement / Action Negative Lead C428-1 - LH LUGGAGE COMPARTMENT LAMP (5-DOOR) Positive Lead Measurement / Action Negative Lead C4198-1 - RH LUGGAGE COMPARTMENT LAMP (5-DOOR) Positive Lead Measurement / Action Negative Lead C4403-1 - Is the voltage greater than 11 volts? Yes: GO to E5 No: REPAIR the luggage compartment lamp voltage supply circuit for an open.
- E5 ISOLATE THE LUGGAGE COMPARTMENT LAMP BULB Measure: LUGGAGE COMPARTMENT LAMP (4-DOOR) Positive Lead Measurement / Action Negative Lead C428-1 C428-2 LH LUGGAGE COMPARTMENT LAMP (5-DOOR) Positive Lead Measurement / Action Negative Lead C4198-1 C4198-2 RH LUGGAGE COMPARTMENT LAMP (5-DOOR) Positive Lead Measurement / Action Negative Lead C4403-1 C4403-2 Is the voltage greater than 11 volts? Yes: INSTALL a new luggage compartment lamp bulb. No: GO to E6
- E6 CHECK THE LUGGAGE COMPARTMENT LAMP GROUND CIRCUIT FOR AN OPEN Ignition OFF. Connect: Inoperative Luggage Compartment Lamp. Disconnect: Liftgate/Luggage Compartment Lid Latch C4223. Ignition ON. Connect: Positive Lead Measurement / Action Negative Lead C4223-4 - Does the luggage compartment lamp illuminate? Yes: REMOVE the jumper wire. GO to E7 No: REMOVE the jumper wire. REPAIR the circuit.
- E7 CHECK THE LIFTGATE LATCH GROUND CIRCUIT FOR AN OPEN Connect: Positive Lead Measurement / Action Negative Lead C4223-4 C4223-2 Does the luggage compartment lamp illuminate? Yes: REMOVE the jumper wire. For a 4-door vehicle, INSTALL a new luggage compartment lid latch. REFER to: «LUGGAGE COMPARTMENT LID LATCH»(/ford/focus-st/iii-2012-2015/remont/door-locks-anti-theft-systems/#handles-locks-latches-and-entry-systems-vehicles-without-one-touch-up-door-window-except-electric) (Vehicles Without: One-Touch Up Door Window) . or REFER to: «LUGGAGE COMPARTMENT LID LATCH»(/ford/focus-st/iii-2012-2015/remont/door-locks-anti-theft-systems/#handles-locks-latches-and-entry-systems-vehicles-with-one-touch-up-door-window-except-electric) (Vehicles With: One-Touch Up Door Window) . REMOVE the jumper wire. For a 5-door vehicle, INSTALL a new liftgate latch. REFER to: «LIFTGATE LATCH»(/ford/focus-st/iii-2012-2015/remont/door-locks-anti-theft-systems/#handles-locks-latches-and-entry-systems-vehicles-without-one-touch-up-door-window-except-electric) (Vehicles Without: One-Touch Up Door Window) . or REFER to: «LIFTGATE LATCH»(/ford/focus-st/iii-2012-2015/remont/door-locks-anti-theft-systems/#handles-locks-latches-and-entry-systems-vehicles-with-one-touch-up-door-window-except-electric) (Vehicles With: One-Touch Up Door Window) . No: REMOVE the jumper wire. REPAIR the circuit.
One Or More Demand Lamps Are Inoperative
Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: DIAGNOSTIC METHODS .
Refer to INTERIOR LAMPS for schematic and connector information.
- Wiring, terminals or connectors
- Demand lamp
- Inspect the bulbs and make sure they are OK.
- Inspect the courtesy lamp operation.
- Inspect the interior lamp for damage.
Scheme 8
Scheme 9
- F1: CHECK THE COURTESY LAMP OPERATION Ignition ON. Open any door and observe the interior courtesy lamps. Do the interior courtesy lamps illuminate? Yes: If the luggage compartment lamp is inoperative, GO to «Pinpoint Test E»(/ford/focus-st/iii-2012-2015/remont/interiorillumination-lights/#interior-lighting-system-except-electric) If a vanity mirror lamp is inoperative, GO to F2 If an overhead map lamp is inoperative, GO to F4 No: GO to «Pinpoint Test B»(/ford/focus-st/iii-2012-2015/remont/interiorillumination-lights/#interior-lighting-system-except-electric)
- F2 CHECK THE VANITY MIRROR VOLTAGE SUPPLY CIRCUIT FOR AN OPEN Ignition OFF. Disconnect: Inoperative Vanity Mirror Lamp. Ignition ON. Measure: LH VANITY MIRROR LAMP Positive Lead Measurement / Action Negative Lead C907-1 - RH VANITY MIRROR LAMP Positive Lead Measurement / Action Negative Lead C906-1 - Is the voltage greater than 11 volts? Yes: GO to F3 No: REPAIR the circuit.
- F3 CHECK THE VANITY MIRROR GROUND CIRCUIT FOR AN OPEN Measure: LH VANITY MIRROR LAMP Positive Lead Measurement / Action Negative Lead C907-1 C907-2 RH VANITY MIRROR LAMP Positive Lead Measurement / Action Negative Lead C906-1 C906-2 Is the voltage greater than 11 volts? Yes: INSTALL a new sun visor for the lamp in question. No: REPAIR the circuit.
- F4 CHECK THE INTERIOR LAMP GROUND CIRCUIT FOR AN OPEN Ignition OFF. Disconnect: Inoperative Lamp. Ignition ON. Measure: FRONT INTERIOR LAMP (WITHOUT A ROOF OPENING PANEL) Positive Lead Measurement / Action Negative Lead C931-1 C931-5 LH FRONT INTERIOR LAMP (WITH A ROOF OPENING PANEL) Positive Lead Measurement / Action Negative Lead C908-1 C908-5 RH FRONT INTERIOR LAMP (WITH A ROOF OPENING PANEL) Positive Lead Measurement / Action Negative Lead C903-1 C903-5 REAR INTERIOR LAMP Positive Lead Measurement / Action Negative Lead C901-1 C901-5 Is the voltage greater than 11 volts? Yes: INSTALL a new interior lamp for the lamp in question. No: REPAIR the circuit.
The Battery Saver Does Not Deactivate After Timeout
Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: DIAGNOSTIC METHODS .
Refer to INTERIOR LAMPS for schematic and connector information.
- Wiring, terminals or connectors
- BCM
PINPOINT TEST G: THE BATTERY SAVER DOES NOT DEACTIVATE AFTER TIMEOUT
- G1: CHECK THE DEMAND LAMP VOLTAGE SUPPLY CIRCUIT FOR A SHORT TO VOLTAGE Ignition OFF. Disconnect: BCM C2280F. Turn any demand (map or vanity mirror) lamp on. Does the demand lamp turn on? Yes: REPAIR the circuit. No: GO to G2
- G2 CHECK FOR CORRECT BODY CONTROL MODULE (BCM) OPERATION Disconnect and inspect all BCM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the BCM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new BCM. REFER to: «BODY CONTROL MODULE (BCM)»(/ford/focus-st/iii-2012-2015/remont/cruise-control-systems/#multifunction-electronic-modules-except-electric) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues. CLEAR the Diagnostic Trouble Codes (DTCs).
The Ambient Lighting Is Inoperative
Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: DIAGNOSTIC METHODS .
Refer to INTERIOR LAMPS for schematic and connector information.
- Wiring, terminals or connectors
- Ambient lighting LED
- BCM
- Ambient lighting module
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| B1088:86 | LIN Bus "B": Signal Invalid | Sets when the BCM loses communication with the ambient lighting module over the LIN circuit. |
| B1088:88 | LIN Bus "B": Bus Off | Sets when the BCM loses communication with the ambient lighting module over the LIN circuit. |
| B1390:87 | Ambient Light Control Module: Missing Message | Sets when the BCM loses communication with the ambient lighting module over the LIN circuit. |
DTC FAULT TRIGGER CONDITIONS
PINPOINT TEST H: THE AMBIENT LIGHTING IS INOPERATIVE
- H1: CHECK FOR AMBIENT LIGHTING DIAGNOSTIC TROUBLE CODES (DTCS) Ignition ON. Using a scan tool, perform the BCM Self-Test. Is DTC B1088:86, B1088:88 or B1390:87 present? Yes: GO to H2 No: GO to H7
- H2 CHECK FOR VOLTAGE TO THE AMBIENT LIGHTING MODULE Ignition OFF. Disconnect: Overhead Console C912. Ignition ON. Measure: Positive Lead Measurement / Action Negative Lead C912-8 - Is the voltage greater than 11 volts? Yes: GO to H3 No: REPAIR the ambient lighting module voltage supply circuit for an open.
- H3 CHECK THE AMBIENT LIGHTING MODULE GROUND CIRCUIT FOR AN OPEN Measure: Positive Lead Measurement / Action Negative Lead C912-8 C912-5 Is the voltage greater than 11 volts? Yes: GO to H4 No: REPAIR the circuit.
- H4 CHECK THE LOCAL INTERCONNECT NETWORK (LIN) CIRCUIT FOR A SHORT TO VOLTAGE Ignition OFF. Disconnect: BCM C2280H. Ignition ON. Measure: Positive Lead Measurement / Action Negative Lead C912-6 - Is any voltage present? Yes: REPAIR the circuit. No: GO to H5
- H5 CHECK THE LOCAL INTERCONNECT NETWORK (LIN) CIRCUIT FOR A SHORT TO GROUND Ignition OFF. Measure: Positive Lead Measurement / Action Negative Lead C912-6 ohms - Is the resistance greater than 10, 000 ohms? Yes: GO to H6 No: REPAIR the circuit.
- H6 CHECK THE LOCAL INTERCONNECT NETWORK (LIN) CIRCUIT FOR AN OPEN Measure: Positive Lead Measurement / Action Negative Lead C912-6 ohms C2280H-12 Is the resistance less than 3 ohms? Yes: GO to H14 No: REPAIR the circuit.
- H7 CHECK THE AMBIENT LIGHTING MODULE LIGHT EMITTING DIODE (LED) POWER SUPPLY CIRCUIT FOR VOLTAGE Ignition OFF. Disconnect: Overhead Console Illumination C9046. Ignition ON. Turn the parking lamps on. Measure: Positive Lead Measurement / Action Negative Lead C9046-1 - Is the voltage greater than 11 volts? Yes: GO to H10 No: GO to H8
- H8 CHECK THE AMBIENT LIGHTING MODULE LIGHT EMITTING DIODE (LED) VOLTAGE OUTPUT CIRCUIT FOR AN OPEN Ignition OFF. Turn the parking lamps off. Disconnect: Overhead Console C912. Measure: Positive Lead Measurement / Action Negative Lead C912-16 ohms C9046-1 Is the resistance less than 3 ohms? Yes: GO to H9 No: REPAIR the circuit.
- H9 CHECK THE AMBIENT LIGHTING LIGHT EMITTING DIODE (LED) CIRCUIT FOR A SHORT TO GROUND Disconnect all of the ambient lighting Light-emitting Diodes (LEDs). Measure: Positive Lead Measurement / Action Negative Lead C912-16 ohms - Is the resistance greater than 10, 000 ohms? Yes: INSTALL a new overhead console. REFER to: «OVERHEAD CONSOLE»(/ford/focus-st/iii-2012-2015/remont/gauges-instrument-panels/#instrument-panel-and-console-except-electric) . No: REPAIR the circuit.
- H10 ISOLATE THE AMBIENT LIGHTING LIGHT-EMITTING DIODES (LEDS) Turn the parking lamps on. Disconnect and then connect the Light-emitting Diodes (LEDs) one at a time while observing the other Light-emitting Diodes (LEDs). Overhead console illumination Left front footwell Right front footwell Passenger door map pocket Passenger door release handle Driver door map pocket Driver door release handle Floor console cupholder Do the other ambient lighting Light-emitting Diodes (LEDs) illuminate when an individual LED is disconnected? Yes: INSTALL a new LED in question. No: GO to H11
- H11 CHECK THE AMBIENT LIGHTING LOCAL INTERCONNECT NETWORK (LIN) CIRCUIT FOR A SHORT TO VOLTAGE Ignition OFF. Disconnect all of the ambient lighting Light-emitting Diodes (LEDs). Ignition ON. Measure: Positive Lead Measurement / Action Negative Lead C912-15 - Is any voltage present? Yes: REPAIR the circuit. No: GO to H12
- H12 CHECK THE AMBIENT LIGHTING LOCAL INTERCONNECT NETWORK (LIN) CIRCUIT FOR A SHORT TO GROUND Ignition OFF. Measure: Positive Lead Measurement / Action Negative Lead C912-15 ohms - Is the resistance greater than 10, 000 ohms? Yes: GO to H13 No: REPAIR the circuit.
- H13 CHECK THE AMBIENT LIGHTING LOCAL INTERCONNECT NETWORK (LIN) CIRCUIT FOR AN OPEN Measure: Positive Lead Measurement / Action Negative Lead C912-15 ohms C3349-2 Is the resistance less than 3 ohms? Yes: INSTALL a new overhead console. REFER to: «OVERHEAD CONSOLE»(/ford/focus-st/iii-2012-2015/remont/gauges-instrument-panels/#instrument-panel-and-console-except-electric) . No: REPAIR the circuit.
- H14 CHECK FOR CORRECT BODY CONTROL MODULE (BCM) OPERATION Disconnect and inspect all BCM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the BCM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new BCM. REFER to: «BODY CONTROL MODULE (BCM)»(/ford/focus-st/iii-2012-2015/remont/cruise-control-systems/#multifunction-electronic-modules-except-electric) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues. CLEAR the Diagnostic Trouble Codes (DTCs).
A Puddle Lamp Is Inoperative Or Always On
Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: DIAGNOSTIC METHODS .
Refer to INTERIOR LAMPS for schematic and connector information.
- Wiring, terminals or connectors
- Puddle lamp
- Exterior mirror
- DDM
- PDM
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| B12C2:11 | Puddle Lamp: Circuit Short To Ground | Sets when the DDM or the PDM detects a short to ground from the puddle lamp output circuit. |
| B12C2:15 | Puddle Lamp: Circuit Short To Battery Or Open | Sets when the DDM or the PDM detects an open or a short to battery voltage from the puddle lamp output circuit. |
DTC FAULT TRIGGER CONDITIONS
- Inspect the bulbs and make sure they are OK.
- Inspect the exterior mirror for damage.
PINPOINT TEST I: A PUDDLE LAMP IS INOPERATIVE OR ALWAYS ON
- I1: CHECK THE OPERATION OF THE INTERIOR COURTESY LAMPS Ignition ON. Ignition OFF. Open and close a door. Observe the interior courtesy lamp operation for 30 seconds. Do the interior courtesy lamps operate correctly? Yes: If a puddle lamp is always on, GO to I2 If a puddle lamp is inoperative, GO to I3 No: REFER to the «Symptom Chart: Interior Lighting»(/ford/focus-st/iii-2012-2015/remont/interiorillumination-lights/#interior-lighting-system-except-electric__symptom-chart-interior-lighting) and diagnose the interior courtesy lamps.
- I2 CHECK THE PUDDLE LAMP POWER SUPPLY CIRCUIT FOR A SHORT TO VOLTAGE Disconnect: DDM C501B (left puddle lamp). Disconnect: PDM C652B (right puddle lamp). Ignition ON. Does the puddle lamp continue to illuminate? Yes: REPAIR the circuit. No: INSTALL a new door module in question. REFER to: «DOOR MODULE»(/ford/focus-st/iii-2012-2015/remont/cruise-control-systems/#multifunction-electronic-modules-except-electric) .
- I3 CHECK THE MIRROR OPERATION Ignition ON. Using the exterior mirror control switch, operate the exterior power mirrors. Do the exterior power mirrors operate? Yes: GO to I4 No: REFER to: «REAR VIEW MIRRORS»(/ford/focus-st/iii-2012-2015/remont/mirrors/#rear-view-mirrors-vehicles-with-one-touch-up-door-window-except-electric) (Vehicles With: One-Touch Up Door Window) .
- I4 CHECK FOR VOLTAGE TO THE PUDDLE LAMP Ignition OFF. Disconnect: LH Exterior Mirror C521 (left puddle lamp). Disconnect: RH Exterior Mirror C626 (right puddle lamp). Ignition ON. Open any door. Measure: LH EXTERIOR MIRROR Positive Lead Measurement / Action Negative Lead C521-8 - RH EXTERIOR MIRROR Positive Lead Measurement / Action Negative Lead C626-8 - Is the voltage greater than 11 volts? Yes: GO to I7 No: GO to I5
- I5 CHECK THE PUDDLE LAMP VOLTAGE SUPPLY CIRCUIT FOR A SHORT TO GROUND Ignition OFF. Disconnect: DDM C501B (left puddle lamp). Disconnect: PDM C652B (right puddle lamp). Measure: LH EXTERIOR MIRROR Positive Lead Measurement / Action Negative Lead C521-8 ohms - RH EXTERIOR MIRROR Positive Lead Measurement / Action Negative Lead C626-8 ohms - Is the resistance greater than 10, 000 ohms? Yes: GO to I6 No: REPAIR the circuit.
- I6 CHECK THE PUDDLE LAMP VOLTAGE SUPPLY CIRCUIT FOR AN OPEN Measure: LH EXTERIOR MIRROR Positive Lead Measurement / Action Negative Lead C521-8 ohms C501B-6 RH EXTERIOR MIRROR Positive Lead Measurement / Action Negative Lead C626-8 ohms C652B-6 Is the resistance less than 3 ohms? Yes: INSTALL a new door module in question. REFER to: «DOOR MODULE»(/ford/focus-st/iii-2012-2015/remont/cruise-control-systems/#multifunction-electronic-modules-except-electric) . No: REPAIR the circuit.
- I7 CHECK THE EXTERIOR MIRROR GROUND CIRCUIT Measure: LH EXTERIOR MIRROR Positive Lead Measurement / Action Negative Lead C521-8 C521-6 RH EXTERIOR MIRROR Positive Lead Measurement / Action Negative Lead C626-8 C626-6 Is the voltage greater than 11 volts? Yes: INSTALL a new exterior mirror. REFER to: «REAR VIEW MIRRORS»(/ford/focus-st/iii-2012-2015/remont/mirrors/#rear-view-mirrors-vehicles-without-one-touch-up-door-window-except-electric) (Vehicles Without: One-Touch Up Door Window) . No: GO to I8
- I8 CHECK THE PUDDLE LAMP GROUND CIRCUIT FOR AN OPEN Ignition OFF. Disconnect: DDM C501B (left puddle lamp). Disconnect: PDM C652B (right puddle lamp). Measure: LH EXTERIOR MIRROR Positive Lead Measurement / Action Negative Lead C521-6 ohms C501B-18 RH EXTERIOR MIRROR Positive Lead Measurement / Action Negative Lead C626-6 ohms C652B-18 Is the resistance less than 3 ohms? Yes: INSTALL a new door module in question. REFER to: «DOOR MODULE»(/ford/focus-st/iii-2012-2015/remont/cruise-control-systems/#multifunction-electronic-modules-except-electric) . No: REPAIR the circuit.
An Individual Ambient Light Is Inoperative or Does Not Change Color
Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.
REFER to: DIAGNOSTIC METHODS .
Refer to INTERIOR LAMPS for schematic and connector information.
- Wiring, terminals or connectors
- Ambient lighting LED
- Ambient lighting module
Scheme 10
- J1: CHECK FOR VOLTAGE TO THE LIGHT EMITTING DIODE (LED) Ignition OFF. Disconnect: Inoperative Ambient Lighting LED. Ignition ON. Turn the parking lamps on. Measure: OVERHEAD CONSOLE Positive Lead Measurement / Action Negative Lead C9046-1 - CUPHOLDER Positive Lead Measurement / Action Negative Lead C3349-1 - LH FRONT FOOTWELL Positive Lead Measurement / Action Negative Lead C2056-1 - RH FRONT FOOTWELL Positive Lead Measurement / Action Negative Lead C2057-1 - LH FRONT DOOR MAP POCKET Positive Lead Measurement / Action Negative Lead C572-1 - LH FRONT DOOR HANDLE Positive Lead Measurement / Action Negative Lead C556-1 - RH FRONT DOOR MAP POCKET Positive Lead Measurement / Action Negative Lead C672-1 - RH FRONT DOOR HANDLE Positive Lead Measurement / Action Negative Lead C620-1 - Is the voltage greater than 11 volts? Yes: GO to J2 No: REPAIR the LED voltage supply circuit in question.
- J2 CHECK THE LIGHT EMITTING DIODE (LED) GROUND CIRCUIT FOR AN OPEN Measure: OVERHEAD CONSOLE Positive Lead Measurement / Action Negative Lead C9046-1 C9046-3 CUPHOLDER Positive Lead Measurement / Action Negative Lead C3349-1 C3349-3 LH FRONT FOOTWELL Positive Lead Measurement / Action Negative Lead C2056-1 C2056-3 RH FRONT FOOTWELL Positive Lead Measurement / Action Negative Lead C2057-1 C2057-3 LH FRONT DOOR MAP POCKET Positive Lead Measurement / Action Negative Lead C572-1 C572-3 LH FRONT DOOR HANDLE Positive Lead Measurement / Action Negative Lead C556-1 C556-3 RH FRONT DOOR MAP POCKET Positive Lead Measurement / Action Negative Lead C672-1 C672-3 RH FRONT DOOR HANDLE Positive Lead Measurement / Action Negative Lead C620-1 C620-3 Is the voltage greater than 11 volts? Yes: GO to J3 No: REPAIR the ground circuit in question.
- J3 CHECK THE AMBIENT LIGHTING LOCAL INTERCONNECT NETWORK (LIN) CIRCUIT FOR AN OPEN Ignition OFF. Turn the parking lamps off. Disconnect: Overhead Console C912. Measure: OVERHEAD CONSOLE Positive Lead Measurement / Action Negative Lead C9046-2 ohms C912-15 CUPHOLDER Positive Lead Measurement / Action Negative Lead C3349-2 ohms C912-15 LH FRONT FOOTWELL Positive Lead Measurement / Action Negative Lead C2056-2 ohms C912-15 RH FRONT FOOTWELL Positive Lead Measurement / Action Negative Lead C2057-2 ohms C912-15 LH FRONT DOOR MAP POCKET Positive Lead Measurement / Action Negative Lead C572-2 ohms C912-15 LH FRONT DOOR HANDLE Positive Lead Measurement / Action Negative Lead C556-2 ohms C912-15 RH FRONT DOOR MAP POCKET Positive Lead Measurement / Action Negative Lead C672-2 ohms C912-15 RH FRONT DOOR HANDLE Positive Lead Measurement / Action Negative Lead C620-2 ohms C912-15 Is the resistance less than 3 ohms? Yes: INSTALL a new ambient lighting LED in question. No: REPAIR the circuit.
See also:
• DIAGNOSTIC METHODS
• COMMUNICATIONS NETWORK
• MODULE CONFIGURATION - SYSTEM OPERATION AND COMPONENT DESCRIPTION
• OVERHEAD CONSOLE
• FRONT DOOR LATCH
• FRONT DOOR LATCH
• REAR DOOR LATCH
• REAR DOOR LATCH
• BODY CONTROL MODULE (BCM)
• REAR VIEW MIRRORS
• REAR VIEW MIRRORS
• Pinpoint Test H
• Pinpoint Test A
• Pinpoint Test C
• Pinpoint Test D
• Pinpoint Test I
• Pinpoint Test G
• Symptom Chart: Interior Lighting
