Evaporative Emission (EVAP) Canister
Note. Five door vehicle shown in illustration, four door vehicle similar.
Scheme 7
| Item | Part Number | Description |
|---|---|---|
| 1 | W707142 | Evaporative Emission (EVAP) canister nut (3 required) |
| 2 | EVAP hose (part of 9A228) | |
| 3 | 9B033 | Fuel vapor tube (to fuel tank) |
| 4 | 9B337 | Fuel vapor tube (to canister purge valve) |
| 5 | 9D653 | EVAP canister |
EVAPORATIVE EMISSION (EVAP) CANISTER COMPONENT DESCRIPTION CHART
Scheme 8
| Item | Part Number | Description |
|---|---|---|
| 1 | 9A228 | Natural vacuum leak detection module |
| 2 | W707142 | Natural vacuum leak detection module nut |
| 3 | Natural vacuum leak detection module electrical connector (part of 14A005) | |
| 4 | 9G297 | Fresh air hose |
| 5 | 9D653 | EVAP canister |
NATURAL VACUUM LEAK DETECTION MODULE COMPONENT DESCRIPTION CHART
Evaporative Emission (EVAP) Fresh Air Hose
Note. The LH wheel liner must be positioned aside to access the fresh air hose.
Note. Press the release tab to disengage the fresh air hose from the fuel filler pipe bracket.
Scheme 9
| Item | Part Number | Description |
|---|---|---|
| 1 | 9G297 | Fresh air hose |
| 2 | W715398 | Fresh air hose retainer |
| 3 | Hose retainer (part of 9A228) | |
| 4 | 9A228 | Natural vacuum leak detection module |
| 5 | Fresh air hose release tab (part of 9G297) |
EVAPORATIVE EMISSION (EVAP) FRESH AIR HOSE COMPONENT DESCRIPTION CHART
| WARNING | Always disconnect the battery ground cable at the battery when working on an evaporative emission (EVAP) system or fuel-related component. Highly flammable mixtures are always present and may be ignited. Failure to follow these instructions may result in serious personal injury. |
| WARNING | Do not smoke, carry lighted tobacco or have an open flame of any type when working on or near any fuel-related component. Highly flammable mixtures are always present and may be ignited. Failure to follow these instructions may result in serious personal injury. |
Note. After installing an Evaporative Emission (EVAP) canister or Evaporative Emission (EVAP) canister purge valve, carry out the Evaporative Emission System Leak Test. For additional information, refer to EVAPORATIVE EMISSION SYSTEM LEAK TEST in this information.
- Refer to the procedures and/or exploded views in this information for any Warnings, Notices, Notes, Materials, Specifications, and Special Tools.
