VECI Decal Location

The decal is typically located on the underside of the hood or on the radiator support sight shield.

Vehicle Certification Label Location

The vehicle certification label is typically located on the LH door or door post pillar.

PCM Locations

For PCM removal and installation procedures, refer to the appropriate ELECTRONIC ENGINE CONTROLS article.

1. Crown Victoria, Grand Marquis, Town Car - engine compartment, driver side, fender mounted.
2. E-Series - engine compartment, driver side, near the cowl (access from the engine compartment).
3. Edge, Expedition, F-150, F-Series Super Duty, MKX, Navigator - passenger side of the engine compartment, mounted to the cowl.
4. Explorer - engine compartment, center position, mounted to the cowl under the cowl panel grille.
5. Fiesta - engine compartment, driver side, near the battery.
6. Flex, MKS, MKT, Taurus - engine compartment, passenger side, mounted to the cowl under the cowl panel grille.
7. Focus, Transit Connect - engine compartment, driver side, front of battery.
8. Fusion, Milan, MKZ - engine compartment, driver side, under battery, mounted to the cowl.
9. Mustang - front of engine compartment, passenger side, near the battery junction box (BJB).

Scheme 22

ITEM DESCRIPTION CHART

Scheme 23

Scheme 24

Scheme 25

ITEM DESCRIPTION CHART

Scheme 26

ITEM DESCRIPTION CHART
