Removal and Installation
- Remove the floor console finish panel for access to the ambient lighting module. Lift upward on the rear of the floor console finish panel to release the floor console finish panel clips. If equipped, disconnect the electrical connector. Slide the park brake lever boot and the floor console finish panel over the park brake lever.
Scheme 33
| Item | Part Number | Description |
|---|---|---|
| 1 | W714972-S1 | Retaining clip (4 required) |
| 2 | 15K12A | Media bezel |
| 3 | 13D806A | Ambient lighting switch |
| 4 | Ambient lighting switch electrical connector (part of 14E078) |
ITEM DESCRIPTION CHART
- Refer to the procedures and/or exploded views in this information for any Warnings, Notices, Notes, Materials, Specifications, and Special Tools. Items in the exploded views may not be listed in order of removal.
