Engine Mechanical - 1.6L: Component Locations Ford Fiesta Mk6

Special Tool(s)

SPECIAL TOOLS CHART Alignment Plate, Camshafts 303-376B Crankshaft TDC Pin 303-748 Strap Wrench 303-D055 (D85L-6000-A) or equivalent

Scheme 23

Scheme 24

Scheme 25

SPECIAL TOOLS CHART Installer, Crankshaft Vibration Damper 303-102 (T74P-6316-B) Installer, Front Cover Oil Seal 303-335 (T88T-6701-A) Replacer, Front Crankshaft Seal 303-420 (T92P-6701-BH) Remover, Input Shaft Oil Seal 308-375 Slide Hammer 100-001 (T50T-100-A)

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

SPECIAL TOOLS CHART Alignment Plate, Camshaft 303-376B Timing Peg, Crankshaft TDC 303-748

Scheme 31

Scheme 32

SPECIAL TOOLS CHART Compressor, Valve Spring 303-300 (T87C-6565-A) Compressor, Valve Spring 303-350 (T89P-6565-A) Compressor, Valve Spring 303-1418

Scheme 33

Scheme 34

Scheme 35

SPECIAL TOOLS CHART Engine Support Bar 303-F072 Lifting Bracket, Engine 303-050 (T70P-6000)

Scheme 36

Scheme 37

SPECIAL TOOLS CHART Heavy Duty Floor Crane 014-00071 or equivalent

Scheme 38

Scheme 39

ITEM DESCRIPTION

SPECIAL TOOLS CHART Heavy Duty Floor Crane 014-00071 or equivalent Powertrain Lift 014-00765 or equivalent Spreader Bar 303-D089 (D93P-6001-A3) or equivalent Universal Adapter Brackets 014-0001 or equivalent

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

Scheme 80

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

Scheme 93

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-382368) .
2. Release the fuel system pressure. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-382416) .
3. Remove the Air Cleaner (ACL) and ACL outlet pipe. For additional information, refer to «INTAKE AIR DISTRIBUTION AND FILTERING»(ref-382417) .
4. Remove the battery. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-382392) .
5. Remove the nut and cable from the positive battery cable terminal.
6. Remove the 2 bolts and the accessory drive belt splash shield.
7. Drain the cooling system. For additional information, refer to «ENGINE COOLING»(ref-382413) .
8. Remove the degas bottle. For additional information, refer to «ENGINE COOLING»(ref-382413) .
9. Remove the bolt and the PCM cover.
10. Disconnect the 3 PCM electrical connectors.
11. Remove the 3 bolts and the battery tray.
12. Detach the 2 positive battery cable wire harness retainers from battery tray bracket.
13. Remove the selector lever cable bracket bolt, 3 battery tray nuts and the battery tray bracket.
14. Disconnect the selector lever cable from the control lever.
15. Detach the wiring harness retainer from the selector lever cable bracket.
16. Remove the 2 selector lever cable bracket bolts from the transaxle and position the selector lever cable and bracket aside.
17. Disconnect the engine harness electrical connector.
18. Disconnect the brake booster vacuum hose.
19. Disconnect the fuel tube spring lock couplings from the fuel rail. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-382416) .
20. Detach the fuel tube from the ignition coil bracket retainer.
21. Remove the generator. For additional information, refer to «CHARGING SYSTEM»(ref-382376) .
22. Remove the cooling fan motor and shroud. For additional information, refer to «ENGINE COOLING»(ref-382413) .
23. Disconnect the lower heater hose from the heater core.
24. Detach the coolant hose retainer from the ignition coil bracket.
25. Disconnect the 2 coolant hose from the engine oil cooler.
26. Disconnect the upper radiator hose from the engine.
27. Disconnect the lower radiator hose and coolant hose from the thermostat housing.
28. Remove the bolt and position the engine ground wire aside.
29. Remove the RH and LH halfshafts. For additional information, refer to «FRONT DRIVE HALFSHAFTS»(ref-382394) .
30. Remove the 3 bolts and the halfshaft bracket.
31. Disconnect the A/C compressor electrical connector.
32. Remove the nut and position the A/C line bracket aside.
33. Disconnect the A/C pressure transducer electrical connector. Detach the wiring harness retainer.
34. Detach the wiring harness retainer from the lower A/C compressor bracket.
35. Remove the 2 bolts, stud bolt and position the A/C compressor aside and support with a length of mechanic's wire.
36. Remove the catalytic converter. For additional information, refer to «EXHAUST SYSTEM»(ref-382375) .
37. Drain the engine oil. Install the drain plug and tighten to 28 Nm (21 lb-ft).
38. Using the Powertrain Lift and Universal Adapter Brackets, secure the engine to the lift table.
39. Remove the 2 bolts and the transaxle roll restrictor.
40. NOTE: The engine mount studs must be held while removing the engine mount nuts or damage to the powertrain may occur. NOTE: Do not loosen the engine mount center bolt or the engine may become improperly positioned. Use the holding feature to prevent the engine mount studs from turning, remove the 2 engine mount nuts.
41. Remove the 3 bolts and the engine mount.
42. Remove the 2 bolt, 2 nuts and the transaxle support insulator.
43. Lower the engine and transaxle assembly from the vehicle.
44. Detach the 2 wiring harness retainers from the ignition coil bracket.
45. Disconnect the ignition coil and Engine Coolant Temperature (ECT) sensor electrical connectors.
46. Detach the Heated Oxygen Sensor (HO2S) sensor electrical connector pin-type retainer from the bracket.
47. Disconnect the 2 Camshaft Position (CMP) sensor electrical connectors.
48. Detach and disconnect the LH Knock Sensor (KS) electrical connector.
49. Disconnect the Variable Camshaft Timing (VCT) oil control solenoid electrical connectors. Detach the 2 wiring harness retainers.
50. Disconnect the 4 fuel injector electrical connectors.
51. Disconnect the Evaporative Emission (EVAP) canister purge valve electrical connector.
52. Disconnect the Throttle Body (TB) electrical connector. Detach the 2 wiring harness retainers from the TB .
53. Disconnect the Crankshaft Position (CKP) sensor electrical connector.
54. Disconnect the Engine Oil Pressure (EOP) switch electrical connector. Detach the wiring harness retainer from the engine block.
55. Disconnect the RH KS electrical connector. Detach the 2 wiring harness retainers from the intake manifold.
56. Remove the 2 nuts and disconnect the starter motor electrical terminals.
57. Detach the wiring harness pin-type retainer and remove the 2 upper bellhousing-to-engine bolts and bracket.
58. Remove the 3 bolts (2 shown in illustration) and the starter motor.
59. Remove the clutch nut access cover.
60. NOTE: Rotate the engine in a clockwise direction only or engine damage may occur. NOTE: Mark one stud and the flexplate for installation reference. Remove the 6 flexplate-to-clutch nuts and discard.
61. NOTE: Lower the engine to within a few inches of the floor. Using the Heavy Duty Floor Crane and Spreader Bar, remove the engine and transaxle assembly from the lift table.
62. Remove the 6 clutch housing-to-engine bolts and separate the engine and transaxle.

SPECIAL TOOLS CHART Heavy Duty Floor Crane 014-00071 or equivalent Powertrain Lift 014-00765 or equivalent Spreader Bar 303-D089 (D93P-6001-A3) or equivalent Universal Adapter Brackets 014-0001 or equivalent

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

Scheme 100

Scheme 101

Scheme 102

Scheme 103

Scheme 104

Scheme 105

Scheme 106

Scheme 107

Scheme 108

Scheme 109

Scheme 110

Scheme 111

Scheme 112

Scheme 113

Scheme 114

Scheme 115

Scheme 116

Scheme 117

Scheme 118

Scheme 119

Scheme 120

Scheme 121

Scheme 122

Scheme 123

Scheme 124

Scheme 125

Scheme 126

Scheme 127

Scheme 128

Scheme 129

Scheme 130

Scheme 131

Scheme 132

Scheme 133

Scheme 134

Scheme 135

Scheme 136

Scheme 137

Scheme 138

Scheme 139

Scheme 140

Scheme 141

Scheme 142

Scheme 143

Scheme 144

Scheme 145

Scheme 146

Scheme 147

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-382368) .
2. Release the fuel system pressure. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-382416) .
3. Remove the Air Cleaner (ACL) and ACL outlet pipe. For additional information, refer to «INTAKE AIR DISTRIBUTION AND FILTERING»(ref-382417) .
4. Remove the battery. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-382392) .
5. Remove the nut and cable from the positive battery cable terminal.
6. Remove the 2 bolts and the accessory drive belt splash shield.
7. Drain the cooling system. For additional information, refer to «ENGINE COOLING»(ref-382413) .
8. Remove the degas bottle. For additional Information, refer to «ENGINE COOLING»(ref-382413) .
9. Remove the bolt and the PCM cover.
10. Disconnect the 3 PCM electrical connectors.
11. Remove the 3 bolts and the battery tray.
12. Detach the 2 positive battery cable wire harness retainers from battery tray bracket.
13. Remove the 3 battery tray nuts and the battery tray bracket.
14. Release the 7 retainers (2 shown in illustration) and remove the gearshift cable cover.
15. Remove the gearshift cables. Using a suitable tool, lightly pry the gearshift cables off the transaxle shift control levers. Remove the gearshift cable by pulling the lower part of abutment down and removing from the brackets.
16. Disconnect the engine harness electrical connector.
17. Disconnect the brake booster vacuum hose.
18. Disconnect the fuel tube spring lock couplings from the fuel rail. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-382416) .
19. Detach the fuel tube from the ignition coil bracket retainer.
20. Remove the generator. For additional information, refer to «CHARGING SYSTEM»(ref-382376) .
21. Remove the cooling fan motor and shroud. For additional information, refer to «ENGINE COOLING»(ref-382413) .
22. Disconnect the lower heater hose from the heater core.
23. Detach the coolant hose retainer from the ignition coil bracket.
24. Disconnect the 2 coolant hose from the engine oil cooler.
25. Disconnect the upper radiator hose from the engine.
26. Disconnect the lower radiator hose and coolant hose from the thermostat housing.
27. WARNING: Carefully read cautionary information on product label. For EMERGENCY MEDICAL INFORMATION seek medical advice. In the USA or Canada on Ford/Motorcraft products call: 1-800-959-3673. For additional information, consult the product Material Safety Data Sheet (MSDS) if available. Failure to follow these instructions may result in serious personal injury. NOTE: Do not spill brake fluid on painted or plastic surfaces or damage to the surface may occur. If brake fluid is spilled onto a painted or plastic surface, immediately wash the surface with water. Remove the clip and disconnect the clutch hydraulic hose.
28. Detach the clutch hydraulic hose from the transaxle retainer.
29. Remove the bolt and position the engine ground wire aside.
30. Remove the RH and LH halfshafts. For additional information, refer to «FRONT DRIVE HALFSHAFTS»(ref-382394) .
31. Remove the 3 bolts and the halfshaft bracket.
32. Disconnect the A/C compressor electrical connector.
33. Remove the nut and position the A/C line bracket aside.
34. Disconnect the A/C pressure transducer electrical connector. Detach the wiring harness retainer.
35. Detach the wiring harness retainer from the lower A/C compressor bracket.
36. Remove the 2 bolts, stud bolt and position the A/C compressor aside and support with a length of mechanic's wire.
37. Remove the catalytic converter. For additional information, refer to «EXHAUST SYSTEM»(ref-382375) .
38. Drain the engine oil. Install the drain plug and tighten to 28 Nm (21 lb-ft).
39. Using the Powertrain Lift and Universal Adapter Brackets, secure the engine to the lift table.
40. Remove the 2 bolts and the transaxle roll restrictor.
41. NOTE: The engine mount studs must be held while removing the engine mount nuts or damage to the powertrain may occur. NOTE: Do not loosen the engine mount center bolt or the engine may become improperly positioned. Use the holding feature to prevent the engine mount studs from turning, remove the 2 engine mount nuts.
42. Remove the 3 bolts and the engine mount.
43. Remove the 2 bolt, 2 nuts and the transaxle support insulator.
44. Lower the engine and transaxle assembly from the vehicle.
45. Detach the 2 wiring harness retainers from the ignition coil bracket.
46. Disconnect the ignition coil and Engine Coolant Temperature (ECT) sensor electrical connectors.
47. Detach the Heated Oxygen Sensor (HO2S) sensor electrical connector pin-type retainer from the bracket.
48. Disconnect the 2 Camshaft Position (CMP) sensor electrical connectors.
49. Detach and disconnect the LH Knock Sensor (KS) electrical connector.
50. Disconnect the Variable Camshaft Timing (VCT) oil control solenoid electrical connectors. Detach the 2 wiring harness retainers.
51. Disconnect the 4 fuel injector electrical connectors.
52. Disconnect the Evaporative Emission (EVAP) canister purge valve electrical connector.
53. Disconnect the Throttle Body (TB) electrical connector. Detach the 2 wiring harness retainers from the TB .
54. Disconnect the Crankshaft Position (CKP) sensor electrical connector.
55. Disconnect the Engine Oil Pressure (EOP) switch electrical connector. Detach the wiring harness retainer from the engine block.
56. Disconnect the RH KS electrical connector. Detach the 2 wiring harness retainers from the intake manifold.
57. Remove the 2 nuts and disconnect the starter motor electrical terminals.
58. Detach the wiring harness pin-type retainer and remove the 2 upper bellhousing-to-engine bolts and bracket.
59. Remove the 3 bolts (2 shown in illustration) and the starter motor.
60. NOTE: Lower the engine to within a few inches of the floor. Using the Heavy Duty Floor Crane and Spreader Bar, remove the engine and transaxle assembly from the lift table.
61. Remove the 6 clutch housing-to-engine bolts and separate the engine and transaxle.

SPECIAL TOOLS CHART Heavy Duty Floor Crane 014-00071 or equivalent Powertrain Lift 014-00765 or equivalent Spreader Bar 303-D089 (D93P-6001-A3) or equivalent Universal Adapter Brackets 014-0001 or equivalent

Scheme 148

Scheme 149

Scheme 150

Scheme 151

SPECIAL TOOLS CHART Heavy Duty Floor Crane 014-00071 or equivalent Powertrain Lift 014-00765 or equivalent Spreader Bar 303-D089 (D93P-6001-A3) or equivalent Universal Adapter Brackets 014-0001 or equivalent

Scheme 152

Scheme 153

Scheme 154

Scheme 155
