Exterior Mirror

The exterior mirror consists of the following serviceable components

1. Exterior mirror glass (heated glass optional)
2. Exterior mirror cover
3. Exterior mirror housing
4. Exterior mirror control switch
5. Exterior mirror motor
6. Turn signal (if equipped)

Interior Mirror

This vehicle is equipped with either a non-dimming or auto-dimming interior rear view mirror.

Heated Exterior Mirror

The rear window defrost switch controls the operation of the heated exterior rear view mirrors. The heated exterior rear view mirrors only operate when the rear window defrost system is operating. The heated exterior rear view mirror voltage is supplied by the rear defrost relay output from the Body Control Module (BCM) and Central Junction Box (CJB) fuse 25 (7.5A), which isolates the heated exterior rear view mirrors from the rear window defrost system in the event of a fault.

Exterior Mirrors - Exploded View

Note. Click here or refer to the on-line Workshop web site to view this illustration as an interactive exploded view, requires Adobe® Acrobat® 8.0 or higher .

Note. Click here or refer to the on-line Workshop web site to learn about using an Interactive Illustration .

Note. LH side shown in illustration, RH side similar.

Scheme 33

ITEMS DESCRIPTION CHART

1. For additional information, refer to the other appropriate procedures in this information.
