Diagnostic Trouble Code (DTC) Chart
Each module has a comprehensive DTC chart listed in an appropriate table. Refer to the table below for the appropriate information
Master DTC Index
| ABS Module | Refer to VEHICLE DYNAMIC SYSTEMS . |
|---|---|
| Audio Control Module (ACM) | Refer to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| Accessory Protocol Interface Module (APIM) | Refer to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| Body Control Module (BCM) | Refer to the BODY CONTROL MODULE (BCM) DTC CHART in this information. |
| Front Control/Display Interface Module (FCDIM) | Refer to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| Global Positioning System Module (GPSM) | Refer to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| Instrument Panel Cluster (IPC) | Refer to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES . |
| Occupant Classification Sensor (OCS) Module | Refer to SUPPLEMENTAL RESTRAINT SYSTEM . |
| Power Steering Control Module (PSCM) | Refer to STEERING SYSTEM . |
| PCM | Refer to ELECTRONIC ENGINE CONTROLS . |
| Remote Function Actuator (RFA) Module | Refer to the REMOTE FUNCTION ACTUATOR (RFA) MODULE DTC CHART in this information. |
| Restraints Control Module (RCM) | Refer to SUPPLEMENTAL RESTRAINT SYSTEM . |
| Transmission Control Module (TCM) | Refer to AUTOMATIC SHIFTING MANUAL TRANSMISSION/TRANSAXLE . |
| Vehicle Security Module (VSM) | Refer to WHEELS & TIRES . |
MASTER DTC INDEX REFERENCE CHART
Inspection and Verification
- Verify the customer concern.
- Visually inspect for obvious signs of electrical damage. VISUAL INSPECTION CHART Electrical Wiring, terminals or connectors
- If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
- NOTE: Make sure to use the latest scan tool software release If the cause is not visually evident, connect the scan tool to the Data Link Connector (DLC).
- NOTE: The Vehicle Communication Module (VCM) LED prove-out confirms power and ground from the DLC are provided to the VCM . If the scan tool does not communicate with the VCM : check the VCM connection to the vehicle. check the scan tool connection to the VCM . Refer to «MODULE COMMUNICATIONS NETWORK»(ref-382388) , No Power To The Scan Tool, to diagnose no power to the scan tool.
- If the scan tool does not communicate with the vehicle: Verify the ignition is in the ON state. The air bag warning indicator prove-out confirms ignition ON (other indicators may not prove ignition ON). If the ignition does not turn on, refer to «STEERING COLUMN SWITCHES»(ref-382407) to diagnose no power in RUN. Verify the scan tool operation with a known good vehicle. Refer to «MODULE COMMUNICATIONS NETWORK»(ref-382388) to diagnose no response from the PCM.
- Carry out the network test. If the scan tool responds with no communication for one or more modules, refer to «MODULE COMMUNICATIONS NETWORK»(ref-382388) . If the network test passes, retrieve and record the continuous memory DTCs.
- Clear the continuous DTCs and carry out the self-test diagnostics for the Body Control Module (BCM).
- If the DTCs retrieved are related to the concern, go to the «BODY CONTROL MODULE (BCM) DTC CHART»(ref-382389-S12049203892011012300000) .
- If no DTCs related to the concern are retrieved, go to «SYMPTOM CHART»(ref-382389-S21234129092011012300000) .
DTC Charts
| DTC | Description | Action |
|---|---|---|
| B1007:92 | High-Beam Headlamp Switch: Performance Or Incorrect Operation | Refer to EXTERIOR LIGHTING . |
| B1008:92 | Wiper Mode Switch: Performance Or Incorrect Operation | Refer to WIPERS AND WASHERS . |
| B100A:23 | Fuel Pump Authorization: Signal Stuck Low | Refer to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES . |
| B1013:23 | Heater Rear Defog Switch: Signal Stuck Low | Refer to GLASS, FRAMES AND MECHANISMS . |
| B1034:12 | Left Front Seat Heater Element: Circuit Short To Battery | Refer to SEATING . |
| B1034:14 | Left Front Seat Heater Element: Circuit Short To Ground Or Open | Refer to SEATING . |
| B1051:92 | Front Washer Switch: Performance Or Incorrect Operation | Refer to WIPERS AND WASHERS . |
| B1052:92 | Rear Washer Switch: Performance Or Incorrect Operation | Refer to WIPERS AND WASHERS . |
| B108F:23 | Cabin Lock/Unlock Switch: Signal Stuck Low | Refer to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B1091:12 | Courtesy Lamp Sense: Circuit Short To Battery | Refer to INTERIOR LIGHTING . |
| B1092:12 | Daytime Running Light Relay: Circuit Short To Battery | Refer to EXTERIOR LIGHTING . |
| B1092:14 | Daytime Running Light Relay: Circuit Short To Ground Or Open | Refer to EXTERIOR LIGHTING . |
| B1098:11 | Left Position Light: Circuit Short To Ground | Refer to EXTERIOR LIGHTING . |
| B1098:15 | Left Position Light: Circuit Short To Battery Or Open | Refer to EXTERIOR LIGHTING . |
| B1099:11 | Right Position Light: Circuit Short To Ground | Refer to EXTERIOR LIGHTING . |
| B1099:15 | Right Position Light: Circuit Short To Battery Or Open | Refer to EXTERIOR LIGHTING . |
| B109A:12 | High Beam Relay: Circuit Short To Battery | Refer to EXTERIOR LIGHTING . |
| B109A:14 | High Beam Relay: Circuit Short To Ground Or Open | Refer to EXTERIOR LIGHTING . |
| B10A6:92 | Main Light Switch: Performance Or Incorrect Operation | Refer to EXTERIOR LIGHTING . |
| B10A8:12 | Low Beam Relay: Circuit Short To Battery | Refer to EXTERIOR LIGHTING . |
| B10A8:14 | Low Beam Relay: Circuit Short To Ground Or Open | Refer to EXTERIOR LIGHTING . |
| B10B1:92 | Cabin Set/Reset Switch: Performance Or Incorrect Operation | Refer to ANTI-THEFT - PERIMETER . |
| B1108:92 | Driver Door Central Locking Motor: Performance Or Incorrect Operation | Refer to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B1118:11 | Left Rear Sidemarker: Circuit Short To Ground | Refer to EXTERIOR LIGHTING . |
| B1118:15 | Left Rear Sidemarker: Circuit Short To Battery Or Open | Refer to EXTERIOR LIGHTING . |
| B113E:23 | External Boot/Trunk Release Switch: Signal Stuck Low | Refer to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B115A:23 | Front Passenger Seat Heater: Signal Stuck Low | Refer to SEATING . |
| B115B:23 | Front Driver Seat Heater: Signal Stuck Low | Refer to SEATING . |
| B1175:92 | Drivers Door Ajar Switch: Performance Or Incorrect Operation | Refer to INTERIOR LIGHTING . |
| B1176:92 | Passenger Door Ajar Switch: Performance Or Incorrect Operation | Refer to INTERIOR LIGHTING . |
| B1178:92 | Boot/Trunk Ajar Switch: Performance Or Incorrect Operation | Refer to INTERIOR LIGHTING . |
| B1187:92 | Trunk Motor: Performance Or Incorrect Operation | Refer to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B11DC:92 | Rear Wiper Mode Switch: Performance Or Incorrect Operation | Refer to WIPERS AND WASHERS . |
| B11E9:92 | Left Rear Door Ajar Switch: Performance Or Incorrect Operation | Refer to INTERIOR LIGHTING . |
| B11EA:92 | Right Rear Door Ajar Switch: Performance Or Incorrect Operation | Refer to INTERIOR LIGHTING . |
| B12F1:11 | Ambient Lighting Zone 1 Output: Circuit Short To Ground | Refer to INTERIOR LIGHTING . |
| B12F1:15 | Ambient Lighting Zone 1 Output: Circuit Short To Battery Or Open | Refer to INTERIOR LIGHTING . |
| B132B:12 | Left Stop/Turn Lamp: Circuit Short To Battery | Refer to EXTERIOR LIGHTING . |
| B132B:14 | Left Stop/Turn Lamp: Circuit Short To Ground Or Open | Refer to EXTERIOR LIGHTING . |
| B132C:12 | Right Stop/Turn Lamp: Circuit Short To Battery | Refer to EXTERIOR LIGHTING . |
| B132C:14 | Right Stop/Turn Lamp: Circuit Short To Ground Or Open | Refer to EXTERIOR LIGHTING . |
| B134E:23 | Switch Illumination Adjustment Control: Signal Stuck Low | Refer to INSTRUMENT CLUSTER AND PANEL ILLUMINATION . |
| B1A84:41 | Car Configuration Data: General Checksum Failure | CARRY OUT PMI on the BCM . Refer to MODULE CONFIGURATION . CLEAR the DTCs. REPEAT the self-test. If DTC B1A84:41 is retrieved again, INSTALL a new BCM . Refer to BODY CONTROL MODULE (BCM) in this information. TEST the system for normal operation. |
| B1A84:51 | Car Configuration Data: Not Programmed | CARRY OUT PMI on the BCM . Refer to MODULE CONFIGURATION . CLEAR the DTCs. REPEAT the self-test. If DTC B1A84:51 is retrieved again, INSTALL a new BCM . Refer to BODY CONTROL MODULE (BCM) in this information. TEST the system for normal operation. |
| B1C45:24 | Front Wiper Park Position Switch: Signal Stuck High | Refer to WIPERS AND WASHERS . |
| B1C53:13 | Front Wiper Intermittent Data: Circuit Open | Refer to WIPERS AND WASHERS . |
| B1D06:11 | Left Turn Indicator: Circuit Short To Ground | Refer to EXTERIOR LIGHTING . |
| B1D06:15 | Left Turn Indicator: Circuit Short To Battery Or Open | Refer to EXTERIOR LIGHTING . |
| B1D07:11 | Right Turn Indicator: Circuit Short To Ground | Refer to EXTERIOR LIGHTING . |
| B1D07:15 | Right Turn Indicator: Circuit Short To Battery Or Open | Refer to EXTERIOR LIGHTING . |
| B1D14:11 | Interior Lights Circuit "B": Circuit Short To Ground | Refer to INTERIOR LIGHTING . |
| B1D35:23 | Hazard Switch: Signal Stuck Low | Refer to EXTERIOR LIGHTING . |
| B1D36:92 | Turn Indicator Switch: Performance Or Incorrect Operation | Refer to EXTERIOR LIGHTING . |
| C1137:24 | Reverse Gear Switch: Signal Stuck High | Refer to EXTERIOR LIGHTING . |
| P062F:41 | Internal Control Module EEPROM Error: General Checksum Failure | CARRY OUT Programmable Module Installation (PMI) on the BCM . Refer to MODULE CONFIGURATION . |
| P062F:46 | Internal Control Module EEPROM Error: Calibration/Parameter Memory Failure | CARRY OUT the Programmable Module Installation (PMI) Using the Integrated Diagnostic System (IDS) When the Original Module is NOT Available procedure. Refer to MODULE CONFIGURATION . TEST the system for normal operation. |
| P1397:00 | System Voltage Out Of Self Test Range: No Sub Type Information | Go to PINPOINT TEST A . |
| P254F:00 | Engine Hood Switch Circuit/Open: No Sub Type Information | Refer to ANTI-THEFT - PERIMETER . |
| U0010:88 | Medium Speed CAN Communication Bus: Bus Off | Refer to MODULE COMMUNICATIONS NETWORK . |
| U0121:00 | Lost Communication With Anti-Lock Brake System (ABS) Control Module: No Sub Type Information | Go to PINPOINT TEST B . |
| U0155:00 | Lost Communication With Instrument Panel Cluster (IPC) Control Module: No Sub Type Information | Go to PINPOINT TEST C . |
| U0167:00 | Lost Communication With Vehicle Immobilizer Control Module: No Sub Type Information | Go to PINPOINT TEST D . |
| U0257:00 | Lost Communication With Front Controls/Display Interface Module: No Sub Type Information | Go to PINPOINT TEST E . |
| U0415:68 | Invalid Data Received From Anti-Lock Brake System (ABS) Control Module: Event Information | RETRIEVE and REPAIR all non-network DTCs set in the ABS module. Refer to VEHICLE DYNAMIC SYSTEMS or the ENGINE EMISSION CONTROL . |
| U2005:81 | Vehicle Speed: Invalid Serial Data Received | A speed signal is detected during the self-test. DIAGNOSE any symptoms or other module DTCs that are present. CLEAR the DTCs. REPEAT the BCM self-test. If no other symptoms (inaccurate speedometer) or DTCs are present, INSTALL a new BCM . Refer to BODY CONTROL MODULE (BCM) in this information. TEST the system for normal operation. |
| U2010:11 | Switch Illumination: Circuit Short To Ground | Refer to INSTRUMENT CLUSTER AND PANEL ILLUMINATION . |
| U2101:00 | Control Module Configuration Incompatible: No Sub Type Information | CARRY OUT Programmable Module Installation (PMI) on the BCM . Refer to MODULE CONFIGURATION . |
| U3000:44 | Control Module: Data Memory Failure | CARRY OUT PMI on the BCM . Refer to MODULE CONFIGURATION . CLEAR the DTCs. REPEAT the self-test. If DTC U3000:44 is retrieved again, INSTALL a new BCM . Refer to BODY CONTROL MODULE (BCM) in this information. TEST the system for normal operation. |
| U3000:45 | Control Module: Program Memory Failure | CARRY OUT PMI on the BCM . Refer to MODULE CONFIGURATION . CLEAR the DTCs. REPEAT the self-test. If DTC U3000:45 is retrieved again, INSTALL a new BCM . Refer to BODY CONTROL MODULE (BCM) in this information. TEST the system for normal operation. |
| U3003:16 | Battery Voltage: Circuit Voltage Below Threshold | Go to PINPOINT TEST F . |
| U3003:17 | Battery Voltage: Circuit Voltage Above Threshold | Go to PINPOINT TEST G . |
BODY CONTROL MODULE (BCM) DTC CHART
Symptom Chart
| Condition | Possible Sources | Action |
|---|---|---|
| No communication with the Body Control Module (BCM) | Fuse(s) Wiring, terminals or connectors BCM | Refer to MODULE COMMUNICATIONS NETWORK , The BCM Does Not Respond To The Scan Tool. |
SYMPTOM CHART
PINPOINT TEST A: DTC P1397:00
Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.
Note. Failure to disconnect the battery when instructed results in false resistance readings. Refer to BATTERY, MOUNTING AND CABLES .
Note. DTC P1397:00 may be stored in the module memory due to previous battery charging or vehicle jump starting events
Scheme 123
Scheme 124
- A1 CHECK FOR DTCs U3003:16 AND U3003:17 Check for recorded BCM DTCs from the self-test. Is DTC U3003:16 or DTC U3003:17 present? No: Go to A2 . No: For DTC U3003:16, go to «PINPOINT TEST F»(ref-382389-S25314795732011012300000) . For DTC U3003:17, go to «PINPOINT TEST G»(ref-382389-S20029323832011012300000) .
- A2 RECHECK THE BCM DTCs Ignition OFF. Ignition ON. Enter the following diagnostic mode on the scan tool: BCM Module Self-Test. Clear the DTCs. Repeat the BCM self-test. Is DTC P1397:00 still present? No: Go to A3 . No: The system is operating correctly at this time. The DTC may have been set due to a previous low battery voltage condition, during battery charging or while jump starting the vehicle.
- A3 CHECK FOR CHARGING SYSTEM DTCs IN THE PCM Enter the following diagnostic mode on the scan tool: PCM Self-Test. Carry out the PCM KOEO self-test. Retrieve the continuous memory DTCs from the PCM. Is DTC P0562, P0620, P0622, P0625, P0626 or P065B set in the PCM? Yes: Refer to «CHARGING SYSTEM»(ref-382376) . No: Go to A4 .
- A4 CHECK FOR DTCs B1317, B1318, B1676, P0563 OR U3003:17 SET IN OTHER MODULES Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC B1317, B1318, B1676, P0563 (PCM) or U3003:17 set in any other module? Yes: Refer to «CHARGING SYSTEM»(ref-382376) to diagnose the charging system condition. No: Go to A5 .
- A5 CHECK THE BATTERY VOLTAGE Turn off all interior/exterior lights and accessories. Start and run the engine at approximately 2,000 rpm for 3 minutes while monitoring the battery voltage. Does the battery voltage rise to 15.5 volts or higher? Yes: Refer to «CHARGING SYSTEM»(ref-382376) to diagnose an overcharging condition. No: Go to A6 .
- A6 CHECK THE BATTERY CONDITION AND STATE OF CHARGE Ignition OFF. Check the battery condition and verify the battery is fully charged. Refer to «BATTERY, MOUNTING AND CABLES»(ref-382392) . Is the battery OK and fully charged? Yes: Go to A7 . No: Refer to «CHARGING SYSTEM»(ref-382376) .
- A7 CHECK THE BCM VOLTAGE PID Ignition ON. Measure and record the voltage at the battery. Enter the following diagnostic mode on the scan tool: BCM DataLogger. Monitor the BCM voltage PID. Is the voltage within 0.2 volt of the recorded battery voltage? Yes: Go to A10 . No: Go to A8 .
- A8 CHECK THE BCM VOLTAGE SUPPLY Ignition OFF. Disconnect: BCM C2280A. Ignition ON. Measure the voltage between the BCM C2280A-8, circuit SBB06 (BN/RD), harness side and ground; and between the BCM C2280A-14, circuit SBB24 (VT/RD), harness side and ground. Is the voltage within 0.2 volt of the recorded battery voltage? Yes: Go to A9 . No: REPAIR circuit SBB06 (BN/RD) or circuit SBB24 (VT/RD) as necessary for high resistance. CLEAR the DTC. REPEAT the self-test.
- A9 CHECK THE BCM GROUND CIRCUIT FOR HIGH RESISTANCE Ignition OFF. Disconnect: Negative Battery Cable. Disconnect: BCM C2280B. Measure the resistance between the BCM C2280A-16, circuit GD115 (BK/GY), harness side and ground; and between the BCM C2280B-7, circuit GD115 (BK/GY), harness side and ground. Is the resistance less than 5 ohms? Yes: Go to A10 . No: REPAIR circuit GD115 (BK/GY) for high resistance. CLEAR the DTC. REPEAT the self-test.
- A10 CHECK FOR CORRECT BCM OPERATION Disconnect the BCM connectors. Check for: corrosion damaged pins pushed-out pins Connect the BCM connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes: INSTALL a new BCM . Refer to «BODY CONTROL MODULE (BCM)»(ref-382389-S02443611962011012300000) in this information. TEST the system for normal operation. No: The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.
PINPOINT TEST B: DTC U0121:00
- B1 VERIFY THE CUSTOMER CONCERN Ignition ON. Verify that there is an observable symptom present. Is an observable symptom present? Yes: Go to B2 . No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
- B2 CHECK THE COMMUNICATION NETWORK Ignition ON. Enter the following diagnostic mode on the scan tool: Network Test. Carry out the network test. Does the ABS module pass the network test? Yes: Go to B3 . No: Refer to «MODULE COMMUNICATIONS NETWORK»(ref-382388) , The ABS Module Does Not Respond To The Scan Tool.
- B3 RETRIEVE THE RECORDED DTCs FROM THE BCM SELF-TEST Check for recorded BCM DTCs from the self-test. Is DTC U3003:16 or DTC U3003:17 recorded? Yes: For DTC U3003:16, go to «PINPOINT TEST F»(ref-382389-S25314795732011012300000) . For DTC U3003:17, go to «PINPOINT TEST G»(ref-382389-S20029323832011012300000) . No: Go to B4 .
- B4 CHECK FOR DTCs U3003:16 AND U3003:17 FROM THE ABS MODULE SELF-TEST Retrieve the continuous memory DTCs from the ABS module. Is DTC U3003:16 or DTC U3003:17 recorded? Yes: Refer to «VEHICLE DYNAMIC SYSTEMS»(ref-382397) . No: Go to B5 .
- B5 RECHECK THE BCM DTCs NOTE: If new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during Programmable Module Installation (PMI) or the PMI may not have been carried out. Clear the DTCs. Repeat the BCM self-test. Is DTC U0121:00 still present? Yes: Go to B6 . No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
- B6 CHECK FOR DTC U0121:00 or U0121 SET IN OTHER MODULES Clear the DTCs. Ignition OFF. Ignition ON. Wait 10 seconds. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC U0121:00 or DTC U0121 set in any other module? Yes: INSTALL a new ABS module. Refer to «VEHICLE DYNAMIC SYSTEMS»(ref-382397) . CLEAR the DTCs. REPEAT the BCM self-test. No: INSTALL a new BCM . Refer to «BODY CONTROL MODULE (BCM)»(ref-382389-S02443611962011012300000) in this information. TEST the system for normal operation.
PINPOINT TEST C: DTC U0155:00
- C1 VERIFY THE CUSTOMER CONCERN Ignition ON. Verify that there is an observable symptom present. Is an observable symptom present? Yes: Go to C2 . No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
- C2 CHECK THE COMMUNICATION NETWORK Ignition ON. Enter the following diagnostic mode on the scan tool: Network Test. Carry out the network test. Does the IPC pass the network test? Yes: Go to C3 . No: Refer to «MODULE COMMUNICATIONS NETWORK»(ref-382388) , The Instrument Panel Cluster (IPC) Does Not Respond To The Scan Tool.
- C3 RETRIEVE THE RECORDED DTCs FROM THE BCMSELF-TEST Check for recorded BCM DTCs from the self-test. Is DTC U3003:16 or DTC U3003:17 recorded? Yes: For DTC U3003:16, go to «PINPOINT TEST F»(ref-382389-S25314795732011012300000) . For DTC U3003:17, go to «PINPOINT TEST G»(ref-382389-S20029323832011012300000) . No: Go to C4.
- C4 CHECK FOR DTC U3006:16 FROM THE IPC SELF-TEST Retrieve the continuous memory DTCs from the IPC. Is DTC U3006:16 recorded? Yes: Refer to «INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES»(ref-382387) . No: Go to C5.
- C5 RECHECK THE BCM DTCs NOTE: If new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during Programmable Module Installation (PMI) or the PMI may not have been carried out. Clear the DTCs. Repeat the BCM self-test. Is DTC U0155:00 still present? Yes: Go to C6. No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
- C6 CHECK FOR DTC U0155:00 or U0155 SET IN OTHER MODULES Clear the DTCs. Ignition OFF. Ignition ON. Wait 10 seconds. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC U0155:00 or DTC U0155 set in any other module? Yes: INSTALL a new IPC. Refer to «INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES»(ref-382387) . CLEAR the DTCs. REPEAT the BCM self-test. No: INSTALL a new BCM. Refer to «BODY CONTROL MODULE (BCM)»(ref-382389-S02443611962011012300000) in this information. TEST the system for normal operation.
PINPOINT TEST D: DTC U0167:00
- D1 VERIFY THE CUSTOMER CONCERN Ignition ON. Verify that there is an observable symptom present. Is an observable symptom present? Yes: Go to D2. No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
- D2 CHECK THE COMMUNICATION NETWORK Ignition ON. Enter the following diagnostic mode on the scan tool: Network Test. Carry out the network test. Does the RFA module pass the network test? Yes: Go to D3. No: Refer to «MODULE COMMUNICATIONS NETWORK»(ref-382388) , The Remote Function Actuator (RFA) Module Does Not Respond To The Scan Tool.
- D3 RETRIEVE THE RECORDED DTCs FROM THE BCMSELF-TEST Check for recorded BCM DTCs from the self-test. Is DTC U3003:16 or DTC U3003:17 recorded? Yes: For DTC U3003:16, go to «PINPOINT TEST F»(ref-382389-S25314795732011012300000) . For DTC U3003:17, go to «PINPOINT TEST G»(ref-382389-S20029323832011012300000) . No: Go to D4.
- D4 CHECK FOR DTCs U3003:16 AND U3003:17 FROM THE RFA MODULE SELF-TEST Retrieve the continuous memory DTCs from the RFA module. Is DTC U3003:16 or U3003:17 recorded? Yes: For DTC U3003:16, go to «PINPOINT TEST O»(ref-382389-S31196067442011012300000) . For DTC U3003:17, go to «PINPOINT TEST P»(ref-382389-S24017988252011012300000) . No: Go to D5.
- D5 RECHECK THE BCM DTCs NOTE: new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during Programmable Module Installation (PMI) or the PMI may not have been carried out. Clear the DTCs. Repeat the BCM self-test. Is DTC U0167:00 still present? Yes: INSTALL a new RFA module. Refer to «REMOTE FUNCTION ACTUATOR (RFA) MODULE»(ref-382389-S08787707832011012300000) in this information. CLEAR the DTCs. REPEAT the BCM self-test. If the concern is still present after the repair, INSTALL a new BCM. Refer to Body Control Module (BCM ) in this information. TEST the system for normal operation. No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
PINPOINT TEST E: DTC U0257:00
- E1 VERIFY THE CUSTOMER CONCERN Ignition ON. Verify that there is an observable symptom present. Is an observable symptom present? Yes: Go to E2. No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
- E2 CHECK THE COMMUNICATION NETWORK Ignition ON. Enter the following diagnostic mode on the scan tool: Network Test. Carry out the network test. Does the FCDIM pass the network test? Yes: Go to E3. No: Refer to «MODULE COMMUNICATIONS NETWORK»(ref-382388) , The Front Control/Display Interface Module (FCDIM) Does Not Respond To The Scan Tool.
- E3 RETRIEVE THE RECORDED DTCs FROM THE BCMSELF-TEST Check for recorded BCM DTCs from the self-test. Is DTC U3003:16 or DTC U3003:17 recorded? Yes: For DTC U3003:16, go to «PINPOINT TEST F»(ref-382389-S25314795732011012300000) . For DTC U3003:17, go to «PINPOINT TEST G»(ref-382389-S20029323832011012300000) . No: Go to E4.
- E4 CHECK FOR DTCs U3006:16 AND U3006:17 FROM THE FCDIM SELF-TEST Retrieve the continuous memory DTCs from the FCDIM. Is DTC U3006:16 or DTC U3006:17 recorded? Yes: Refer to «INFORMATION AND ENTERTAINMENT SYSTEMS»(ref-382429) . No: Go to E5 .
- E5 RECHECK THE BCM DTCs NOTE: new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during Programmable Module Installation (PMI) or the PMI may not have been carried out. Clear the DTCs. Repeat the BCM self-test. Is DTC U0257:00 still present? Yes: Go to E6 . No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
- E6 CHECK FOR DTC U0257:00 OR U0257 SET IN OTHER MODULES Clear the DTCs. Ignition OFF. Ignition ON. Wait 10 seconds. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC U0257:00 or DTC U0257 set in any other module? Yes: INSTALL a new FCDIM. Refer to «INFORMATION AND ENTERTAINMENT SYSTEMS»(ref-382429) . CLEAR the DTCs. REPEAT the BCM self-test. No: INSTALL a new BCM. Refer to «BODY CONTROL MODULE (BCM)»(ref-382389-S02443611962011012300000) in this information. TEST the system for normal operation.
Pinpoint Test F: DTC U3003:16
Refer to the appropriate SYSTEM WIRING DIAGRAMS article for schematic and connector information.
Note. the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.
Note. to disconnect the battery when instructed results in false resistance readings. Refer to BATTERY, MOUNTING AND CABLES .
Scheme 125
Scheme 126
- F1 RECHECK THE BCM DTCs Ignition ON. Enter the following diagnostic mode on the scan tool: BCM Self-Test. Clear the DTCs. Repeat the BCM self-test. Is DTC U3003:16 still present? Yes: Go to F2 . No: The system is operating correctly at this time. The DTC may have been set due to a previous low battery voltage condition.
- F2 CHECK FOR CHARGING SYSTEM DTCs IN THE PCM Enter the following diagnostic mode on the scan tool: PCM Self-Test. Carry out the PCM KOEO self-test. Retrieve the continuous memory DTCs from the PCM. Is DTC P0562, P0620, P0622, P0625, P0626 or P065B set in the PCM? Yes: Refer to «CHARGING SYSTEM»(ref-382376) . No: Go to F3 .
- F3 CHECK THE BATTERY CONDITION AND STATE OF CHARGE Ignition OFF. Check the battery condition and verify the battery is fully charged. Refer to «BATTERY, MOUNTING AND CABLES»(ref-382392) . Is the battery OK and fully charged? Yes: Go to F4 . No: Refer to «CHARGING SYSTEM»(ref-382376) .
- F4 CHECK THE BCM VOLTAGE PID Ignition ON. Measure and record the voltage at the battery. Enter the following diagnostic mode on the scan tool: BCM DataLogger. Monitor the BCM voltage PID. Is the voltage within 0.2 volt of the recorded battery voltage? Yes: Go to F7 . No: Go to F5 .
- F5 CHECK THE BCM VOLTAGE SUPPLY Ignition OFF. Disconnect: BCM C2280A. Ignition ON. Measure the voltage between the BCM C2280A-8, circuit SBB06 (BN/RD), harness side and ground; and between the BCM C2280A-14, circuit SBB24 (VT/RD), harness side and ground. Is the voltage within 0.2 volt of the recorded battery voltage? Yes: Go to F6 . No: REPAIR circuit SBB06 (BN/RD) or circuit SBB24 (VT/RD) as necessary for high resistance. CLEAR the DTC. REPEAT the self-test.
- F6 CHECK THE BCM GROUND CIRCUIT FOR HIGH RESISTANCE Ignition OFF. Disconnect: Negative Battery Cable. Disconnect: BCM C2280D. Measure the resistance between the BCM C2280A-16, circuit GD115 (BK/GY), harness side and ground; and between the BCM C2280B-7, circuit GD115 (BK/GY), harness side and ground. Is the resistance less than 5 ohms? Yes: Go to F7 . No: REPAIR circuit GD115 (BK/GY) for high resistance. CLEAR the DTC. REPEAT the self-test.
- F7 CHECK FOR CORRECT BCM OPERATION Disconnect the BCM connectors. Check for: corrosion damaged pins pushed-out pins Connect the BCM connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes: INSTALL a new BCM . Refer to «BODY CONTROL MODULE (BCM)»(ref-382389-S02443611962011012300000) in this information. TEST the system for normal operation. No: The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.
Pinpoint Test G: DTC U3003:17
Refer to the appropriate SYSTEM WIRING DIAGRAMS article for schematic and connector information.
Note. DTC U3003:17 may be stored in the module memory due to previous battery charging or vehicle jump starting events
- G1 CHECK FOR DTC B1317, B1676, P0563 (PCM) OR U3003:17 SET IN OTHER MODULES Ignition ON. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC B1317, B1676, P0563 (PCM) or U3003:17 set in more than one module? Yes: Refer to «CHARGING SYSTEM»(ref-382376) to diagnose an overcharging condition. No: Go to G2 .
- G2 CHECK THE BATTERY VOLTAGE Turn off all interior/exterior lights and accessories. Start and run the engine at approximately 2,000 rpm for 3 minutes while monitoring the battery voltage. Does the battery voltage rise to 15.5 volts or higher? Yes: Refer to «CHARGING SYSTEM»(ref-382376) to diagnose an overcharging condition. No: Go to G3 .
- G3 RECHECK FOR DTC U3003:17 Turn the engine off. Ignition ON. Enter the following diagnostic mode on the scan tool: BCM Self-Test. Clear the continuous memory DTCs. Carry out the BCM self-test. Is DTC U3003:17 present? Yes: INSTALL a new BCM . Refer to «BODY CONTROL MODULE (BCM)»(ref-382389-S02443611962011012300000) in this information. TEST the system for normal operation. No: The system is operating correctly at this time. The DTC may have been set previously during battery charging or while jump starting the vehicle.
Pinpoint Test G
G5
DLC
- NOTE: The Vehicle Communication Module (VCM) prove-out confirms power and ground from the DLC are provided to the VCM .
- If the scan tool does not communicate with the VCM
Remote Function Actuator (RFA) Module DTC Chart
Note. to Description and Operation, Intelligent Access (IA) with Push Button Start in ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) to review the procedures for achieving the various ignition states (ignition off, ignition on, ignition start) on vehicles with this feature.
| DTC | Description | Action |
|---|---|---|
| B102B:05 | Passive Key: System Programming Failure | Refer to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) . |
| B108B:23 | Start Button Circuit "A": Signal Stuck Low | Refer to STEERING COLUMN SWITCHES . |
| B108B:29 | Start Button Circuit "A": Signal Invalid | Refer to STEERING COLUMN SWITCHES . |
| B108C:23 | Start Button Circuit "B": Signal Stuck Low | Refer to STEERING COLUMN SWITCHES . |
| B10C6:1F | Exterior Trunk Antenna: Circuit Intermittent | Refer to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B10C7:1F | Interior Trunk Antenna: Circuit Intermittent | Refer to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) . |
| B10C8:1F | Interior Centre Antenna: Circuit Intermittent | Refer to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) . |
| B10C9:1F | Interior Front Antenna: Circuit Intermittent | Refer to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) . |
| B10D1:24 | Left Front Lock Button: Signal Stuck High | Refer to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B10D3:24 | Right Front Lock Button: Signal Stuck High | Refer to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B10D5:13 | PATS Antenna: Circuit Open | Refer to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) . |
| B10D6:62 | PATS Enable Status: Signal Compare Failure | Refer to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) . |
| B10D7:05 | PATS Key: System Programming Failure | Refer to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) . |
| B10D7:51 | PATS Key: Not Programmed | Refer to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) . |
| B10D7:81 | PATS Key: Invalid Serial Data Received | Refer to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) . |
| B10D8:00 | PATS Key Less Than Minimum Programmed: No Sub Type Information | Refer to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) . |
| B10D9:87 | PATS Transponder: Missing Message | Refer to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) . |
| B10DA:51 | PATS Target Identifier: Not Programmed | Refer to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) . |
| B10DA:62 | PATS Target Identifier: Signal Compare Failure | Refer to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) . |
| B10E6:11 | PATS Power Supply: Circuit Short To Ground | Refer to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) . |
| B10E6:12 | PATS Power Supply: Circuit Short To Battery | Refer to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) . |
| B10E7:11 | Ignition On Relay: Circuit Short To Ground | Refer to STEERING COLUMN SWITCHES . |
| B10E7:12 | Ignition On Relay: Circuit Short To Battery | Refer to STEERING COLUMN SWITCHES . |
| B10E7:16 | Ignition On Relay: Circuit Voltage Below Threshold | Refer to STEERING COLUMN SWITCHES . |
| B10E7:17 | Ignition On Relay: Circuit Voltage Above Threshold | Refer to STEERING COLUMN SWITCHES . |
| B113E:24 | External Boot/Trunk Release Switch: Signal Stuck High | Refer to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B11FD:1F | Left Front Exterior Antenna: Circuit Intermittent | Refer to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B1210:1F | Right Front Exterior Antenna: Circuit Intermittent | Refer to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| P0560:16 | System Voltage: Circuit Voltage Below Threshold | Go to PINPOINT TEST H . |
| P0560:17 | System Voltage: Circuit Voltage Above Threshold | Go to PINPOINT TEST I . |
| P0615:12 | Starter Relay Circuit: Circuit Short To Battery | Refer to STARTING SYSTEM . |
| P081C:62 | Park Input Circuit: Signal Compare Failure | Refer to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES . |
| P1571:62 | Brake Switch: Signal Compare Failure | Refer to STARTING SYSTEM . |
| P1708:62 | Clutch Switch Circuit: Signal Compare Failure | Refer to STARTING SYSTEM . |
| U0001:00 | High Speed CAN Communication Bus: No Sub Type Information | Refer to MODULE COMMUNICATIONS NETWORK . |
| U0010:00 | Medium Speed CAN communication Bus: No Sub Type Information | Refer to MODULE COMMUNICATIONS NETWORK . |
| U0100:00 | Lost Communication With ECM/PCM "A": No Sub Type Information | Go to PINPOINT TEST J . |
| U0100:87 | Lost Communication With ECM/PCM "A": Missing Message | Refer to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) . |
| U0101:00 | Lost Communication with TCM: No Sub Type Information | Go to PINPOINT TEST K . |
| U0121:00 | Lost Communication With Anti-Lock Brake System (ABS) Control Module: No Sub Type Information | Go to PINPOINT TEST L . |
| U0140:00 | Lost Communication With Body Control Module: No Sub Type Information | Go to PINPOINT TEST M . |
| U0155:00 | Lost Communication With Instrument Panel Cluster (IPC) Control Module: No Sub Type Information | Go to PINPOINT TEST N . |
| U0300:05 | Internal Control Module Software Incompatibility: System Programming Failure | CARRY OUT Programmable Module Installation (PMI) on the RFA module. Refer to MODULE CONFIGURATION . |
| U201B:54 | Control Module Calibration Data #2: Missing Calibration | CARRY OUT Programmable Module Installation (PMI) on the RFA module. Refer to MODULE CONFIGURATION . |
| U201F:00 | External Receiver: No Sub Type Information | Refer to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) . |
| U201F:13 | External Receiver: Circuit Open | Refer to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) . |
| U2100:00 | Initial Configuration Not Complete: No Sub Type Information | CARRY OUT Programmable Module Installation (PMI) on the RFA module. Refer to MODULE CONFIGURATION . |
| U2101:00 | Control Module Configuration Incompatible: No Sub Type Information | CARRY OUT Programmable Module Installation (PMI) on the RFA module. Refer to MODULE CONFIGURATION . |
| U3000:01 | Control Module: General Electrical Failure | ADDRESS all other DTCs first. CLEAR the DTCs. REPEAT the self-test. If DTC U3000:01 is retrieved again, INSTALL a new RFA . Refer to REMOTE FUNCTION ACTUATOR (RFA) MODULE in this information. |
| U3000:42 | Control Module: General Memory Failure | ADDRESS all other DTCs first. CLEAR the DTCs. REPEAT the self-test. If DTC U3000:42 is retrieved again, INSTALL a new RFA . Refer to REMOTE FUNCTION ACTUATOR (RFA) MODULE in this information. |
| U3003:16 | Battery Voltage: Circuit Voltage Below Threshold | Go to PINPOINT TEST O . |
| U3003:17 | Battery Voltage: Circuit Voltage Above Threshold | Go to PINPOINT TEST P . |
| U3003:62 | Battery Voltage: Signal Compare Failure | Go to PINPOINT TEST Q . |
| U3004:11 | Accessory Power Relay: Circuit Short To Ground | Refer to STEERING COLUMN SWITCHES . |
| U3004:12 | Accessory Power Relay: Circuit Short To Battery | Refer to STEERING COLUMN SWITCHES . |
| U300E:62 | Ignition Input On: Signal Compare Failure | Refer to STEERING COLUMN SWITCHES . |
| U300F:62 | Ignition Input Accessory: Signal Compare Failure | Refer to STEERING COLUMN SWITCHES . |
| U3010:62 | Ignition Input Start: Signal Compare Failure | Refer to STEERING COLUMN SWITCHES . |
| U3011:62 | Ignition Input Off: Signal Compare Failure | Refer to STEERING COLUMN SWITCHES . |
DTC DESCRIPTION CHART
Note. Refer to Description and Operation, Intelligent Access (IA) with Push Button Start in ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) to review the procedures for achieving the various ignition states (ignition off, ignition in accessory, ignition on, ignition start) on vehicles with this feature.
| Condition | Possible Sources | Action |
|---|---|---|
| No communication with the Remote Function Actuator (RFA) Module | Fuse Wiring, terminals or connectors RFA module | Refer to MODULE COMMUNICATIONS NETWORK , The Remote Function Actuator (RFA) Module Does Not Respond To The Scan Tool. |
SYMPTOM CHART
PINPOINT TEST H: DTC P0560:16
Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.
Note. Failure to disconnect the battery when instructed results in false resistance readings. Refer to BATTERY, MOUNTING AND CABLES .
Scheme 127
Scheme 128
- H1 RECHECK THE RFA MODULE DTCs Ignition ON. Enter the following diagnostic mode on the scan tool: RFA Module Self-Test. Clear the DTCs. Repeat the RFA module self-test. Is DTC P0560:16 still present? Yes: Go to H2 . No: The system is operating correctly at this time. The DTC may have been set due to a previous low battery voltage condition.
- H2 CHECK FOR CHARGING SYSTEM DTCs IN THE PCM Enter the following diagnostic mode on the scan tool: PCM Self-Test. Carry out the PCM KOEO self-test. Retrieve the continuous memory DTCs from the PCM. Is DTC P0562, P0620, P0622, P0625, P0626 or P065B set in the PCM? Yes: Refer to «CHARGING SYSTEM»(ref-382376) . No: Go to H3 .
- H3 CHECK THE BATTERY CONDITION AND STATE OF CHARGE Ignition OFF. Check the battery condition and verify the battery is fully charged. Refer to «BATTERY, MOUNTING AND CABLES»(ref-382392) . Is the battery OK and fully charged? Yes: Go to H4 . No: Refer to «CHARGING SYSTEM»(ref-382376) .
- H4 CHECK THE RFA MODULE VOLTAGE PID Ignition ON. Measure and record the voltage at the battery. Enter the following diagnostic mode on the scan tool: RFA Module DataLogger. Monitor the RFA module voltage PID (ECU_Pwr_Sup). Is the voltage within 0.2 volt of the recorded battery voltage? Yes: Go to H7 . No: Go to H5 .
- H5 CHECK THE RFA MODULE VOLTAGE SUPPLY Ignition OFF. Disconnect: RFA Module C3503a. Ignition ON. Measure the voltage between the RFA module C3503a-2, circuit SBP14 (BN/RD), harness side and ground. Is the voltage within 0.2 volt of the recorded battery voltage? Yes: Go to H6 . No: REPAIR circuit SBP14 (BN/RD) for high resistance. CLEAR the DTC. REPEAT the self-test.
- H6 CHECK THE RFA MODULE GROUND CIRCUIT FOR HIGH RESISTANCE Ignition OFF. Disconnect: Negative Battery Cable. Disconnect: RFA Module C3503d. Measure the resistance between the RFA module and ground as follows: CONNECTOR-PIN REFERENCE CHART Connector-Pin Circuit C3503a-3 GD145 (BK/BU) C3503d-3 GD145 (BK/BU) C3503d-4 GD145 (BK/BU) Are the resistances less than 5 ohms? Yes: Go to H7 . No: REPAIR circuit GD145 (BK/BU) for high resistance. CLEAR the DTC. REPEAT the self-test.
- H7 CHECK FOR CORRECT RFA MODULE OPERATION Disconnect the RFA module connectors. Check for: corrosion damaged pins pushed-out pins Connect the RFA module connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes: INSTALL a new RFA module. Refer to «REMOTE FUNCTION ACTUATOR (RFA) MODULE»(ref-382389-S08787707832011012300000) in this information. TEST the system for normal operation. If the No: The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.
PINPOINT TEST I: DTC P0560:17
Note. DTC P0560:17 may be stored in the module memory due to previous battery charging or vehicle jump starting events
- I1 CHECK FOR DTC B1317, B1676, P0563 (PCM) OR U3003:17 SET IN OTHER MODULES Ignition ON. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC B1317, B1676, P0563 (PCM) or U3003:17 set in more than one module? Yes: Refer to «CHARGING SYSTEM»(ref-382376) to diagnose an overcharging condition. No: Go to I2 .
- I2 CHECK THE BATTERY VOLTAGE Turn off all interior/exterior lights and accessories. Start and run the engine at approximately 2,000 rpm for 3 minutes while monitoring the battery voltage. Does the battery voltage rise to 16 volts or higher? Yes: Refer to «CHARGING SYSTEM»(ref-382376) to diagnose an overcharging condition. No: Go to I3 .
- I3 RECHECK FOR DTC P0560:17 Turn the engine off. Ignition ON. Enter the following diagnostic mode on the scan tool: RFA Module Self-Test. Clear the continuous memory DTCs. Carry out the RFA module self-test. Is DTC P0560:17 present? Yes: INSTALL a new RFA module. Refer to «REMOTE FUNCTION ACTUATOR (RFA) MODULE»(ref-382389-S08787707832011012300000) in this information. TEST the system for normal operation. No: The system is operating correctly at this time. The DTC may have been set previously during battery charging or while jump starting the vehicle.
PINPOINT TEST J: DTC U0100:00
- J1 VERIFY THE SCAN TOOL CAN COMMUNICATE WITH THE PCM Connect the scan tool. Check that a vehicle session can be established using the scan tool. Can a vehicle session be established? Yes: Go to J2 . No: Refer to «MODULE COMMUNICATIONS NETWORK»(ref-382388) , The PCM Does Not Respond To The Scan Tool.
- J2 CHECK THE RFA MODULE CONTINUOUS MEMORY DTCs Ignition ON. Enter the following diagnostic mode on the scan tool: RFA Module Self-Test. Clear the DTCs. Repeat the RFA module self-test. Is DTC U0100:00 retrieved again? Yes: Go to J3 . No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
- J3 RETRIEVE THE RECORDED DTCs FROM THE RFA MODULE SELF-TEST Check for recorded RFA module DTCs from the self-test. Is DTC U3003:16 or DTC U3003:17 recorded? Yes: For DTC U3003:16, go to «PINPOINT TEST O»(ref-382389-S31196067442011012300000) . For DTC U3003:17, go to «PINPOINT TEST P»(ref-382389-S24017988252011012300000) . No: Go to J4 .
- J4 CHECK FOR DTC U0100:00 OR DTC U0100 SET IN OTHER MODULES Ignition ON. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC U0100:00 or DTC U0100 set in any other module? Yes: INSTALL a new PCM. Refer to «ELECTRONIC ENGINE CONTROLS»(ref-382403) . TEST the system for normal operation. No: INSTALL a new RFA module. Refer to «REMOTE FUNCTION ACTUATOR (RFA) MODULE»(ref-382389-S08787707832011012300000) in this information. TEST the system for normal operation
PINPOINT TEST K: DTC U0101:00
- K1 VERIFY THE CUSTOMER CONCERN Ignition ON. Verify that there is an observable symptom present. Is an observable symptom present? Yes: Go to K2 . No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
- K2 CHECK THE COMMUNICATION NETWORK Enter the following diagnostic mode on the scan tool: Network Test. Carry out the network test. Does the TCM pass the network test? Yes: Go to K3 . No: Refer to «MODULE COMMUNICATIONS NETWORK»(ref-382388) .
- K3 RETRIEVE THE RECORDED DTCs FROM THE RFA MODULE SELF-TEST Check for recorded RFA module DTCs from the self-test. Is DTC U3003:16 or DTC U3003:17 recorded? Yes: For DTC U3003:16, go to «PINPOINT TEST O»(ref-382389-S31196067442011012300000) . For DTC U3003:17, go to «PINPOINT TEST P»(ref-382389-S24017988252011012300000) . No: Go to K4 .
- K4 RECHECK THE RFA MODULE DTCs NOTE: new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during the Programmable Module Installation (PMI) or the PMImay not have been carried out. Clear the DTCs. Repeat the RFA module self-test. Is DTC U0101:00 still present? Yes: Go to K5 . No: The system is operating correctly at this time. The DTC may have been set due to high network traffic.
- K5 CHECK FOR DTC U0101:00 OR DTC U0101 SET IN OTHER MODULES Clear all DTCs. Ignition OFF. Ignition ON. Wait 10 seconds. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC U0101:00 or DTC U0101 set in any other module? Yes: INSTALL a new TCM. Refer to «AUTOMATIC SHIFTING MANUAL TRANSMISSION/TRANSAXLE»(ref-382366) . CLEAR the DTCs. REPEAT the self-test. No: INSTALL a new RFA module. Refer to «REMOTE FUNCTION ACTUATOR (RFA) MODULE»(ref-382389-S08787707832011012300000) in this information. TEST the system for normal operation.
PINPOINT TEST L: DTC U0121:00
- L1 VERIFY THE CUSTOMER CONCERN Ignition ON. Verify that there is an observable symptom present. Is an observable symptom present? Yes: Go to L2 . No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
- L2 CHECK THE COMMUNICATION NETWORK Ignition ON. Enter the following diagnostic mode on the scan tool: Network Test. Carry out the network test. Does the ABS module pass the network test? Yes: Go to L3 . No: Refer to «MODULE COMMUNICATIONS NETWORK»(ref-382388) , The ABS Module Does Not Respond To The Scan Tool.
- L3 RETRIEVE THE RECORDED DTCs FROM THE RFA MODULE SELF-TEST Check for recorded RFA module DTCs from the self-test. Is DTC U3003:16 or DTC U3003:17 recorded? Yes: For DTC U3003:16, go to «PINPOINT TEST O»(ref-382389-S31196067442011012300000) . For DTC U3003:17, go to «PINPOINT TEST P»(ref-382389-S24017988252011012300000) . No: Go to L4
- L4 CHECK FOR DTCs U3003:16 AND U3003:17 FROM THE ABS MODULE SELF-TEST Retrieve the continuous memory DTCs from the ABS module. Is DTC U3003:16 or DTC U3003:17 recorded? Yes: Refer to «VEHICLE DYNAMIC SYSTEMS»(ref-382397) . No: Go to L5 .
- L5 RECHECK THE RFA MODULE DTCs NOTE: new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during Programmable Module Installation (PMI) or the PMImay not have been carried out. Clear the DTCs. Repeat the RFA module self-test. Is DTC U0121:00 still present? Yes: Go to L6 . No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
- L6 CHECK FOR DTC U0121:00 OR DTC U0121 SET IN OTHER MODULES Clear the DTCs. Ignition OFF. Ignition ON. Wait 10 seconds. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC U0121:00 OR DTC U0121 set in any other module? Yes: INSTALL a new ABS module. Refer to «VEHICLE DYNAMIC SYSTEMS»(ref-382397) . CLEAR the DTCs. REPEAT the self-test. No: INSTALL a new RFA module. Refer to «REMOTE FUNCTION ACTUATOR (RFA) MODULE»(ref-382389-S08787707832011012300000) in this information. TEST the system for normal operation.
PINPOINT TEST M: DTC U0140:00
- M1 VERIFY CUSTOMER CONCERN Ignition ON. Verify that there is an observable symptom present. Is an observable symptom present? Yes: Go to M2 . No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
- M2 CHECK THE COMMUNICATION NETWORK Ignition ON. Enter the following diagnostic mode on the scan tool: Network Test. Carry out the network test. Does the BCM pass the network test? Yes: Go to M3 . No: Refer to «MODULE COMMUNICATIONS NETWORK»(ref-382388) .
- M3 RETRIEVE THE RECORDED DTCs FROM THE RFA MODULE SELF-TEST Check for recorded RFA module DTCs from the self-test. Is DTC U3003:16 or DTC U3003:17 recorded? Yes: For DTC U3003:16, go to «PINPOINT TEST O»(ref-382389-S31196067442011012300000) . For DTC U3003:17, go to «PINPOINT TEST P»(ref-382389-S24017988252011012300000) . No: Go to M4 .
- M4 CHECK FOR DTCs U3003:16 AND U3003:17 FROM THE BCMSELF-TEST Retrieve the continuous memory DTCs from the BCM self-test. Is DTC U3003:16 or DTC U3003:17 recorded? Yes: For DTC U3003:16, go to «PINPOINT TEST F»(ref-382389-S25314795732011012300000) . For DTC U3003:17, go to «PINPOINT TEST G»(ref-382389-S20029323832011012300000) . No: Go to M5 .
- M5 RECHECK THE RFA MODULE DTCs NOTE: new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during Programmable Module Installation (PMI) or the PMImay not have been carried out. Clear the DTCs. Repeat the RFA module self-test. Is DTC U0140:00 still present? Yes: Go to M6 . No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
- M6 CHECK FOR DTC U0140:00 OR DTC U0140 OTHER MODULES Clear all DTCs. Ignition OFF. Ignition ON. Wait 10 seconds. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC U0140:00 or DTC U0140 set in any other module? Yes: INSTALL a new BCM. Refer to «BODY CONTROL MODULE (BCM)»(ref-382389-S02443611962011012300000) in this information. TEST the system for normal operation. No: INSTALL a new RFA module. Refer to «REMOTE FUNCTION ACTUATOR (RFA) MODULE»(ref-382389-S08787707832011012300000) in this information. TEST the system for normal operation.
PINPOINT TEST N: DTC U0155:00
- N1 VERIFY CUSTOMER CONCERN Ignition ON. Verify that there is an observable symptom present. Is an observable symptom present? Yes: Go to N2 . No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
- N2 CHECK THE COMMUNICATION NETWORK Ignition ON. Enter the following diagnostic mode on the scan tool: Network Test. Carry out the network test. Does the IPC pass the network test? Yes: Go to N3 . No: Refer to «MODULE COMMUNICATIONS NETWORK»(ref-382388) , The IPC Does Not Respond To The Scan Tool.
- N3 RETRIEVE THE RECORDED DTCs FROM THE RFA MODULE SELF-TEST Check for recorded RFA module DTCs from the self-test. Is DTC U3003:16 or DTC U3003:17 recorded? Yes: For DTC U3003:16, go to «PINPOINT TEST O»(ref-382389-S31196067442011012300000) . For DTC U3003:17, go to «PINPOINT TEST P»(ref-382389-S24017988252011012300000) . No: Go to N4 .
- N4 RECHECK THE RFA MODULE DTCs NOTE: new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during Programmable Module Installation (PMI) or the PMImay not have been carried out. Clear the DTCs. Repeat the RFA module self-test. Is DTC U0155:00 still present? Yes: Go to No . No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
- No CHECK FOR DTC U0155:00 OR DTC U0155 SET IN OTHER MODULES Clear the DTCs. Ignition OFF. Ignition ON. Wait 10 seconds. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC U0155:00 or DTC U0155 set in any other module? Yes: INSTALL a new IPC. Refer to «INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES»(ref-382387) . No: INSTALL a new RFA module. Refer to «REMOTE FUNCTION ACTUATOR (RFA) MODULE»(ref-382389-S08787707832011012300000) in this information. TEST the system for normal operation.
PINPOINT TEST O: DTC U3003:16
Note. the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.
Note. to disconnect the battery when instructed results in false resistance readings. Refer to BATTERY, MOUNTING AND CABLES .
Scheme 129
Scheme 130
- O1 RECHECK THE RFA MODULE DTCs Ignition ON. Enter the following diagnostic mode on the scan tool: RFA Module Self-Test. Clear the DTCs. Repeat the RFA module self-test. Is DTC U3003:16 still present? Yes: Go to O2 . No: The system is operating correctly at this time. The DTC may have been set due to a previous low battery voltage condition.
- O2 CHECK FOR CHARGING SYSTEM DTCs IN THE PCM Enter the following diagnostic mode on the scan tool: PCM Self-Test. Carry out the PCM KOEO self-test. Retrieve the continuous memory DTCs from the PCM. Are any low or high voltage DTCs set in the PCM? Yes: Refer to «CHARGING SYSTEM»(ref-382376) . No: Go to O3 .
- O3 CHECK THE BATTERY CONDITION AND STATE OF CHARGE Ignition OFF. Check the battery condition and verify the battery is fully charged. Refer to «BATTERY, MOUNTING AND CABLES»(ref-382392) . Is the battery OK and fully charged? Yes: Go to O4 . No: Refer to «CHARGING SYSTEM»(ref-382376) .
- O4 CHECK THE RFA MODULE VOLTAGE PID Ignition ON. Measure and record the voltage at the battery. Enter the following diagnostic mode on the scan tool: RFA Module DataLogger. Monitor the RFA module voltage PID (ECU_VPWR). Is the voltage within 0.2 volt of the recorded battery voltage? Yes: Go to O7 . No: Go to O5 .
- O5 CHECK THE RFA MODULE VOLTAGE SUPPLY Ignition OFF. Disconnect: RFA Module C3503a. Ignition ON. Measure the voltage between the RFA module C3503a-1, circuit SBP09 (RD), harness side and ground. Is the voltage within 0.2 volt of the recorded battery voltage? Yes: Go to O6 . No: REPAIR circuit SBP09 (RD) for high resistance. CLEAR the DTC. REPEAT the self-test.
- O6 CHECK THE RFA MODULE GROUND CIRCUIT FOR HIGH RESISTANCE Ignition OFF. Disconnect: Negative Battery Cable. Disconnect: RFA Module C3503d. Measure the resistance between the RFA module and ground as follows: CONNECTOR-PIN REFERENCE CHART Connector-Pin Circuit C3503a-3 GD145 (BK/BU) C3503d-3 GD145 (BK/BU) C3503d-4 GD145 (BK/BU) Are the resistances less than 5 ohms? Yes: Go to O7 . No: REPAIR circuit GD145 (BK/BU) for high resistance. CLEAR the DTC. REPEAT the self-test.
- O7 CHECK FOR CORRECT RFA MODULE OPERATION Disconnect the RFA module connectors. Check for: corrosion damaged pins pushed-out pins Connect the RFA module connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes: INSTALL a new RFA module. Refer to «REMOTE FUNCTION ACTUATOR (RFA) MODULE»(ref-382389-S08787707832011012300000) in this information. TEST the system for normal operation. No: The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.
PINPOINT TEST P: DTC U3003:17
Note. DTC U3003:17 may be stored in the module memory due to previous battery charging or vehicle jump starting events
- P1 CHECK FOR DTC B1317, B1676, P0563 (PCM) OR U3003:17 SET IN OTHER MODULES Ignition ON. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC B1317, B1676, P0563 (PCM) or U3003:17 set in more than one module? Yes: Refer to «CHARGING SYSTEM»(ref-382376) to diagnose an overcharging condition. No: Go to P2 .
- P2 CHECK THE BATTERY VOLTAGE Turn off all interior/exterior lights and accessories. Start and run the engine at approximately 2,000 rpm for 3 minutes while monitoring the battery voltage. Does the battery voltage rise to 16 volts or higher? Yes: Refer to «CHARGING SYSTEM»(ref-382376) to diagnose an overcharging condition. No: Go to P3 .
- P3 RECHECK FOR DTC U3003:17 Turn the engine off. Ignition ON. Enter the following diagnostic mode on the scan tool: RFA Module Self-Test. Clear the continuous memory DTCs. Carry out the RFA module self-test. Is DTC U3003:17 present? Yes: INSTALL a new RFA module. Refer to «REMOTE FUNCTION ACTUATOR (RFA) MODULE»(ref-382389-S08787707832011012300000) in this information. TEST the system for normal operation. No: The system is operating correctly at this time. The DTC may have been set previously during battery charging or while jump starting the vehicle.
PINPOINT TEST Q: DTC U3003:62
Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.
Note. Failure to disconnect the battery when instructed results in false resistance readings. Refer to BATTERY, MOUNTING AND CABLES .
Note. DTC U3003:62 may be stored in the module memory due to previous battery charging or vehicle jump starting events
Scheme 131
Scheme 132
- Q1 CHECK FOR DTCs U3003:16 AND U3003:17 Check for recorded RFA module DTCs from the self-test. Is DTC U3003:16 or DTC U3003:17 present? No: Go to Q2 . No: For DTC U3003:16, go to «PINPOINT TEST O»(ref-382389-S31196067442011012300000) . For DTC U3003:17, go to «PINPOINT TEST P»(ref-382389-S24017988252011012300000) .
- Q2 RECHECK THE RFA MODULE DTCs Ignition OFF. Ignition ON. Enter the following diagnostic mode on the scan tool: RFA Module Self-Test. Clear the DTCs. Repeat the RFA Module self-test. Is DTC U3003:62 still present? Yes: Go to Q3 . No: The system is operating correctly at this time. The DTC may have been set due to a previous low battery voltage condition, during battery charging or while jump starting the vehicle.
- Q3 CHECK FOR CHARGING SYSTEM DTCs IN THE PCM Enter the following diagnostic mode on the scan tool: PCM Self-Test. Carry out the PCM KOEO self-test. Retrieve the continuous memory DTCs from the PCM. Is DTC P0562, P0620, P0622, P0625, P0626 or P065B set in the PCM? Yes: Refer to «CHARGING SYSTEM»(ref-382376) . No: Go to Q4 .
- Q4 CHECK FOR DTCs B1317, B1318 B1676, P0563 OR U3003:62 SET IN OTHER MODULES Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC B1317, B1676, P0563 (PCM) or U3003:17 set in more than one module? Yes: Refer to «CHARGING SYSTEM»(ref-382376) to diagnose the charging system condition. No: Go to Q5 .
- Q5 CHECK THE RFA MODULE VOLTAGE PID Ignition ON. Measure and record the voltage at the battery. Enter the following diagnostic mode on the scan tool: RFA Module DataLogger. Monitor the RFA module voltage PID (ECU_VPWR). Is the voltage within .2 volts of the recorded battery voltage? Yes: Refer to «CHARGING SYSTEM»(ref-382376) to diagnose the charging system condition. No: Go to Q6 .
- Q6 CHECK THE RFA MODULE VOLTAGE SUPPLY Ignition OFF. Disconnect: RFA Module C3503a. Ignition ON. Measure the voltage between the RFA module C3503a-1, circuit SBP09 (RD), harness side and ground. Is the voltage within 0.2 volt of the recorded battery voltage? Yes: Go to Q7 . No: REPAIR circuit SBP09 (RD) for high resistance. CLEAR the DTC. REPEAT the self-test.
- Q7 CHECK THE RFA MODULE GROUND CIRCUIT FOR HIGH RESISTANCE Ignition OFF. Disconnect: Negative Battery Cable. Measure the resistance between the RFA module and ground as follows: CONNECTOR-PIN REFERENCE CHART Connector-Pin Circuit C3503a-3 GD145 (BK/BU) C3503d-3 GD145 (BK/BU) C3503d-4 GD145 (BK/BU) Are the resistances less than 5 ohms? Yes: Go to Q8 . No: REPAIR circuit GD145 (BK/BU) for high resistance. CLEAR the DTC. REPEAT the self-test.
- Q8 CHECK FOR CORRECT RFA MODULE OPERATION Disconnect the RFA module connectors. Check for: corrosion damaged pins pushed-out pins Connect the RFA module connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes: INSTALL a new RFA module. Refer to «REMOTE FUNCTION ACTUATOR (RFA) MODULE»(ref-382389-S08787707832011012300000) in this information. TEST the system for normal operation. No: The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.
