Rear View Mirror: Removal & Installation Ford Explorer V

Installation

1. To install, reverse the removal procedure.

Removal

Scheme 64

Scheme 65

1. Position the exterior mirror glass to the full upward and inward position.
2. NOTE: LH mirror and motor removed from the housing and from the back to show location of clips and placement of screwdriver. Remove the exterior mirror glass using a screwdriver to release the tabs starting at the lower outboard side of mirror and continuing around the mirror until all 4 tabs are released.
3. Disconnect the electrical connectors.

Scheme 66

1. NOTE: If required, install the 2 dampners on the LH exterior mirror glass.
2. WARNING: Place a shop towel between the hands and the exterior mirror glass for protection in case of glass breakage during mirror service. Failure to follow this instruction may result in serious personal injury. Connect the electrical connectors.
3. Position the exterior mirror glass onto the exterior mirror motor.
4. NOTE: An audible click will be heard during installation. Firmly press the exterior mirror glass until it snaps onto the exterior mirror motor.
5. Rotate the exterior mirror glass in all directions after the installation to make sure that all of the exterior mirror glass retaining clips are completely fastened.

Scheme 67

1. Remove the exterior mirror glass. REFER to «Exterior Mirror Glass»(ref-517613-S18376651162012121200000) .
2. Remove the 3 exterior mirror motor screws.
3. Disconnect the exterior mirror motor electrical connectors.
4. Remove the exterior mirror motor.

1. To install, reverse the removal procedure.

Scheme 68

Scheme 69

1. Remove the exterior mirror glass. REFER to «Exterior Mirror Glass»(ref-517613-S18376651162012121200000) .
2. Remove the 4 exterior mirror bezel screws and bezel.
3. Press the 4 tabs and remove the exterior mirror cover.

1. To install, reverse the removal procedure.

1. The exterior mirror control switch is integral to window control switch. REFER to «WINDOW CONTROL SWITCH»(ref-517617-S36404010492012121200000) .

1. The exterior mirror control switch is integral to window control switch. REFER to «WINDOW CONTROL SWITCH»(ref-517617-S36404010492012121200000) .
