Rear View Mirror: Component Locations Ford Explorer V

Special Tool(s)

Illustration Name Number TKIT Number Circuit Tester / Test Light SGT27000 - Flex Probe Kit NUD105-R025D

Scheme 70

Scheme 71

Illustration Name Number TKITNumber Remover, Mirror 501-D118 ( 501-D118A )

Scheme 72

Scheme 73

Scheme 74

Scheme 75

1. NOTE: This procedure should be used only for an interior rear view mirror with the top access mount. Otherwise, damage to the windshield glass may occur. NOTE: The windshield must be at room temperature. Otherwise, damage to the windshield glass may occur. Disconnect the electrical connector.
2. Position the interior rear view mirror to the full downward position.
3. If equipped, position aside the interior auto-dimming rear view mirror electrical harness shield.
4. If equipped, remove the rain sensor cover. REFER to «RAIN SENSOR»(ref-517620-S33694652592012121200000) .
5. NOTE: Make sure 501-D118 (501-D118A) is fully inserted into the interior rear view mirror mount access hole. Otherwise, damage to the windshield glass may occur. Insert 501-D118 ( 501-D118A ) between the interior rear view mirror mount and windshield bracket, located at the top of the interior rear view mirror mount.
6. NOTE: Twisting the interior rear view mirror mount from right to left may cause a stress fracture to the windshield. NOTE: Make sure to use the windshield bracket as the pivot point. Otherwise, damage to the windshield will occur. Release the interior rear view mirror mount from the windshield bracket by pulling 501-D118 ( 501-D118A ) downward and away from the windshield.

Scheme 76

1. Slide the interior rear view mirror mount over the windshield bracket from the top.
2. Press the interior rear view mirror mount downward along the windshield bracket until a click is felt. The click indicates that the mirror mount is engaged onto the windshield bracket.
3. If equipped, install the rain sensor cover. REFER to «RAIN SENSOR»(ref-517620-S33694652592012121200000) .
4. If equipped, position back the interior auto-dimming rear view mirror electrical harness shield.
5. Connect the electrical connector.

Illustration Name Number TKITNumber Remover, Mirror 501-D118 ( 501-D118A ) - Installer, Rear Mirror 501-025 (T94P-17700-AH) TKIT-1994-FH TKIT-1994-FMH/FLMH TKIT-1994-LMH/MH

Scheme 77

Scheme 78

Scheme 79

1. NOTE: This procedure should be used only for an interior rear view mirror with the bottom access mount. Otherwise, damage to the windshield glass may occur. NOTE: The windshield must be at room temperature. Otherwise, damage to the windshield glass may occur. Insert 501-D118 ( 501-D118A ) between the interior rear view mirror mount and windshield bracket, located at the bottom of the interior rear view mirror mount.
2. NOTE: Twisting the interior rear view mirror mount from right to left may cause a stress fracture to the windshield. NOTE: Make sure to use the windshield bracket as the pivot point. Otherwise, damage to the windshield will occur. Release the interior rear view mirror mount from the windshield bracket by pulling 501-D118 ( 501-D118A ) away from the windshield.

Scheme 80

Scheme 81

1. Slide the interior rear view mirror mount over the windshield bracket from the top.
2. Using 501-025 (T94P-17700-AH), press the interior rear view mirror mount downward along the windshield bracket until the mirror mount is fully seated onto the windshield mounting button.
