This table contains references to module DTC charts which are related to this system.
| Module | Reference |
|---|---|
| DSM | REFER to DTC CHART: DRIVER SEAT MODULE (DSM) . |
| HVAC Module - DATC | REFER to DTC CHART: HEATING, VENTILATION, AND AIR CONDITIONING (HVAC) MODULE - DATC . |
| HVAC Module - EMTC | REFER to DTC CHART: HEATING VENTILATION AIR CONDITIONING (HVAC) MODULE - EMTC . |
Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices. Refer to DIAGNOSTIC METHODS for information regarding Ford-specific diagnostic practices.
| Condition | Possible Sources | Actions |
|---|---|---|
| The mirrors are inoperative - turn indicator | Fuse Wiring, terminals or connectors Exterior mirror | REFER to DIAGNOSTIC ROUTINE R : One Turn Signal Lamp Is Inoperative Or Always On. |
| The mirrors are inoperative - puddle/approach lamp | Fuse Wiring, terminals or connectors Exterior mirror | REFER to DIAGNOSTIC ROUTINE G : One Or Both Puddle Lamps Are Inoperative. |
| The mirrors are inoperative - BLIS® / CTA indicator always on or always off | Fuse Wiring, terminals or connectors Exterior mirror | REFER to SYMPTOM CHART: SIDE AND REAR VISION . |
| The mirrors are inoperative - non-memory | Fuse Wiring, terminals or connectors Exterior mirror control switch | REFER to Diagnostic Routine A: The Mirrors Are Inoperative - Non-Memory . |
| A single mirror is inoperative - non-memory | Wiring, terminals or connectors Exterior mirror control switch Exterior mirror motor Exterior mirror | REFER to Diagnostic Routine B: A Single Mirror Is Inoperative - Non-Memory . |
| A single mirror does not function with switch logic | Wiring, terminals or connectors Exterior mirror control switch Exterior mirror motor Exterior mirror | REFER to Diagnostic Routine C: A Single Mirror Does Not Function With Switch Logic . |
SYMPTOM CHART
Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices. Refer to DIAGNOSTIC METHODS for information regarding Ford-specific diagnostic practices.
| Condition | Possible Sources | Actions |
|---|---|---|
| The memory mirror is inoperative | Fuse Wiring, terminals or connectors Exterior mirror control switch Exterior mirror motor Exterior mirror DSM | REFER to Diagnostic Routine D: The Memory Mirror Is Inoperative . |
| The memory mirror makes unexpected movements without exterior mirror control switch input | Memory position not set. Memory position changed. | Make sure the memory positions are set. Make sure customer is using the intended IA key. Each IA key is tied to it's own memory position. |
SYMPTOM CHART
Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices. Refer to DIAGNOSTIC METHODS for information regarding Ford-specific diagnostic practices.
| Condition | Possible Sources | Actions |
|---|---|---|
| The heated mirrors are inoperative | Fuse Wirings terminals or connectors Exterior mirror glass HVAC module | REFER to Diagnostic Routine E: The Heated Mirror Is Inoperative . |
SYMPTOM CHART
Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices. Refer to DIAGNOSTIC METHODS for information regarding Ford-specific diagnostic practices.
| Condition | Possible Sources | Actions |
|---|---|---|
| Mirrors fold inward due to wind pressure | Power folding mirrors are not synchronized | SYNCHRONIZE the power folding mirrors. REFER to Mirror Synchronization - Exterior, Power Folding . |
| Mirror structural bracket is damaged | CLEAN the mirror housing and bracket. INSPECT the mirror for structural damage. If necessary, INSTALL a new mirror. REFER to Exterior Mirror . | |
| The power folding mirrors do not operate - do not operate correctly | Wiring terminals or connectors Exterior mirror control switch Power folding exterior mirror Binding or obstructed power folding mirror DSM | REFER to Diagnostic Routine F: The Power Folding Mirrors Do Not Operate Correctly . |
| The power folding mirror motor lockout feature is active | WAIT approximately 3 minutes with the vehicle running or up to 10 minutes with the vehicle off, for the system to reset and for function to return to normal. | |
| Power folding mirror not synchronized | REFER to Mirror Synchronization - Exterior, Power Folding . |
SYMPTOM CHART
Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices. Refer to DIAGNOSTIC METHODS for information regarding Ford-specific diagnostic practices.
| Condition | Possible Sources | Actions |
|---|---|---|
| The interior mirror is blemished | Interior mirror glass/housing is dirty | NOTE: Do not clean the housing or glass of any mirror with harsh abrasives, fuel or other petroleum-based cleaning products. CLEAN the affected interior mirror surface. |
| The interior mirror is damaged | INSPECT the interior mirror for damage. If needed, INSTALL a new interior rear view mirror. REFER to Interior Rear View Mirror - Auto-Dimming . | |
| The auto-dimming mirror does not operate correctly | Fuse Wiring, terminals or connectors Interior rear view mirror | REFER to Diagnostic Routine G: The Auto-Dimming Mirror Does Not Operate Correctly . |
| Obstructed rearward or forward facing sensor Stickers, window decals, tags Non- OEM window tinting | If possible, REMOVE the obstruction. If the obstruction cannot be removed, REFER to Diagnostic Routine G: The Auto-Dimming Mirror Does Not Operate Correctly to test the mirror auto-dimming feature for correct function. | |
| Light source near or inside of vehicle | None. Any light source the rearward-facing sensor is exposed to can be considered glare. | |
| Vehicle inside garage or tunnel | None. Ambient light conditions are similar to nighttime. |
| NOTE |
|---|
| Do not clean the housing or glass of any mirror with harsh abrasives, fuel or other petroleum-based cleaning products. |
SYMPTOM CHART
Symptom Chart: NVH
Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices. Refer to DIAGNOSTIC METHODS for information regarding Ford-specific diagnostic practices.
| Condition | Possible Sources | Actions |
|---|---|---|
| Exterior mirror vibrates/loose | Mirror structural bracket is damaged | CLEAN the mirror housing and bracket. INSPECT the mirror for structural damage. If necessary, INSTALL a new mirror. REFER to Exterior Mirror . |
| Exterior mirror motor screws loose | REMOVE mirror glass and TIGHTEN the 3 exterior mirror motor screws. | |
| Exterior mirror mounting nuts loose | TIGHTEN the exterior mirror mounting nuts. REFER to Torque Specifications . | |
| Exterior mirror glass loose | PRESS the center of the exterior mirror glass up, down, left and right to make sure that the exterior mirror glass is seated correctly. If the exterior mirror glass is still loose, REMOVE the exterior mirror glass and INSPECT the exterior mirror backing plate and motor for damage. If the exterior mirror backing plate is damaged, INSTALL a new exterior mirror glass. REFER to Exterior Mirror Glass . If the motor is damaged, INSTALL a new exterior mirror motor. REFER to Exterior Mirror Motor . For LH mirror only, INSPECT the back of the mirror glass for damaged or missing dampers. If any dampers are missing or damaged, INSTALL a new exterior mirror glass. REFER to Exterior Mirror Glass . | |
| Aftermarket air deflector/stone shields or spotter | If possible, REMOVE the aftermarket air deflector/stone shield, then ROAD TEST the vehicle. If concern is no longer present, ADVISE customer that aftermarket components were causing undesired vibration. | |
| Power folding mirrors are not synchronized (if equipped) | SYNCHRONIZE the power folding mirrors. REFER to Mirror Synchronization - Exterior, Power Folding . | |
| Wind noise | Foam gasket between exterior mirror housing and door is misaligned or damaged | VERIFY the gasket is in good condition. If necessary, REPOSITION the foam gasket between exterior rear view mirror housing and door frame or REPAIR the foam gasket as needed. The foam gasket is not serviceable and if it cannot be REPAIRED, INSTALL a new exterior mirror. REFER to Exterior Mirror . |
| Exterior mirror is not correctly fitted to the door | VERIFY there are no gaps between the exterior mirror and the door. If necessary, LOOSEN the exterior mirror nuts and REPOSITION the exterior mirror. | |
| Exterior mirror cover | VERIFY the exterior mirror cover is not loose or broken. If necessary, INSTALL a new exterior mirror cover. REFER to Exterior Mirror Cover . | |
| The interior mirror vibrates/loose | Interior mirror mounting loose | If the mirror is still on the windshield do not remove . ATTEMPT to fully seat the mirror first. If the mirror is still loose or vibrates, REMOVE and REINSTALL the mirror. REFER to Interior Rear View Mirror - Auto-Dimming . If the condition still exists, INSTALL a new mirror. |
SYMPTOM CHART
Visual Inspection and Diagnostic Pre-checks
- Inspect BCM fuse 48 (30A) (base mirrors).
- Inspect BCM fuse 32 (15A) (heated mirrors).
- Inspect the exterior mirror control switch
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
- CHECK FOR VOLTAGE TO THE EXTERIOR MIRROR CONTROL SWITCH Ignition OFF. Disconnect: Exterior Mirror Control Switch C535B (base mirrors). Disconnect: Exterior Mirror Control Switch C504 (heated mirrors). Ignition ON. For vehicles with base mirrors, measure: Exterior Mirror Control Switch Ground C535B Ground Pin Circuit Measurement / Action Pin Circuit 3 CBP01 (BU) - Ground For vehicles with heated mirrors, measure: Exterior Mirror Control Switch Ground C504 Ground Pin Circuit Measurement / Action Pin Circuit 10 CBP32 (GN/VT) - Ground Is the voltage greater than 11 volts? Yes: GO to 2 . No: VERIFY BCM fuse 48 (30A) (base mirrors) or 32 (15A) (heated mirrors) is OK. If OK, REPAIR the circuit. If not OK, REFER to «OEM FUSE AND RELAY INFORMATION»(ref-485835) and «OEM WIRING DIAGRAMS»(ref-514995) .
- CHECK THE EXTERIOR MIRROR CONTROL SWITCH GROUND CIRCUIT For vehicles with base mirrors, measure: Exterior Mirror Control Switch Ground C535B Ground Pin Circuit Measurement / Action Pin Circuit 1 GD233 (BK) - Ground For vehicles with heated mirrors, measure: Exterior Mirror Control Switch Ground C504 Ground Pin Circuit Measurement / Action Pin Circuit 1 GD233 (BK) - Ground Is the resistance less than 3 ohms? Yes: GO to 3 . No: REPAIR the circuit.
- CHECK THE EXTERIOR MIRROR COMMON CIRCUIT FOR A SHORT TO VOLTAGE Disconnect: LH Exterior Mirror. Disconnect: RH Exterior Mirror. Disconnect: Exterior Mirror Control Switch C535A (base mirrors). Ignition ON. For vehicles with base mirrors, measure: Exterior Mirror Control Switch Ground C535A Ground Pin Circuit Measurement / Action Pin Circuit 4 CPM28 (BU/BN) - Ground For vehicles with heated mirrors, measure: Exterior Mirror Control Switch Ground C504 Ground Pin Circuit Measurement / Action Pin Circuit 4 CPM28 (BU/BN) - Ground Is any voltage present? Yes: REPAIR the circuit. No: GO to 4 .
- CHECK THE EXTERIOR MIRROR COMMON CIRCUIT FOR A SHORT TO GROUND Ignition OFF. For vehicles with base mirrors, measure: Exterior Mirror Control Switch Ground C535A Ground Pin Circuit Measurement / Action Pin Circuit 4 CPM28 (BU/BN) - Ground For vehicles with heated mirrors, measure: Exterior Mirror Control Switch Ground C504 Ground Pin Circuit Measurement / Action Pin Circuit 4 CPM28 (BU/BN) - Ground Is the resistance greater than 10, 000 ohms? Yes: GO to 5 . No: REPAIR the circuit.
- CHECK THE EXTERIOR MIRROR COMMON CIRCUIT FOR AN OPEN For vehicles with base mirrors, measure: Exterior Mirror Control Switch LH Exterior Mirror C535A C516 Pin Circuit Measurement / Action Pin Circuit 4 CPM28 (BU/BN) 2 CPM28 (BU/BN) For vehicles with heated mirrors, measure: Exterior Mirror Control Switch LH Exterior Mirror C504 C516 Pin Circuit Measurement / Action Pin Circuit 4 CPM28 (BU/BN) 2 CPM28 (BU/BN) Is the resistance less than 3 ohms? Yes: INSTALL a new exterior mirror control switch (integral to the master window control switch). REFER to «WINDOW CONTROL SWITCH»(ref-517617-S36404010492012121200000) . No: REPAIR the circuit.
- Inspect the exterior mirror control switch.
- Inspect the exterior mirror.
Scheme 12
Scheme 13
Scheme 14
Scheme 15
Scheme 16
Scheme 17
Scheme 18
Scheme 19
Scheme 20
Scheme 21
Scheme 22
Scheme 23
Scheme 24
- CHECK THE EXTERIOR MIRROR LEFT AND RIGHT MOVEMENT Ignition ON. Operate the LH and RH exterior mirrors in the left and right direction using the exterior mirror control switch. Do both exterior mirrors move left and right? Yes: GO to 2 . No: GO to 7 .
- CHECK THE EXTERIOR MIRROR UP/DOWN MOTOR NOTE: The following step uses a test light to simulate normal circuit loads. Use only the test light recommended in the Special Tools table at the beginning of this information. To avoid connector terminal damage, use the Flex Probe Kit for the test light probe connection to the vehicle. Do not use the test light probe directly on any connector. Refer to «Special Tool(s)»(ref-517613-S26115124192013012300000) . Ignition OFF. Disconnect: Incorrectly Operating RH Exterior Mirror or LH Exterior Mirror. Ignition ON. Select the incorrectly operating mirror on the exterior mirror control switch. For incorrectly operating LH mirror, while using the exterior mirror control switch in the up, down and released positions, monitor: LH Exterior Mirror LH Exterior Mirror C516 C516 Pin Circuit Measurement / Action Pin Circuit 2 CPM28 (BU/BN) Test Light 1 CPM29 (GN) For incorrectly operating RH mirror, while using the exterior mirror control switch in the up, down and released positions, monitor: RH Exterior Mirror RH Exterior Mirror C601 C601 Pin Circuit Measurement / Action Pin Circuit 2 CPM28 (BU/BN) Test Light 1 CPM34 (WH/BN) Did the test light illuminate in the up and down position and not illuminate in the released position? Yes: CHECK the inoperative exterior mirror jumper harness between the vehicle harness and the exterior mirror motor for open circuits and damaged or pushed-out pins. If the jumper harness is not OK, REPAIR the jumper harness. If the jumper harness cannot be repaired, INSTALL a new exterior mirror. REFER to «Exterior Mirror»(ref-517613-S13969929342012121200000) . If the jumper harness is OK, INSTALL a new exterior mirror motor. REFER to «Exterior Mirror Motor»(ref-517613-S31855867162012121200000) . No: GO to 3 .
- CHECK THE EXTERIOR MIRROR UP/DOWN CIRCUIT FOR A SHORT TO VOLTAGE Ignition OFF. Disconnect: Exterior Mirror Control Switch C535A (base mirrors). Disconnect: Exterior Mirror Control Switch C504 (heated mirrors). Ignition ON. For incorrectly operating LH mirror, measure: LH Exterior Mirror Ground C516 Ground Pin Circuit Measurement / Action Pin Circuit 1 CPM29 (GN) - Ground For incorrectly operating RH mirror, measure: RH Exterior Mirror Ground C601 Ground Pin Circuit Measurement / Action Pin Circuit 1 CPM34 (WH/BN) - Ground Is any voltage present? Yes: REPAIR the circuit. No: GO to 4 .
- CHECK THE EXTERIOR MIRROR UP/DOWN CIRCUIT FOR A SHORT TO GROUND Ignition OFF. For incorrectly operating LH mirror, measure: LH Exterior Mirror Ground C516 Ground Pin Circuit Measurement / Action Pin Circuit 1 CPM29 (GN) - Ground For incorrectly operating RH mirror, measure: RH Exterior Mirror Ground C601 Ground Pin Circuit Measurement / Action Pin Circuit 1 CPM34 (WH/BN) - Ground Is the resistance greater than 10, 000 ohms? Yes: For vehicles with base mirrors, GO to 5 . For vehicles with heated mirrors, GO to 6 . No: REPAIR the circuit.
- CHECK THE BASE EXTERIOR MIRROR UP/DOWN CIRCUIT FOR AN OPEN For incorrectly operating LH mirror, measure: LH Exterior Mirror Exterior Mirror Control Switch C516 C535A Pin Circuit Measurement / Action Pin Circuit 1 CPM29 (GN) 6 CPM29 (GN) For incorrectly operating RH mirror, measure: RH Exterior Mirror Exterior Mirror Control Switch C601 C535A Pin Circuit Measurement / Action Pin Circuit 1 CPM34 (WH/BN) 8 CPM34 (WH/BN) Is the resistance less than 3 ohms? Yes: INSTALL a new exterior mirror control switch (integral to the master window control switch). REFER to «WINDOW CONTROL SWITCH»(ref-517617-S36404010492012121200000) . No: REPAIR the circuit.
- CHECK THE HEATED EXTERIOR MIRROR UP/DOWN CIRCUIT FOR AN OPEN For incorrectly operating LH mirror, measure: LH Exterior Mirror Exterior Mirror Control Switch C516 C504 Pin Circuit Measurement / Action Pin Circuit 1 CPM29 (GN) 6 CPM29 (GN) For incorrectly operating RH mirror, measure: RH Exterior Mirror Exterior Mirror Control Switch C601 C504 Pin Circuit Measurement / Action Pin Circuit 1 CPM34 (WH/BN) 8 CPM34 (WH/BN) Is the resistance less than 3 ohms? Yes: INSTALL a new exterior mirror control switch (integral to the master window control switch). REFER to «WINDOW CONTROL SWITCH»(ref-517617-S36404010492012121200000) . No: REPAIR the circuit.
- CHECK THE EXTERIOR MIRROR LEFT/RIGHT MOTOR NOTE: The following step uses a test light to simulate normal circuit loads. Use only the test light recommended in the Special Tools table at the beginning of this information. To avoid connector terminal damage, use the Flex Probe Kit for the test light probe connection to the vehicle. Do not use the test light probe directly on any connector. Refer to «Special Tool(s)»(ref-517613-S26115124192013012300000) . Ignition OFF. Disconnect: Incorrectly Operating RH Exterior Mirror or LH Exterior Mirror. Ignition ON. Select the incorrectly operating mirror on the exterior mirror control switch. For incorrectly operating LH mirror, while using the exterior mirror control switch in the right, left and released positions, monitor: LH Exterior Mirror LH Exterior Mirror C516 C516 Pin Circuit Measurement / Action Pin Circuit 2 CPM28 (BU/BN) Test Light 4 CPM26 (WH) For incorrectly operating RH mirror, while using the exterior mirror control switch in the right, left and released positions, monitor: RH Exterior Mirror RH Exterior Mirror C601 C601 Pin Circuit Measurement / Action Pin Circuit 2 CPM28 (BU/BN) Test Light 4 CPM31 (YE/GY) Did the test light illuminate in the right and left position and not illuminate in the released position? Yes: CHECK the inoperative exterior mirror jumper harness between the vehicle harness and the exterior mirror motor for open circuits and damaged or pushed-out pins. If the jumper harness is not OK, REPAIR the jumper harness. If the jumper harness cannot be repaired, INSTALL a new exterior mirror. REFER to «Exterior Mirror»(ref-517613-S13969929342012121200000) . If the jumper harness is OK, INSTALL a new exterior mirror motor. REFER to «Exterior Mirror Motor»(ref-517613-S31855867162012121200000) . No: GO to 8 .
- CHECK THE EXTERIOR MIRROR LEFT/RIGHT CIRCUIT FOR A SHORT TO VOLTAGE Ignition OFF. Disconnect: Exterior Mirror Control Switch C535A (base mirrors). Disconnect: Exterior Mirror Control Switch C504 (heated mirrors). Ignition ON. For incorrectly operating LH mirror, measure: LH Exterior Mirror Ground C516 Ground Pin Circuit Measurement / Action Pin Circuit 4 CPM26 (WH) - Ground For incorrectly operating RH mirror, measure: RH Exterior Mirror Ground C601 Ground Pin Circuit Measurement / Action Pin Circuit 4 CPM31 (YE/GY) - Ground Is any voltage present? Yes: REPAIR the circuit. No: GO to 9 .
- CHECK THE EXTERIOR MIRROR LEFT/RIGHT CIRCUIT FOR A SHORT TO GROUND Ignition OFF. For incorrectly operating LH mirror, measure: LH Exterior Mirror Ground C516 Ground Pin Circuit Measurement / Action Pin Circuit 4 CPM26 (WH) - Ground For incorrectly operating RH mirror, measure: RH Exterior Mirror Ground C601 Ground Pin Circuit Measurement / Action Pin Circuit 4 CPM31 (YE/GY) - Ground Is the resistance greater than 10, 000 ohms? Yes: For vehicles with base mirrors, GO to 10 . For vehicles with heated mirrors, GO to 11 . No: REPAIR the circuit.
- CHECK THE BASE EXTERIOR MIRROR LEFT/RIGHT CIRCUIT FOR AN OPEN For incorrectly operating LH mirror, measure: LH Exterior Mirror Exterior Mirror Control Switch C516 C535A Pin Circuit Measurement / Action Pin Circuit 4 CPM26 (WH) 5 CPM26 (WH) For incorrectly operating RH mirror, measure: RH Exterior Mirror Exterior Mirror Control Switch C601 C535A Pin Circuit Measurement / Action Pin Circuit 4 CPM31 (YE/GY) 7 CPM31 (YE/GY) Is the resistance less than 3 ohms? Yes: INSTALL a new exterior mirror control switch (integral to the master window control switch). REFER to «WINDOW CONTROL SWITCH»(ref-517617-S36404010492012121200000) . No: REPAIR the circuit.
- CHECK THE HEATED EXTERIOR MIRROR LEFT/RIGHT CIRCUIT FOR AN OPEN For incorrectly operating LH mirror, measure: LH Exterior Mirror Exterior Mirror Control Switch C516 C504 Pin Circuit Measurement / Action Pin Circuit 4 CPM26 (WH) 5 CPM26 (WH) For incorrectly operating RH mirror, measure: RH Exterior Mirror Exterior Mirror Control Switch C601 C504 Pin Circuit Measurement / Action Pin Circuit 4 CPM31 (YE/GY) 7 CPM31 (YE/GY) Is the resistance less than 3 ohms? Yes: INSTALL a new exterior mirror control switch (integral to the master window control switch). REFER to «WINDOW CONTROL SWITCH»(ref-517617-S36404010492012121200000) . No: REPAIR the circuit.
- Inspect BCM fuses 7 (7.5A), 23 (30A) and 32 (15A).
- Inspect the exterior mirror control switch.
- Inspect the exterior mirror.
Scheme 25
Scheme 26
Scheme 27
Scheme 28
Scheme 29
Scheme 30
Scheme 31
Scheme 32
Scheme 33
Scheme 34
Scheme 35
Scheme 36
Scheme 37
Scheme 38
Scheme 39
Scheme 40
Scheme 41
Scheme 42
Scheme 43
- RETRIEVE THE DTCs FROM THE DSM Ignition ON. Using a scan tool, perform DSM self-test. Are any DTCs retrieved? Yes: If DTC B1667 or B1668 is present with other DTCs , DIAGNOSE the other DTCs first. If DTC B1667 or B1668 is present without other DTCs , INSPECT the LH exterior mirror motor for foreign material, damage or a binding condition. If no condition is found, GO to 10 . If DTC B1669 or B1670 is present with other DTCs , DIAGNOSE the other DTCs first. If DTC B1669 or B1670 is present without other DTCs , INSPECT the RH exterior mirror motor for foreign material, damage or a binding condition. If no condition is found, GO to 12 . For DTCs B1733, B1737, B1741 or B1745, GO to 14 . For DTC B2223, GO to 17 . For DTC B2224, GO to 19 . For DTCs B2312, B2316, B2320 or B2324, GO to 21 . For DTCs B2314, B2318, B2322 or B2326, GO to 24 . For all other DSM DTCs , REFER to «DTC CHART: DRIVER SEAT MODULE (DSM)»(ref-517614-S22354534442012121200000) . No: GO to 2 .
- CHECK OPERATION OF THE MIRRORS FROM THE EXTERIOR MIRROR CONTROL SWITCH Operate the mirrors using the exterior mirror control switch. Does the LH or RH mirror operate using the exterior mirror control switch? Yes: If the LH or RH exterior mirror operates correctly in at least one direction, GO to 9 . No: If both the LH and RH exterior mirrors are inoperative, GO to 3 .
- CHECK THE EXTERIOR MIRROR CONTROL SWITCH NOTE: The following step uses a test light to simulate normal circuit loads. Use only the test light recommended in the Special Tools table at the beginning of this information. To avoid connector terminal damage, use the Flex Probe Kit for the test light probe connection to the vehicle. Do not use the test light probe directly on any connector. Refer to «Special Tool(s)»(ref-517613-S26115124192013012300000) . Ignition OFF. Disconnect: DSM C341D. Select the LH mirror on the exterior mirror control switch. Ignition ON. While selecting the right direction on the exterior mirror control switch, monitor: DSM DSM C341D C341D Pin Circuit Measurement / Action Pin Circuit 20 CPM16 (BN/BU) Test Light 16 RPM11 (YE/OG) Did the light illuminate? Yes: GO to 26 . No: GO to 4 .
- CHECK FOR VOLTAGE TO THE EXTERIOR MIRROR CONTROL SWITCH Measure: Exterior Mirror Control Switch Ground C504 Ground Pin Circuit Measurement / Action Pin Circuit 10 CBP32 (GN/VT) - Ground Is the voltage greater than 11 volts? Yes: GO to 5 . No: VERIFY that BCM fuse 32 (15A) is OK. If OK, REPAIR the circuit. If not OK, REFER to «OEM FUSE AND RELAY INFORMATION»(ref-485835) and «OEM WIRING DIAGRAMS»(ref-514995) .
- CHECK FOR GROUND TO THE EXTERIOR MIRROR CONTROL SWITCH Ignition OFF. Measure: Exterior Mirror Control Switch Ground C504 Ground Pin Circuit Measurement / Action Pin Circuit 1 GD233 (BK) - Ground Is the resistance less than 3 ohms? Yes: GO to 6 . No: REPAIR the circuit.
- CHECK THE MIRROR SWITCH COMMON CIRCUIT FOR A SHORT TO VOLTAGE Ignition ON. Measure: Exterior Mirror Control Switch Ground C504 Ground Pin Circuit Measurement / Action Pin Circuit 4 RPM11 (YE/OG) - Ground Is any voltage present? Yes: REPAIR the circuit. No: GO to 7 .
- CHECK THE MIRROR SWITCH COMMON CIRCUIT FOR A SHORT TO GROUND Ignition OFF. Measure: Exterior Mirror Control Switch Ground C504 Ground Pin Circuit Measurement / Action Pin Circuit 4 RPM11 (YE/OG) - Ground Is the resistance greater than 10, 000 ohms? Yes: GO to 8 . No: REPAIR the circuit.
- CHECK THE MIRROR SWITCH COMMON CIRCUIT FOR AN OPEN Measure: Exterior Mirror Control Switch DSM C504 C341D Pin Circuit Measurement / Action Pin Circuit 4 RPM11 (YE/OG) 16 RPM11 (YE/OG) Is the resistance less than 3 ohms? Yes: GO to 26 . No: REPAIR the circuit.
- CHECK THE EXTERIOR MIRROR SWITCH CIRCUITS FOR AN OPEN Ignition OFF. Disconnect: Exterior Mirror Control Switch. Disconnect: DSM C341D. Measure: Exterior Mirror Control Switch DSM C504 C341D Pin Circuit Measurement / Action Pin Circuit 8 CPM21 (YE/VT) 17 CPM21 (YE/VT) 6 CPM17 (BU/WH) 19 CPM17 (BU/GN) 7 CPM20 (BN/WH) 18 CPM20 (BN/WH) 5 CPM16 (BN/BU) 20 CPM16 (BN/BU) Are the resistances less than 3 ohms? Yes: GO to 26 . No: REPAIR the affected circuit.
- CHECK THE LH EXTERIOR MIRROR FOR VOLTAGE WHILE COMMANDING THE DSM PIDs Ignition OFF. Disconnect: LH Exterior Mirror. Ignition ON. Using a scan tool, view DSM PIDs . If only DTC B1667 is set, while toggling the DSM PID Driver's Mirror Up (DR_UP) to On, measure: LH Exterior Mirror Ground C516 Ground Pin Circuit Measurement / Action Pin Circuit 1 CPM29 (GN) - Ground If only DTC B1668 is set, while toggling the DSM PID Driver's Mirror Right (DR_RIGHT) to On, measure: LH Exterior Mirror Ground C516 Ground Pin Circuit Measurement / Action Pin Circuit 4 CPM28 (BU/BN) - Ground If both DTCs B1667 and B1668 are set, while toggling the DSM PID Driver's Mirror Down (DR_DOWN) to On, measure: LH Exterior Mirror Ground C516 Ground Pin Circuit Measurement / Action Pin Circuit 2 CPM26 (WH) - Ground Does the voltage momentarily change from 0 volts to greater than 11 volts when the active command is toggled ON? Yes: CHECK the LH exterior mirror jumper harness between the vehicle harness and the exterior mirror motors for open circuits and damaged or pushed-out pins. If the jumper harness is not OK, REPAIR the jumper harness. If the jumper harness cannot be repaired, INSTALL a new LH exterior mirror. REFER to «Exterior Mirror»(ref-517613-S13969929342012121200000) . If the jumper harness is OK, INSTALL a new LH exterior mirror motor. REFER to «Exterior Mirror Motor»(ref-517613-S31855867162012121200000) . No: GO to 11 .
- CHECK THE LH EXTERIOR MIRROR CONTROL OUTPUT CIRCUITS FOR AN OPEN Ignition OFF. Disconnect: DSM C341D. If only DTC B1667 is set, measure: LH Exterior Mirror DSM C516 C341D Pin Circuit Measurement / Action Pin Circuit 1 CPM29 (GN) 4 CPM29 (GN) If only DTC B1668 is set, measure: LH Exterior Mirror DSM C516 C341D Pin Circuit Measurement / Action Pin Circuit 4 CPM28 (BU/BN) 5 CPM28 (BU/BN) If both DTCs B1667 and B1668 are set, measure: LH Exterior Mirror DSM C516 C341D Pin Circuit Measurement / Action Pin Circuit 2 CPM26 (WH) 2 CPM26 (WH) Is the resistance less than 3 ohms? Yes: GO to 26 . No: REPAIR the circuit.
- CHECK THE RH EXTERIOR MIRROR FOR VOLTAGE WHILE COMMANDING THE DSM PIDs Ignition OFF. Disconnect: RH Exterior Mirror. Ignition ON. Using a scan tool, view DSM PIDs . If only DTC B1669 is set, while toggling the DSM PID Passenger's Mirror Up (PR_UP) to On, measure: RH Exterior Mirror Ground C601 Ground Pin Circuit Measurement / Action Pin Circuit 1 CPM34 (WH/BN) - Ground If only DTC B1670 is set, while toggling the DSM PID Passenger's Mirror Right (PR_RIGHT) to On, measure: RH Exterior Mirror Ground C601 Ground Pin Circuit Measurement / Action Pin Circuit 4 CPM33 (WH/VT) - Ground If both DTCs B1669 and B1670 are set, while toggling the DSM PID Passenger's Mirror Left (PR_LEFT) to On, measure: RH Exterior Mirror Ground Ground C601 Pin Circuit Measurement / Action Pin Circuit 2 CPM31 (YE/GY) - Ground Does the voltage momentarily change from 0 volts to greater than 11 volts when the active command is toggled ON? Yes: CHECK the RH exterior mirror jumper harness between the vehicle harness and the exterior mirror motors for open circuits and damaged or pushed-out pins. If the jumper harness is not OK, REPAIR the jumper harness. If the jumper harness cannot be repaired, INSTALL a new RH exterior mirror. REFER to «Exterior Mirror»(ref-517613-S13969929342012121200000) . If the jumper harness is OK, INSTALL a new exterior mirror motor. REFER to «Exterior Mirror Motor»(ref-517613-S31855867162012121200000) . No: GO to 13 .
- CHECK THE RH EXTERIOR MIRROR CONTROL OUTPUT CIRCUITS FOR AN OPEN Ignition OFF. Disconnect: DSM C341D. If only DTC B1669 is set, measure: RH Exterior Mirror DSM C601 C341D Pin Circuit Measurement / Action Pin Circuit 1 CPM34 (WH/BN) 7 CPM34 (WH/BN) If only DTC B1670 is set, measure: RH Exterior Mirror DSM C601 C341D Pin Circuit Measurement / Action Pin Circuit 4 CPM33 (WH/VT) 6 CPM33 (WH/VT) If both DTCs B1669 and B1670 are set, measure: RH Exterior Mirror DSM C601 C341D Pin Circuit Measurement / Action Pin Circuit 2 CPM31 (YE/GY) 8 CPM31 (YE/GY) Is the resistance less than 3 ohms? Yes: GO to 26 . No: REPAIR the circuit.
- CHECK THE EXTERIOR MIRROR CONTROL SWITCH Ignition OFF. Disconnect: Exterior Mirror Control Switch. Ignition ON. Using a scan tool, clear the DTCs and perform DSM self-test. Did DSM DTC B1733, B1737, B1741 or B1745 return? Yes: GO to 15 . No: INSTALL a new exterior mirror control switch (integral to the master window control switch). REFER to «WINDOW CONTROL SWITCH»(ref-517617-S36404010492012121200000) .
- CHECK THE MIRROR CONTROL CIRCUITS FOR A SHORT TO VOLTAGE Ignition OFF. Disconnect: DSM C341D. Ignition ON. Measure: Exterior Mirror Control Switch Ground C504 Ground Pin Circuit Measurement / Action Pin Circuit 6 CPM17 (BU/WH) (B1733) - Ground 5 CPM16 (BN/BU) (B1737) - Ground 8 CPM21 (YE/VT) (B1741) - Ground 7 CPM20 (BN/WH) (B1745) - Ground Is any voltage present? Yes: REPAIR the circuit. No: GO to 16 .
- CHECK THE EXTERIOR MIRROR SWITCH CIRCUITS FOR A SHORT TO GROUND Ignition OFF. Measure: Exterior Mirror Control Switch Ground C504 Ground Pin Circuit Measurement / Action Pin Circuit 6 CPM17 (BU/WH) (B1733) - Ground 5 CPM16 (BN/BU) (B1737) - Ground 8 CPM21 (YE/VT) (B1741) - Ground 7 CPM20 (BN/WH) (B1745) - Ground Is the resistance greater than 10, 000 ohms? Yes: GO to 26 . No: REPAIR the circuit.
- CHECK THE LH EXTERIOR MIRROR CONTROL OUTPUT CIRCUITS FOR A SHORT TO VOLTAGE Ignition OFF. Disconnect: LH Exterior Mirror. Disconnect: DSM C341D. Ignition ON. Measure: LH Exterior Mirror Ground C516 Ground Pin Circuit Measurement / Action Pin Circuit 1 CPM29 (GN) - Ground 2 CPM26 (WH) - Ground 4 CPM28 (BU/BN) - Ground Are any voltages present? Yes: REPAIR the affected circuit. No: GO to 18 .
- CHECK THE LH EXTERIOR MIRROR CONTROL OUTPUT CIRCUITS FOR A SHORT TO GROUND Ignition OFF. Measure: LH Exterior Mirror Ground C516 Ground Pin Circuit Measurement / Action Pin Circuit 1 CPM29 (GN) - Ground 2 CPM26 (WH) - Ground 4 CPM28 (BU/BN) - Ground Are the resistances greater than 10, 000 ohms? Yes: GO to 25 . No: REPAIR the affected circuit.
- CHECK THE RH EXTERIOR MIRROR CONTROL OUTPUT CIRCUITS FOR A SHORT TO VOLTAGE Ignition OFF. Disconnect: RH Exterior Mirror. Disconnect: DSM C341D. Ignition ON. Measure: RH Exterior Mirror Ground C601 Ground Pin Circuit Measurement / Action Pin Circuit 1 CPM34 (WH/BN) - Ground 2 CPM31 (YE/GY) - Ground 4 CPM33 (WH/VT) - Ground Are any voltages present? Yes: REPAIR the affected circuit. No: GO to 20 .
- CHECK THE RH EXTERIOR MIRROR CONTROL OUTPUT CIRCUITS FOR A SHORT TO GROUND Ignition OFF. Measure: RH Exterior Mirror Ground C601 Ground Pin Circuit Measurement / Action Pin Circuit 1 CPM34 (WH/BN) - Ground 2 CPM31 (YE/GY) - Ground 4 CPM33 (WH/VT) - Ground Are the resistances greater than 10, 000 ohms? Yes: GO to 25 . No: REPAIR the affected circuit.
- CHECK THE MIRROR POSITION SENSOR CIRCUITS FOR A SHORT TO GROUND Ignition OFF. Disconnect: DSM C341D. Disconnect: RH Exterior Mirror. Disconnect: LH Exterior Mirror. For DTC B2312 or B2316, measure: DSM Ground C341D Ground Pin Circuit Measurement / Action Pin Circuit 1 LPM30 (GY/VT) - Ground 11 RPM30 (YE) - Ground 14 VPM38 (BN/GN) - Ground 15 VPM37 (BU/OG) - Ground For DTC B2320 or B2324, measure: DSM Ground C341D Ground Pin Circuit Measurement / Action Pin Circuit 1 LPM30 (GY/VT) - Ground 11 RPM30 (YE) - Ground 12 VPM36 (BN/YE) - Ground 13 VPM35 (YE/BU) - Ground Are the resistances greater than 10, 000 ohms? Yes: GO to 22 . No: REPAIR the affected circuit.
- CHECK THE MIRROR POSITION SENSOR CIRCUITS FOR AN OPEN For DTC B2312 or B2316, measure: RH Exterior Mirror DSM C601 C341D Pin Circuit Measurement / Action Pin Circuit 9 VPM38 (BN/GN) 14 VPM38 (BN/GN) 10 LPM30 (GY/VT) 1 LPM30 (GY/VT) 11 VPM37 (BU/OG) 15 VPM37 (BU/OG) 12 RPM30 (YE) 11 RPM30 (YE) For DTC B2320 or B2324, measure: LH Exterior Mirror DSM C516 C341D Pin Circuit Measurement / Action Pin Circuit 9 VPM36 (BN/YE) 12 VPM36 (BN/YE) 10 LPM30 (GY/VT) 1 LPM30 (GY/VT) 12 RPM30 (YE) 11 RPM30 (YE) 11 VPM35 (YE/BU) 13 VPM35 (YE/BU) Are the resistances less than 3 ohms? Yes: GO to 23 . No: REPAIR the affected circuit.
- CHECK THE MIRROR POSITION SENSOR FEED AND RETURN FROM THE DSM Connect: DSM C341D. Ignition ON. For DTC B2312 or B2316, measure: RH Exterior Mirror RH Exterior Mirror C601 C601 Pin Circuit Measurement / Action Pin Circuit 10 LPM30 (GY/VT) 12 RPM30 (YE) For DTC B2320 or B2324, measure: LH Exterior Mirror LH Exterior Mirror C516 C516 Pin Circuit Measurement / Action Pin Circuit 10 LPM30 (GY/VT) 12 RPM30 (YE) Is the voltage approximately 5 volts? Yes: For DTC B2312 or B2316, CHECK the RH exterior mirror jumper harness between the vehicle harness and the exterior mirror motors for open or shorted circuits and damaged or pushed-out pins. For DTC B2320 or B2324, CHECK the LH exterior mirror jumper harness between the vehicle harness and the exterior mirror motors for open or shorted circuits and damaged or pushed-out pins. If the jumper harness is not OK, REPAIR the jumper harness. If the jumper harness cannot be repaired, INSTALL a new exterior mirror. REFER to «Exterior Mirror»(ref-517613-S13969929342012121200000) . If the jumper harness is OK, INSTALL a new exterior mirror motor. REFER to «Exterior Mirror Motor»(ref-517613-S31855867162012121200000) . No: GO to 26 .
- CHECK THE EXTERIOR MIRROR POSITION SENSOR CIRCUITS FOR A SHORT TO VOLTAGE Ignition OFF. Disconnect: DSM C341D. Disconnect: RH Exterior Mirror. Disconnect: LH Exterior Mirror. Ignition ON. For DTC B2314 or B2318, measure: RH Exterior Mirror Ground C601 Ground Pin Circuit Measurement / Action Pin Circuit 9 VPM38 (BN/GN) - Ground 10 LPM30 (GY/VT) - Ground 11 VPM37 (BU/OG) - Ground 12 RPM30 (YE) - Ground For DTC B2322 or B2326, measure: LH Exterior Mirror Ground C516 Ground Pin Circuit Measurement / Action Pin Circuit 9 VPM36 (BN/YE) - Ground 10 LPM30 (GY/VT) - Ground 11 VPM35 (YE/BU) - Ground 12 RPM30 (YE) - Ground Are any voltages present? Yes: REPAIR the affected circuit. No: For DTC B2314 or B2318, CHECK the RH exterior mirror jumper harness between the vehicle harness and the exterior mirror motors for open or shorted circuits and damaged or pushed-out pins. For DTC B2322 or B2326, CHECK the LH exterior mirror jumper harness between the vehicle harness and the exterior mirror motors for open or shorted circuits and damaged or pushed-out pins. If the jumper harness is not OK, REPAIR the jumper harness. If the jumper harness cannot be repaired, INSTALL a new exterior mirror. REFER to «Exterior Mirror»(ref-517613-S13969929342012121200000) . If the jumper harness is OK, INSTALL a new exterior mirror motor. REFER to «Exterior Mirror Motor»(ref-517613-S31855867162012121200000) .
- CHECK THE EXTERIOR MIRROR Ignition OFF. Connect: DSM C341D. Ignition ON. Using a scan tool, clear the DTCs and perform DSM self-test. Did DSM DTC B2223 or B2224 return? Yes: GO to 26 . No: CHECK the LH or RH exterior mirror jumper harness between the vehicle harness and the exterior mirror motors for shorted circuits or damaged and pushed-out pins. If the jumper harness is not OK, REPAIR the jumper harness. If the jumper harness cannot be repaired, INSTALL a new exterior mirror. REFER to «Exterior Mirror»(ref-517613-S13969929342012121200000) . If the jumper harness is OK, INSTALL a new exterior mirror motor. REFER to «Exterior Mirror Motor»(ref-517613-S31855867162012121200000) .
- CHECK THE DSM FOR CORRECT OPERATION Ignition OFF. Disconnect and inspect all DSM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the DSM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable TSBs . If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no TSBs address this concern, INSTALL a new DSM. REFER to «DRIVER SEAT MODULE (DSM)»(ref-517614-S41646412882012121200000) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.
- Inspect BJB fuse 50 (15A).
- Inspect the exterior mirror glass.
- Inspect the exterior mirror.
Scheme 44
Scheme 45
Scheme 46
- CHECK THE OPERATION OF THE REAR WINDOW DEFROST SYSTEM With the engine running, activate the rear window defrost. Using an infrared temperature gun or equivalent, measure the temperature of the rear window glass for approximately 30 seconds, noting changes in temperature. Does the temperature of the rear window glass rise? Yes: GO to 2 . No: REFER to «SYMPTOM CHART: GLASS, FRAMES AND MECHANISMS»(ref-517617-S10632931292012121200000) and diagnose the rear window defrost system.
- CHECK THE OPERATION OF THE HEATED EXTERIOR REAR VIEW MIRRORS With the rear window defrost activated, using an infrared temperature gun or equivalent, measure the temperature of the RH and LH exterior rear view mirror glass for approximately 30 seconds, noting changes in temperature. Does at least one heated mirror glass operate correctly? Yes: GO to 4 . No: VERIFY that BJB fuse 50 (15A) is OK. If OK, GO to 3 . If not OK, REFER to the appropriate wiring diagrams to identify the possible causes of the circuit short. REFER to «OEM FUSE AND RELAY INFORMATION»(ref-485835) and «OEM WIRING DIAGRAMS»(ref-514995) .
- CHECK FOR VOLTAGE TO BJB FUSE 50 (15A) Verify BJB fuse 50 (15A) is installed. Ignition ON. With the engine running, activate the rear window defrost. Measure: BJB Ground Fuse Ground Fuse Circuit Measurement / Action Pin Circuit 50 (15A) CRD06 (BN/YE) - Ground Is the voltage greater than 11 volts? Yes: REPAIR circuit CRD17 (GY). No: REPAIR circuit CRD06 (BN/YE).
- CHECK THE VOLTAGE TO THE INOPERATIVE HEATED EXTERIOR REAR VIEW MIRROR GLASS Ignition OFF. Disconnect: Inoperative LH or RH Heated Exterior Mirror. Ignition ON. With the engine running, activate the rear window defrost. For inoperative LH heated mirror, measure: LH Exterior Mirror Ground C516 Ground Pin Circuit Measurement / Action Pin Circuit 6 CRD17 (GY) - Ground For inoperative RH heated mirror, measure: RH Exterior Mirror Ground C601 Ground Pin Circuit Measurement / Action Pin Circuit 6 CRD17 (GY) - Ground Is the voltage greater than 11 volts? Yes: GO to 5 . No: REPAIR the circuit.
- CHECK THE INOPERATIVE EXTERIOR REAR VIEW MIRROR GROUND CIRCUIT FOR AN OPEN Ignition OFF. For inoperative LH heated mirror, measure: LH Exterior Mirror Ground C516 Ground Pin Circuit Measurement / Action Pin Circuit 8 GD233 (BK) - Ground For inoperative RH heated mirror, measure: RH Exterior Mirror Ground C601 Ground Pin Circuit Measurement / Action Pin Circuit 8 GD348 (BK/YE) - Ground Is the resistance less than 3 ohms? Yes: CHECK the LH or RH exterior mirror jumper harness between the vehicle harness and the exterior mirror motors for shorted circuits and damaged or pushed-out pins. If the jumper harness is not OK, REPAIR the jumper harness. If the jumper harness cannot be repaired, INSTALL a new LH or RH exterior mirror. REFER to «Exterior Mirror»(ref-517613-S13969929342012121200000) . If the jumper harness is OK, INSTALL a new exterior mirror glass. REFER to «Exterior Mirror Glass»(ref-517613-S18376651162012121200000) . No: REPAIR the circuit.
- Inspect the power folding mirror control switch.
- Inspect the power folding exterior mirror.
- Inspect for a binding or obstructed mirror.
- Power folding mirror not synchronized.
Scheme 47
Scheme 48
Scheme 49
Scheme 50
Scheme 51
Scheme 52
Scheme 53
Scheme 54
Scheme 55
Scheme 56
Scheme 57
Scheme 58
Scheme 59
- CHECK FOR DTCs FROM THE DSM Ignition ON. Using a scan tool, perform DSM self-test. Are any DTCs retrieved? Yes: If DTC B112B is present, GO to 4 . For all other DSM DTCs , REFER to «DTC CHART: DRIVER SEAT MODULE (DSM)»(ref-517614-S22354534442012121200000) . No: GO to 2 .
- CHECK THE OPERATION OF THE POWER FOLDING MIRRORS Position the exterior mirror control switch to the center position. Press the exterior mirror control switch rearward towards the FOLD/UNFOLD position to activate the power folding mirrors. Does either the LH or RH power folding mirror operate? Yes: GO to 10 . No: GO to 3 .
- CHECK THE EXTERIOR MIRROR CONTROL SWITCH NOTE: The following step uses a test light to simulate normal circuit loads. Use only the test light recommended in the Special Tools table at the beginning of this information. To avoid connector terminal damage, use the Flex Probe Kit for the test light probe connection to the vehicle. Do not use the test light probe directly on any connector. Refer to «Special Tool(s)»(ref-517613-S26115124192013012300000) . Ignition OFF. Disconnect: DSM C341C. Ignition ON. While pressing and releasing the power folding mirror button, monitor: DSM Ground C341C Ground Pin Circuit Measurement / Action Pin Circuit 21 CPP09 (VT/OG) Test Light - Ground Did the test light illuminate when the button is pressed and not illuminate when the button is released? Yes: GO to 7 . No: If the test light was always illuminated, GO to 4 . If the test light was never illuminated, GO to 5 .
- CHECK THE FOLDING MOTOR CONTROL CIRCUIT FOR A SHORT TO VOLTAGE Ignition OFF. Disconnect: DSM C341C. Ignition ON. Measure: DSM Ground C341C Ground Pin Circuit Measurement / Action Pin Circuit 21 CPP09 (VT/OG) - Ground Is any voltage present? Yes: GO to 12 . No: GO to 13 .
- CHECK THE FOLDING MOTOR CONTROL CIRCUIT FOR A SHORT TO GROUND Ignition OFF. Disconnect: Master Window Control Switch. Measure: DSM Ground C341C Ground Pin Circuit Measurement / Action Pin Circuit 21 CPP09 (VT/OG) - Ground Is the resistance greater than 10, 000 ohms? Yes: GO to 6 . No: REPAIR the circuit. SYNCHRONIZE the power folding mirrors. REFER to «Mirror Synchronization - Exterior, Power Folding»(ref-517613-S09176829362012121200000) .
- CHECK THE FOLDING MOTOR CONTROL CIRCUIT FOR AN OPEN Measure: DSM Exterior Mirror Control Switch C341C C504 Pin Circuit Measurement / Action Pin Circuit 21 CPP09 (VT/OG) 19 CPM22 (GY/BN) Is the resistance less than 3 ohms? Yes: INSTALL a new exterior mirror control switch (integral to the master window control switch). REFER to «WINDOW CONTROL SWITCH»(ref-517617-S36404010492012121200000) . SYNCHRONIZE the power folding mirrors. REFER to «Mirror Synchronization - Exterior, Power Folding»(ref-517613-S09176829362012121200000) . No: REPAIR the circuit. SYNCHRONIZE the power folding mirrors. REFER to «Mirror Synchronization - Exterior, Power Folding»(ref-517613-S09176829362012121200000) .
- CHECK THE FOLDING MIRROR OUTPUT CIRCUITS FOR A SHORT TO VOLTAGE Ignition OFF. Disconnect: LH and RH Exterior Mirror. Ignition ON. Measure: DSM Ground C341C Ground Pin Circuit Measurement / Action Pin Circuit 1 CPM39 (GN/VT) - Ground 2 CPM04 (VT/BN) - Ground Are any voltages present? Yes: REPAIR the affected circuit(s). SYNCHRONIZE the power folding mirrors. REFER to «Mirror Synchronization - Exterior, Power Folding»(ref-517613-S09176829362012121200000) . No: GO to 8 .
- CHECK THE FOLDING MIRROR OUTPUT CIRCUITS FOR A SHORT TO GROUND Ignition OFF. Measure: DSM Ground C341C Ground Pin Circuit Measurement / Action Pin Circuit 1 CPM39 (GN/VT) - Ground 2 CPM04 (VT/BN) - Ground Are the resistances greater than 10, 000 ohms? Yes: GO to 9 . No: REPAIR the affected circuit(s). SYNCHRONIZE the power folding mirrors. REFER to «Mirror Synchronization - Exterior, Power Folding»(ref-517613-S09176829362012121200000) .
- CHECK THE FOLDING MIRROR OUTPUT CIRCUITS FOR AN OPEN For incorrectly folding LH mirror, measure: DSM LH Exterior Mirror C341C C516 Pin Circuit Measurement / Action Pin Circuit 1 CPM39 (GN/VT) 16 CPM01 (YE/GN) 2 CPM04 (VT/BN) 14 CPM02 (BU) For incorrectly folding RH mirror, measure: DSM RH Exterior Mirror C341C C601 Pin Circuit Measurement / Action Pin Circuit 1 CPM39 (GN/VT) 16 CPM01 (YE/GN) 2 CPM04 (VT/BN) 14 CPM02 (BU) Are the resistances less than 3 ohms? Yes: GO to 13 . No: REPAIR the affected circuit(s). SYNCHRONIZE the power folding mirrors. REFER to «Mirror Synchronization - Exterior, Power Folding»(ref-517613-S09176829362012121200000) .
- CHECK THE EXTERIOR MIRROR NOTE: The following step uses a test light to simulate normal circuit loads. Use only the test light recommended in the Special Tools table at the beginning of this information. To avoid connector terminal damage, use the Flex Probe Kit for the test light probe connection to the vehicle. Do not use the test light probe directly on any connector. Refer to «Special Tool(s)»(ref-517613-S26115124192013012300000) . Ignition OFF. Disconnect: Incorrectly folding RH or LH Exterior Mirror. Ignition ON. For incorrectly folding LH mirror, while pressing and releasing the power folding mirror button, monitor: LH Exterior Mirror LH Exterior Mirror C516 C516 Pin Circuit Measurement / Action Pin Circuit 14 CPM02 (BU) Test Light 16 CPM01 (YE/GN) For incorrectly folding RH mirror, while pressing and releasing the power folding mirror button, monitor: RH Exterior Mirror RH Exterior Mirror C601 C601 Pin Circuit Measurement / Action Pin Circuit 14 CPM02 (BU) Test Light 16 CPM01 (YE/GN) Did the test light illuminate when the button is pressed? Yes: CHECK the exterior mirror jumper harness between the vehicle harness and the exterior mirror glass for open circuits and damaged or pushed-out pins. If the jumper harness is not OK, REPAIR the jumper harness. If the jumper harness cannot be repaired, INSTALL a new exterior mirror. REFER to «Exterior Mirror»(ref-517613-S13969929342012121200000) . SYNCHRONIZE the power folding mirrors. REFER to «Mirror Synchronization - Exterior, Power Folding»(ref-517613-S09176829362012121200000) . No: GO to 11 .
- CHECK THE POWER FOLD EXTERIOR MIRROR CIRCUITS FOR AN OPEN Ignition OFF. Disconnect: DSM C341C. For incorrectly folding LH mirror, measure: DSM LH Exterior Mirror C341C C516 Pin Circuit Measurement / Action Pin Circuit 1 CPM39 (GN/VT) 16 CPM01 (YE/GN) 2 CPM04 (VT/BN) 14 CPM02 (BU) For incorrectly folding RH mirror, measure: DSM RH Exterior Mirror C341C C601 Pin Circuit Measurement / Action Pin Circuit 1 CPM39 (GN/VT) 16 CPM01 (YE/GN) 2 CPM04 (VT/BN) 14 CPM02 (BU) Are the resistances less than 3 ohms? Yes: GO to 13 . No: REPAIR the affected circuit(s). SYNCHRONIZE the power folding mirrors. REFER to «Mirror Synchronization - Exterior, Power Folding»(ref-517613-S09176829362012121200000) .
- CHECK THE EXTERIOR MIRROR CONTROL SWITCH Ignition OFF. Disconnect: Master Window Control Switch. Ignition ON. Measure: DSM Ground C341C Ground Pin Circuit Measurement / Action Pin Circuit 21 CPP09 (VT/OG) - Ground Is any voltage present? Yes: REPAIR the circuit. SYNCHRONIZE the power folding mirrors. REFER to «Mirror Synchronization - Exterior, Power Folding»(ref-517613-S09176829362012121200000) . No: INSTALL a new exterior mirror control switch (integral to the master window control switch). REFER to «WINDOW CONTROL SWITCH»(ref-517617-S36404010492012121200000) . SYNCHRONIZE the power folding mirrors. REFER to «Mirror Synchronization - Exterior, Power Folding»(ref-517613-S09176829362012121200000) .
- CHECK THE DSM FOR CORRECT OPERATION Ignition OFF. Disconnect and inspect all DSM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the DSM connectors and all previously disconnected exterior system connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable TSBs . If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no TSBs address this concern, INSTALL a new DSM. REFER to «DRIVER SEAT MODULE (DSM)»(ref-517614-S41646412882012121200000) . No: The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.
- Inspect BCM fuse 38 (10A).
- Inspect for obstructed forward or rearward sensors.
- Inspect the interior mirror.
Scheme 60
Scheme 61
Scheme 62
Scheme 63
- CHECK THE OPERATION OF THE REVERSING LAMPS Ignition ON. Move the selector lever through the entire range. Do the reversing lamps illuminate only in REVERSE? Yes: GO to 2 . No: REFER to «SYMPTOM CHART: REVERSING LAMPS»(ref-517594-S00446900912012121200000) .
- VERIFY THE FORWARD AND REARWARD FACING SENSORS ARE NOT BLOCKED Verify the forward and rearward facing sensors are not blocked. Sources of blockage can include: stickers, window decals or tags. fold-down screens for TVs or DVD players. non- OEM window tinting. Were either of the sensors blocked? Yes: If possible, REMOVE the blockage. If the blockage cannot be removed, ADVISE the customer that the blockage will effect the correct operation of the interior auto-dimming mirror. No: GO to 3 .
- CHECK OPERATION OF THE INTERIOR AUTO-DIMMING MIRROR - DAYLIGHT CONDITIONS Ignition ON. Use a bright lamp to illuminate the forward facing sensor. The mirror should adjust to a high reflectance mode (mirror will be clear). Does the mirror adjust to the high reflectance (clear) mode? Yes: GO to 4 . No: INSTALL a new interior auto-dimming mirror. REFER to «Interior Rear View Mirror - Auto-Dimming»(ref-517613-S31995946772012121200000) .
- CHECK OPERATION OF THE INTERIOR AUTO-DIMMING MIRROR - NIGHTTIME CONDITIONS WITH GLARE Ignition ON. NOTE: Covering the sensor with a finger or hand is not adequate. Simulate nighttime conditions with glare: Cover the forward sensor with black electrical tape or other dark material. Illuminate the rearward facing sensor. The mirror should darken to a lower reflectance mode. Did the mirror darken to a lower reflectance (darker) mode? Yes: GO to 5 . No: GO to 7 .
- CHECK OPERATION OF THE INTERIOR AUTO-DIMMING MIRROR - NIGHTTIME CONDITIONS WITHOUT GLARE Ignition ON. NOTE: Covering the sensor with a finger or hand is not adequate. Simulate nighttime conditions without glare by covering the rearward facing sensor. The mirror should adjust to the high reflectance mode. Did the mirror adjust to the high reflectance (clear) mode? Yes: GO to 6 . No: GO to 7 .
- CHECK OPERATION OF THE INTERIOR AUTO-DIMMING MIRROR - NIGHTTIME CONDITIONS WITH THE VEHICLE IN REVERSE Ignition ON. NOTE: Covering the sensor with a finger or hand is not adequate. Simulate nighttime conditions with glare: Cover the forward sensor with black electrical tape or other dark material. Illuminate the rearward facing sensor (mirror should darken at this time). Select REVERSE. Did the mirror adjust to a high reflectance (clear) mode? Yes: The system is operating normally at this time. ADVISE the customer of the correct operation of the interior auto-dimming mirror. No: GO to 7 .
- CHECK FOR VOLTAGE TO THE INTERIOR AUTO-DIMMING MIRROR Ignition OFF. Disconnect: Interior Auto-Dimming Mirror. Ignition ON. Measure: Interior Auto-Dimming Mirror Ground C911 Ground Pin Circuit Measurement / Action Pin Circuit 1 CBP38 (GY/BU) - Ground Is the voltage greater than 11 volts? Yes: GO to 8 . No: VERIFY that BCM fuse 38 (10A) is OK. If OK, REPAIR the circuit for an open. If not OK, REFER to «OEM FUSE AND RELAY INFORMATION»(ref-485835) and «OEM WIRING DIAGRAMS»(ref-514995) .
- CHECK FOR GROUND TO THE INTERIOR AUTO-DIMMING MIRROR Ignition OFF. Measure: Interior Auto-Dimming Mirror Ground C911 Ground Pin Circuit Measurement / Action Pin Circuit 4 GD233 (BK) - Ground Is the resistance less than 3 ohms? Yes: GO to 9 . No: REPAIR the circuit.
- CHECK FOR VOLTAGE TO THE INTERIOR AUTO-DIMMING MIRROR REVERSE CIRCUIT Ignition ON. Select REVERSE. Measure: Interior Auto-Dimming Mirror Ground C911 Ground Pin Circuit Measurement / Action Pin Circuit 9 CLS28 (BU/WH) - Ground Is the voltage greater than 11 volts? Yes: INSTALL a new interior auto-dimming mirror. REFER to «Interior Rear View Mirror - Auto-Dimming»(ref-517613-S31995946772012121200000) . No: REPAIR the circuit.
Pinpoint Test
- REVIEW THE DTCs Review the DTCs from the DSM self-test. Are DTCs B106F and B1342 present? Yes: CORRECT the cause of any other DTCs present first. When other DTCs are corrected, INSTALL a new DSM. REFER to «DRIVER SEAT MODULE (DSM)»(ref-517614-S41646412882012121200000) . No: GO to 2 .
- REPAIR OTHER DTCs Repair the cause of any DTCs present, other than DTC B106E. REFER to «DTC CHART: DRIVER SEAT MODULE (DSM)»(ref-517614-S22354534442012121200000) . Clear the DTCs . Using a scan tool, perform the DSM self-test. Is DTC B106E still present? Yes: The fault causing the output state to be disabled is still present. REPAIR the cause of the concern. No: The system is operating correctly at this time. The concern was caused by a fault in one of the output circuits.
