Torque Specifications
| Description | Part Number | Torque |
|---|---|---|
| A/C compressor bolts | W714077 | 25 Nm (18 lb-ft) |
| A/C compressor fitting nuts (suction and discharge) | W520413 | 15 Nm (133 lb-in) |
| A/C compressor nut | W520413 | 25 Nm (18 lb-ft) |
| A/C stud | W712610 | 9 Nm (80 lb-in) |
| A/C condenser bolts | W707393 | 6 Nm (53 lb-in) |
| A/C condenser fitting nuts (inlet and outlet) | W520413 | 15 Nm (133 lb-in) |
| Auxiliary evaporator outlet and inlet line fitting nuts | W520413 | 15 Nm (133 lb-in) |
| Condenser-to-evaporator line bracket bolt | W705139 | 8 Nm (71 lb-in) |
| Evaporator-to-compressor suction line fitting nut | W520413 | 15 Nm (133 lb-in) |
| Evaporator outlet line bracket bolt | W708877 | 15 Nm (133 lb-in) |
| Heater core and evaporator core housing bolts | N807316 | 7 Nm (62 lb-in) |
| Receiver/drier plug | 22 Nm (16 lb-ft) | |
| TXV bolts | 8 Nm (71 lb-in) | |
| TXV fitting nut | W520413 | 18 Nm (159 lb-in) |
| TXV manifold and tube assembly clamp bracket bolt | W705622 | 8 Nm (71 lb-in) |
TORQUE SPECIFICATIONS
General Specifications
| Item | Specification |
|---|---|
| A/C clutch air gap | 0.35 mm (0.0138 in) to 0.6 mm (0.0236 in) |
| A/C pressure relief valve OPEN pressure | 3, 430 kPa (497.46 psi) to 4, 137 kPa (600 psi) |
| A/C pressure relief valve CLOSE pressure | 2, 756 kPa (399.71 psi) |
| Evaporator discharge air temperature sensor OFF temperature | 0 C (32 F) |
| Evaporator discharge air temperature sensor ON temperature | 2 C (35.6 F) |
GENERAL SPECIFICATIONS
Scheme 129
| Item | Description |
|---|---|
| 1 | Defrost/panel/floor mode door actuator |
| 2 | Air inlet mode door actuator |
| 3 | Blower motor |
| 4 | Blower motor speed control |
| 5 | A/C evaporator discharge air temperature sensor |
| 6 | LH temperature blend door actuator |
Scheme 130
| Item | Description |
|---|---|
| 1 | A/C compressor |
| 2 | Compressor-to-condenser discharge line |
| 3 | Condenser core |
| 4 | Integrated receiver/drier |
| 5 | TXV manifold and tube assembly |
| 6 | TXV |
| 7 | Evaporator-to-compressor suction line |
| 8 | A/C pressure transducer |
| 9 | High-pressure service gauge port valve |
| 10 | Low-pressure service gauge port valve |
