Climate Control - Datc: Specifications Ford Explorer V

Manual HVAC System 3 illustrations

Torque Specifications

DescriptionPart NumberTorque
A/C combo-cooler block studW7018908 Nm (71 lb-in)
A/C compressor boltsW71407725 Nm (18 lb-ft)
A/C compressor fitting nuts (suction and discharge)W52041315 Nm (133 lb-in)
A/C compressor nutW52041325 Nm (18 lb-ft)
A/C studW7126109 Nm (80 lb-in)
A/C condenser boltW7073936 Nm (53 lb-in)
A/C condenser boltW5039246 Nm (53 lb-in)
A/C condenser fitting nuts (inlet and outlet)W52041315 Nm (133 lb-in)
Auxiliary evaporator outlet and inlet line fitting nutsW52041315 Nm (133 lb-in)
Condenser-to-evaporator line bracket boltW7051398 Nm (71 lb-in)
Condenser-to-evaporator line bracket studW7153908 Nm (71 lb-in)
Evaporator-to-compressor suction line fitting nutW52041315 Nm (133 lb-in)
Evaporator outlet line bracket boltW70887715 Nm (133 lb-in)
Heater core and evaporator core housing boltsN8073167 Nm (62 lb-in)
Receiver/drier plug22 Nm (16 lb-ft)
TXV bolts8 Nm (71 lb-in)
TXV fitting nutW52041318 Nm (159 lb-in)
TXV manifold and tube assembly clamp bracket boltW7056228 Nm (71 lb-in)

TORQUE SPECIFICATIONS

General Specifications

ItemSpecification
A/C clutch air gap0.35 mm (0.0138 in) to 0.6 mm (0.0236 in)
A/C pressure relief valve OPEN pressure3, 430 kPa (497.46 psi) to 4, 137 kPa (600 psi)
A/C pressure relief valve CLOSE pressure2, 756 kPa (399.71 psi)
Evaporator discharge air temperature sensor OFF temperature0 C (32 F)
Evaporator discharge air temperature sensor ON temperature2 C (35.6 F)

GENERAL SPECIFICATIONS

Scheme 1

Scheme 1: Component Location
ItemDescription
1Defrost/panel/floor mode door actuator
2RH temperature blend door actuator
3Air inlet mode door actuator
4Blower motor
5Blower motor speed control
6A/C evaporator discharge air temperature sensor
7LH temperature blend door actuator

Scheme 2

Scheme 2
ItemDescription
1AAT sensor
2HVAC module
3In-vehicle temperature sensor and hose assembly
4A/C evaporator discharge air temperature sensor

Scheme 3

Scheme 3
ItemDescription
1A/C compressor
2Compressor-to-condenser discharge line
3Condenser core
4Integrated receiver/drier
5TXV manifold and tube assembly
6TXV
7Evaporator-to-compressor suction line
8A/C pressure transducer
9High-pressure service gauge port valve
10Low-pressure service gauge port valve
